Net to Net Technologies AIM24000 User Manual page 41

PARAMETER
END IP RANGE 1
ifCfgPortFltrIP1End
START IP RANGE 2
ifCfgPortFltrIP2Start
END IP RANGE 2
ifCfgPortFltrIP2End
BACKBONE-VLAN
ifCfgPortBackboneVlan
VLAN PRIORITY
ifCfgPortVlanPriority
FLOOD
ifCfgPortFloodMde
PROTOCOL
ifCfgPortIpFltProtocol
VLAN SLOT INDEX
ifCfgIfSlotIndex
VLAN PORT INDEX
ifCfgIfPortIndex
VLAN RANGE INDEX
ifCfgVlanIndex
VLAN START TAG
ifCfgVlanIdStart
VLAN END TAG
ifCfgVlanIdEnd
ADSL SLOT INDEX
ifCfgAdslSlotIndex
ADSL PORT INDEX
ifCfgAdslPortIndex
PORT MODE
ifCfgAdslPortMode
VPI/VCI DETECT
ifCfgAdslVpiVciDetect
RX RATE
ifCfgAdslRxRate
AIM24000 Installation 210-0000056 rev 01
OID (1.3.6.1.4.1.8059. INPUT/RETURN
+) VALUES
1.2.1.1.1.2.1.1.5.x.y User Defined
1.2.1.1.1.2.1.1.6.x.y User Defined
1.2.1.1.1.2.1.1.7.x.y User Defined
1.2.1.1.1.2.1.1.8.x.y 0-4085
1.2.1.1.1.2.1.1.9.x.y 0-7
1.2.1.1.1.2.1.1.10.x.y 1, 2
1.2.1.1.1.2.1.1.11.x.y 1, 2
x=1-12 (Slot)
1.2.1.1.1.2.2.1.1.x.y.z y=1-48 (Port)
z=1-10 (VLAN)
x=1-12 (Slot)
1.2.1.1.1.2.2.1.2.x.y.z y=1-48 (Port)
z=1-10 (VLAN)
x=1-12 (Slot)
1.2.1.1.1.2.2.1.3.x.y.z y=1-48 (Port)
z=1-10 (VLAN)
1.2.1.1.1.2.2.1.4.x.y.z 0-4085
1.2.1.1.1.2.2.1.5.x.y.z 0-4085
x=1-12 (Slot)
1.2.1.1.1.2.3.1.1.x.y
y=1-48 (Port)
x=1-12 (Slot)
1.2.1.1.1.2.3.1.2.x.y
y=1-48 (Port)
1.2.1.1.1.2.3.1.3.x.y 1-3
1.2.1.1.1.2.3.1.4.x.y 1, 2
1.2.1.1.1.2.3.1.5.x.y 1-32
SYNTAX ADDITIONAL INFORMATION
Default: 255.255.255.255
IP Address:
Value range for each triple-digit
___.___.___.___
quadrant: 0-255
Default: 0.0.0.0
IP Address:
Value range for each triple-digit
___.___.___.___
quadrant: 0-255
Default: 0.0.0.0
IP Address:
Value range for each triple-digit
___.___.___.___
quadrant: 0-255
0=OFF (Default)
32-bit Integer Refer to Section 4.2.2.7 for
configuration application details.
0=No Priority (Default)
1=Lowest Priority
32-bit Integer 7=Highest Priority
Refer to Section 4.2.2.8 for
configuration application details.
1=Uplink (Default)
32-bit Integer
2=VLAN
1=ALL Traffic (Default)
32-bit Integer
2=TCP/IP/ARP traffic only
32-bit Integer Input x,y and z; returns x
32-bit Integer Input x,y and z; returns y
Input x,y and z; returns z
32-bit Integer Up to 10 VLAN Ranges may be
specified per port.
Default=0
32-bit Integer Refer to Section 4.2.2.6 for
configuration application details.
Default=0
32-bit Integer Refer to Section 4.2.2.6 for
configuration application details.
32-bit Integer Input x and y; returns x
32-bit Integer Input x and y; returns y
1=Fixed
2=OFF
3=Adaptive (Default)
An AIM24000 Port configured with
32-bit Integer
Port Mode Fixed requires the
additional configuration of upstream
(ifCfgAdslTxRate) and downstream
(ifCfgAdslRxRate) speeds.
1=ON (Default)
2=OFF
An AIM24000 port configured with
32-bit Integer
VPI/VCI Detect OFF requires the
configuration of VPI (ifCfgAdslVpi)
and VCI (ifCfgAdslVci) values.
Upstream Speed = [1-32] x 32kbps
= 32kbps - 1024kbps
NOTE: A zero [0] returned via a GET
32-bit Integer
command indicates that the port is in
Adaptive Mode and is experiencing
link-down.
Page 41 of 44
