Chapter 2: Jumpers and Connectors
LAN Connectors
Connector type: RJ45 port with LEDs
Connector location: LAN1, LAN2
8
1
LAN1
Pin
Definition
1
MDI1P
3
MDI2P
5
MDI3N
7
MDI4P
9
LED2-/Y
11
LED1-/Y
Copyright © 2024 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MDI1N
4
MDI3P
6
MDI2N
8
MDI4N
10
LED2+/Y
12
LED1+/Y
LAN2
Pin
Definition
1
MDI1P
3
MDI2P
5
MDI3N
7
MDI4P
9
LED2-/Y
11
LED1-/Y
35
Pin
Definition
2
MDI1N
4
MDI3P
6
MDI2N
8
MDI4N
10
LED2+/Y
12
LED1+/Y
NViS 66162/6602 Series User Manual
