Parts and Accessories
Accessing the Power Feed on the Roof
1. Ensure that Cybertruck is powered off (see
Off on page 73).
WARNING: Failure to ensure the vehicle is
powered off can result in serious injury. Tesla
recommends wearing appropriate personal
protective equipment to mitigate any potential
for injury.
2. Locate the strip of applique on the right side of the
roof and use a flat, non-marring tool to gently lift
under the edge and release the five clips that hold it
in place. Lift upwards to remove the applique.
3. Locate the shrink-wrapped loop of wires. This is the
power feed.
4. Remove the shrink wrap from the power feed, then
splice or solder the accessory's wire harness to it.
202
WARNING: Use extreme care when accessing
the power feed. Assume that the low voltage
components of Cybertruck, including all wires
Powering
and connectors, are always energized. Because
the 48V low voltage system operates at a
higher voltage than a typical low voltage
system, there is an increased risk of personal
injury, arcing, or component damage if the low
voltage components of Cybertruck are handled
improperly.
CAUTION: Carefully check the wiring of the
accessory and ensure that you are connecting
the positive (+) wire of the accessory to the
positive wire (red with a blue stripe) of the
power feed, and the negative (-) wire of the
accessory to ground (black with a blue stripe).
See
201. Accessories without proper power and
grounding may not function as expected, and
may be damaged as a result.
CAUTION: Ensure that the wires are properly
insulated (taped or heatshrinked) after splicing
or soldering an accessory's wiring to the power
feed.
5. Ensure your accessory or attachment is properly
secured to the vehicle.
6. Replace the roof applique by pressing it into place to
ensure that the trim clips are secured.
7. Power on the vehicle (see
on page 73) and enable power to the power feed, if
desired (see
page 204).
Accessing the Power Feed in the Powered
Frunk
To access the power feed in the powered frunk, you
must first remove the frunk lining.
1. Open the powered frunk (see
page 58).
2. Ensure that Cybertruck is powered off (see
Off on page
WARNING: Failure to ensure the vehicle is
powered off can result in serious injury. Tesla
recommends wearing appropriate personal
protective equipment to mitigate any potential
for injury.
3. Remove the frunk maintenance panel by pulling it
upwards to release the trim clips that hold it in place.
48V Power Feed Specifications on page
Starting and Powering Off
Enabling Power to the Power Feeds on
Powered Frunk on
73).
