Industrial Electronic Devices
User Manual
Revision 2.100
English
Modbus Slave / Modbus TCP Master - Converter
(Order Code: HD67510-A1, HD67510-A1-422,
HD67510-B2)
For Website information:
www.adfweb.com?Product=HD67510
For Price information:
www.adfweb.com?Price=HD67510-A1
www.adfweb.com?Price=HD67510-A1-422
www.adfweb.com?Price=HD67510-B2
Benefits and Main Features:
Very easy to configure
32mm Rail DIN mount
Wide supply input range
Triple electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual Modbus Slave / Modbus TCP Master
Document code: MN67510_ENG
For others products, see also the following links:
RS232 / RS485 / USB / Ethernet
www.adfweb.com?Product=HD67118
www.adfweb.com?Product=HD67119
www.adfweb.com?Product=HD67038
CAN / CANopen / Modbus / Modbus TCP
www.adfweb.com?Product=HD67001
www.adfweb.com?Product=HD67502
www.adfweb.com?Product=HD67011
www.adfweb.com?Product=HD67012
www.adfweb.com?Product=HD67514
www.adfweb.com?Product=HD67515
Modbus TCP Slave / Modbus Master - Converter
www.adfweb.com?Product=HD67507
www.adfweb.com?Product=HD67508
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 2.100
Page 1 of 33
(RS232 / RS485 - Converter)
(USB / RS485 - Converter)
(RS485 / RS232 / Ethernet - Converter)
(CANopen / Modbus Master - Converter)
(CANopen / Modbus Slave - Converter)
(CAN / Modbus Master - Converter)
(CAN / Modbus Slave - Converter)
(CAN / Modbus TCP Master – Converter)
(CAN / Modbus TCP Slave – Converter)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD67510-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for ADF Web HD67510-A1

Summary of Contents for ADF Web HD67510-A1

  • Page 1 Revision 2.100 Page 1 of 33 Industrial Electronic Devices User Manual Revision 2.100 English Modbus Slave / Modbus TCP Master - Converter (Order Code: HD67510-A1, HD67510-A1-422, HD67510-B2) For Website information: www.adfweb.com?Product=HD67510 For Price information: www.adfweb.com?Price=HD67510-A1 www.adfweb.com?Price=HD67510-A1-422 For others products, see also the following links: www.adfweb.com?Price=HD67510-B2...

  • Page 2: Updated Documentation

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 2 of 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...

  • Page 3: Security Alert

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 3 of 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.

  • Page 4: Examples Of Connection

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 4 of 33 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l.

  • Page 5: Connection Scheme

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 5 of 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67510-A1 ADFweb.com S.r.l.
  • Page 6 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 6 of 33 Industrial Electronic Devices Figure 1b: Connection scheme for HD67510-A1-422 ADFweb.com S.r.l.
  • Page 7 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 7 of 33 Industrial Electronic Devices Figure 1c: Connection scheme for HD67510-B2 ADFweb.com S.r.l.
  • Page 8 Page 8 of 33 Industrial Electronic Devices CHARACTERISTICS: The HD67510-A1 and HD67510-B2 are a Modbus Slave / Modbus TCP Master – Converter. It allows for the following characteristics: Triple isolation between Serial - Power Supply, Serial - Ethernet, Power Supply - Ethernet.

  • Page 9: Power Supply

    The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67510-A1-xxx HD67510-B2 Caution: Not reverse the polarity power HD67510-A1 HD67510-B2 HD67510-A1-422 ADFweb.com S.r.l.

  • Page 10: Function Modes

    FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip-Switch A’. HD67510-A1-xxx version: With ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. With ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
  • Page 11 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 11 of 33 Industrial Electronic Devices LEDS: The devices has got four (five for HD67510-B2) LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below.
  • Page 12 ETHERNET: The Ethernet connection must be made using Connector5 of HD67510-A1/HD67510-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to a Hub/Switch the use of a straight cable is recommended.
  • Page 13 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 13 of 33 Industrial Electronic Devices RS485: To terminate the RS485 line with a 120Ω resistor, it is necessary to put dip 1 ON, like in figure. The maximum length of the cable should be 1200m (4000 feet).
  • Page 14 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 14 of 33 Industrial Electronic Devices RS422: For terminate the RS422 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure. The maximum length of the cable should be 1200m (4000 feet).
  • Page 15 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 15 of 33 Industrial Electronic Devices USE OF COMPOSITOR SW67510: To configure the Converter, use the available software that runs with Windows called SW67510. It is downloadable on the site www.adfweb.com and its operation is described in this document.

  • Page 16: New Configuration / Open Configuration

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 16 of 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “Modbus Slave / Modbus TCP Master - Converter”...

  • Page 17: Software Options

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 17 of 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.

  • Page 18: Set Communication

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 18 of 33 Industrial Electronic Devices SET COMMUNICATION: By Pressing the “Set Communication” button from the main window for SW67510 (Fig. 2) the window “Set Communication” appears (Fig. 3). The window is divided in different sections in order to define the different parameters of the converter: Operation Mode...

  • Page 19: Operation Mode

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 19 of 33 Industrial Electronic Devices PERATION This section is used to define the working mode of MQTT side of the converter. It is possible to define: Normal Mode (with Translate Table): the converter can be seen like a Figure 3b: “Set Communication...

  • Page 20: Modbus Tcp Master

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 20 of 33 Industrial Electronic Devices TCP M ODBUS ASTER This section is used to define the main parameters of Modbus line. The means of the fields are: In the field “IP...
  • Page 21 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 21 of 33 Industrial Electronic Devices ORMAL WITH RANSLATE ABLE Using this function, the converter can be seen like a single serial Modbus slave. The address of Modbus is assigned in the “Set Communication”...
  • Page 22 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 22 of 33 Industrial Electronic Devices XAMPLE Taking the first row of Figure 4: Step 1: A serial Modbus master do the request to the Converter to read the “Coil Status”...
  • Page 23 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 23 of 33 Industrial Electronic Devices OUTING LAVE DDRESS Using this function, the converter can be seen like more than one serial Modbus slave. Each serial Modbus slave is a row of the table and it is possible to define to which TCP device is linked.
  • Page 24 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 24 of 33 Industrial Electronic Devices XAMPLE Taking the first row of Figure 6: Step 1: A serial Modbus master do the request to the Converter to read/write a register from the serial slave Modbus ID 1;...
  • Page 25 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 25 of 33 Industrial Electronic Devices IP A ORK WITH DDRESS Using this function, the converter can be seen like a single serial Modbus slave. The address of Modbus is assigned in the “Set Communication”...
  • Page 26 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 26 of 33 Industrial Electronic Devices UPDATE VIA SERIAL (only for hardware with jumpers): By pressing the “Update Via Serial” button it is possible to load the created configuration into the device, and also the Firmware if is necessary.
  • Page 27 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 27 of 33 Industrial Electronic Devices UPDATE VIA UDP (only for hardware with dip-switches): By pressing the “Update via UDP” button, it is possible to load the created configuration into the device;...
  • Page 28 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 28 of 33 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67510 device.

  • Page 29: Mechanical Dimensions

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 29 of 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 12a: Mechanical dimensions scheme for HD67510-A1 Figure 12b: Mechanical dimensions scheme for HD67510-A1-422 ADFweb.com S.r.l.
  • Page 30 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 30 of 33 Industrial Electronic Devices Figure 12c: Mechanical dimensions scheme for HD67510-B2 ADFweb.com S.r.l.

  • Page 31: Ordering Informations

    Order Code: HD67510-A1 Modbus Slave / Modbus TCP Master - Converter ( Housing type: A, Terminal Blocks Connectors ) Order Code: HD67510-A1-422 - Modbus Slave / Modbus TCP Master - Converter ( Housing type: A, Terminal Blocks Connectors ) Order Code: HD67510-B2...
  • Page 32 User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 32 of 33 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 33: Warranties And Technical Support

    User Manual Modbus Slave / Modbus TCP Master Document code: MN67510_ENG Revision 2.100 Page 33 of 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
