Jacking And Lifting - Tesla CYBERTRUCK Owner's Manual

WARNING: Ensure the equipment you are using is
rated for the weight of Cybertruck, including any
cargo, installed accessories, or upgrades before
attempting to lift.
Follow the steps below to lift Cybertruck. Ensure that
any non-Tesla repair facility is aware of these
instructions, including lift points and warnings.
Using a Jack and Jack Stand
1. Ensure Cybertruck is located in a flat, stable, and
secure area with enough space surrounding the
vehicle to jack it.
2. Ensure the vehicle ride height is set to Medium and
enable Jack Mode (Controls > Service > Jack Mode
see Jack Mode on page
WARNING: You MUST enable Jack Mode,
otherwise the vehicle may try to self-level while
on the jack. Failing to engage Jack Mode may
cause serious injury or death.
3. If available, chock the wheel diagonal to the corner
you're working on (for example, if you are replacing
the rear driver's side tire, chock the front passenger's
side tire).
4. Remove the wheel cover from the wheel with the flat
tire (see Removing and Installing Wheel Covers on
page 188).
5. Use the lug nut wrench to break loose the lug nuts on
the wheel.
6. Place the jack under the vehicle's lift point (shown in
green) corresponding to the location you are working
on.
WARNING: DO NOT position the jack under the
Battery or side rails (shown in red).
Lift points:
7. Following the jack manufacturer's instructions, begin
to lift the vehicle, making sure to constantly monitor
the contact with the lift point.
Maintenance
200) to disable self-leveling.

Jacking and Lifting

8. Place the jack stand under the appropriate jack stand
location in the image corresponding to the area
you're working on. Ensure the jack stand is
appropriately oriented and does not touch any of the
red areas in the image. Adjust to meet the jack's
height. The vehicle should be able to be solely
propped up with the jack stand.
WARNING: Do not get under the vehicle when
it is propped up on the jack or jack stands.
Doing so may cause serious injury or death.
Jack stand points:
9. Slowly lower the jack following manufacturer
instructions, constantly monitoring the contact
between the vehicle and the jack stand. Then release
the jack from the vehicle's lift point and check that it
is secure.
10. To lower the vehicle off of the jack stand, use the jack
to raise the vehicle until the jack stand is no longer
supporting the vehicle, remove the jack stand, and
slowly lower the vehicle down.
11. Disengage Jack Mode by touching Controls > Service
> Jack Mode.
Using a 2-Post Lift:
1. Ensure the vehicle ride height is set to Medium and
enable Jack Mode (Controls > Service > Jack Mode
see Jack Mode on page
WARNING: You MUST enable Jack Mode,
otherwise the vehicle may try to self-level while
on the jack. Failing to engage Jack Mode may
cause serious injury or death.
2. Position the lift arm pads under the lift points at the
locations shown.
WARNING: DO NOT position the lift arm pads
under the Battery or side rails.
Lift points:
200) to disable self-leveling.
199
