Ingress Protection
Enclosure
5.9
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Figure 5.1
RUGGEDCOM RSG920P
Equipment Manual, 10/2023, C79000-G8976-1172-09
IP40 (1 mm or 0.04 in objects)
Aluminum
152.0
Overall Dimensions
Technical Specifications
5.9 Dimension Drawings
165.6
154.0
33
