- Page 1 User Manual Multisignal HD Video Recorder, HD-TVI, AHD, 960H MPR-32R080200A MPR-32R160200A...
- Page 3 Digital Video Recorder WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
- Page 4 User’s Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result appliance is operated. in the risk of fire or electric shock. 2.
-
Page 5: Table Of Contents
Digital Video Recorder Table of Contents Chapter 1 — Introduction........................1 Feature ............................1 Technical Overview ........................1 Chapter 2 — Installation ........................3 Package Contents ......................... 3 Required Installation Tools ......................3 Video Input ..........................3 Alarm Input/Output ........................4 RS485 Port .......................... - Page 6 User’s Manual Pre-Event ..........................31 Event Setup ..........................32 Motion ............................. 32 Tripzone ..........................33 Alarm-In ..........................35 Video Loss ..........................36 Video Blind ..........................37 Text-In ............................ 38 Camera Setup ..........................40 General ........................... 40 PTZ ............................41 Device Setup ..........................42 Audio ............................
- Page 7 Digital Video Recorder Text-In Search ........................78 Bookmarks ..........................79 Clip-Copy ..........................80 Print ............................82 Disk Mirroring ..........................82 Appendix ............................85 USB Hard Disk Drive Preparation ....................85 Text-In Search Examples ......................85 Search Example I ........................85 Search Example II ........................
- Page 8 User’s Manual Figure 28: Network – General setup screen..................45 Figure 29: Network – LAN setup screen..................46 Figure 30: Network – FEN setup screen..................48 Figure 31: Network – RTSP setup screen..................49 Figure 32: Network – WebGuard setup screen................50 Figure 33: Network –...
-
Page 9: Chapter 1 - Introduction
Digital Video Recorder Chapter 1 — Introduction Feature Your color digital video recorder (DVR) provides recording capabilities for eight or 16 camera inputs. It provides exceptional picture quality in both live and playback modes, and offers the following features: Live Monitoring for Each Channel ... -
Page 10: Figure 1: Typical Dvr Installation
User’s Manual You can view video and control your DVR remotely by connecting via Ethernet. There is an eSATA port that can be used to record (eSATA interface only) video to external hard disk drives, and there are two USB ports that can be used to upgrade the system or copy video clips to external hard disk and flash drives. -
Page 11: Chapter 2 - Installation
Digital Video Recorder Chapter 2 — Installation Package Contents The package contains the following: Digital Video Recorder Power Cord Quick User Guide Software CD (User’s Manual included) Rack-mount Kit Assembly Screws for Adding Hard Disk Drives ... -
Page 12: Alarm Input/Output
User’s Manual Alarm Input/Output NOTE: To make connections on the Alarm Connector Strip, press and hold the button and insert the wire in the hole below the button. After releasing the button, tug gently on the wire to make certain it is connected. To disconnect a wire, press and hold the button above the wire and pull out the wire. -
Page 13: Esata Port
Digital Video Recorder NOTE: Refer to the following for pin-out details for the 9-pin connector of the slave unit. Pin 2 RXD (Receive Data) Pin 3 TXD (Transmit Data) Pin 5 GND (Ground) Male Female eSATA Port An eSATA port is provided to connect external storage devices for recording or archiving video. Connect the external eSATA hard disk drive (RAID) cable to the eSATA port. -
Page 14: Audio In/Out
User’s Manual Audio In/Out Your DVR can record audio from up to four sources. Connect the audio sources to Audio In 1, Audio In 2, Audio In 3 and Audio In 4 as needed using RCA jacks. Connect Audio Out to your amplifier. NOTE: It is the user’s responsibility to determine if local laws and regulations permit recording audio. -
Page 15: Chapter 3 - Configuration
Digital Video Recorder Chapter 3 — Configuration NOTE: Your DVR should be completely installed before proceeding. Refer to Chapter 2 — Installation. Front Panel Controls Figure 3: DVR front panel. Camera Buttons Enter Button Arrow Buttons Menu Button Zoom Button PTZ Button Panic Button Display Button... -
Page 16: Camera Buttons (1 To 16)
User’s Manual ID Button Alarm Button Monitor Buttons Freeze Button Display Button Clip Copy Button Sequence Button Bookmark Button Camera Buttons Zoom In/Out Button Triplex Button Preset Set/View Button Audio Buttons PTZ Mode Button Focus Near/Far Button Arrow Buttons Menu Button Zoom Mode Button Enter Button Play Button... -
Page 17: Ptz Button
Digital Video Recorder PTZ Button Pressing the button enters the PTZ (Pan/Tilt/Zoom) mode which allows you to control properly configured cameras. Panic Button Pressing the button starts panic recoding of all camera channels, and displays on the screen. Pressing the button PANIC again will stop panic recording. -
Page 18: Playback Buttons
User’s Manual Playback Buttons Backward: When in the pause mode, pressing the button moves to the previous image. The button is also used to Zoom Out while in the PTZ mode. Forward: When in the pause mode, pressing the button moves to the next image. -
Page 19: Sequence Button On Remote Control
Digital Video Recorder Sequence Button on Remote Control Pressing the button displays live channels sequentially. SEQUENCE Clip Copy Button on Remote Control Pressing the button allows you to copy video clips. CLIP COPY Turning on the Power Connecting the power cord to the DVR turns on the unit. The unit takes approximately one minute and 30 seconds to initialize. -
Page 20: Setup Screen
User’s Manual Setup Screen System Record Event Camera Device Network Notification Display Figure 7: Setup screen. Press the button or move the mouse pointer on the right edge of the screen and then select (Setup) in the Live MENU Monitoring menu to enter the setup screen. While setting up the DVR, there will be many opportunities to enter names and titles. -
Page 21: System Setup
Digital Video Recorder System Setup General Figure 8: System – General setup screen. Highlight the Site box and press the button. A virtual keyboard appears that you can use to enter a Site Name. Once you have entered your title, highlight OK and press the button. - Page 22 User’s Manual You can import saved DVR settings or export the current DVR settings. To import saved DVR settings, connect the USB device containing the setup file (.dat) to the DVR. If you enabled the NetFS function (Network menu > NetFS tab), you can download the setup file from the registered NetFS site.
- Page 23 Digital Video Recorder To export the system log information, connect the USB device to the DVR. If you enabled the NetFS function (Network menu > NetFS tab), you can upload the log information on the registered NetFS site. Highlight Export… button.
- Page 24 User’s Manual If you selected the Quick wizard, selecting the Next button starts the Quick Setup Wizard. Date/Time Setup Date: Set the system date and select the date format. Time: Set the system time and select the time format. ...
- Page 25 Digital Video Recorder Record Method Setup Select the desired recording mode from: – Motion Event Record (Recommended) – Continuous & Motion Event Record – Continuous Record NOTE: You should understand each recording mode before setting the DVR’s recording method. Record Video Quality Setup ...
- Page 26 User’s Manual NOTE: The recording quality, recording resolution, and recording speed of each camera channel will be set as show below according to the Record Method and Record Video Quality you set. HVQPP* SRP* LRTPP* Motion Event 30 ips / Very High / Very High 15 ips / High / Very High 5 ips / Standard / High Record...
- Page 27 Digital Video Recorder Internet Connection Select whether or not your DVR is connected to the Internet. LAN Setup Select between Auto Configuration and Manual Configuration for network configuration, and then select the Test button to test the network configuration you selected. NOTE: Selecting Auto Configuration allows the DVR to automatically obtain LAN parameters (IP address, Gateway, Subnet Mask and DNS Server address).
- Page 28 User’s Manual FEN Setup Use FEN: Highlight and press the button to toggle between On and Off. NOTE: FEN is the technology that automatically sets up your DVR to work seamlessly for remote viewing via your network internet connection. For FEN to work, naming your DVR will be required. ...
-
Page 29: Date/Time
Digital Video Recorder Date/Time Figure 9: System – Date/Time setup screen. Highlight the first box beside Date and press the button. The individual sections of the date will highlight. Use the Up and Down arrow buttons to change the number. Use the Left and Right arrow buttons to move between month, date and year. -
Page 30: User
User’s Manual Highlight the box beside Automatic Sync. and press the button. This toggles between On and Off. Highlight the box beside Time Server and press the button. A virtual keyboard appears that you can use to enter the IP address or domain name of the time server. Highlighting allows you to select your time server from a list of registered time servers. - Page 31 Digital Video Recorder The +/– column is used to collapse and expand user groups. If there is a + or – in this column, it indicates the item is a Group Name. If there is a – in front of the Group Name, it indicates that the group has been “expanded” and all of the User Names within that group are displayed below the Group Name.
- Page 32 User’s Manual To add a User, highlight the + User… box and press the button. A virtual keyboard appears allowing you to enter the User Name. Enter the name and assign the User to a Group and password. The password can be up to 8 digits. You will be asked to confirm the password. NOTE: In addition to using the front panel buttons or the infrared remote control, you can use the virtual keyboard to assign the password.
-
Page 33: Storage
Digital Video Recorder Storage < RAID Non-Supported Models > < RAID Supported Models > Figure 11: System – Storage setup screen. The information in the Type column describes the storage device. The capacity of the storage device is displayed in the Capacity column. The Format column displays whether the device is used for recording (Record) or not (Not Using). -
Page 34: System Event
User’s Manual The Information column displays whether the device is being used or not. Other indicates the device has been used for another DVR. Highlight the box in the Information column for the desired storage device and press the button. You will be able to check the model name, serial number and the time information about recorded data of the selected storage device. - Page 35 Digital Video Recorder Highlight the Settings box beside Check Recording and press the button. The Check Recording screen appears. Highlighting Schedule On and pressing the button toggles On and Off. When set to On, you can select the day, time range and interval that you want the DVR to run self-diagnostics on the recorder.
-
Page 36: Recording Setup
User’s Manual Recording Setup General Figure 13: Record – General setup screen. Highlighting Recycle and pressing the button toggles between On and Off. In the Recycle mode, the DVR records over the oldest video data once all available storage space has been used. When Recycle is turned off, the DVR stops recording once all available storage space has been used. -
Page 37: Schedule
Digital Video Recorder Highlighting the Panic Recording – ips and pressing the button allows you to set the images per second for Panic recording. You can select from 1.00 to 30.00 ips (25.00 ips PAL). Highlighting the Panic Recording – Quality and pressing the button allows you to set the recorded image quality for Panic recording. -
Page 38: Figure 15: Schedule - Settings (Advanced Mode) Setup Screen
User’s Manual When the DVR is in the Event mode, the red icon displays at the top-left corner of the screen. The DVR will record icon at the top-left corner of the screen when any event occurs. When the DVR is in the Pre-Event and displays the recoding mode, the yellow icon displays when there is no event, and the DVR is not recording. -
Page 39: Pre-Event
Digital Video Recorder Highlight Default… and press the button. The Default screen appears. Highlighting boxes under ips and pressing the button allows you to set the images per second for Time and Event recording. You can select from 1.00 to 30.00 ips (25.00 ips PAL). Highlighting boxes under Quality and pressing the button allows you to set the recorded image quality for Time and Event recording. -
Page 40: Event Setup
User’s Manual Event Setup Motion Figure 17: Event – Motion setup screen. Your DVR has built-in video motion detection. Video motion detection can be turned On or Off for each camera. Highlighting the box under the Sensitivity heading and pressing the button allows you to adjust the DVR’s sensitivity to motion for Daytime and Nighttime independently. -
Page 41: Tripzone
Digital Video Recorder You can adjust the minimum number of detection blocks that must be activated to trigger a motion alarm. Highlighting the box under the Min. Blocks heading and pressing the button allows you to adjust the minimum number of detection blocks for Daytime and Nighttime independently. Smaller numbers provide greater sensitivity because fewer detection blocks must be activated. - Page 42 User’s Manual The Motion Zone screen is laid over the video for the selected camera. You can set up motion zones by selecting or clearing blocks. NOTE: You can set up motion zones one block at a time in groups of 16 individual block groups. A block group is positioned within the image area using the Up and Down arrow buttons, and individual blocks within the block groups are selected or cleared...
-
Page 43: Alarm-In
Digital Video Recorder Alarm-In Figure 19: Event – Alarm-In setup screen. The alarm terminal strip on the back of the DVR has inputs associated with each alarm. You can set up each input on the Alarm-In screen. You can turn each input On or Off by highlighting the alarm number and pressing the button. -
Page 44: Video Loss
User’s Manual Video Loss Figure 20: Event – Video Loss setup screen. Highlighting the box under the Video Loss Interval heading allows you to set the duration of a signal loss before the DVR will report a Video Loss. The DVR will not consider any signal loss from a camera to be a Video Loss if the detected signal loss is shorter than the interval set on this screen. -
Page 45: Video Blind
Digital Video Recorder Video Blind Figure 21: Event – Video Blind setup screen. The DVR checks to see if anything is blinding a camera. Highlighting the box under the Sensitivity heading allows you to adjust the DVR’s sensitivity to video blind for Black and White independently from 0 (Never) and 1 (least sensitive) to 15 (most sensitive). -
Page 46: Text-In
User’s Manual Text-In Figure 22: Event – Text-In setup screen. The DVR can be set to react to text input from devices such as ATMs (Automated Teller Machines) and POS (Point of Sale; i.e., cash registers). This screen allows you to configure the DVR for each text-in device. Highlight the box under the Setup heading, and press the button. - Page 47 Digital Video Recorder NOTE: The following description is for a Generic Text Device. The screen changes for different types of text input devices, and there will be different parameter boxes for you to enter information. Highlight the box beside Transaction Start, and press the button.
-
Page 48: Camera Setup
User’s Manual Camera Setup General Figure 23: Camera – General setup screen. You can turn the camera number On or Off, and you can change the Title of each camera using the virtual keyboard. You can also determine which cameras will display on the monitors by selecting Normal, Covert 1 or Covert 2 from a drop-down list in the Use column. -
Page 49: Ptz
Digital Video Recorder Figure 24: Camera – PTZ setup screen. NOTE: You will only be able to set up PTZ devices if the PTZ port is set to RS232 or RS485. Highlight the box in the Product column for the PTZ camera you wish to configure and press the button. -
Page 50: Device Setup
User’s Manual Configure the port’s setting based on the PTZ camera manufacturer’s instructions. Device Setup Audio Figure 25: Device – Audio setup screen. The DVR can record up to four audio inputs. Highlight the box beside the input and press the button. -
Page 51: Alarm-Out
Digital Video Recorder Alarm-Out Figure 26: Device – Alarm-Out setup screen. Highlighting the box beside Dwell Time and pressing the button allows you to set the dwell time of the alarm output. Dwell times range from 5 seconds to 30 minutes. Each alarm output can be given its own title by highlighting Title…... -
Page 52: Remote Control
User’s Manual Remote Control Figure 27: Device – Remote Control setup screen. Highlight the box beside Port and select from None, RS232 and RS485. If the RS232 port and RS485 port are in use for PTZ control, networking or text input, the remote keyboard cannot be configured. Highlight Setup…... -
Page 53: Network Setup
Digital Video Recorder Network Setup General Figure 28: Network – General setup screen. Highlight Multi Stream and press the button to toggle between On and Off. When it is On, the DVR supports more than one stream. You can configure to use a different stream depending on the layout mode or channel in a remote program. -
Page 54: Lan
User’s Manual Highlight Enable SSL for Transferring Data and press the button to toggle between On and Off. When it is On, the security of data except video and audio transmitted for remote monitoring or remote recording can be enhanced by using the SSL (Secure Sockets Layer) authentication. - Page 55 Digital Video Recorder Change the numbers by highlighting them and using the Up and Down arrow buttons to increase or decrease the number. The factory default Port settings are: Remote Admin: 8200 Remote Callback: 8201 Remote Watch: 8016 Remote Search: 10019 NOTE: The system restarts automatically after changing the port settings.
-
Page 56: Fen
User’s Manual Figure 30: Network – FEN setup screen. Highlight Use FEN and press the button to toggle between On and Off. NOTE: FEN is the technology that automatically sets up your DVR to work seamlessly for remote viewing via your network internet connection. -
Page 57: Rtsp
Digital Video Recorder RTSP Figure 31: Network – RTSP setup screen. Highlight Enable RTSP (Real-Time Streaming Protocol) and press the button to toggle between On and Off. You will be able to change the settings if Enable RTSP is enabled. Highlight the box beside RTSP Port and press the button. -
Page 58: Webguard
User’s Manual WebGuard Figure 32: Network – WebGuard setup screen. Highlight Use WebGuard Service and press the button to toggle between On and Off. See Appendix – WebGuard for detailed descriptions of the WebGuard service. Highlight the box beside Port and press the button. -
Page 59: Netfs
Digital Video Recorder Highlight the box beside Password and press the button. A virtual keyboard appears allowing you to enter the password for VNC connection. NOTE: Up to three users at a time can access a DVR remotely via VNC service. When controlling the DVR remotely using a keyboard, shortcut keys perform the following functions as described below: Function... -
Page 60: Figure 34: Network - Netfs
User’s Manual Figure 34: Network – NetFS. Highlight Use NetFS and press the button to toggle between On and Off. The Title box displays the NetFS site name. Use the virtual keyboard to enter the name. The Use box allows you to select the usage of the NetFS function. ... -
Page 61: Notification Setup
Digital Video Recorder Notification Setup Callback Figure 35: Notification – Callback setup screen. The DVR can be set up to contact a computer running RAS (Remote Administration System) when an event occurs. Highlight the box under the No. heading and press the button to toggle between On and Off. - Page 62 User’s Manual The DVR can be set up to send an email when an event occurs. The Mail Group and Recipient can be turned On or Off by highlighting the boxes beside the individual mail group and recipient accounts and pressing the button.
-
Page 63: Sns
Digital Video Recorder Highlight Use SSL/TLS and press the button to toggle between On and Off. When it is On, the DVR can send an email via an SMTP server requiring SSL (Secure Sockets Layer) authentication. NOTE: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/). -
Page 64: Ftp
User’s Manual Figure 38: Notification – FTP setup screen. The DVR can be set up to upload event detected image or video clip on an FTP site when an event occurs. The FTP box displays the FTP site information. The Upload File box displays the file format to be uploaded on the FTP site. Highlight the + and press the button to register a FTP site (max. -
Page 65: Schedule
Digital Video Recorder Schedule Figure 39: Notification – Schedule setup screen. You can add and edit notification schedules on this screen. Highlight the + and press the button to add a schedule. Highlighting the boxes under the Column heading and pressing the button allows you to edit the information in those boxes. -
Page 66: Display Setup
User’s Manual Display Setup Figure 40: Display – OSD setup screen. Highlighting an item and pressing the button toggles that item On and Off. When an item is On, there is a checkmark in the box beside it. The following items can be turned On or Off: ... -
Page 67: Main Monitor
Digital Video Recorder Main Monitor Figure 41: Display – Main Monitor setup screen. Highlight the box beside Mode and press the button. You can select between Full Sequence and Cameo Sequence. Pressing the button causes the DVR to sequence cameras, and the DVR can sequence cameras in two SEQUENCE modes: “Full”... -
Page 68: Spot Monitor
User’s Manual Spot Monitor Highlight Spot Monitor and press the button, and the Spot Monitor setup screen appears. Figure 42: Display – Spot Monitor setup screen. Highlight the box in the Channels column and press the button. You can define which cameras display sequentially on the Spot Monitor when in the single-screen display format. -
Page 69: Chapter 4 - Operation
Digital Video Recorder Chapter 4 — Operation NOTE: This chapter assumes your DVR has been installed and configured. If it has not, please refer to Chapters 2 and 3. The DVR’s controls are similar to a VCR. As with a VCR, the main functions are recording and playing back video. However, you have much greater control over recording and playing back video. -
Page 70: Live Monitoring Menu
User’s Manual Live Monitoring Menu Login/Logout Selecting (Login) in the Live Monitoring menu accesses the Login screen, and you will be asked to select a User and enter the password to log into the system. Selecting (Logout) in the Live Monitoring menu displays the Logout screen asking you to confirm whether or not you want to log out the current user. - Page 71 Digital Video Recorder Sequence Selecting (Sequence) in the Live Monitoring menu causes the cameras to display sequentially. It is the same as pressing and holding the button for three seconds or longer. When in one of the multi-view formats, selecting SEQUENCE will cause the DVR to go through predefined screen layouts (Full Sequence).
-
Page 72: Active Cameo Mode
User’s Manual Search (Search) → All Channels exits the live monitoring mode and enters the search mode. All Channels: Selecting It is the same as pressing the button. SEARCH (Search) → Triplex enters the Triplex mode. Selecting the camera number plays back video ... -
Page 73: Figure 44: Ptz Select Camera Menu
Digital Video Recorder To use the front panel buttons, press the Left and Right arrow buttons to pan left and right. Press the Up and Down arrow buttons to tilt the camera up and down. Press the button to zoom in, and press the button to zoom out. -
Page 74: Event Monitoring
User’s Manual Clicking on the left side exits the toolbar. If you want to display the toolbar again, position the mouse pointer at the bottom of the screen. Change the toolbar location by clicking the empty space on the left side of the toolbar and drag it to where you want it located on the screen. -
Page 75: Status Monitoring
Digital Video Recorder Status Monitoring Selecting (Status) in the Live Monitoring menu or Search menu displays the Event Status screen. Figure 46: Event Status – Event Status screen. The Event Status screen displays the status of the DVR’s systems and inputs. Events will be highlighted, and related channels or events will flicker for five seconds when detected. -
Page 76: Recording Video
User’s Manual Figure 47: Event Status – Storage screen. The Type column displays the type of storage device. The Disk Bad column displays the percentage of bad sectors. Not formatted indicates the device is not formatted. The Temperature column displays the temperature of the storage device. The S.M.A.R.T. -
Page 77: Panic Recording
Digital Video Recorder Panic Recording Selecting (Panic) in the Live Monitoring menu or pressing the button starts panic recording of all cameras, PANIC and selecting or pressing the button again stops panic recording. If you set the Panic Recording Duration in the Panic Record setup screen, panic recording will stop automatically according to the preset duration as long as not selected or the PANIC... -
Page 78: Searching Video
User’s Manual Play/Pause Button: Pressing the button plays back images at regular speed or pauses playing video. Search Button: Pressing the button enters the search mode, and pressing the button again exits the search SEARCH mode. When entering the search mode, video is paused. Pressing the (Enter) button plays back video at regular speed. -
Page 79: Search Menu
Digital Video Recorder Search Menu Search (Search) → Event Log Search selects video from the event log. See the following Event Log Search: Selecting Event Log Search section for details. (Search) → Record Table Search selects using a recording table. See ... - Page 80 User’s Manual Panic Selecting (Panic) in the Search menu starts panic recording of all cameras, and selecting again stops panic recording. It is the same as pressing the button. PANIC Camera Menu (Camera Menu) → Zoom and choosing the camera number zooms the current playback image ...
-
Page 81: Event Log Search
Digital Video Recorder Event Log Search Figure 50: Event Log Search screen. The DVR maintains a log of each time the Alarm Input port is activated. The Event Log Search screen displays this list. Use the arrow buttons to highlight the event for which you would like to see video. There is no determined user authority to display the Event Log Search screen, however, the event video will not be played unless a user with Search authority logs into the system . - Page 82 User’s Manual Highlight the box beside Check Time Overlap and press the button. It toggles between On and Off. You will only be able to turn the Check Time Overlap on or off if a user-defined date and time is set to From and To. If the DVR’s date and time have been reset, it is possible for the DVR to have more than one overlapping start and stop time.
-
Page 83: Record Table Search
Digital Video Recorder Record Table Search < Compact View > < Standard View > < Expanded View > Figure 51: Record Table Search screen. Recording information about video images currently displayed on the screen displays on the recording status bar. A grey vertical line indicates the current search position. -
Page 84: Motion Search
User’s Manual Selecting located at the bottom displays the Calendar Search screen. Days with recorded video display on the calendar with white numbers. You can highlight the days with recorded video by using the arrow buttons. Once you have highlighted a day, press the (Enter) button to select it. - Page 85 Digital Video Recorder You can also narrow your event search by selecting the Option… button and setting up the new search condition. You can search video from the first to last recorded images, or you can set the start and stop times and dates. Highlight the box beside From and press the button to toggle between On and Off.
-
Page 86: Text-In Search
User’s Manual Text-In Search Figure 53: Text-In Search screen. The DVR maintains a log of each time there is Text Input. The Text-In Search screen displays this list. Use the arrow buttons to highlight the event for which you would like to see video. Pressing the (Enter) button will extract the video associated with the Text Input and display the first image of the event. -
Page 87: Bookmarks
Digital Video Recorder Highlight the box beside From and press the button to toggle between On and Off. When set to Off, you can enter a specific Date and Time. When set to On, the search will be from the first recorded image. When highlighting pressing the button the bookmark list displays and the bookmark point you selected will be the starting date and time. -
Page 88: Clip-Copy
User’s Manual Clip-Copy Video clips can be copied on an external USB hard disk or flash drive. The copied video clips can be viewed on computers running Microsoft Windows 2000, XP, Vista or 7. Refer to the Appendix – USB Hard Disk Drive Preparation for information on preparing the external drive for clip copy. - Page 89 Digital Video Recorder NOTE: When copying video clips on a NetFS site, you cannot check the disk volume of the NetFS site for the video clips to be uploaded. The DVR displays the volume as 30GB regardless of the actual disk volume, and limits the file size for clip copy to 30GB.
-
Page 90: Print
User’s Manual Print You can print images on a printer. Connect a PostScript™ printer, or external hard disk drive or flash drive to one of the USB ports. If you enabled the NetFS function (Network menu > NetFS tab), you can upload the images on the registered NetFS site. - Page 91 Digital Video Recorder NOTE: The capacity and model of the two disks should be the same for proper mirroring between the two disks. CAUTION: If you change the setup related to Mirror, you must reboot the system. If disk mirroring fails, you must restart the system before trying disk mirroring again. When a disk mirroring failure is caused by a disk error, you must replace the disk with a new one.
- Page 92 User’s Manual...
-
Page 93: Appendix
Digital Video Recorder Appendix USB Hard Disk Drive Preparation NOTE: The following description is for preparing a USB hard disk drive under Windows 2000. Preparing a USB hard disk drive under Windows XP, Window Vista and Window 7 is almost identical to Windows 2000. Connect the USB hard disk drive to your computer using the USB Cable. -
Page 94: Search Example Ii
User’s Manual Search Example II 123456789012345678901234567890123456789012345678901234567890 Item Unit price amount ================================================== Coke 2.20 | 1(s) 2.20 Fanta 2.20 | 1(s) 2.20 Hotdog 3.50 | 3(s) 10.50 Pepsi 1.95 | 1(s) 1.95 ================================================== total : $ 16.85 Thank you~~ In the above text-in data, you can find that the comparison value is located at 17th (Unit price, $ mark will be ignored automatically), 28 (Qty) and 40 (amount) characters (including spaces) from the left, but the value of amount... -
Page 95: Webguard
Digital Video Recorder WebGuard WebGuard allows you to access a remote DVR, monitor live video images and search recorded video using Internet Explorer web browser anytime from virtually anywhere. Computer system requirements for using the WebGuard program are: ® ® ®... -
Page 96: Web Monitoring Mode
User’s Manual NOTE: There might be a problem with screen display or screen update due to low image transmission speed when using the Microsoft Windows Vista or higher operating system. In this situation, it is recommended that you disable the Auto Tuning capability of your computer. Run the Command Prompt with elevated administrator permissions (Go to the Start Menu ... -
Page 97: Web Search Mode
Digital Video Recorder ⑩ Click the to save the current image as a bitmap or JPEG file format. ⑪ Click the to set up the image drawing mode, OSD display and beep on/off. You can adjust the display speed by changing the image drawing mode, select OSD information to be displayed on the screen, and turn the DVR’s internal buzzer on and off from a remote site. - Page 98 User’s Manual ③ Position the mouse pointer on the WebSearch logo to see the version of the WebGuard program. ④ The DVR information window displays the time information of recorded data on the remote DVR and login information of WebGuard. ⑤...
-
Page 99: Time Overlap
Digital Video Recorder Time Overlap If the DVR’s time and date have been reset to a time that is earlier than the existing recorded video, it is possible for the DVR to have more than one video stream in the same time range. In this case, you can search overlapping video streams individually by selecting a specific segment. -
Page 100: System Log Notices
User’s Manual System Upgrade Related Clip Copy Related Description Description USB device is not connected. Unsupported file system. USB device is being used. Verify failed. Unsupported file system. System is busy clip copying. System Log Notices Boot Up Clear All Data Shutdown Clear Disk Restart... -
Page 101: Map Of Screens
Digital Video Recorder Map of Screens MENU SYSTEM General Date/Time User Storage System Event RECORD General Schedule Pre-Event EVENT Motion Alarm-In Tripzone Video Loss Video Blind Text-In CAMERA General DEVICE Audio Alarm-Out Remote Control NETWORK General RTSP WebGuard NetFS NOTIFICATION Callback Mail Schedule... -
Page 102: Troubleshooting
User’s Manual Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. Check camera video cable and connections. Check monitor video cable and connections. Confirm that the camera has power. No Live Video ... - Page 103 Digital Video Recorder CONNECTORS Video Input Composite 8 or 16 BNC HDMI: 1 HDMI Monitor Output VGA: 1 VGA SPOT (Composite): 1 BNC Audio In 4 RCA connector Audio Out 1 RCA connector Alarm Input/Output Terminal Blocks Ethernet Port RJ-45 eSATA Port eSATA RS232 Serial Port...
