Industrial Electronic Devices

User Manual

Revision 1.100

English

PROFIBUS Slave / Modbus TCP Master -

Converter

(Order Code: HD67564-A1, HD67564M)

For Website information:

www.adfweb.com?Product=HD67564

For Price information:

www.adfweb.com?Price=HD67564-A1

www.adfweb.com?Price=HD67564M

Benefits and Main Features:

Triple electrical isolation

Two Ethernet ports

Temperature range: -40°C/+85°C (-40°F/+185°F)

User Manual

ADFweb.com Srl – IT31010 – Mareno – Treviso

Axis Solutions Pvt Ltd is the Authorized Distributor of

www.axisindia.in | info@axisindia.in

User Manual PROFIBUS Slave / Modbus TCP Master

Document code: MN67564_ENG

HD67564-A1

For others Gateway / Adapters:

PROFIBUS to

Need help?

Do you have a question about the HD67564-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67564-A1

Page 1 Revision 1.100 Page 1 of 29 Industrial Electronic Devices User Manual Revision 1.100 English PROFIBUS Slave / Modbus TCP Master - Converter (Order Code: HD67564-A1, HD67564M) HD67564M For Website information: HD67564-A1 www.adfweb.com?Product=HD67564 For Price information: For others Gateway / Adapters: www.adfweb.com?Price=HD67564-A1 PROFIBUS to www.adfweb.com?Price=HD67564M...
Page 2 ADFweb.com reserves the right to change information in this manual about UPDATE VIA SERIAL (only for HD67564M) our product without warning. UPDATE VIA UDP (only for HD67564-A1) ADFweb.com is not responsible for any error this manual may contain. MECHANICAL DIMENSIONS...
Page 3 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 3 of 29 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.
Page 4 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 4 of 29 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 5 of 29 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67564-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 6 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 6 of 29 Industrial Electronic Devices Figure 1b: Connection scheme for HD67564M ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 7 Revision 1.100 Page 7 of 29 Industrial Electronic Devices CHARACTERISTICS: The HD67564-A1 and HD67564M are a PROFIBUS Slave / Modbus TCP Master Converter. They allows the following characteristics: Two-directional information between Modbus TCP network and PROFIBUS; Eletrical isolation between two buses;...
Page 8 POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC (for the HD67564-A1) and at 8…19V AC and 8…35V DC (for HD67564M). The consumption depends to the code of the device. For more details see the two tables below.
Page 9 FUNCTION MODES: HD67564-A1 The HD67564-A1 has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
Page 10 Revision 1.100 Page 10 of 29 Industrial Electronic Devices LEDS (HD67564-A1): The device has got six LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode...
Page 11 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 11 of 29 Industrial Electronic Devices LEDS (HD67564M): The device has got two LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: Device State (green)
Page 12 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 12 of 29 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the following figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®...
Page 13 ETHERNET: The Ethernet connection must be made using Connector2/3/4 of HD67564-A1/HD67564M with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
Page 14 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 14 of 29 Industrial Electronic Devices USE OF COMPOSITOR SW67564: To configure the Converter, use the available software that runs with Windows called SW67564. It is downloadable on the site www.adfweb.com and its operation is described in this document.
Page 15 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 15 of 29 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “PROFIBUS Slave / Modbus TCP Master - Converter”...
Page 16 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 16 of 29 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.
Page 17 (Ethernet) and one for the PROFIBUS. In the section “Select Device” is possible to select the type of converter used: HD67564-A1 (“Device from May 2014 (with Dip-Switch)”); HD67564M (“Device till April 2014 (with Jumper)”). The means of the fields for “Modbus TCP Master”...
Page 18 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 18 of 29 Industrial Electronic Devices The means of the fields for “PROFIBUS Slave” are: In the field “ID Device”, the address of the PROFIBUS side is defined; In the field “Baudrate”, the baudrate of the PROFIBUS side is defined (fixed to “Auto Baudrate”);...
Page 19 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 19 of 29 Industrial Electronic Devices SET ACCESS: By pressing the “Set Access” button from the main window for SW67564 (Fig. 2) the window “Set Modbus TCP Master Access” appears. The window is divided in two parts, the “Modbus Read”...
Page 20 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 20 of 29 Industrial Electronic Devices If “Device from May 2014 (with Dip-Switch)” is set in section “Set Communication”, window appears like below: If the field “Enable” is checked, the Modbus TCP request is enabled;...
Page 21 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 21 of 29 Industrial Electronic Devices GSD FILE: By pressing the “PROFIBUS GSD” button it is possible to save the GSD file for the PROFIBUS side. With this feature you can save the configuration of the gateway of the PROFIBUS side.
Page 22 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 22 of 29 Industrial Electronic Devices UPDATE VIA SERIAL (only for the HD67564M): By pressing the “Update Device” button it is possible to load the created Configuration into the device, and also the Firmware if is necessary, using the RS232 port.
Page 23 Document code: MN67564_ENG Revision 1.100 Page 23 of 29 Industrial Electronic Devices UPDATE VIA UDP (only for HD67564-A1): By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary.
Page 24 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 24 of 29 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67564 device.
Page 25 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 25 of 29 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8a: Mechanical dimensions for HD67564-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 26 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 26 of 29 Industrial Electronic Devices Figure 8b: Mechanical dimensions for HD67564M ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 27 Page 27 of 29 Industrial Electronic Devices ORDER CODE: Order Code: HD67564-A1 PROFIBUS Slave / Modbus TCP Master - Converter ( Housing type: A, Terminal Blocks Connectors ) Order Code: HD67564M PROFIBUS Slave / Modbus TCP Master - Converter ( Housing type: B, Terminal Blocks Connectors )
Page 28 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 28 of 29 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
Page 29 User Manual PROFIBUS Slave / Modbus TCP Master Document code: MN67564_ENG Revision 1.100 Page 29 of 29 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
