Net to Net Technologies AIM24000 User Manual page 4

1.0 ADSL2+ INVERSE MULTIPLEXER MODEL TYPES
1.1 AIM24000-48
The AIM24000-48 is a 48-port ADSL2+ inverse multiplexer that supports Annex A (Plain
Old Telephone Service-POTS) on lower end frequencies (up to 4 kHz).
1.2 AIM24000-48B
The AIM24000-48B is a 48-port ADSL2+ inverse multiplexer that supports Annex B
(Integrated Services Digital Network-ISDN) on lower end frequencies: up to 80 kHz over a
Two Binary, One Quaternary (2B1Q) line and up to 100 kHz over a Four Binary, Three
Ternary (4B3T) line.
2.0 INSTALLATION
C AUTION Net to Net Technologies strongly recommends the use of proper electrostatic discharge (ESD) precautions when handling this
equipment.
2.1 Unpack and Inspect the AIM24000
AIM24000 SPECIFICATIONS
12.75" High x 1.15" Wide x 16.75" Deep
(32.4cm x 2.9cm x 42.5cm)
3.6 lbs (1.6 kg)
If there is visible damage, do not attempt to connect the device. Contact Customer
Support: customers in Europe, the Middle East and Africa please call 44-0-1635-570953 or
email support-emea@nettonet.com
2638 or email support@nettonet.com. All other customers please call 1-603-427-0600 or
email support@nettonet.com.
2.2 Install the AIM24000 in an IP DSLAM
There must be a management module, complete with an uplink module, installed in your
IP DSLAM chassis in order for the AIM24000 to operate.
N OTE All of Net to Net Technologies' IP DSLAM interface modules are hot swappable; installing or removing an interface module
while the chassis is powered up does not affect the operational status of other interface modules within the chassis.
AIM24000 OPERATING REQUIREMENTS
Operating Temperature:
32°F to 122°F (0°C to 50°C) in an IPD12000E
-40°F to 149°F (-40°C to 65°C) in an IPD4000E
Non-Operating Temperature: -40°F to 158°F (-40°C to 70°C)
Humidity: 5% to 95%, non-condensing
Altitude: -200 ft to 16,500ft (-60m to 5,000m)
AIM24000 Installation 210-0000056 rev 01
; customers in the United States please call 1-877-638-
Page 4 of 44
