Wiring diagram with T-Harness (THFOD2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
BCM
(Gray plug 'F' in passenger footwell)
2
1
11
12
25
24
37
38
51 52 53
50
63
64
(+) Parking Lights (LR):Violet/Green, pin 53
(+) Parking Lights (LF) & (RF): Blue/Gray, pin 52
(+) Parking Lights Output
(+) 12V Input
(+) Ignition Status Input
(-) Hood Input
(-) Ground
5 403.FORD12 2.07 2020 Ford Escape (Smart Key)
©2023 Directed. All rights reserved.
10
23
36
48 49
62
72
(+) Parking Lights (RR): White/Orange, pin 48
3 x 1A Diodes
(+) 12V
Hood Pin
Gateway Module
(Black connector Gateway Module
on OBDII connector)
(+) Ignition Status Output: Gray/Black: 7
).
Type 1
Type 2
4-pin
connectors
NOT USED
White/Black N.C.
Remote Start Safety
Override Switch
T-Harness THFOD2
(optional)
D2D
only
Do not
connect
