Chapter 2: Jumpers and Connectors
M.2 Key M Slot
Connector type: M.2 Key M 2280 slot (PCIe Gen4 x4)
Connector location: CN15
74
2
75
1
Pin
Definition
1
GND1
3
GND2
5
NVME_RXN3
7
NVME_RXP3
9
GND3
11
NVME_TXN3
13
NVME_TXP3
15
GND4
17
NVME_RXN2
19
NVME_RXP2
21
GND5
23
NVME_TXN2
25
NVME_TXP2
27
GND6
29
NVME_RXN1
31
NVME_RXP1
33
GND7
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
V3P3A_M2M_1
4
V3P3A_M2M_2
6
M2M_FULL_PWROFF_N
8
M2M_PLN_N
10
M2M_LED_OC
12
V3P3A_M2M_6
14
V3P3A_M2M_7
16
V3P3A_M2M_8
18
V3P3A_M2M_9
20
NC2
22
NC3
24
NC4
26
NC5
28
NC6
30
NC7
32
NC8
34
NC9
Pin
Definition
35
NVME_TXN1
37
NVME_TXP1
39
GND8
41
NVME_RXN0
43
NVME_RXP0
45
GND9
47
NVME_TXN0
49
NVME_TXP0
51
GND10
53
NVME_CLKN
55
NVME_CLKP
57
GND11
67
NC26
69
M2M_SSD_DETECT
71
GND12
73
GND13
75
M2M_Mount_Detect
22
Pin
Definition
36
NC10
38
M2M_DEVSLP
40
M2M_SMBCLK_V1P8
42
M2M_SMBDAT_V1P8
44
M2M_ALERT_N_V1P8
46
NC14
48
NC15
50
M2M_PERST_N
52
M2M_NVME_PCH_CLKREQ_N
54
M2M_WAKE_N
56
NC16
58
NC17
68
M2M_SUSCLK
70
V3P3A_M2M_3
72
V3P3A_M2M_4
74
V3P3A_M2M_5
