Chapter 1: Product Introduction

Hardware Specifications

CPU Support
▪ Intel
® Core™ i9-12900E/i7-12700E/i5-12500E/i3-12100E
Main Memory
▪ 2 x DDR4 SO-DIMM non-ECC support up to 64G
▪ Support OOB ECC in R680E
Platform Control Hub
▪ Intel
® Q670E (option R680E)
I/O Interface-Front
▪ 2 x Hot swappable 3.5" HDD bays
▪ 2 x USB 2.0 Type-A (per port output Max 500mA)
I/O Interface-Rear
▪ 4 x USB 3.2 Gen1, Type-A (Per port output Max 900mA)
▪ 1 x DP 1.4 (4K@60)
▪ 1 x HDMI 2.0b (4K@60Hz)
▪ 1 x HDMI 1.4b (4K@30Hz)
▪ 1 x Audio port (Line in/Line out/MIC)
▪ 2 x RJ45 LAN (2 x 2.5Gps)
▪ 1 x 4DI/2DO GPIO terminal block (option)
▪ 1 x COM (RS232/RS485) Port
Expansions
▪ 2 x PCIe by 16 slots, support x 16 lanes (riser slot could be compatible
one x16 or two x8)
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Storage
▪ Hot swappable 3.5" HDD x 2
▪ M.2 2280 Key M support NVMe Gen4
▪ M.2 2242 Key B support SATA3
Power Input
▪ Single PSU 600W
Dimensions
▪ 430mm (W) x 84mm (H) x 330mm (D)
Environment
▪ Operating temperature: Ambient with air flow: 0°C ~ 40°C
▪ Storage temperature: -20°C ~ 70°C
▪ Relative humidity: 0% ~ 90% (non-condensing)
Certifications
▪ CE approval
▪ FCC Class A
▪ UL compliance
