Chapter 1: Product Introduction

Rear Panel

1
1
5 7 9 10 11
6 8
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
1
1
12 13 14
NEXB ∞ T Switch
5
Enable or disable NETBOOT, refer to
configurations.
12V DC-IN 1 Cnnector
6
Power ButtonHDMI
7
Reset Pin Hole
8
RJ45 Console Connector
9
USB 2.0 Connector
10
1GbE RJ45 Management Port
11
2.5GbE RJ45 LAN Port
12
2.5GbE RJ45 PoE LAN Port (supports up to 30w, 802.3at, optional)
13
54V DC-IN 2 Cnnector
14
Plug in this power adapter for additional power supply when using PoE
functionality ( ). Note that to power the system, the original power
13
adapter ( ) must remain connected.
6
5
Appendix A for more detailed
