Functions compatible with the 2022 Ford Transit
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Door Lock Control
Door Unlock
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Fuel level/EV battery level
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Parking Lights Control
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
403.FORD12
v2.07
2022 Ford Transit
THFOD2 Compatible
(Sold Separately)
Advertisement
Table of Contents
Related Manuals for Directed DIRECTECHS DB3
Summary of Contents for Directed DIRECTECHS DB3
- Page 1 403.FORD12 v2.07 2022 Ford Transit THFOD2 Compatible (Sold Separately) Functions compatible with the 2022 Ford Transit *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer Factory Alarm Trigger Monitoring 3x LOCK START (Start control using OEM Remote) Fuel level/EV battery level 3x LOCK STOP (Stop control using OEM Remote) Ignition Status...
-
Page 2: Table Of Contents
Contents Introduction Pre-installation and application warnings Installation Wiring diagram with T-Harness (THFOD2) Wiring diagram Locating components in the vehicle Vehicle connections Module programming Key vehicles Push-to-Start (PTS) vehicles Module programming for convenience only (skip transponder) SmartStart Pro/Digital RF Kit/XL202 installation notes LED diagnostics and troubleshooting Parking light error codes Soft reset... -
Page 3: Introduction
• XL202 & Analog RF Kit Notes • This module can only be flashed and configured using DirectLink at www.directechs.com. • RSR mode is not compatible with vehicles equipped with a manual transmission. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 4: Pre-Installation And Application Warnings
[2] Optional parking lights: They will flash when locked/unlocked, and stay ON during remote start runtime. They are only required for visual confirmation in the event of a remote start failure. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 5: Installation
(-) Ground: Brown/Red (-) Parking Light Output: Yellow/Red (+) Parking Lights (R): White/Orange, pin 51 (Blue plug ‘E’ 3A Diodes at dash fuse box) (+) Parking Lights (L): Violet/Green, pin 25 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 6: Wiring Diagram
(+) 12V: Red, pin 22 (+) 12V Input: Brown/Red: 12 20 21 (+) 12V Input: Red: 13 Fuse 15A 6: White/Black: (-) Ground: Black: 14 (-) Hood Remote Start Safety Override Switch Hood Pin 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 7: Locating Components In The Vehicle
Locating components in the vehicle 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 8: Vehicle Connections
No Connection H2/8 Violet/Green No Connection No Connection H2/9 Violet/Brown No Connection No Connection H2/10 Yellow/Black No Connection No Connection H2/11 Orange/Black No Connection No Connection H2/12 Blue/Red No Connection No Connection 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... - Page 9 H4/1 Blue (Data) TX H4/2 Black (-) Ground H4/3 Green (Data) RX H4/4 (+) 12 Volt RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 No Connection H5/2 No Connection 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights...
-
Page 10: Module Programming
The LED will flash green then stay green for 3 seconds and then turn OFF. Turn the ignition OFF and remove the key from the ignition barrel. You have successfully completed the module programming sequence. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 11: Push-To-Start (Pts) Vehicles
The LED will flash green then stay solid green for 3 seconds and then turn OFF. Press the PTS button once (1) more to turn the ignition OFF. You have successfully completed the module programming sequence. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 12: Module Programming For Convenience Only (Skip Transponder)
Press & Release x5 Key IN START Turn ignition ON and wait until the LED turns OFF. Key OUT Turn ignition OFF. START You have successfully completed the module programming sequence. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 13: Smartstart Pro/Digital Rf Kit/Xl202 Installation Notes
Use the D2D Crossover (XOVER) cable that is provided with XL202 (not the one in the DB3 package) Follow the XL202 Programming Guide to pair the remote to the XL202. XOVER Cable XOVER Cable Note: The XL202 and antenna are optional and must be purchased separately. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 14: Led Diagnostics And Troubleshooting
Flashes red x 7 External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... - Page 15 Lock Start is selected from the web in the flashing process. Flashes red x 7 Feature error. An RSR feature file mismatch was detected. Please contact Technical Support. Flashes red x 9 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights...
-
Page 16: Parking Light Error Codes
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Solid Release 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 17: Limited One Year Consumer Warranty
This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... -
Page 18: Quick Reference Guide (Customer Copy)
Press the PTS button once. Depress the brake pedal, put the car in gear and drive Ready to drive off off. * Icon and remote appearance may differ depending on the model purchased. 403.FORD12 2.07 2022 Ford Transit ©2023 Directed. All rights... - Page 19 * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. SmartStart compatible This system is compatible with Directed SmartStart. For a complete list of supported features, please visit www.mysmartstart.com. What is SmartStart? Now you can remote start, lock and unlock your car just by pushing a button on your mobile device;...
