Ithaca
8000 Color Graphics
®
Ithaca
8000 Coupon-Cut-Logo Feature
®
The Ithaca
8000 printer has a feature that will allow a coupon and or logo graphic to
printed as part of the existing auto cutter command.
To activate this feature, it must first be configured. Configuration consists of specifying
in what order the Coupon-Cut-Logo is processed and optionally, how much paper is to
be feed after the new cut operation.
Once configured, the Coupon and/or logo must be defined and loaded into the printer.
The ―Universal Graphics‖ feature should be used to define and load the graphic. The
Coupon is named ―Coupon‖, and the Logo is named ―Logo‖. They may be saved in any
resolution and of any size. They also need not be all graphics.
The existing application cut command will be replaced by the Coupon-Cut-Logo
operation. Configuration options are as follows:
Cut Command Logo:
Cut-Logo
Coupon-Cut
Logo-Cut
Cut-Coupon
Coupon-Cut-Logo
Logo-Cut-Coupon
Cut-Logo-Coupon
Cut-Coupon-Logo
Logo-Coupon-Cut
Coupon-Logo-Cut
Disabled
Cut Command Logo Feed: 0 to 80 mm.
Page 252
Ithaca
Perform Feed to cut, then cut, and then print the Logo.
Print the Coupon, Feed to Cut, and Cut.
Print the Logo, Feed to Cut, and Cut.
Perform Feed to cut, then cut, and then print the Coupon.
Print the Coupon, Feed to cut, Cut, ad then print the Logo.
Print the Logo, Feed to cut, Cut, ad then print the Coupon.
Perform the Feed to cut, Print the Logo and then the Coupon.
Perform the Feed to cut, Print the Coupon and then the Logo.
Print the Logo, then the Coupon, feed to cut and Cut.
Print the Coupon, then the Logo, feed to cut and Cut.
Perform the Normal cut.
Rev D
®
8000 Programmer's Guide
100-06908
