Device Management

This section describes how to connect to and manage the device.
3.1

Connecting to the Device

The following describes the various methods for accessing the RUGGEDCOM
RSG920P console and Web interfaces on the device. For more detailed instructions,
refer to the "RUGGEDCOM ROS Configuration Manual" for the RUGGEDCOM
RSG920P.
RS-232 Console Port
Connect a workstation directly to either the RJ45 or USB Type-B console port to
access the boot-time control and RUGGEDCOM RSG920P interfaces. Both console
ports provide access to RUGGEDCOM RSG920P's console and Web interfaces.
Console ports are intended to be used only as a temporary connection during initial
configuration or troubleshooting.
Note
When the USB Type-B console port is in use, the RJ45 console port will echo the
console output but not accept any user input.
Note
For Microsoft Windows users, the RUGGEDCOM USB Serial Console driver must be
installed on the users workstation before connecting via the USB Type-B console port.
For more information, refer to the "RUGGEDCOM ROS Configuration Manual" for the
RUGGEDCOM RSG920P.
