02.99
PNU OP1 parameter name
*
: Ack.
Description
par.
Binary inputs (F60 to F130)
Binary input terminal 77
Function: Depending on the state of terminal 77, either the signal determined by H170 or the value from H171 is applied to connector
K010.
H170 BE77=1 C_SetVal.
*
Selection of signal to be applied to connector when terminal state = 1
0 = Fixed value 0
1 = Fixed value 100 %
2 = Fixed value 0
3 = Connector K003
4 = Connector K004
etc.
PNU=492 Hex; Type=O2; Normalization: 1==1; Block diag.: [5.5]
H171 BE77=0 SetVal
*
Value which is applied to connector when terminal state = 0
PNU=493 Hex; Type=I2; Normalization: 1==0.01%; Block diag.: [5.6]
Binary input terminal 78
Function: Depending on the state of terminal 78, either the signal determined by H172 or the value from H173 is applied to connector
K011.
H172 BE78=1 C_SetVal.
*
PNU=494 Hex; Type=O2; Normalization: 1==1; Block diag.: [5.5]
H173 BE78=0 SetVal
*
PNU=495 Hex; Type=I2; Normalization: 1==0.01%; Block diag.: [5.6]
Binary input terminal 79
Function: Depending on the state of terminal 79, either the signal determined by H174 or the value from H175 is applied to connector
K012.
H174 BE79=1 C_SetVal.
*
PNU=496 Hex; Type=O2; Normalization: 1==1; Block diag.: [5.5]
H175 BE79=0 SetVal.
*
PNU=497 Hex; Type=I2; Normalization: 1==0.01%; Block diag.: [5.6]
Binary input terminal 80
Function: Depending on the state of terminal 80, either the signal determined by H176 or the value from H177 is applied to connector
K013.
H176 BE80=1 C_SetVal.
*
PNU=498 Hex; Type=O2; Normalization: 1==1; Block diag.: [5.5]
H177 BE80=0 SetVal.
*
PNU=499 Hex; Type=I2; Normalization: 1==0.01%; Block diag.: [5.6]
Binary input terminal 81
Function: Depending on the state of terminal 81, either the signal determined by H178 or the value from H179 is applied to connector
K014.
H178 BE81=1 C_SetVal.
*
PNU=49A Hex; Type=O2; Normalization: 1==1; Block diag.: [6.5]
H179 BE81=0 SetVal.
*
PNU=49B Hex; Type=I2; Normalization: 1==0.01%; Block diag.: [6.6]
Binary input terminal 82
Function: Depending on the state of terminal 82, either the signal determined by H180 or the value from H181 is applied to connector
K015.
H180 BE82=1 C_SetVal.
*
PNU=49C Hex; Type=O2; Normalization: 1==1; Block diag.: [6.5]
Siemens AG 6SE7087-6CX84-0BB1
T100 Technology Board Manual for Software Module MS100 "Multi-Purpose Drive"
as for H170
as for H171
as for H170
as for H171
as for H170
as for H171
as for H170
as for H171
as for H170
Value range No. of
[unit] indices
Selection text Factory
setting
0 to 180 Ind: None
FS=0
-200.00 to 199.99 Ind: None
[%] FS=0.00
0 to 180 Ind: None
FS=0
-200.00 to 199.99 Ind: None
[%] FS=0.00
0 to 180 Ind: None
FS=0
-200.00 to 199.99 Ind: None
[%] FS=0.00
0 to 180 Ind: None
FS=0
-200.00 to 199.99 Ind: None
[%] FS=0.00
0 to 180 Ind: None
FS=0
-200.00 to 199.99 Ind: None
[%] FS=0.00
0 to 180 Ind: None
FS=0
Parameter List
Read
Write
(Access /
State)
F60
1/UHABR
1/UHAB
1/UHABR
1/UHAB
F70
1/UHABR
1/UHAB
1/UHABR
1/UHAB
F80
1/UHABR
1/UHAB
1/UHABR
1/UHAB
F90
1/UHABR
1/UHAB
1/UHABR
1/UHAB
F100
1/UHABR
1/UHAB
1/UHABR
1/UHAB
F110
1/UHABR
1/UHAB
4-17
