Wiring Diagram - Directed DIRECTECHS DB3 Installation Manual

Wiring diagram

with T-Harness (TLTH1,THTOD1)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Headlight Switch
(white conn. at
headlight switch)
10 9 8 7 6 5 4 3 2 1
20 19 18 17 16 15 14 13 12 11
Autolight:
(-) Parking Lights: Lt. Blue, pin 18
Green, pin 19
86 87
85
CUT
87a
30
(-) Factory Alarm Re-arm
(-) Parking Light Output
(+) 12V Input
(AC) Tach Input
(+) Ignition Input
(-) Trunk/Hatch Release Output
(-) Ground
Do not connect any other accessory, ignition or starter wires
from the remote starter to the vehicle. The interface module
is handling the required vehicle power and start sequence.
Refer to the
Vehicle wiring
reference chart for
more information on
vehicle-specific wiring
connections.
5 403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Main Body ECU
(white conn.
Dash Fuse Box under drivers dash)
(white conn.)
2
6 5
(+) 12V,
Black, pin 1 10 9 8
1
(+) STSW: Pink
1
or Yellow, pin 4
4 3
7
OBDII
Diagnostic Connector
(+) Start Stop Switch Output: Yellow
PTS Switch
(black conn.
behind PTS button)
ENGINE
7
START
1 6 5 4 3 2 1
STOP
14 13 12 11 10 9 8
(-) Push-To-Start:
Pink, pin 7
(-) Push-to-Start Output: Green/Black:2
(AC) Tach Output: Violet/White: 5
(+) Ignition Status Output: Gray/Black:7
).
TLTH1/THTOD1
(optional T-Harness)
XKD2D65
D2D
only
Do not
connect
