Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
D2D Port
(-) Ground
(+) 12V Input
(-) Hood Pin Input
(-) Lock Output
(-) Unlock Output
(+) Brake Input
(AC) Tach Input
(+) Parking Lights Output
(+) Accessories 1,2,3 Outputs
(-) Trunk Release Output (if equipped)
(+) Starter Output
(+) Ignition Output
6 403.FORD1 4.22 2005 Mercury Grand Marquis
©2022 VOXX•DEI LLC. All rights reserved.
HS CAN High: White/Lt.Green or White/Blue, pin 6
(-) Driver
Door Trigger
(-) RAP Off Output: Yellow/Red: 11
Connect to vehicle
Go to www.di-
rectechs.com for more
information on
vehicle-specific wiring
connections.
Passive Anti-Theft Security System (PATS) connectors (wire-side view)
See Vehicle Connections for more information.
3 1
3 1
4 2
4 2
TX Ignition
1 8
9 16
HS CAN Low: Pink/Lt.Green or White, pin 14
HS CAN High: Orange/Green: 5
HS CAN Low: Orange/Brown: 6
(+)12V Input: Brown: 7
(+) Ignition Output: Yellow: 8
(-) Ground: Brown/Red: 12
TX: Yellow/Black: 10
RX: Orange/Black: 11
4 4
RX
OR
3 3
TX
2 2
Ground
1 1
Ignition
).
XKD2D65
OBDII Diagnostic Connector,
under Driver Dash
(connector side view)
9: Pink: (+) Ignition Input
