Parameters, relays and events

4 Parameters, relays and events
4.1

Parameter list

The following parameters are relevant for Tensor STB tools. See the Power Focus user
manual for a description of all parameters in Power Focus.
Parameter Parameter name
number
T270 Power save
timeout
T271 Start condition
T272 Link timeout
T276 Max sender power
T277 Torque and angle
trace
T278 Power save
T290 Primary tool
T292 IRC pairing
T293 Power Focus IP
port
T294 Serial port
T296 IRC-W operational
mode
T297 IRC-W channel
T470 Use standalone
T472 Accessory
T473 Pset position 1
T474 Pset position 2
T475 Pset position 3
T476 Pset position 4
T477 Start select source
T478 Power save
timeout
T480 Power save
T481 ST selector
T482 Torque unit
22 (36)
Description
Tool will turn off automatically if inactive for this period of time.
Unit: Minutes. Min value: 1. Max value: 120.
Tool radio start condition
Alternatives: Off, Connected, Start request
After this timeout the tool is considered offline.
Unit: Milliseconds. Min value: 5000. Max value: 60000.
Max sender power on the IRC module. Only IRC-B. Valid settings:
Low, Medium, High and Full.
Selects if torque or angle traces shall be created. Up to 10 torque and
angle can be stored in the STB tool. Alternatives: All, None and Not
OK.
Flag that specifies whether T270 is active or not.
Expected primary tool connection. Cable or IRC.
When selected, IRC pairing starts if tool is in pairing mode and tool
connection is IRC-B.
Port number for IRC-W tool connection.
Serial port where IRC-B device is connected. Serial 2 or internal.
Operational mode when IRC-W is used. Ad-hoc or Infrastructure
Radio channel when IRC-W is used. Valid channels: 0,1-14, 36, 40,
44, 48, 52, 56, 60 and 64.
Defines if the tool is used as standalone.
Specifies the attached tool accessory.
None, ST selector, GPIO.
Selected when accessory is in position 1.If no accessory is selected,
this will be the onlay available position.
Selected when accessory is in position 2.
Selected when accessory is in position 3.
Selected when accessory is in position 4.
Same function as T200, and overrides it when in standalone mode.
Same function as T270, and overrides it when in standalone mode.
Flag that specifies whether T478 is active or not
Settings for the ST selector functions.
When T472 is ST selector this setting will set the torque unit in
which the tightening result and Pset target will be displayed
Default setup
30
Off
5000
Full
No
On
Cable
6677
Serial 2
Ad hoc
0 (Auto)
None
Tool trigger
30 min
On
Off
Nm
