Wiring Diagram - Directed DIRECTWIRE DIRECTECHS DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(-) PTS 2: Pin 4
ESCLCM
(Black conn. under
Diode 1A
steering column)
1 8
9 14 16
(-) PTS 1: Pin 13 FT CAN High:
Orange/Green, pin 16
Diode 1A
FT CAN Low:
Orange/Brown, pin 15
CUT
(+) Parking Light:
VESCM - Driver side under dashboard
6 403.VW09 2.00 2014 Volkswagen Jetta GLI (Smart Key)
©2023 Directed. All rights
This connector is located
at the Electronic Steering
Column Lock Module
(behind steering column trim)
Orange/Brown, pin 14
Parking Light
Interr.: Pin 8
Parking conn.
(Black conn. at
10 9 8 7 6
parking light
5 4 3 2 1
switch)
Pin 3
(brown conn. at VESCM
on driver side
under dashboard)
52
OBDII Diagnostic Connector
(connector side view)
(-) Ground: HS CAN High:
Orange/Black, pin 6
Brown, pin 4
1 8
9 16
HS CAN Low:
(+) 12V:
pin 16
HS CAN High: Tan/Black: 3
FT CAN High: Orange/Green: 5
FT CAN Low: Orange/Brown: 6
(+) Parking Light Output: Brown: 7
Parking Light Interr. (veh. side): Yellow: 8
Parking Light Interr. (conn. side): Orange/Yellow: 9
Key Wrap: Orange/Red: 10
Key Wrap: Yellow/Red: 11
Key Wrap: Brown/Red: 12
(+) 12V Input: Red: 13
(-) Ground: Black: 14
(-) PTS Output: Green/Black: 2
(+) Brake Activation Output: Gray: 6
VESCM
42 25 1
28
29 12
(+) Brake:
Black/Red,
pin 17
41 24 11
HS CAN Low: Tan: 4
).
You can connect to either a
XL202 RFTD OR a SmartStart
module.
Refer to the SmartStart/XL202
Installation Notes for more
information.
6: White/Black:
(-) Hood
Remote Start Safety
Override Switch
Hood Pin
Note: hood pin only
required on vehicles not
equipped with a factory
hood pin.
