Vehicle connections

The connection information listed below is specific to the 2020 Ford Escape (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
8 403.FORD12 2.07 2020 Ford Escape (Smart Key)
©2023 Directed. All rights reserved.
Description
No Connection
No Connection
(Data) HS CAN 3 High
(Data) HS CAN 3 Low
(Data) HS CAN High 1
(Data) HS CAN Low 1
Relay N.O. - No Connection
Relay COM - No Connection
Relay N.C. - No Connection
Relay N.C. - No Connection
Relay COM - No Connection
Relay N.O. - No Connection
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) Trunk Release Output
No Connection
(-) W2W Only - Door Output
(-) W2W Only - Trunk Output
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
(+) Ignition Output
No Connection
No Connection
No Connection
No Connection
(-) W2W Only - Hood Output
Description
(-) W2W Only - Lock Input
Connects To
Wire Location
No Connection
No Connection
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 18
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 17
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 20
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 19
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 24
Gateway Module on OBD-Data Link Connector, black 24 pin plug, pin 14
Connects To
Wire Location
No Connection
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
No Connection
Remote Starter
Connects To
Wire Location
Remote Starter
(+/-) Wire Color
Data Green/Orange (HS2 CAN)
Data Gray/Blue (HS2 CAN)
Data Blue (HS1 CAN)
Data White (HS1 CAN)
+ Brown/Red (7.5A)
- Black/Blue
(+/-) Wire Color
(+/-) Wire Color
