3.0 ADSL Parameters

3.1 Default Configurations

No configuration is necessary for the AIM24000 to operate at default settings.
PARAMETER
Standard Mode
Port Mode
Upstream Speed
Downstream Speed
IP Range 1
IP Range 2-4
VLAN
Backbone-VLAN
VLAN Priority
Protocol
Flood
Frame Type
VPI/VCI Detect
Virtual Path Identifier (VPI)
Virtual Channel Identifier (VCI) 35

3.2 Parameter Definitions

3.2.1 Circuit ID
Circuit Identification (ID) is a unique and searchable 15-character, alpha-numberic,
user-defined identifier used to label each port. If the Circuit ID entered is longer than
AIM24000 Installation 210-0000056 rev 01
DEFAULT

Multimode

Adaptive

n/a (Adaptive Port Mode)
n/a (Adaptive Port Mode)
0.0.0.0 - 255.255.255.255
0.0.0.0 - 0.0.0.0
0 - 0
0
0
All
Uplink
1483LLC
On
0
Page 14 of 44
