15 characters, it will automatically truncate to 15. Typically, service providers use a
corresponding Customer # or Circuit ID # from their Operations Support System (OSS)
in order to facilitate troubleshooting.
N OTE Net to Net's Circuit ID field is not yet integrated with any OSS system and is currently for reference only.
3.2.2 Standard Mode
Default: Multimode
3.2.2.1 Multimode
An AIM24000 port set to multimode detects and matches the standard mode of
the remote ADSL modem to which it's connected.

3.2.2.2 Full Rate ADSL2

An AIM24000 port that is operating in full rate ADSL2 mode and utilizing a
single line for both phone and data, requires an in-line splitter at both ends of
the ADSL2 connection.
N OTE The Full Rate ADSL2 options (G.DMT.BIS, G.DMT.BISplus and READSL2) are not yet available for
3.2.2.3 Full Rate ADSL
An AIM24000 port that is operating in full rate ADSL mode and utilizing a single
line for both phone and data, requires an in-line splitter at both ends of the
ADSL connection.
AIM24000 Installation 210-0000056 rev 01
configuration via CLI or SNMP; these standard modes are currently configurable via NMS only.
3.2.2.2.1 G.DMT.BIS
G.DMT.BIS is ADSL2 technology in compliance with the standards of the
International Telecommunications Union Telecommunication
Standardization Sector (ITU-T) Recommendation G.992.3 which specifies a
downstream frequency range of 1100 kHz.
3.2.2.2.2 G.DMT.BISplus
G.DMT.BISplus is ADSL2+ technology in compliance with the standards of
ITU-T Recommendation G.992.5 which specifies a downstream frequency
range of 2200 kHz.
3.2.2.2.3 READSL2
Reach Expanded ADSL2 is ADSL2 technology in compliance with the
standards of ITU-T Recommendation G.992.3 in Annex L format.
3.2.2.3.1 G.DMT
G.DMT is ADSL technology in compliance with the standards of ITU-T
Recommendation G.992.1. The AIM24000 exceeds the ITU-T G.992.1
minimum requirements of 640 kbps upstream and 6,000 kbps downstream
speeds in G.DMT mode.
3.2.2.3.2 T1.413
T1.413 is ADSL technology in compliance with the standards of the
American National Standards Institute (ANSI) Standard T1.413.
3.2.2.3.3 Alcatel
Alcatel is ADSL technology and Alcatel ADSL modem compatible.
Page 15 of 44
