1.0 SDSL ACCESS MODULE MODELS
SDSL access multiplexers are intended for use in Net to Net Technologies' IPD12000 and IPD4000
DSLAMs. Model types vary by the SDSL line code utilized.
1.1 SAM2000G-12
The SAM2000G-12 operates with Transmission Convergence/Pulse Amplitude Modulation (TC/PAM)
line code: a sixteen-level PAM technique which incorporates advanced Trellis code, precoding,
spectral shaping, equalization circuits and forward error correction. Otherwise known as G.SHDSL or
SHDSL.
1.2 SAM2000Q-12
The SAM2000Q-12 operates with Two Binary, One Quaternary (2B1Q) line code: a four-level PAM
technique which reduces the signaling rate to half of the bit rate.
1.3 SAM2000-12
The SAM2000G-12 operates with Carrierless Amplitude and Phase (CAP) modulation line code:
transmit and receive signals are modulated into two wide-frequency bands that can pass through a
filter without being attenuated.
N
Throughout this document, "SAM2000G" is utilized to indicate all three SDSL access multiplexer models; information
OTE
given applies to all three models except as individually stated or otherwise noted.
210-0000026 rev07
SAM2000G-12
12-Port SHDSL Access Multiplexer
Interface Module User Guide
Advertisement
Table of Contents
Related Manuals for Net to Net Technologies 12-Port SHDSL Access Multiplexer SAM2000G-12
Summary of Contents for Net to Net Technologies 12-Port SHDSL Access Multiplexer SAM2000G-12
- Page 1 12-Port SHDSL Access Multiplexer Also: SAM2000Q-12 (2B1Q) and SAM2000-12 (CAP) 1.0 SDSL ACCESS MODULE MODELS SDSL access multiplexers are intended for use in Net to Net Technologies' IPD12000 and IPD4000 DSLAMs. Model types vary by the SDSL line code utilized. 1.1 SAM2000G-12 The SAM2000G-12 operates with Transmission Convergence/Pulse Amplitude Modulation (TC/PAM) line code: a sixteen-level PAM technique which incorporates advanced Trellis code, precoding,...
-
Page 2: Installation
2.0 INSTALLATION Net to Net Technologies strongly recommends the use of proper electrostatic discharge (ESD) precautions when AUTION handling this equipment. 2.1 Unpack and Inspect the SAM2000G If there is visible damage, do not attempt to connect the device; contact Customer Support at 1-877- 638-2638 (1-603-427-0600 for international customers) or support@nettonet.com. - Page 3 SHDSL RJ21 PORT PINOUT PORT Ring SHDSL (pins 13-25 and 38-50 are not used) 3.0 SAM2000G DEFAULT CONFIGURATIONS No configuration is necessary for the SAM2000G to operate at default settings. 3.1 IP DSLAM Management 3.1.1 User Access All usernames and passwords are case sensitive. 3.1.1.1 Network Management System (NMS) and Command Line Interface (CLI) ACCESS read/write...
- Page 4 PARAMETER Gateway Inband Management Inband Management VLAN ID IP Address: IPD12000 Slot 13 IP Address: IPD12000 Slot 14 IP Address: IPD4000 Slot 5 Management IP Address Filter Range Subnet Mask 3.2 SAM2000G Port Parameters PARAMETER Circuit Identification Back-bone VLAN Flood IP Range 1 IP Range 2 Priority (VLAN)
- Page 5 If you have an IPD12000 with two MUMs, configuration alterations can be made to a SAM2000G through either MUM; most configuration(s) will be saved to the NVRAM of both. Refer to your MUM Installation Instructions for specifics. 4.1 Via Command Line Interface (CLI) 4.1.1 Establish a Connection With Your IP DSLAM Establish a connection between your IP DSLAM and your PC, either directly (through the COM port on the MUM faceplate) or, if your DSLAM has been configured to allow inband...
-
Page 6: Bandwidth And Distance
4.2.4 Log In Log in with your assigned username and password. For SAM2000G configuration, you must log in as a superuser (general users have read only access). If your username and/or password are unknown, contact your System Administrator or Information Technology Manager for assistance. -
Page 7: Additional Information
The SAM2000G-12, SAM2000Q-12 and SAM2000-12 each have nine SHDSL bandwidth options; default is 272 kbps. Distance capabilities at each bandwidth vary, dependent upon the type of line code being utilized. Distances listed below assume the use of 26 American Wire Gauge (AWG) cable; connections made with cable of a greater gauge will link up at greater distances. -
Page 8: Led Indications
concurrently; SAM2000G configurations cannot be saved independently. Once your IP DSLAM has been configured as desired (including the SAM2000G), settings can be flash uploaded (to a local file) through a Trivial File Transfer Protocol (TFTP) tool with a GET command and the following information: 6.1.2.1 Backup An IP DSLAM backup file records ALL management and port configurations. -
Page 9: Regulatory Compliance For Class A Equipment
SHDSL Data flashing Reception (Rx) amber solid amber illumination SHDSL Data flashing Transmission amber (Tx) solid amber illumination (A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.) 6.3 Regulatory Compliance for Class A Equipment The following regulatory compliance information applies to the SAM2000G-12, SAM2000Q-12 and/or SAM2000-12 as installed in Net to Net Technologies' IP DSLAMs. - Page 10 210-0000026 rev07 © Copyright 2003 Net to Net Technologies, Inc. ™ The Net to Net Logo is a trademark of Net to Net Technologies, Inc. Worldwide Headquarters Net to Net Technologies 112 Corporate Drive Portsmouth, NH 03801 +1 877-638-2638 210-0000026 rev07 http://www.NetToNet.com/ Contact@NetToNet.com EMEA Headquarters...
