5.6

Operating Environment

The RUGGEDCOM i803 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
Vibration
Shock
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing, 55 °C (131 °F), 6 cycles.
5.7

Mechanical Specifications

Weight
Ingress Protection
Enclosure
5.8

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
RUGGEDCOM i803
Equipment Manual, 10/2023, C79000-G8976-1005-09
-20 to 60 °C (-4 to 140 °F)
a
-40 to 85 °C (-40 to 185 °F) (Optional)
-40 to 85 °C (-40 to 185 °F)
b
up to 95%
2000 m (6562 ft)
1 g @ 10 to 500 Hz
30 g @ 11 ms
1.0 kg (2.2 lbs)
IP40 (1 mm or 0.04 in objects)
Cast Aluminum Enclosure
