User Guide
Tensor STB
Wireless tool for the Power Focus tightening controller
Atlas Copco Industrial Technique AB
9836 3043 01
Software version 10.11
Edition 7.0
2013-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tensor STB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atlas Copco Tensor STB

Summary of Contents for Atlas Copco Tensor STB

  • Page 1 User Guide Tensor STB Wireless tool for the Power Focus tightening controller Atlas Copco Industrial Technique AB 9836 3043 01 Software version 10.11 Edition 7.0 2013-05...
  • Page 2 Copyright Atlas Copco Tools and Assembly Systems Note! This manual can be altered without further notice. For further information log in to Atlas Copco www.atlascopco.com 2 (36) 9836 3043 01...

  • Page 3: Table Of Contents

    Contents Contents Introduction ......................4 Radio Frequency Exposure ..................4 System overview ....................5 Functionality ......................6 2.1.1 System functionality ....................6 2.1.2 Tool functionality ......................6 Technical data ......................7 2.2.1 Memory capacity ....................... 7 2.2.2 Battery ........................7 2.2.3 IRC ..........................

  • Page 4: Introduction

    See also the Power Focus User guide, 9836 3123 01. Radio Frequency Exposure The Serial Port Adapter (or the IRC Focus front panel) and the Tensor STB contain a small radio transmitter and receiver. During communication all IRC products receive and transmit radio frequency (RF) electromagnetic fields in the frequency range for the ISM (Industrial, Scientific and Medical) band (2.4GHz and 5.0 GHz).

  • Page 5: System Overview

    System overview System overview Tensor STB is battery powered and communicates with the Power Focus tightening controller system through wireless digital communication built on Industrial Radio Communication (IRC) technology. Figure 1 System overview A Tensor STB system includes the following parts.

  • Page 6: Functionality

    Power Focus SW may not be available in STB. For a complete list, see Tensor STB release notes. Remote start is not available, for safety reasons.

  • Page 7: Technical Data

    STB. 2.2.2 Battery Tensor STB is equipped with a Lithium-Ion battery. Figure 4 Number of tightenings The capacity is dependent on the battery type and joint, softer joints gives less tightenings. See Figure 4 Number of tightenings illustrates the number of tightening between re-charge for different tools and different types of joints (rundown angle in degrees) at the maximum torque for the tool.

  • Page 8: Irc

    The Industrial Radio Communication (IRC) technology operates on the free 2.4 GHz ISM band and also the 5.0GHz band (Uniband I and II). The Tensor STB tool is available in two different versions for the different IRC standards:  IRC-B ...
  • Page 9 Europe or ETSI domain (1-13) Japan (1-14) – not supported 5.15-5.25 GHz Unii-band 1 Unii-band II (restrictions for ad-hoc usage – please contact Atlas Copco representative) 5.25-5.35 GHz Uniband IIe (restrictions for ad-hoc usage – please contact Atlas Copco representative) 5.5 GHz 5.6-5.7 GHz...

  • Page 10: System Setup

    When using a Serial Port Adapter, connect it according to the following instructions. 1. Turn off the Power Focus. 2. Connect an Atlas Copco crossover cable between the Serial Port Adapter and the Power Focus serial port 2, called RS232 (2). Recommended maximum cable length: 2 metres.

  • Page 11: Antenna Placement

    System setup 3.2.2 Antenna placement The antenna must be located with free line of sight to the tool, for example above pallets and other equipment. The antenna on the serial port adapter can be adjusted to optimize performance. In IRC Focus, the antenna is built-in behind the front panel.

  • Page 12: Getting Started With Irc-B

    System setup Figure 10 Tool configuration 3.5.1 Getting started with IRC-B In ToolsTalk Power Focus do the following settings: 1. Set parameter T290 Primary tool IRC-B 2. Set if a Serial Port Adapter is used or for IRC Focus. T294 Serial port Serial 2 Internal 3.

  • Page 13: Getting Started With Irc-W - Ad Hoc

    System setup  PEAP, TKIP  PEAP, AES/CCMP  EAP/TLS, WEP128  EAP/TLS, TKIP  EAP/TLS, AES/CCMP  To setup the controller use ToolsTalk Power Focus or Graph interface and do the following settings: 1. Set parameter T290 Primary tool IRC-W 2.

  • Page 14: Connecting Tool With Power Focus (Pairing)

    System setup Connecting tool with Power Focus (Pairing) The Power Focus and the tool need to be paired together in order to establish the IRC-B or IRC-W ad hoc connection. This is not needed when running in infrastructure mode. 1. Disconnect the (charged) battery from the tool. 2.

  • Page 15: Radio Diagnostics

    System setup 3.6.1 Radio diagnostics It is possible to see some radio diagnostics in ToolsTalk Power Focus:  Select Power Focus Map > Tool > Diagnostics > Radio Figure 14 Radio diagnostics window  If you press the button Radio diagnostic you can get the actual reading for response time, RSSI value (Received Signal Strength Indication) channel used and MAC address for the accesspoint (BSSID).

  • Page 16: Setting Up Standalone

    System setup Setting up standalone This can be done after setting up the tool communication according to section 3.5 Setting up tool and performing a pairing. Standalone mode can be configured preferably when working communication with IRC-B or IRC-W ad-hoc mode. 3.7.1 Getting started with Standalone The STB power tool can be used in standalone mode, i.e., without being connected to the controller.

  • Page 17: Setting St-Selector In Stand-Alone Mode

    System setup The ST selector functions can be programmed in ToolsTalk by selecting the item “ST selector” in T472 Accessory. Figure 18 ST selector programming Standalone mode is indicated by the flashing blue Connection LED on the tool. It will take some time (up to 15 seconds) for this to occur.

  • Page 18: Connecting Tool With Toolstalk Service

    4. Click Figure 20 TTS settings 5. Click the icon Connect when the tool is connected to the Tensor STB docking station. The tool stays connected during the session with ToolsTalk Service. Figure 21 Connect icon 6. Open . Set parameters to the IP address of the Configuration >...
  • Page 19 System setup Figure 22 IRC Hardware settings 7. Enter the settings for the parameters. The data for Authentication/Encryption type and key IRC-W is submitted by the network administrator. Figure 23 IRC-W settings 9836 3043 01 19 (36)
  • Page 20 System setup Figure 24 Authentication/Encryption Key dialog 8. Store the settings in the Authentication/Encryption window and then also on the previous window. Finally, click on the Disconnect icon. Remove the tool from the docking station and attach the battery. The tool is automatically connected to Power Focus.

  • Page 21: Other Settings In Toolstalk Power Focus

    (provided the tool is in radio range). 3.9.1 Batch count Batch count is supported by the Tensor STB tool family according to the functionality described in the Power Focus User guide, 9836 3123 01 with the following exceptions in standalone mode: ...

  • Page 22: Parameters, Relays And Events

    Parameters, relays and events Parameters, relays and events Parameter list The following parameters are relevant for Tensor STB tools. See the Power Focus user manual for a description of all parameters in Power Focus. Parameter Parameter name Description Default setup...

  • Page 23: Digital Outputs (Relays)

    Parameters, relays and events Digital outputs (relays) The following outputs are relevant for Tensor STB tools. See the Power Focus user manual for a description of all available inputs/outputs and how to set up. String Set signal / Reset Name...
  • Page 24 If possible use a shorter tool cable. For STB, see E601 System voltage low E621 Current Current cannot be measured correctly. Contact the Atlas Copco measurement error service representative if it occurs frequently. 24 (36) 9836 3043 01...
  • Page 25 Atlas Copco service when battery is approaching low level. representative and send back May occasionally be due to internal battery to Atlas Copco (do not electronics in the tool misjudging reuse it if faulty!). If battery is battery alarm level.

  • Page 26: Faq

    When connection has been re-established the tightening results are automatically uploaded to the Power Focus. This function can be configured differently. See chapter 3.9 Other settings. Can I run the Tensor STB on Power Focus Yes, if you install WR7.5 or a later release. 3100? ...

  • Page 27: Appendix

    Connecting to PC Hardware setup 1. Connect the power supply to the Tensor STB docking station. 2. Connect the Tensor STB docking station to the PC using the USB cable. is displayed. Found New Hardware Wizard This may look different depending on the version of Windows being used.
  • Page 28 Appendix Figure 27 Found New Hardware Wizard, second screen 4. Select , and click Install from a list or specific location Next Figure 28 Found New Hardware Wizard, third screen 5. Select and click to locate the ToolsTalk Software. Include this location in the search Browse 28 (36) 9836 3043 01...
  • Page 29 Appendix Figure 29 Found New Hardware Wizard, browse for TTS 6. Select the ToolsTalk Service directory, and then click Figure 30 Found New Hardware Wizard, fourth screen 7. Click Continue Anyway 9836 3043 01 29 (36)
  • Page 30 4. In the main window, select Options > Settings 5. In the window, select from the drop-down list. Select communication Tensor STB Docking Station 6. In the Communication field set to the USB Port device that matches the Tensor STB docking station.

  • Page 31: Toolstalk Service With Serial Port Adapter

    Appendix Connecting STB tool to ToolsTalk Service 1. Place the Tensor STB tool in the Tensor STB docking station. 2. Select or click the Connection button on the toolbar. Connection > Connect The indicator on the docking station marked is lit and ToolsTalk Service opens the main window.

  • Page 32: Cross-Over Ethernet Connection

    Appendix Cross-over Ethernet connection The instructions in this section are only applicable if it is not possible to connect to the PF via the network or via USB connection and when the serial connection is used by the Serial port adapter.
  • Page 33 Appendix 3. Under the tab, select General Internet Protocol (TCP/IP) click Properties Figure 35 LAN properties 4. Click Use the following IP and enter Address IP address to use for this PC, Subnet mask according to the example. is not needed for Default gateway crossover cable connections.
  • Page 34 Appendix 2. In ToolsTalk, open and check that the Power Focus is present Option > Settings > Power Focus List in the Power Focus list. 3. Connect the Power Focus. Troubleshooting the connection If no connection is established, do the following to check that the network configuration is correct. 1.
  • Page 36 9836 3043 01 Edition 7.0 www.atlascopco.com...
