Also: SAM2000QV-12 (2B1Q) and SAM2000V-12 (CAP)
1.0 VoSDSL ACCESS MODULE MODELS
VoSDSL access multiplexers are intended for use in Net to Net Technologies' IPD12000 and IPD4000
DSLAMs. Model types vary by the SDSL line code utilized.
1.1 SAM2000GV-12
The SAM2000GV-12 operates with Transmission Convergence/Pulse Amplitude Modulation
(TC/PAM) line code: a sixteen-level PAM technique which incorporates advanced Trellis code,
precoding, spectral shaping, equalization circuits and forward error correction. Otherwise known as
G.SHDSL or SHDSL.
1.2 SAM2000QV-12
The SAM2000QV-12 operates with Two Binary, One Quaternary (2B1Q) line code: a four-level PAM
technique which reduces the signaling rate to half of the bit rate.
1.3 SAM2000V-12
The SAM2000V-12 operates with Carrierless Amplitude and Phase (CAP) modulation line code:
transmit and receive signals are modulated into two wide-frequency bands that can pass through a
filter without being attenuated.
N
Throughout this document, "SAM2000GV" is utilized to indicate all three VoSDSL access multiplexer models;
OTE
information given applies to all three models except as individually stated or otherwise noted.
210-0000045 rev04
SAM2000GV-12
12-Port VoSHDSL Access Multiplexer
Interface Module User Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Net to Net Technologies 12-Port VoSHDSL Access Multiplexer SAM2000GV-12
Summary of Contents for Net to Net Technologies 12-Port VoSHDSL Access Multiplexer SAM2000GV-12
- Page 1 12-Port VoSHDSL Access Multiplexer Also: SAM2000QV-12 (2B1Q) and SAM2000V-12 (CAP) 1.0 VoSDSL ACCESS MODULE MODELS VoSDSL access multiplexers are intended for use in Net to Net Technologies' IPD12000 and IPD4000 DSLAMs. Model types vary by the SDSL line code utilized. 1.1 SAM2000GV-12 The SAM2000GV-12 operates with Transmission Convergence/Pulse Amplitude Modulation (TC/PAM) line code: a sixteen-level PAM technique which incorporates advanced Trellis code,...
-
Page 2: Installation
2.0 INSTALLATION Net to Net Technologies strongly recommends the use of proper electrostatic discharge (ESD) precautions when AUTION handling this equipment. 2.1 Unpack and Inspect the SAM2000GV If there is visible damage, do not attempt to connect the device; contact Customer Support at 1-877- 638-2638 (1-603-427-0600 for international customers) or support@nettonet.com. - Page 3 PORT Ring SDSL Ring VOICE (pins 13 and 38 are not used) 2.3.2 Voice Connection(s) The SAM2000GV has Foreign Exchange Office (FXO) capability for connection to voice switches or Private Branch Exchanges (PBXs). Net to Net Technologies' remote VoSHDSL modems (SNE2000GV-Ss) have Foreign Exchange Station (FXS) capability for connection to an analog station (phone, fax, modem, etc.).
-
Page 4: Management Parameters
3.1.1.2 Simple Network Management Protocol (SNMP) ACCESS read/write read only 3.1.2 Management Parameters The parameter defaults listed are common to all DSLAM/MUM model types. Some models have additional configuration possibilities; refer to the User Guide and/or Installation Instructions for your particular model. PARAMETER Gateway Inband Management... - Page 5 4.0 SAM2000GV MANAGEMENT Once your SAM2000GV has been installed, bandwidth and other configurations are software selectable via your IP DSLAM's MUM. Dependent upon the MUM model installed, the SAM2000GV may be configured via Command Line Interface (CLI), Simple Network Management Protocol (SNMP) and/or Net to Net Technologies' web-based Network Management System (NMS).
- Page 6 4.2.2 Launch Your Web Browser Launch a web browser on your PC such as Microsoft Internet Explorer or Netscape Navigator. 4.2.3 Enter Your DSLAM's IP Address Enter the DSLAM's IP Address into the address field at the top of your browser window and press the Enter key.
-
Page 7: Bandwidth And Distance
5.0 BANDWIDTH AND DISTANCE Parameters common to all interface module models are defined in the CLI, NMS and SNMP Management User Guides. Bandwidth, however, is specific to the SAM2000GV-12, SAM2000QV-12 and SAM2000-12. The SAM2000GV-12, SAM2000QV-12 and SAM2000-12 each have nine SHDSL bandwidth options; default is 272 kbps. -
Page 8: Local Files
6.1.2 Local Files Management and interface module configurations can be saved on your PC, or local network, as a backup and/or for use as a template for future configurations, via the MUM in your IP DSLAM. Management configurations and all interface module port configurations are saved concurrently;... -
Page 9: Country Codes
SHDSL Data flashing Reception (Rx) amber solid amber illumination SHDSL Data flashing Transmission (Tx) amber solid amber illumination (A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.) 6.3 Country Codes All of Net to Net Technologies' voice capable products include Country Codes. - Page 10 6.4.3 Europe This Class A product complies with European Norm EN55022. Warning: In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures to correct the situation. 210-0000045 rev04 ©...
