Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Manual transmission: Not compatible with vehicles equipped with a manual transmission.
Š
Factory hood pin: In vehicles not equipped with a Factory Hood Pin, must permanently ground the vehicles N.C. OEM Hood Pin
Š
input for successful operation. See Directechs for hood pin location.
Pit Stop: The vehicle pit stop/idle mode feature is not available in this firmware.
Š
T-Harness THFOD2 notes:
Š
•All T-Harness wires not listed in the diagram are not required for the installation.
•The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
•The optional Plug & Play T-Harness is sold separately
All connectors are displayed from the wire side (unless specified otherwise).
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Conditions and Limitations
IMPORTANT: In the event of a module power cycle or vehicle battery disconnection or replacement, the ignition must be cycled to
Š
activate the Lock/Unlock functions for proper functionality with aftermarket remote controls.
NOTE: This firmware has the same restrictions as an OEM remote starter. There may be a limit of only 1 or 2 remote starts before
Š
needing to key-start the vehicle to allow additional remote starts.
Š This installation enables the OEM remote starter and the remote start system will not work in the following conditions:
Š The ignition is on.
Š The alarm system is triggered.
Š The doors/hood are open.
Š The transmission is not in Park (P).
Š The vehicle battery voltage is too low.
Š The service engine light is on.
Note: Any stored DTC code errors will prevent vehicle from remote starting (no visual lights on dash).
RS Features: The following remote starter features can be configured via the information display:
Š
Š Climate control
Š Heated seats/steering wheel
Š Runtime (for best results, program the remote starter runtime to match the OEM setting)
Š Remote Starter enable/disable
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Optional parking lights: They will flash when locked/unlocked, and stay ON during remote start runtime. They are only required for
visual confirmation in the event of a remote start failure.
4
403.FORD12 2.07 2020 Ford Escape (Smart Key)
©2023 Directed. All rights reserved.
THFOD2
Refer to the Quick Reference Guide section for more details.
Keys required for 1 Keys required
programming for operation
