Chapter 2: Jumpers and Connectors
M.2 Key B Slot
Connector type: M.2 Key B 2280 slot (SATA/USB3.0)
Connector location: CN12
74
2
75
1
Pin
Definition
1
M2B_CONFIG_3
3
GND1
5
GND2
7
M2B_USB2_DP
9
M2B_USB2_DN
11
GND3
21
M2B_CONFIG_0
23
WAKE_ON_WWA#_1.8V
25
DPR_1.8V
27
GND4
29
M2B_PER1N
31
M2B_PER1P
33
GND5
35
M2B_PET1N
37
M2B_PET1P
39
GND6
41
M2B_PER0P
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
V3P3_M2B_1
4
V3P3_M2B_2
6
M2B_SSD_FULL_PWR_OFF_N
8
M2B_PLN_N
10
M2B_SATA_LED_N
20
GPIO_5/RFU_1.8V
22
GPIO_6/RFU_1.8V
24
GPIO_7/RFU_1.8V
26
W_DISABLE2#_1.8V
28
GPIO_8/RFU_1.8V
30
UIM-RESET
32
UIM-CLK
34
UIM-DATA
36
UIM-PWR
38
DEVSLP
40
GPIO_0
42
GPIO_1
Pin
Definition
43
M2B_PER0N
45
GND7
47
M2B_PET0N
49
M2B_PET0P
51
GND8
53
REFCLKn
55
REFCLKp
57
GND9
59
ANTCTL0_1.8V
61
ANTCTL1_1.8V
63
ANTCTL2_1.8V
65
ANTCTL3_1.8V
67
LTE_RST#_1.8V
67
M2B_CONFIG_1
71
GND10
73
GND11
75
M2B_CONFIG_2
20
Pin
Definition
44
GPIO_2
46
GPIO_3
48
GPIO_4
50
M2B_PCI_RST_N
52
CLKREQ#
54
PCIE_WAKE#
56
M2B_SMDAT
58
M2B_SMCLK
60
COEX3_1.8V
62
COEX_TXD_1.8V
64
COEX_RXD_1.8V
66
SIM_DETECT
68
M2B_SUSCLK
70
V3P3_M2B_3
72
V3P3_M2B_4
74
V3P3_M2B_5
