DEMO MANUAL DC2737A

QUICK START PROCEDURE

Demo circuit 2737A is easy to set up to evaluate the per-
formance of the LT8301. Refer to Figure 1 for proper
equipment setup and follow the procedure below.
1. With power off, connect the input power supply to the
board through V
to the terminals V
2. Turn on the power at the input. Increase V
10V.
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
and GND terminals. Connect the load
IN
+ –
and V on the board.
OUT OUT
3. Check for the proper output voltages. The output should
be regulated at 5V (±5%).
4. Once the proper output voltage is established, adjust
the input voltage and load current within the operat-
ing range and observe the output voltage regulation,
transient response, ripple voltage, efficiency and other
parameters.
slowly to
IN
dc2737af
