Parameters, relays and events
Event
Event name
code
E555 Condition change not
reflected in tool,
wireless tool
inaccessible
E556 Tool battery low
E557 Tool battery empty
E558 Tool software
version mismatch
E559 IRC pairing
completed
E561 Tool locked, do
Store standalone
E562 Condition change not
reflected in tool,
wireless tool
standalone
E563 IRC configuration
mismatch
E564 Reboot of wireless
tool needed for
changes to take
effect
E565 Locked while
updating Pset/Job in
tool
E601 System voltage low
E602 Dcbus HI during
rundown
E620 Tool stall
E621 Current
measurement error
24 (36)
Description
A condition change in the controller
(Pset selection, Job selection, Job
aborted etc.) could not be reflected in
the tool. The tool was currently
inaccessible.
Tool battery voltage is low.
Tool battery voltage is empty. Tool
locked
The implemented protocol version in
Power Focus for connected tool differs
from the protocol version in tool.
Additional parameter information:
First parameter is Power Focus protocol
version second parameter is Tool
protocol version.
An IRC paring sequence has been
successfully completed.
Tool locked since no Pset has been
actively stored in the tool.
A condition change in the controller
(Pset selection, Job selection, Job
aborted ...) could not be reflected in the
tool. The tool was currently standalone
Not possible to establish radio
connection with wireless tool.
Reboot of wireless tool needed for
changes to take effect.
The controller has locked the tool while
updating the Pset/Job in the tool.
DC voltage too low. Tool locked.
DC voltage too high
Tool motor stall.
Current cannot be measured correctly.
Procedure
Re-establish connection.
The condition change is now
automatically transferred to the
tool.
Complete work and replace
battery.
Replace the battery.
The tool is unlocked
automatically.
Upgrade the software in tool or
Power Focus.
For information only.
Do Store Standalone or deselect
Standalone, parameter
T470
.
Use Standalone
Make changes in the standalone
interface instead if the change
is meant to apply.
Check if tool is in correct
operation mode (Ad-hoc and
not Infrastructure mode) and
the PF IRC settings.
Acknowledge the event on the
PF and power cycle the
wireless tool
For information only. The tool
trigger was pressed before the
tightening programme was
fully read by the tool.
Acknowledge the event.
Check the battery. If occurring
frequently, check Pset settings.
Lastly, service tool.
Check that the tool cable and
connectors are undamaged and
correctly connected.
If possible use a shorter tool
cable.
For STB, see
E601 System
voltage low .
Contact the Atlas Copco
service representative if it
occurs frequently.
x
x
x
x x x
x x x
x
