Net to Net Technologies AIM24000 User Manual page 17

AIM24000 Installation 210-0000056 rev 01
DISTANCE
feet meters
8,000 2,438
9,000 2,743
10,000 3,048
11,000 3,353
12,000 3,658
13,000 3,962
14,000 4,267
15,000 4,572
16,000 4,877
17,000 5,182
18,000 5,486
19,000 5,791
3.2.4.1.2 G.DMT.BISplus (ADSL2+)
An AIM24000 port in ADSL2+ mode is capable of reaching downstream
speeds of up to 21,790 kbps under optimal circumstances.
DISTANCE
feet meters
8,000 2,438
9,000 2,743
10,000 3,048
11,000 3,353
12,000 3,658
13,000 3,962
14,000 4,267
15,000 4,572
16,000 4,877
17,000 5,182
18,000 5,486
19,000 5,791
HIGH INTERLEAVE
upstream downstream
kbps kbps
1,085 10,104
1,085 9,681
1,085 8,544
1,085 7,179
1,085 5,721
992 4,381
896 3,375
795 2,535
703 1,826
611 1,349
508 847
405 468
HIGH INTERLEAVE
upstream downstream
kbps kbps
1,085 13,036
1,067 10,718
1,085 8,335
1,085 6,692
1,085 5,020
1,015 3,820
925 2,856
821 2,135
740 1,513
659 985
586 637
361 379
LOW INTERLEAVE
upstream downstream
kbps kbps
1,154 10,069
1,154 9,525
1,150 8,305
1,146 6,957
1,099 5,428
996 4,044
892 3,357
775 2,521
692 1,820
590 1,293
495 861
397 468
LOW INTERLEAVE
upstream downstream
kbps kbps
1,126 12,589
1,087 10,385
1,130 8,057
1,075 6,305
1,063 4,606
1,015 3,772
924 2,880
830 2,131
731 1,464
613 1,000
570 641
344 354
Page 17 of 44
