6.2.2.1 6.2.2.1 DeviceNet Status - parameter r731.02
"CB/TB diagnostics" index 02 (DeviceNet™ Status):
"CB/TB
diagnostics"
Each hexadecimal digit contains a different status indicator.
Thousand's Digit
IDLE Indicator
LED Coding for Network Status LED: (One's Digit)
Value LED State
0 Off
1 Flashing Green
2 Solid Green
3 Flashing Red
4 Solid Red
Bit Coding for Channel Allocation: (Hundred's Digit)
Bit in Digit (Bit in full word)
0 (8)
1 (9)
2 (10)
3 (11)
Digit Coding for IDLE Indicator: (Thousand's Digit)
Value Indication
0 Device is not in IDLE condition.
n
A non-zero length POLL or BIT STROBE command was the latest data received.
1 Device is in IDLE condition. Also refer to alarm A081 in section 6.1.1
n
A zero length POLL or BIT STROBE command was the latest data received.
"CB/TB diagnostics" index 03 (counter, all telegrams received):
"CB/TB
diagnostics"
Counter for DeviceNet™ telegrams which were received error-free since power-on. This counter includes all Group 2
DeviceNet™ messages, including those not directed to this CBD.
"CB/TB diagnostics" index 08 (counter, PZD receive telegrams):
"CB/TB
diagnostics"
Siemens AG 477 759 4070 76 J AA-74
SIMOVERT MASTER DRIVES
6 Troubleshooting
6.2 Diagnostics
6.2.2 CBD diagnostic parameters
CUVC & CUMC DC-Master
r732.2 n732.2
Hundred's Digit
Channel Allocation
Indication
Device is not on-line.
n
The device has not completed the Dup_MAC_ID test yet.
Device is on-line but has no connection in the established state.
n
This device is not allocated to a master.
Device is on-line and has connections in the established state.
n
This device is allocated to a master.
Not presently used.
Failed communication device.
n
This device has detected an error that has rendered it incapable of
communicating on the network (Duplicate MAC ID or Bus-off). This
condition can be reset only by cycling the power on the drive.
Indication
1 = Explicit Channel allocated
1 = I/O Poll Channel allocated
1 = I/O Bit Strobe Channel allocated
Future Use
CUVC & CUMC DC-Master
r732.3 n732.3
CUVC & CUMC DC-Master
r732.8 n732.8
Betriebsanleitung / Operating Instructions
CU2
r731.2
Ten's Digit
Reserved
CU2
r731.3
CU2
r731.8
One's Digit
Network Status LED
