LEDS:
The device has got three LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED
1: Not used (yellow)
2: Not used (green)
3: Device State (green)
ADFweb.com Srl – IT31010 – Mareno – Treviso
Normal Mode
Not used
Not used
Blinks slowly (~1Hz)
User Manual DeviceNet Slave / PROFIBUS Slave
Document code: MN67574_ENG
Boot Mode
Not used
Not used
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
