turning the VPI/VCI Detect function off will lock in the previously detected
settings until, or unless, the VPI and VCI values are altered manually.
3.2.12.3 Manual
If you wish to set VPI and VCI values manually, VPI/VCI Detect should be set to
off BEFORE the VPI and VCI values are entered. When manually configuring VPI
and VCI, each port on the AIM24000 must be assigned the same VPI and VCI
values as the remote ADSL modem to which that port is connected in order for
the units to communicate.
4.0 AIM24000 Management
All parameters on the AIM24000 are software selectable. Dependent upon the management
module installed in your IP DSLAM, the AIM24000 can be configured via Command Line
Interface (CLI), Simple Network Management Protocol (SNMP) and/or Net to Net Technologies'
web-based Network Management System (NMS).
4.1 Via NMS
NMS is an embedded web server that resides within the firmware of IP DSLAM management
modules. This web server maintians statistical and configurational data for the AIM24000.
N OTE If your IP DSLAM is newly installed and has not yet been initialized, you must configure the IP Address, Subnet Mask and
Gateway before you will be able to access data or complete any other configurations. Refer to Net to Net's NMS
Management User Guide at
4.1.1 Log In
Open an NMS window and log on. You must log on as a Superuser in order to
configure the AIM24000.
4.1.2 Circuit Configuration
Click on the AIM24000 port LED corresponding to the port you wish to configure, as
depicted on the DSLAM image in the NMS main window; clicking on a port LED will
open the Circuit Configuration window for that port.
AIM24000 Installation 210-0000056 rev 01
http://www.nettonet.com/support/docs/210-0000048
N OTE Net to Net's default Superuser username is "superuser" and the
default Superuser password is "Password" (both are case
sensitive).
for instructions.
