Installation; Wiring Diagram With T-Harness (Thniss3/Thniss3D) - Automatic Transmission - Directed DIRECTECHS DB3 Installation Manual

Wiring diagram with T-Harness (THNISS3D)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Clock & Data Wire
at Key Port Connector
(refer to the Vehicle
wiring reference charts
for wire location)
(-) Ground
(-) Hood Pin Input
(AC) Tach Input
(+) Ignition Input
(+) Starter Output
(+) 12V Input
20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
BCM
(green conn. behind instrument cluster)
Note: insert pin if wire is not present
Lt.Blue,
(-) Driver Door Trigger: pin 39
5 403.NISS3HT 3.17 2010 Nissan Altima (Smart Key)
©2023 Directed. All rights reserved.
with automatic transmission
NOT USED
T-02 T-02
T-01 T-01
Hood Pin
(+) Brake: pin 7
1
Connectors T-01 and T-02
(each pair has one male and
one female) are not interchangeable,
thus you will be able to connect
ONLY the correct connectors.
(AC) Tach Output: Violet/White
(+) Ignition Status Input: Violet/Green
(+) Ignition Status Output: Violet/Brown
(-) RAP Off Output: Red/Black
(-) Push-To-Start Output: Green/Black
Push-to-Start
(brown conn. at Push-to-Start switch)
2 3
1
4 5 6 7 8
(-) Push-to-Start:
Brown, pin 4
B-01 B-02
NOT USED
).
The Remote Start Safety
Override Switch is
inactive (used for RSR only)
NOT USED
THNISS3D
(optional T-Harness)
Diagnostic Connector
OBDII
D2D
only
Do not
connect
