Technical Specifications
5.5 Copper Ethernet Port Specifications
5.5

Copper Ethernet Port Specifications

The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM RSG920P.
Speed Interface
a
(Mbps)
10/100/1000 TX
a
Auto-negotiating.
b
Shielded or unshielded.
c
Auto-crossover and auto-polarity.
d
Typical distance. Dependent on the number of connectors and splices.
e
RMS 1 minute.
5.6

Digital Input Specifications

Isolation to System
Input 1 to Input 2
Isolation
Input Voltage
Logic High
Logic Low
Wetting Voltage
Input/Output Current
5.7

Operating Environment

The RUGGEDCOM RSG920P is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
Ambient Storage Temperature
Ambient Relative Humidity
Maximum Altitude
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Operating temperature may vary based on the limitations of installed SFPs. Refer to the "RUGGEDCOM SFP Transceivers Catalog" for
SFP temperature ratings.
c
Non-condensing.
5.8

Mechanical Specifications

Weight
32
a
Connector Duplex
RJ45 FDX/HDX
1.5 kVAC
1 kVDC
+/- 30 V Maximum
+10 ~ + 30 V
-30 ~ + 8 V
+9.5 V
5-10 mA
-40 to 85 °C (-40 to 185 °F)
ab
-40 to 85 °C (-40 to 185 °F)
c
5% to 95%
2000 m (6562 ft)
4.7 kg (10.5 lbs)
b
Cable Type Wiring
Standard
> CAT-5 TIA/EIA
T568A/B
Equipment Manual, 10/2023, C79000-G8976-1172-09
Maximum Isolation
c d
Distance
100 m 1.5 kVAC
(328 ft)
RUGGEDCOM RSG920P
e
