Push-to-Start (PTS) vehicles

For Convenience-Only programming, see next section.
Ensure vehicle is in a safe location and cannot move forward during programming. For
1
vehicles equipped with a manual transmission, make sure the gearshift is in the neutral
position.
The harnesses must be connected in this exact order:
1. Connect the 14-pin.
2. Connect the 12-pin.
2
3. Connect the 10-pin.
4. Connect the 4-pin D2D cable (if being used).
When the LED turns ON solid red, proceed with the next step.
Press on the Push-to-Start (PTS) button once (1) to turn the ignition ON.
3
The LED will flash green then stay solid green for 3 seconds and then turn OFF.
4
Press the PTS button once (1) more to turn the ignition OFF.
You have successfully completed the module programming sequence.
11
403.FORD12 2.07 2020 Ford Escape (Smart Key)
