5.2.1 Memory
AIM24000 parameter configurations are automatically recorded in both the Random
Access Memory (RAM) of the AIM24000 and the Non-Volatile Random Access Memory
(NVRAM) of the IP DSLAM's management module.
5.2.1.1 RAM
Statistical data stored only in AIM24000 RAM, such as traffic statistics and link
up/down time, will be erased if the module is removed from the IP DSLAM or the
IP DSLAM loses power.
5.2.1.2 NVRAM
AIM24000 data stored in the IP DSLAM's management module NVRAM, such as
port parameter configurations, will remain intact (even if the IP DSLAM loses
power) unless deliberately cleared or reconfigured.
5.2.2 Local Files
5.2.2.1 Uploading a Port Template
AIM24000 port configurations can be flash uploaded from your IP DSLAM
management module TO a file on your PC or local network via a Trivial File
Transfer Protocol (TFTP) tool and a get command. A port template file contains
all of a selected port's configurations EXCEPT Circuit ID.
ITEM
Host Name
Remote Filename Nvr_PortCfg.Bin."Superuser password".[slot][port] nvr_portcfg.bin.Password.[2][10]
Local Filename
5.2.2.2 Downloading a Port Template
AIM24000 configuration files can also be flash downloaded FROM a local file TO
your IP DSLAM's management module via a TFTP tool, simply replace the get
command with a put command. A previously saved port configuration file can be
applied to multiple ports on your AIM24000 simultaneously, via your IP DSLAM
management module, by entering the port value [ports] as follows:
METHOD OF ENTRY
comma-separated list nvr_portcfg.bin.Password.[2][10,12,20,45,]
dash-indicated range nvr_portcfg.bin.Password.[2][10-45]
keyword "all"
N OTE Refer to your TFTP user manual for further instruction.
5.3 Firmware Upgrades
N OTE Net to Net strongly recommends creating an IP DSLAM back-up file prior to downloading any new firmware revisions.
Refer to Net to Net's Firmware Upgrade Procedure at
instructions.
All customers registered with Net to Net's website (http://www.nettonet.com/register) will
automatically receive notification of new firmware versions and accompanying
documentation. New firmware versions can be downloaded from
AIM24000 Installation 210-0000056 rev 01
DATA NEEDED FOR BACKUP
DSLAM IP Address (xxx.xxx.xxx.xxx)
User Preference
EXAMPLE: nvr_portcfg.bin.Password.[slot][ports]
nvr_portcfg.bin.Password.[2][all]
http://www.nettonet.com/support/docs/230-0000032
EXAMPLE
193.166.254.98
Adsl_ServiceLevel_4_template.bin
