  • Page 1 Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM RSG2100 Edition 03/2020 https://www.siemens.com...
  • Page 2 Preface Introduction Installing the Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM RSG2100 Communication Ports Technical Specifications Installation Manual Certification 03/2020 C79000-G8976-1040-17...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommend- ed or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 4: Table Of Contents

    Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................v Training ..........................vi Customer Support ........................vi Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Required Tools and Materials ................. 3 Decommissioning and Disposal ................3 Cabling Recommendations ..................
  • Page 5 FCC ........................41 6.1.5 FDA/CDRH ......................42 6.1.6 ISED ........................42 6.1.7 ISO ........................42 6.1.8 ACMA ........................42 6.1.9 RoHS ........................43 6.1.10 Other Approvals ....................43 EMC and Environmental Type Tests ..............43 RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 6: Preface

    Warranty Siemens warrants this product for a period of five (5) years from the date of pur- chase, conditional upon the return to factory for maintenance during the warranty term.
  • Page 7: Training

    Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request...
  • Page 8: Contacting Siemens

    Preface Contacting Siemens • Ask questions or share knowledge with fellow Siemens customers and the support community Contacting Siemens Address Siemens AG Industry Sector 300 Applewood Crescent Concord, Ontario Canada, L4K 5C7 Telephone Toll-free: 1 888 264 0006 Tel: +1 905 856 5288...
  • Page 9 Preface Contacting Siemens viii RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 10: Introduction

    (ST, MTRJ, LC, SC) without loss of port density. The RUGGEDCOM RSG2100 is packaged in a rugged galvanized steel enclo- sure with industrial grade DIN, panel, or 48 cm (19 in) rack-mount mounting options.
  • Page 11: Description

    CSA/UL 60950-1 safety approved to 85 °C (185 °F) Description The RUGGEDCOM RSG2100 features various ports, controls and indicator LEDs on the display panel for connecting, configuring and troubleshooting the device. The dis- play panel can be located on the rear, front or top of the device, depending on the mounting configuration.
  • Page 12: Required Tools And Materials

    "Connect- ing to the Device (Page 21)". Required Tools and Materials The following tools and materials are required to install the RUGGEDCOM RSG2100: Tools/Materials Purpose AC power cord (16 AWG) For connecting power to the device.
  • Page 13: Cabling Recommendations

    Siemens also does not recommend using copper Ethernet ports to interface with de- vices in the field across distances that could produce high levels of ground potential rise (i.e.
  • Page 14: 1.5.3 Supported Fiber Optic Cables

    1000Base-SX 10GBase-SR OM1 (62.5/125) — 1300 2000 — — OM2 (50/125) — 1300 2000 — — OM3 (50/125) 1500 — 1300 2000 — — OM4 (50/125) 3500 — 1300 2000 — — Laser optimized. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 15 Introduction 1.5.3 Supported Fiber Optic Cables RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 16: Installing The Device

    Use of controls or adjustments or performance of procedures other than those speci- fied herein may result in hazardous radiation exposure. NOTICE This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 17: General Procedure

    Installing the Device 2.1 General Procedure Changes or modifications not expressly approved by Siemens AG could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment. NOTICE This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken.
  • Page 18: Installing The Device In Hazardous Locations

    2.3 Installing the Device in Hazardous Locations Installing the Device in Hazardous Locations The RUGGEDCOM RSG2100 is designed to comply with the safety standards for Class I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to normal operating environments.
  • Page 19: Mounting The Device

    2.4.1 Mounting the Device to a Rack The RUGGEDCOM RSG2100 can be secured to a standard 48 cm (19 in) rack using separately purchased rack mount adapters. The adapters can be installed at the front or rear of the chassis.
  • Page 20: 2.4.2 Mounting The Device On A Din Rail

    2.4.2 Mounting the Device on a DIN Rail For DIN rail installations, the RUGGEDCOM RSG2100 can be equipped with panel/DIN rail adapters pre-installed on each side of the chassis. The adapters allow the device to be slid onto a standard 35 mm (1.4 in) DIN rail.
  • Page 21: 2.4.3 Mounting The Device To A Panel

    2.4.3 Mounting the Device to a Panel For panel installations, the RUGGEDCOM RSG2100 can be equipped with panelDIN rail adapters pre-installed on each side of the chassis. The adapters allow the device to be attached to a panel using screws.
  • Page 22: Connecting The Failsafe Alarm Relay

    Control of the failsafe relay output is configurable through RUGGEDCOM RSG2100 . One common application for this relay is to signal an alarm if a power failure oc- curs. For more information, refer to the RUGGEDCOM RSG2100 User Guide for the RUGGEDCOM RSG2100.
  • Page 23: Connecting Power

    Figure 2.5 Failsafe Alarm Relay Wiring Connecting Power The RUGGEDCOM RSG2100 supports a single or dual redundant AC and/or DC power supplies. The RUGGEDCOM RSG2100 can be equipped with either a screw-type or pluggable terminal block, which provides power to both power supplies . The screw-type ter- minal block is installed using Phillips screws and compression plates, allowing either bare wire connections or crimped terminal lugs.
  • Page 24: Connecting Ac Or Dc Power

    Identify the internal power module (POWER 1 or POWER 2) appropriate for the power supply (AC or DC). Use these screws along with #6 ring lugs to secure the wires to the terminal block. Note For wiring options, refer to "Wiring Examples (Page 17)". RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 25 Install the supplied metal jumper between terminals 2, 4 and 6 to connect the surge ground terminals to the chassis ground terminal. The surge ground termi- nals are used as the ground conductor for all surge and transient suppression cir- cuitry internal to the unit. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 26: 2.6.2 Wiring Examples

    Make sure the supplied terminal block cover is always installed before the de- vice is powered. Install the terminal block cover. 2.6.2 Wiring Examples The following illustrate how to connect power to single and dual power supplies. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 27 Installing the Device 2.6.2 Wiring Examples Figure 2.8 Single AC Power Supply Figure 2.9 Single DC Power Supply RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 28 Installing the Device 2.6.2 Wiring Examples Figure 2.10 Dual AC Power Supply Figure 2.11 Dual DC Power Supply RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 29 Installing the Device 2.6.2 Wiring Examples Figure 2.12 Dual AC/DC Power Supply RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 30: Device Management

    The following describes the various methods for accessing the RUGGEDCOM RSG2100 console and Web interfaces on the device. For more detailed instructions, refer to the RUGGEDCOM RSG2100 User Guide for the RUGGEDCOM RSG2100. RS232 Console Port Connect a workstation directly to the RS232 console port to access the boot-time control and RUGGEDCOM RSG2100 interfaces.
  • Page 31: Configuring The Device

    Communication Ports Connect any of the available Ethernet ports on the device to a management switch and access the RUGGEDCOM RSG2100 console and Web interfaces via the device's IP address. For more information about available ports, refer to "Communication Ports (Page 23)".
  • Page 32: Communication Ports

    The exact configuration of the device can be determined by reading the factory data file through the RUGGEDCOM RSG2100 user interface. For more information about how to read the factory data file, refer to the RUGGEDCOM RSG2100 User Guide for the RUGGEDCOM RSG2100.
  • Page 33: Copper Ethernet Ports

    Figure 4.2 Port LEDs Copper Ethernet Ports The RUGGEDCOM RSG2100 supports several 10/100/1000Base-TX Ethernet ports that allow connection to standard Category 5 (CAT-5) unshielded twisted-pair (UTP) cables with either RJ45 or Micro-D male connectors. The RJ45 and Micro-D connec- tors are directly connected to the chassis ground on the device and can accept CAT-5 shielded twisted-pair (STP) cables.
  • Page 34: Fiber Optic Ethernet Ports

    Jack), LC (Lucent Connector), SC (Standard or Subscriber Connector) or ST (Straight Tip) connectors. Make sure the Transmit (Tx) and Receive (Rx) connections of each port are properly connected and matched to establish a proper link. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 35: Sfp Transceivers

    The RUGGEDCOM RSG2100 features two Small Form-Factor Pluggable (SFP) trans- ceiver sockets, which are compatible with a wide array of SFP transceivers available from Siemens. The following SFP transceivers are compatible with the RUGGEDCOM RSG2100. For more information, including installation/removal instructions and ordering infor- mation, refer to the RUGGEDCOM SFP Transceiver Catalog [https://support.indus-...
  • Page 36: Gbic Optic Ethernet Ports

    Do not install or remove GBIC optical ports when an explosive atmosphere is present. CAUTION Electrical hazard – risk of damage to equipment Use only components certified by Siemens with RUGGEDCOM products. Damage to the module and device may occur if compatibility and reliability have not been prop- erly assessed. RUGGEDCOM RSG2100...
  • Page 37 NOTICE Only install GBIC optical ports that are compatible with the RUGGEDCOM RSG2100. Make sure all potential electrostatic build-up has been properly discharged to prevent electrostatic discharges (ESD). This can be accomplished by wearing an ESD-preventive wrist strap connected to either the chassis ground connector or a bare metal surface on the router/switch.
  • Page 38: Removing A Gbic Optical Port

    ESD-preventive wrist trap connected to either the chassis ground connector or a bare metal surface on the router/switch. Disconnect the cable from the port and install the dust cap to the cable end. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 39 Store the port in an ESD-safe bag or other suitable ESD-safe environment, free from moisture and stored at the proper temperature (-40 to 85 °C or -40 to 185 °F). Insert a dust plug into the socket opening to prevent the ingress of dust and dirt. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 40: Technical Specifications

    Technical Specifications This section details the specifications and operating conditions of the device. Power Supply Specifications The RUGGEDCOM RSG2100 can be equipped with the following power supplies: CAUTION Electrical hazard – risk of power supply failure or damage to the device Make sure power input to the device is within the specified input range.
  • Page 41: Failsafe Relay Specifications

    RUGGEDCOM RSG2100. Note • Maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a Siemens sales associate when determining maximum segment distances. RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 42: Fiber Optic Ethernet Port Specifications

    14.2 Typical. Typical distance. The maximum distance is greatly dependent on factors such as cable type, the number of connectors and number of splices. Consult a Siemens sales associates when determining maximum distances. Fast Ethernet (10/100 Mbps) Optical Specifications Mode...
  • Page 43 All optical power numbers are listed as dBm averages. Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a Siemens sales associates when determining maximum segment distances. GBIC Gigabit (1 Gbps) Transceiver Specifications Note GBIC transceivers have a temperature range of -40 to 85 °C (-40 to 185 °F), unless...
  • Page 44: Operating Environment

    Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a Siemens sales associates when determining maximum segment distances. Operating temperature range of -20 to 85 °C (-4 to 185 °F) .
  • Page 45 Technical Specifications 5.8 Dimension Drawings 438.15 Figure 5.1 Overall Dimensions RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 46 Technical Specifications 5.8 Dimension Drawings 32.77 21.08 11.68 479.29 478.79 4.57 Figure 5.2 Rack Mount Dimensions RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 47 Technical Specifications 5.8 Dimension Drawings 11.7 10.4 476.3 486.4 Figure 5.3 Panel and DIN Rail Mount Dimensions RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 48: Certification

    Certification The RUGGEDCOM RSG2100 device has been thoroughly tested to guarantee its con- formance with recognized standards and has received approval from recognized reg- ulatory agencies. Approvals This section details the standards to which the RUGGEDCOM RSG2100 complies. 6.1.1 This device meets the requirements of the following Canadian Standards Association (CSA) standards under certificate 16.70068356:...
  • Page 49: 6.1.2 Csa/Sira

    For the maximum ambient temperature, refer to the hazardous location label affixed to the device. 6.1.3 European Union (EU) This device is declared by Siemens AG to comply with essential requirements and other relevant provisions of the following EU directives: • EN 60950-1 Information Technology Equipment –...
  • Page 50: Fcc

    Methods of Measurement The device is marked with a CE marking and can be used throughout the European community. A copy of the CE Declaration of Conformity is available from Siemens AG. For contact information, refer to "Contacting Siemens (Page vii)".
  • Page 51: 6.1.5 Fda/Cdrh

    Title 21 Code of Federal Regulations (CFR) – Chapter I – Sub-chapter J – Radiolog- ical Health 6.1.6 ISED This device is declared by Siemens AG to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) 6.1.7...
  • Page 52: Rohs

    Certification 6.1.9 RoHS 6.1.9 RoHS This device is declared by Siemens AG to meet the requirements of the following Ro- HS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: • China RoHS 2...
  • Page 53 Damped Os- Slow Damped 2.5 kV Common cillatory Wave Mode on Pow- er and Signal 1.0 kV Differential Mode on Power IEC 61000-4-29 Voltage Dips DC Power Ports 30% for 0.1 s   and Interrupts RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 54 EMC Immunity Type Tests per IEEE 1613 Note The RUGGEDCOM RSG2100 meets Class 2 requirements for an all-fiber configuration and Class 1 requirements for copper ports. Class 1 allows for temporary communica- tion loss, while Class 2 requires error-free and interrupted communications.
  • Page 55 Change of Temperature Test Nb 5 Cycles, -40 to 85°   60068-2-14 C (40 to 185° F) Bump 10 g @ 16 ms Class 1 60255-21-2 Seismic Method A, Class 2 Class 1 60255-21-3 RUGGEDCOM RSG2100 Installation Manual, 03/2020, C79000-G8976-1040-17...
  • Page 56 Further Information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens AG Digital Industry Process Automation Postfach 48 48 90026 NÜRNBERG GERMANY...
