Chapter 1: Product Introduction

Rear Panel

5 6 7
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
8 9
5. Power Switch
Used to power on the device.
6. DisplayPort 1.4 Connector
Supports DP1.4 displays.
7. 2.5 GbE RJ45
Used to connect the system to a local area network.
8. GPIO Terminal Block
Connects to an external device with a maximum load of 24V, 1.0A.
9. PCIe Slots
Supports x16 lanes (up to 1 x16 + 1 x4, 2 x8 + 1 x4)
