  • Page 2 Revision 1.100 Page 1 of 22 Industrial Electronic Devices User Manual Revision 1.100 English PROFIBUS Slave / Modbus Master - Converter (Order Code: HD67561) for Website information: www.adfweb.com?Product=HD67561 HD67561 for Price information: For others Gateways / Bridges: www.adfweb.com?Price=HD67561 CANopen to Modbus See also the following links: www.adfweb.com?Product=HD67001...

  • Page 3: Updated Documentation

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 2 of 22 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page Updated INDEX...

  • Page 4: Security Alert

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 3 of 22 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation.

  • Page 5: Connection Scheme

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 4 of 22 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67561 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
  • Page 6 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 5 of 22 Industrial Electronic Devices CHARACTERISTICS: The Configurable ProfiBus Slave to Serial Communication Master Gateway allows the following characteristics: Baud Rate and Parity changeable with software; Mountable on 35mm Rail DIN;...

  • Page 7: Power Supply

    POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67561 Consumption at 24V DC: Device W/VA HD67561 Caution: Not reverse the polarity power HD67561 ADFweb.com Srl –...

  • Page 8: Function Modes

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 7 of 22 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip2 of ‘Dip-Switch A’: The first, with Dip2 in Off position (factory setting), is used for the normal working of the device. The second, with Dip2 in On position, is used for upload the Project/Firmware.
  • Page 9 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 8 of 22 Industrial Electronic Devices LEDS: The device has got three LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode 1: Not used (yellow)
  • Page 10 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 9 of 22 Industrial Electronic Devices PROFIBUS: The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in the right figure. Here some codes of cables: Belden: p/n 183079A - Continuous Armor DataBus®...
  • Page 11 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 10 of 22 Industrial Electronic Devices RS232: The connection from RS232 socket to a serial port (example one from a personal computer), must be made with a Null Modem cable (a serial cable where the pins 2 and 3 are crossed).

  • Page 12: New Project / Open Project

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 11 of 22 Industrial Electronic Devices USE OF COMPOSITOR SW67561: To configure the Gateway, use the available software that runs with Windows, called SW67561. downloadable site www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on our web site).

  • Page 13: Set Communication

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 12 of 22 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameter of two Buses, Serial and ProfiBus. By pressing the "Set Communication" button from the main window for SW67561 (Fig.
  • Page 14 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 13 of 22 Industrial Electronic Devices The means of the fields for “ProfiBUS” are: In the field "ID Dev." the address of the ProfiBus side is defined; In the field "Baud Rate"...

  • Page 15: Set Access

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 14 of 22 Industrial Electronic Devices SET ACCESS: By pressing the “Set Access” button from the main window for SW67561 (Fig. 2) the window “Set SDO Access” appears. This window is divided in two parts, the "ProfiBus IN -->...
  • Page 16 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 15 of 22 Industrial Electronic Devices Serial Write --> ProfiBus OUT The means of the fields are: In the field “Slave ID” the address of the Modbus device that you must write is defined;...
  • Page 17 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 16 of 22 Industrial Electronic Devices ERROR/DIAGNOSIS By pressing the “Set Access” button from the main window for SW67561 (Fig. 2) the window “Error/Diagnosis” appears. In this window is possible to insert all the Modbus devices checked by the gateway. The table give the position of the bit that are set if the device is in error in the Diagnosis array in PROFIBUS.
  • Page 18 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 17 of 22 Industrial Electronic Devices ASYNC MODBUS REQUEST: With the Async Modbus Request is possible to send an Asynchronous Modbus Request form the PROFIBUS to the Modbus network. To use this feature there are 8 bytes in write where the master PROFIBUS can send the parameters of the request and 4 bytes in read where the result of the Modbus communication is saved.
  • Page 19 User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 18 of 22 Industrial Electronic Devices The permits values for the “Status_Request” are: • Performing Request • Answer OK • Answer with Exception • Wrong Answer (CRC) •...

  • Page 20: Update Device

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 19 of 22 Industrial Electronic Devices UPDATE DEVICE: Section “Update Device” (Fig. 7): In order to load the parameters or update the firmware in the gateway, follow these instructions: Turn OFF the device;...

  • Page 21: Mechanical Dimensions

    Page 20 of 22 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9: Mechanical dimensions scheme ORDER CODE: Order Code: HD67561 PROFIBUS Slave / Modbus Master / Converter ACCESSORIES: Order Code: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m Order Code: AC34114...

  • Page 22: Other Regulations And Standards

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 21 of 22 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 23: Warranties And Technical Support

    User Manual PROFIBUS Slave / Modbus Master Document code: MN67561_ENG Revision 1.100 Page 22 of 22 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
