Chapter 2: Jumpers and Connectors
Pin Definition
B1 V12P0_SLOT_3
B3 V12P0_SLOT
B5 SLOT1_SMCLK
B7 GND_36
B9 TRST#
B11 PEG_WAKE_N
B13 GND_37
B15 PEG_TXN0
B17 PEG_PRSNT2_N
B19 PEG_TXP1
B21 GND_40
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B2 V12P0_SLOT_4
B4 GND_35
B6 SLOT1_SMSDA
B8 V3P3S_SLOT_3
B10 V3P3A_SLOT
B12 PEG_B12
B14 PEG_TXP0
B16 GND_38
B18 GND_39
B20 PEG_TXN1
B22 GND_41
Pin Definition
B23 PEG_TXP2
B25 GND_42
B27 PEG_TXP3
B29 GND_44
B31 PEG_PRSNT2_N
B33 PEG_TXP4
B35 GND_46
B37 PEG_TXP5
B39 GND_48
B41 PEG_TXP6
26
Pin Definition
B24 PEG_TXN2
B26 GND_43
B28 PEG_TXN3
B30 PEG_SEL_N
B32 GND_45
B34 PEG_TXN4
B36 GND_47
B38 PEG_TXN5
B40 GND_49
B42 PEG_TXN6
