Wiring Diagram - Directed DIRECTECHS DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
D2D Port
(-) Ground
(+) 12V Input
(+) Parking Lights Output
(-) Hood Input
(+) Ignition Status Input
6 403.FORD12 2.07 2020 Ford Escape (Smart Key)
©2023 Directed. All rights reserved.
(+) Parking Lights (LF) & (RF):
(+) Parking Lights (LR):
Violet/Green, pin 53
3 x
1A Diodes
Hood Pin
BCM
(Gray plug 'F' in passenger footwell)
2 10
1
11
12 23
25 36
24
37
38 48 49
52 53
51 62
50
63
64 72
Blue/Gray, pin 52
(+) Parking Lights (RR):
White/Orange, pin 48
HS CAN 3 High: Tan/Black: 3
HS CAN 3: Low: Tan: 4
HS CAN 1 High: Orange/Green: 5
HS CAN 1 Low: Orange/Brown: 6
(+) Ignition Status Output: Gray/Black: 7
).
Gateway Module
(Black connector Gateway Module
on OBDII connector)
13
(+)12V:
Brown/Red, pin 24
12 24
11 23
10 22
9 21
CAN 1 High:
Blue, pin 20
8 20
7 19
CAN 1 Low:
CAN 3 High: Green/Orange , pin 18
White, pin 19
18
6
CAN 3 Low: Gray/Blue, pin 17
5 17
16
4
3 15
14
2
(-) Ground: Black/Blue
or Black/Violet, pin 14
1
XKD2D65
