Siemens SIMATIC NET RUGGEDCOM RSG920P Equipment Manual page 52

61000-4-17
61000-4-18
61000-4-29
EC 60225-27
a
Severity level set by Siemens.
b
Common mode tests performed on the signal port shield.
c
For IEC 61850-3 compliance when using Power-over-Ethernet (PoE), an IEC 61850-3 compliant PoE power supply must be installed
in the vicinity of the device with power cabling no longer than 3 meters (118 in).
EMC Immunity Type Tests per IEEE 1613
Note
RUGGEDCOM products meet Class 1 requirements for copper Ethernet
configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Electrostatic Discharge (ESD)
Burst (Electrical Fast Transient)
RUGGEDCOM RSG920P
Equipment Manual, 10/2023, C79000-G8976-1172-09
Test
IEC Ripple on DC Power Supply
IEC Damped Oscillatory Wave
IEC DC Voltage Dips
and Interrupts
Dielectric Strength
HV Impulse
Description
Radiated Radio Frequency
Immunity (RFI)
6.2 EMC and Environmental Type Tests
Description
DC Power
Ports
Slow
Damped
PoE Ports
DC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Enclosure
Contact
Enclosure
Contact
Enclosure Ports 35 V/m (80% Modulation)
Signal Ports
DC Power Ports
AC Power Ports
Test Levels
10%
2.5 kV common
1 kHz or 1 MHz
30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
2 kV (Fail-Safe
Relay Output)
2 kV
2 kV
5 kV (Fail-Safe
Relay Output)
5 kV
5 kV
Test Levels
±8 kV
±15 kV
±4 kV at 2.5 kHz
±4 kV
±4 kV
Certification
Severity
Levels
3
3
c
Note
Severity
Levels
43
