Connecting-up
X420 - Pulse encoder
simulation
4-4
At connection X420 you can pick up the signals of the pulse encoder
simulation generated on the optional board.
A zero pulse which does not exist (if a multiturn encoder is connected) is
simulated by the board.
The simulation signals are available as differential signals according to
standard RS 422.
Terminal Designation
80 A+
81 A-
82 B+
83 B-
84 N+
85 N-
Connectable cross-section: 0.5 mm² (AWG 20)
Terminal 80 is at the top when installed.
Table 4-3 Terminal assignment at connection X420
SBM - Sensor Board Encoder / Multiturn
Significance
Pulse encoder simulation track A+
Pulse encoder simulation track A-
Pulse encoder simulation track B+
Pulse encoder simulation track B-
Pulse encoder simulation track zero+
Pulse encoder simulation track zero-
477 754 4070 76 J AB-74
Operating Instructions SIMOVERT MASTERDRIVES
Range
RS 422
standard
RS 422
standard
RS 422
standard
