Peripherals settings

Peripherals Pairing CiscoTouchPanels EmcResilience

If the Touch controller is used in environments with considerable amounts of
electromagnetic noise present, you may experience an appearance of false signals—for
example as if someone tapped the Touch controller when obviously nobody did so. To cope
with this you may enable the EMC Resilience Mode.
Requires user role: ADMIN
Default value: Off
Value space: Off/On
Off: The EMC resilience is disabled.
On: The EMC resilience is enabled.

Peripherals Pairing CiscoTouchPanels RemotePairing

In order to use Cisco Touch 10 (touch controller) as user interface for the video
conferencing device, Touch 10 must be paired to the device via the network (LAN). This is
referred to as remote pairing.
Remote pairing is allowed by default; you must switch this setting Off if you want to prevent
remote pairing.
Requires user role: ADMIN
Default value: On
Value space: Off/On
Off: Remote pairing of Touch 10 is not allowed.
On: Remote pairing of Touch 10 is allowed.
D15330.16 SX10 Administrator Guide CE9.9, OCTOBER 2019.
Configuration Peripherals Maintenance

Peripherals Profile Cameras

Define the number of cameras that are expected to be connected to the video conferencing
device. This information is used by the device's diagnostics service. If the number of
connected cameras does not match this setting, the diagnostics service will report it as an
inconsistency.
Requires user role: ADMIN, INTEGRATOR
Default value: Minimum1
Value space: NotSet/Minimum1/0/1/2/3/4/5/6/7
NotSet: No camera check is performed.
Minimum1: At least one camera should be connected to the device.
0-7: Select the number of cameras that are expected to be connected to the device.

Peripherals Profile ControlSystems

Define if a third-party control system, for example Crestron or AMX, is expected to
be connected to the video conferencing device. This information is used by the video
conferencing device's diagnostics service. If the number of connected control systems
does not match this setting, the diagnostics service will report it as an inconsistency. Note
that only one third-party control system is supported.
If set to 1, the control system must send heart beats to the video conferencing device using
xCommand Peripherals Pair and HeartBeat commands. Failing to do so will cause the video
conferenceing device to show a warning that it has lost connectivity to the control system.
Requires user role: ADMIN, INTEGRATOR
Default value: NotSet
Value space: 1/NotSet
1: One third-party control system should be connected to the device.
NotSet: No check for a third-party control system is performed.
