Page 1 A L L-N EW 2020 GL AD IATOR OWN ER’S MA N UA L...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................8 GETTING TO KNOW YOUR VEHICLE ...................11 GETTING TO KNOW YOUR INSTRUMENT PANEL ............109 SAFETY ............................135 STARTING AND OPERATING ....................199 IN CASE OF EMERGENCY ....................277 SERVICING AND MAINTENANCE ..................310 TECHNICAL SPECIFICATIONS .................... 356 MULTIMEDIA ..........................
Page 4 INTRODUCTION STEERING WHEEL..........41 SENTRY KEY............20 Customer Key Programming....... 21 Tilt/Telescoping Steering Column ....41 HOW TO USE THIS MANUAL ......... 9 Replacement Keys........21 Heated Steering Wheel — If Equipped ..41 Essential Information ........9 General Information ........21 MIRRORS...............42 Symbols ............
Page 5 GETTING TO KNOW YOUR CLIMATE CONTROLS ..........49 HOOD ..............88 Manual Climate Control Overview ....49 Opening The Hood ........88 INSTRUMENT PANEL Automatic Climate Controls Overview ..53 Closing The Hood......... 88 INSTRUMENT CLUSTER........109 Climate Control Functions......58 TAILGATE...............
Page 6 SAFETY Normal Starting .........200 STOP/START SYSTEM — AUTOMATIC Extreme Cold Weather (Below –22°F Or TRANSMISSION (IF EQUIPPED) ...... 221 SAFETY FEATURES ..........135 −30°C) ............202 Automatic Mode ........222 Anti-Lock Brake System (ABS) ....135 If Engine Fails To Start ......202 Possible Reasons The Engine Does Not Electronic Brake Control (EBC) System..136 After Starting..........203 Autostop .............223...
Page 7 Cleaning The ParkSense System....246 Recreational Towing — Four-Wheel Drive ADAPTIVE CRUISE CONTROL (ACC) — ParkSense System Usage Precautions ..246 Models............267 IF EQUIPPED............230 PARKSENSE FRONT AND REAR PARK DRIVING TIPS ............. 269 Adaptive Cruise Control (ACC) ASSIST — IF EQUIPPED........247 On-Road Driving Tips .........269 Operation............231 Off-Road Driving Tips.........269...
Page 8 TECHNICAL SPECIFICATIONS TOWING A DISABLED VEHICLE......307 Transfer Case ..........330 Manual Transmission — If Equipped ..330 Four–Wheel Drive Models......308 VEHICLE IDENTIFICATION NUMBER ....356 Automatic Transmission — If Equipped ...331 Without The Key Fob .........308 BRAKE SYSTEM ..........356 RAISING THE VEHICLE........332 Emergency Tow Hooks —...
Page 9 FOR YOUR VEHICLE .......... 460 AUX/USB/MP3 CONTROL ........446 UCONNECT SETTINGS ........364 Prepare For The Appointment ....460 Jeep Wireless Speaker - If Equipped..447 Prepare A List..........460 Customer Programmable Features — RADIO OPERATION AND MOBILE PHONES ..452 Be Reasonable With Requests ....460 Uconnect 3 Settings ........364...
Page 10: Introduction
INTRODUCTION Dear Customer, congratulations on selecting your new vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality. This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many passenger vehicles, both on-road and off-road, so take time to become familiar with your vehicle.
Page 11: How To Use This Manual
HOW TO USE THIS MANUAL Do not attempt sharp turns, abrupt maneuvers, or other unsafe driving actions that can cause loss of vehicle control. Failure to operate this SSENTIAL NFORMATION vehicle safely may result in a collision, rollover of the vehicle, and severe or fatal injury.
Page 12: Campers
CAMPERS VEHICLE MODIFICATIONS/ALTERATIONS This vehicle is NOT recommended for slide-in camper applications. WARNING! WARNINGS AND CAUTIONS Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in This Owner’s Manual contains WARNINGS against operating procedures serious injury or death.
Page 13: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE VEHICLE USER GUIDE — IF EQUIPPED the features while the vehicle is in motion, the Features/Benefits system will display: “Feature not available while Pre-installed on your Uconnect touchscreen  Access your Owner’s Information right through the vehicle is in motion”.
Page 14: Keys
GETTING TO KNOW YOUR VEHICLE KEYS NOTE: 1 — Mechanical Key Release Button The key fob may not be detected by the vehicle 2 — LED Indicator if it is located next to a mobile phone, laptop or 3 — Lock Button other electronic device;...
Page 15 GETTING TO KNOW YOUR VEHICLE To Unlock The Doors And Tailgate NOTE: NOTE: Pushing the lock button on the key fob while you Push and release the key fob unlock button The interior lights will turn off if you place the ...
Page 16 GETTING TO KNOW YOUR VEHICLE 1. Remove the back cover of the key fob by Request For Additional Key Fobs inserting a flat-blade screw driver into the NOTE: slot on the bottom of the fob. Apply light Only key fobs that are programmed to the pressure until the cover unsnaps being vehicle electronics can be used to start and careful not to damage the seal.
Page 17: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH NOTE: Le présent appareil est conforme aux CNR d`Innovation, Science and Economic When having the Sentry Key Immobilizer  -N-G — I Development applicables aux appareils radio EYLESS NTER GNITION System serviced, bring all vehicle keys with exempts de licence.
Page 18: Vehicle On Message
GETTING TO KNOW YOUR VEHICLE START CAUTION! The engine will start.  An unlocked vehicle is an invitation for thieves. Always remove key fob from the WARNING! vehicle and lock all doors when leaving the When exiting the vehicle, always remove vehicle unattended.
Page 19: Depleted Key Fob Battery
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! WARNING! (Continued) A low key fob battery condition may be indicated Before exiting a vehicle, always come to a by a message in the instrument cluster display, Do not leave children or animals inside ...
Page 20: Remote Starting System - If Equipped
GETTING TO KNOW YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED Battery at an acceptable charge level EMOTE TART  Panic button not pushed Push the Remote Start button on the key fob This system uses the key fob to start ...
Page 21: Remote Start Cancel Message
GETTING TO KNOW YOUR VEHICLE — I NOTE: EMOTE TART ANCEL ESSAGE EMOTE TART QUIPPED RIVE EHICLE If an engine fault is present or fuel level is  low, the vehicle will start and then shut down The following messages will display in the Before the end of the 15 minute cycle, push and in 10 seconds.
Page 22: General Information
GETTING TO KNOW YOUR VEHICLE SENTRY KEY 2. l'utilisateur de l'appareil doit accepter tout ENERAL NFORMATION brouillage radioélectrique subi, même si le The following regulatory statement applies to all The Sentry Key Immobilizer System prevents brouillage est susceptible d'en compro- Radio Frequency (RF) devices equipped in this unauthorized vehicle operation by disabling the mettre le fonctionnement.
Page 23: Customer Key Programming
GETTING TO KNOW YOUR VEHICLE If the vehicle security light turns on during EPLACEMENT ENERAL NFORMATION normal vehicle operation (vehicle running for The following regulatory statement applies to all NOTE: longer than ten seconds), it indicates that there Radio Frequency (RF) devices equipped in this Only key fobs that are programmed to the is a fault in the electronics.
Page 24: Vehicle Security Alarm - If Equipped
GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY ALARM — IF EQUIPPED Le présent appareil est conforme aux CNR Push the lock button on the exterior  d`Innovation, Science and Economic Passive Entry door handle with a valid key The Vehicle Security Alarm monitors the vehicle Development applicables aux appareils radio fob available in the same exterior zone.
Page 25: Rearming Of The System
GETTING TO KNOW YOUR VEHICLE NOTE: EARMING YSTEM The driver's door key cylinder cannot arm or If something triggers the alarm, and no action is  disarm the Vehicle Security Alarm. taken to disarm it, the Vehicle Security Alarm will turn the horn off after 29 seconds, When the Vehicle Security Alarm is armed, ...
Page 26: Power Door Locks - If Equipped
GETTING TO KNOW YOUR VEHICLE — I OWER OCKS QUIPPED WARNING! (Continued) WARNING! (Continued) The power door lock switch is located on each Never leave children alone in a vehicle, or When exiting the vehicle, always place the   front door panel.
Page 27: Keyless Enter-N-Go - Passive Entry
GETTING TO KNOW YOUR VEHICLE -N-G — P If wearing gloves on your hands, or if it has NOTE: EYLESS NTER ASSIVE  been raining/snowing on the Passive Entry If “1st Press Of Key Fob Unlock” is programmed, NTRY QUIPPED door handle, the unlock sensitivity can be all doors will unlock when you grab a hold of the The Passive Entry system is a feature that...
Page 28 GETTING TO KNOW YOUR VEHICLE Preventing Inadvertent Locking Of Passive Entry disabled using the Uconnect system, the key Key Fob In Vehicle (FOBIK-Safe) protection described in this section remains active/functional. To minimize the possibility of unintentionally locking a Passive Entry key fob inside your NOTE: vehicle, the Passive Entry system is equipped The vehicle will only unlock the doors during a...
Page 29: Equipped
GETTING TO KNOW YOUR VEHICLE The vehicle doors can also be locked by using This device complies with Part 15 of the FCC La operación de este equipo está sujeta a las the lock button located on the vehicle’s interior Rules and with Innovation, Science and siguientes dos condiciones: door panel.
Page 30: Child-Protection Door Lock System
GETTING TO KNOW YOUR VEHICLE NOTE: Once the Child-Protection Door Lock system is HILD ROTECTION engaged, it is impossible to open the doors from — R YSTEM OORS When the Child-Protection Door Lock system is  inside the vehicle. Before getting out of the engaged, the door can be opened only by using To provide a safer environment for small vehicle, be sure to check that there is no one...
Page 31 GETTING TO KNOW YOUR VEHICLE Outside rearview mirrors are NOTE: WARNING! mounted on the doors. If you choose The hinge pin nuts can be stowed in the All occupants must wear seat belts during to remove the doors, see an Fastener Bin located under the rear seat.
Page 32 GETTING TO KNOW YOUR VEHICLE 3. Remove the plastic wiring access door 4. Pull up on the red locking tab to unlock the 5. Push and hold down the black security tab under the instrument panel by sliding the wiring harness. under the wiring harness, and lift the plastic panel along the door frame toward harness lever into the open position.
Page 33: Rear Door Removal
GETTING TO KNOW YOUR VEHICLE 7. With the door in the open position, remove NOTE: WARNING! the check bolt from the door check The upper hinge has a longer pin, which can be attachment on the bodyside (using a used to assist in guiding the door into place All occupants must wear seat belts during ...
Page 34 GETTING TO KNOW YOUR VEHICLE To remove the rear doors, proceed 3. Slide the front seat(s) fully forward. 5. Unplug the wiring connector. as follows: 4. Pry open and remove the plastic wiring NOTE: 1. Roll down the glass window to access door from the bottom of the B-pillar.
Page 35: Seats
GETTING TO KNOW YOUR VEHICLE SEATS 6. With the door in the open position, remove To reinstall the door(s), perform the previous the check bolt from the door check steps in the reverse order. Seats are a part of the Occupant Restraint attachment on the bodyside (using a NOTE: System of the vehicle.
Page 36: Manual Front Seats
GETTING TO KNOW YOUR VEHICLE Manual Seat Height Adjustment ANUAL RONT EATS WARNING! The driver's seat height can be raised or Front Seat Adjustment Adjusting a seat while driving may be  lowered by using the ratcheting handle, located dangerous. Moving a seat while driving The seat can be adjusted forward or rearward on the outboard side of the seat.
Page 37: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE — I Front Seatback Recline Lumbar Support EATED EATS QUIPPED To recline the seat, pull on the recline strap and The Lumbar Support Control knob is located on The Heated Seat Control Buttons are located on lean forward or rearward, depending on the the outboard side of the front driver seat.
Page 38: 60/40 Split Folding Rear Seat
GETTING TO KNOW YOUR VEHICLE NOTE: the underseat storage bins (if equipped). Refer WARNING! (Continued) to “Rear Seat Stadium Position” in this section The engine must be running for the heated  for more information. Do not place anything on the seat or seat- ...
Page 39 GETTING TO KNOW YOUR VEHICLE Folding The Rear Seats To fold down the rear seat, pull the release strap located on the upper outboard side of the rear seat to release the seat. The head restraints are folded independently. Refer to “Head Restraints”...
Page 40: Rear Seat Stadium Position
GETTING TO KNOW YOUR VEHICLE TADIUM OSITION The rear seat bottoms can be folded upward into the Stadium Position to create more storage space on the vehicle’s floor, and to access the under seat storage bins (if equipped). To fold the seat bottom upward, proceed as follows: Stadium Position Rear Seat Armrest...
Page 41: Head Restraints
GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS on the head restraint. The release button does WARNING! not need to be pushed to adjust the head Head restraints are designed to reduce the risk restraint. A loose head restraint thrown forward in a ...
Page 42: Rear Head Restraints
GETTING TO KNOW YOUR VEHICLE To raise the center head restraint, lift up on the ESTRAINTS WARNING! head restraint. To lower the center head The rear seat is equipped with nonadjustable, restraint, push the adjustment button, located Do not drive the vehicle without the rear ...
Page 43: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL To lock the steering column in position, pull the The heated steering wheel control button is Tilt/Telescoping lever upward until fully located on the center of the instrument panel ELESCOPING TEERING OLUMN engaged. below the touchscreen and within the climate or controls screen of the touchscreen.
Page 44: Mirrors
GETTING TO KNOW YOUR VEHICLE Headlight glare from other vehicles can be NOTE: WARNING! reduced by moving the small control under the The Automatic Dimming feature is disabled Persons who are unable to feel pain to the mirror to the night position (toward the rear of when the vehicle is in REVERSE to improve the ...
Page 45: If Equipped
GETTING TO KNOW YOUR VEHICLE The Power Mirror controls consist of mirror UTSIDE IRRORS WARNING! select buttons and a four-way mirror control The Outside Mirrors are located on the front Vehicles and other objects seen in the switch. To adjust a mirror, push either the L driver and passenger side doors, and are passenger side convex mirror will look smaller (left) or R (right) button to select the mirror that...
Page 46: Illuminated Vanity Mirrors
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Rotate the headlight switch clockwise to the first LLUMINATED ANITY IRRORS detent for parking light and instrument panel The Illuminated Vanity Mirrors are located on light operation. Rotate the headlight switch to EADLIGHT WITCH the sun visors.
Page 47: High/Low Beam Switch
GETTING TO KNOW YOUR VEHICLE NOTE: WITCH LASH The engine must be running before the head- The High/Low Beam Switch is located within the The Flash-To-Pass feature will illuminate the lights will come on in the automatic mode. Multifunction Lever on the left side of the high beam headlights temporarily to signal —...
Page 48: Turn Signals
GETTING TO KNOW YOUR VEHICLE — I — I IGNALS HANGE SSIST QUIPPED IGHTS QUIPPED Move the multifunction lever up or down and The Lane Change Assist feature will flash the The bed lights will illuminate the bed and cargo the arrows on each side of the instrument turn signal (left or right) three times to indicate area.
Page 49: Interior Lights
GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS IMMER ONTROLS The dimmer controls are part of the headlight OURTESY IGHTS switch and are located on the left side of the The Interior Courtesy Lights will turn on when instrument panel. the front doors are opened, by rotating the instrument panel dimmer control (dial on the right) on the headlight switch fully upward while the doors are closed, or if equipped, when the...
Page 50: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Intermittent Wiper System INDSHIELD IPER PERATION Use the intermittent wiper when weather Rotate the end of the lever upward to the first The windshield wiper/washer control lever is conditions make a single wiping cycle, with a detent past the intermittent settings for located on the right side of the steering column;...
Page 51: Climate Controls
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Windshield Washers Mist Feature To use the washer, pull the lever toward you and Push upward on the wiper lever to activate a The Climate Control system allows you to hold until desired spray is reached. If the lever single wipe to clear off-road mist or spray from regulate the temperature, air flow, and direction is pulled while in the delay range, the wiper will...
Page 52 GETTING TO KNOW YOUR VEHICLE Manual Climate Control Descriptions Icon Description A/C Button — If Equipped Push the A/C button to engage the Air Conditioning (A/C). The A/C indicator illuminates when A/C is on. MAX A/C Setting — If Equipped Set the temperature control knob to the MAX A/C setting to change the current setting to the coldest output of air.
Page 53 GETTING TO KNOW YOUR VEHICLE Icon Description Temperature Control Temperature Control regulates the temperature of the air forced through the climate system. The temperature increases as you turn the temperature control knob clockwise. The temperature decreases as you turn the temperature control knob Heater Only counterclockwise.
Page 54 GETTING TO KNOW YOUR VEHICLE Icon Description Bi-Level Mode Air comes from the instrument panel outlets and floor outlets. A slight amount of air is directed through the defrost and Bi-Level Mode side window demister outlets. NOTE: Bi-Level mode is designed under comfort conditions to provide cooler air out of the panel outlets and warmer air from the floor outlets.
Page 55: Automatic Climate Controls Overview
GETTING TO KNOW YOUR VEHICLE UTOMATIC LIMATE ONTROLS VERVIEW Uconnect 4 With 7–inch Display Automatic Uconnect 4C/4C NAV With 8.4–inch Display Automatic Climate Controls Climate Controls...
Page 56 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Descriptions Icon Description MAX A/C Button Press and release the MAX A/C button on the touchscreen to change the current setting to the coldest output of air. The MAX A/C indicator illuminates when MAX A/C is on. Pressing the button again will cause the MAX A/C operation to exit. NOTE: The MAX A/C button is only available on the touchscreen.
Page 57 GETTING TO KNOW YOUR VEHICLE Icon Description Faceplate AUTO Button AUTO Button Set your desired temperature and press AUTO. AUTO will achieve and maintain your desired temperature by automatically adjusting the blower speed and air distribution. AUTO mode is highly recommended for efficiency. You can press and release this button on the touchscreen, or push the button on the faceplate, to turn AUTO on.
Page 58 GETTING TO KNOW YOUR VEHICLE Icon Description Driver And Passenger Temperature Up And Down Buttons Provides the driver and passenger with independent temperature control. Push the red button on the faceplate or touchscreen or press and slide the temperature bar towards the red arrow button on the touchscreen for warmer temperature settings.
Page 59 GETTING TO KNOW YOUR VEHICLE Icon Description Mode Control Select one of the Mode buttons on the touchscreen or press the Mode button on the faceplate to adjust the airflow distribution. The airflow distribution can be adjusted so air comes from the instrument panel outlets, floor outlets, defrost outlets, and demist outlets.
Page 60: Climate Control Functions
GETTING TO KNOW YOUR VEHICLE Icon Description Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.
Page 61: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE MAX A/C NOTE: UTOMATIC EMPERATURE ONTROL (ATC) — I MAX A/C sets the control for maximum cooling QUIPPED It is not necessary to move the temperature  performance. settings for cold or hot vehicles. The system Automatic Operation automatically adjusts the temperature, Press and release to toggle between MAX A/C...
Page 62: Operating Tips
GETTING TO KNOW YOUR VEHICLE Vacation/Storage PERATING CAUTION! Before you store your vehicle, or keep it out of NOTE: Failure to follow these cautions can cause service (i.e., vacation) for two weeks or more, Refer to the chart at the end of this section for damage to the heating elements: run the air conditioning system at idle for about suggested control settings for various weather...
Page 63: Power Windows - If Equipped
GETTING TO KNOW YOUR VEHICLE POWER WINDOWS — IF EQUIPPED Cabin Air Filter CONTROL WEATHER The Climate Control System filters out dust and SETTINGS The power windows feature allows for pollen from the air. Contact an authorized movement of the windows with the push of a Operate in dealer to service your cabin air filter, and to Cool Sunny...
Page 64: Auto-Down Feature
GETTING TO KNOW YOUR VEHICLE — I EATURE ANUAL LIDING INDOW QUIPPED The driver door power window switch and the front passenger door power window switch have To open the rear sliding window, push the an Auto-Down feature. Push the window switch release button inward while sliding the window down, past the detent, and release and the into the open position.
Page 65: Gladiator Tops
GETTING TO KNOW YOUR VEHICLE GLADIATOR TOPS OWERING Scan this QR code for your digital ROVIDED OOLS experience. For your convenience, a tool kit is provided with your vehicle located in the center console. This kit includes the necessary tools required for the WARNING! operations described in the following sections.
Page 66 GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! CAUTION! (Continued) The soft top is not designed to carry any Do not run a fabric top through an auto- Failure to follow these cautions may cause  matic car wash. Window scratches and wax additional loads such as roof racks, spare tires, interior water damage, stains, or mildew on building, hunting or camping supplies, and/or...
Page 67 GETTING TO KNOW YOUR VEHICLE Side View Top And Components 1 — #1 Bow 6 — Rear Window Vertical Retainer 2 — #2 Bow 7 — Quarter Panel Cover Assembly 3 — #3 Bow 8 — Quarter Panel Vertical Retainer 4 —...
Page 68 GETTING TO KNOW YOUR VEHICLE Rear Window View And Components 1 — Top Retainer 4 — Pull Tabs 2 — Right Vertical Retainer 5 — Lower Center Retainer 3 — Lower Retainers 6 — Left Vertical Retainer...
Page 69 GETTING TO KNOW YOUR VEHICLE Lowering The Soft Top Into The Sunrider® 3. From both the left and right sides, lift up on 5. Secure the top in this position by using the Position: the #1 B ow of the soft top to begin the two hook-and-loop fasteners provided in the operation.
Page 70 GETTING TO KNOW YOUR VEHICLE Removing The Rear Window And Quarter Panel Cover Assemblies NOTE: Both quarter panel cover assemblies and the rear window must ALL be removed together, or installed together. 1. Start by removing the rear window first. Use the two straps located on the bottom Step One Step Two...
Page 71 GETTING TO KNOW YOUR VEHICLE 4. With two hands, grasp the front of the Soft Top Rear Window Storage Bag — If quarter panel cover assembly and pull Equipped outward to disengage it from its retainer on To safely store the soft top rear window, the door frame.
Page 72 GETTING TO KNOW YOUR VEHICLE 2. Fold the divider upward, covering the rear NOTE: 4. Close the storage bag and store in a safe window. The quarter panel cover assemblies are marked location. “1” and “2” on the inside of the panel assembly. Step Two Step Four Step Three...
Page 73: Raising The Soft Top
GETTING TO KNOW YOUR VEHICLE AISING Scan this QR code for your digital experience. 1. From the Sunrider® Position, remove straps if previously secured. Step Two Step Three 4. Pull the handle back upward while squeezing the hook, locking the latch into place.
Page 74 GETTING TO KNOW YOUR VEHICLE Installing The Rear Window And Quarter 3. Secure the hook-and-loop fastener at the CAUTION! upper front corner of each quarter panel Panel Cover Assemblies Failure to follow all quarter panel cover cover assembly by pressing firmly. NOTE: assembly and rear window install steps could Both quarter panel cover assemblies and the...
Page 75: Removing The Soft Top
GETTING TO KNOW YOUR VEHICLE 5. Engage the retainer along the bottom of the 8. Engage the rear window retainers in the rear window beginning on the left side of the lower right and left corners. vehicle and working toward the center. Then, move to the right side of the vehicle CAUTION! and continue from the center, working to...
Page 76: Installing The Soft Top
GETTING TO KNOW YOUR VEHICLE 2. Using the provided #T50 Torx head driver 5. Using the provided #T50 Torx head driver NSTALLING and ratchet, unscrew the two Torx head and ratchet, unscrew the six Torx head NOTE: fasteners on the inside of each top fasteners on both rear corners and the back If installing the soft top immediately after mechanism.
Page 77 GETTING TO KNOW YOUR VEHICLE 5. Using the provided #T50 Torx head driver CAUTION! CAUTION! and ratchet, install and tighten the Torx Failure to follow the next steps could result in fasteners by turning them clockwise. Do not overtighten Torx fasteners. Damage to Secure them until they are snug, being the retainers will occur.
Page 78: Hard Top Front Panel(S) Removal
GETTING TO KNOW YOUR VEHICLE CAUTION! CAUTION! (Continued) Do not overtighten Torx fasteners. You can Failure to follow these cautions may cause strip the fasteners if they are overtightened. interior water damage, stains or mildew: It is recommended that the top be free of ...
Page 79 GETTING TO KNOW YOUR VEHICLE Hard Top Components 1 — Right Side Panel 2 — Left Side Panel 3 — Hard Top...
Page 80 GETTING TO KNOW YOUR VEHICLE NOTE: 3. Unlatch the left side header panel latch Hard Top Panel(s) Storage Bag — If The left side panel must be removed before located at the top of the windshield. Equipped removing the right side panel. The Freedom Top panels storage bag allows you to store your hard top panels.
Page 81: Hard Top Front Panel(S) Installation
GETTING TO KNOW YOUR VEHICLE 3. Insert the right side Freedom Top panel into 3. Using the provided #50 Torx head driver RONT ANEL the bag with the latches facing downward. and ratchet, remove the two Torx head NSTALLATION screws that secure the hard top at the NOTE: 1.
Page 82 GETTING TO KNOW YOUR VEHICLE 4. If equipped, remove the lower interior soft 5. Remove the Torx head fasteners that 6. Locate the wire harness on the left rear trim panel (attached by the hook-and-loop secure the hard top to the vehicle: two along inside corner of the vehicle.
Page 83 GETTING TO KNOW YOUR VEHICLE 7. To release the wire harness, pull back on CAUTION! the red latch (1), then push down on the black button (2) while pulling the harness The removal of the Freedom Top requires four out. adults located on each corner.
Page 84: Installing The Hard Top
GETTING TO KNOW YOUR VEHICLE DOOR FRAME — IF EQUIPPED WITH A SOFT NOTE: CAUTION! (Continued) Inspect the hard top seals for damage and  The hard top is not designed to carry any  replace if necessary. additional loads, such as after-market roof WARNING! racks, spare tires, building materials, Install the hard top using the same steps for...
Page 85: Door Frame Removal
GETTING TO KNOW YOUR VEHICLE CAUTION! (Continued) Careless handling and storage of the  removable door frame(s) may damage the seals, causing water to leak into the vehicle's interior. The door frame(s) must be positioned prop-  erly to ensure sealing. Improper installation can cause water to leak into the vehicle's Step One Step Two...
Page 86: Door Frame Installation
GETTING TO KNOW YOUR VEHICLE RAME NSTALLATION Target Torque Specification Maximum Minimum 1. Install the front door frame first. For Torx Fasteners 2. Ensure the windshield is in the “up” position. Carefully place the front door 8.8 ft-lbs 11.0 ft-lbs 3.6 ft-lbs frame in the rubber seal at the top of the (12 N·...
Page 87: Folding Windshield
GETTING TO KNOW YOUR VEHICLE FOLDING WINDSHIELD OWERING INDSHIELD WARNING! The fold-down windshield on your vehicle is a 1. Before completing the steps below: Carefully follow these warnings to help structural element that can provide protection protect against personal injury: If your vehicle is equipped with a soft top, ...
Page 88 GETTING TO KNOW YOUR VEHICLE 2. Manually remove the protective caps over 5. Using the provided #T40 Torx head driver, the windshield wiper hex bolts. remove the four Torx head fasteners located along the interior of the windshield (two on each side of the header trim). Step Six 1 —...
Page 89: Raising The Windshield
GETTING TO KNOW YOUR VEHICLE Adaptive Cruise Control (ACC)/Forward NOTE: Be sure to remove the cover before returning Collision Warning (FCW) Sensor Protective the windshield to the normal position. Store the Cover — If Equipped cover in the cargo area. Your vehicle may be equipped with a protective cover that is to be used whenever the Cleaning Instructions...
Page 90: Hood
GETTING TO KNOW YOUR VEHICLE HOOD 5. Reinstall the protective caps over the wiper LOSING arm hex bolts and push gently until they To close the hood, remove the support rod from snap into place. PENING the radiator crossmember, and install into the Release both the hood latches.
Page 91: Tailgate
GETTING TO KNOW YOUR VEHICLE TAILGATE To use the mid position, open the tailgate and Ensure the tailgate strap is properly seated lower it to near mid position. behind the circular retainer against the sides of PENING the sheet metal. Tailgate In Mid Position Correctly Seated Tailgate Strap Tailgate Release Handle...
Page 92: Closing
GETTING TO KNOW YOUR VEHICLE When hauling cargo using the mid position NOTE:  LOSING and the tailgate, you must support the load at Failure to support the load at these two forward To close the tailgate, lift upward until both sides two forward locations: locations could result in damage.
Page 93: Garage Door Opener (Homelink®) - If
GETTING TO KNOW YOUR VEHICLE GARAGE DOOR OPENER (HOMELINK®) — IF To operate HomeLink®, push and release any To erase the channels, place the ignition in the of the programmed HomeLink® buttons. These ON/RUN position, and push and hold the two EQUIPPED buttons will activate the devices they are outside HomeLink®...
Page 94 GETTING TO KNOW YOUR VEHICLE Programming A Rolling Code 1. Place the ignition in the ON/RUN position. NOTE: You have 30 seconds in which to initiate the Programming garage door openers that were 2. Place the hand-held transmitter 1 to next step after the LEARN button has been manufactured after 1995 can be identified by 3 inches (3 to 8 cm) away from the...
Page 95: Canadian/Gate Operator Programming
GETTING TO KNOW YOUR VEHICLE Reprogramming A Single HomeLink® Button 3. Press and hold the HomeLink® button you Reprogramming A Single HomeLink® Button (Rolling Code) want to program while you press and hold (Non-Rolling Code) the hand-held transmitter button. To reprogram a channel that has been To reprogram a channel that has been previously trained, follow these steps: previously trained, follow these steps:...
Page 96: Using Homelink
GETTING TO KNOW YOUR VEHICLE Canadian radio frequency laws require 4. Watch for the HomeLink® indicator to Reprogramming A Single HomeLink® Button transmitter signals to time-out (or quit) after change flash rates. When it changes, it is (Canadian/Gate Operator) several seconds of transmission – which may programmed.
Page 97: Security
GETTING TO KNOW YOUR VEHICLE Push the LEARN button on the garage door ECURITY  WARNING! (Continued) opener to complete the training for a rolling It is advised to erase all channels before you sell code. Your motorized door or gate will open and ...
Page 98: General Information
GETTING TO KNOW YOUR VEHICLE La operación de este equipo está sujeta a las ENERAL NFORMATION siguientes dos condiciones: The following regulatory statement applies to all 1. es posible que este equipo o dispositivo no Radio Frequency (RF) devices equipped in this cause interferencia perjudicial y vehicle: This device complies with Part 15 of the FCC...
Page 99 GETTING TO KNOW YOUR VEHICLE To access the lower storage compartment, lift Non-Locking Storage Wall Locking Storage Bin the bottom latch. Non-Locking Storage Wall Under Seat Locking Storage Bin Location Console Storage Latches The Non-Locking Storage Wall can be used for If equipped, the Locking Storage Bin is located 1 —...
Page 100 GETTING TO KNOW YOUR VEHICLE The Locking Storage Bin can be removed by Your Locking Storage bin also has a front Rear Wall Storage Bin unfastening the four bolts that attach the bin to handle that makes it easier to carry and pull out the vehicle floor using the provided #40 Torx from the floor of the vehicle when the four bolts head driver and ratchet.
Page 101: Electrical Power Outlets
GETTING TO KNOW YOUR VEHICLE Rear Wall Netting To remove the Fastener Bin: LECTRICAL OWER UTLETS The rear wall netting can be accessed the same 1. Remove the lid and foam inserts from the There is a 12 V (13 A) auxiliary power outlet that way as the rear wall storage bin.
Page 102: Power Inverters - If Equipped
GETTING TO KNOW YOUR VEHICLE — I OWER NVERTERS QUIPPED CAUTION! CAUTION! There is a 115 V (400 W) maximum inverter Many accessories that can be plugged in Do not exceed the maximum power of   outlet located on the back of the center console draw power from the vehicle's battery, even 160 W (13 A) at 12 Volts.
Page 103 GETTING TO KNOW YOUR VEHICLE There may also be a second 115 V (400 W) NOTE: maximum exterior power inverter located on the The Power Inverter will only turn on if the igni-  rear right side of the truck bed near the tailgate. tion is in the ACC or ON/RUN position.
Page 104: Auxiliary Switches - If Equipped
GETTING TO KNOW YOUR VEHICLE — I NOTE: UXILIARY WITCHES QUIPPED Holding last state conditions are met when Four auxiliary switches are located in the lower switch type is set to latching and power source switch bank of the instrument panel and can be is set to ignition.
Page 105 GETTING TO KNOW YOUR VEHICLE Wire Color Chart Circuit Function Fuse Wire Color Locations Interior (passenger side under instrument panel) & Aux Switch 1 F93 – 40 Amp Beige/Pink Underhood (right side near battery) Interior (passenger side under instrument panel) & Aux Switch 2 F92 –...
Page 106: Bed Rail Tie Down System - If Equipped
GETTING TO KNOW YOUR VEHICLE BED RAIL TIE DOWN SYSTEM — IF To remove the utility rail cleats from the side utility rails, slide the cleat to the rectangular EQUIPPED cutout located at the end of the rail toward the front of the vehicle.
Page 107: Tonneau Cover Installation
GETTING TO KNOW YOUR VEHICLE 4. Release the stowage straps used to secure 6. Position both Tonneau Cover latches over ONNEAU OVER NSTALLATION the Tonneau Cover in the rolled up position. the locking mechanisms (one on each side To install the Tonneau Cover, proceed as of the truck bed), making sure the plastic follows: retainer is correctly seated in the forward...
Page 108: Tonneau Cover Removal
GETTING TO KNOW YOUR VEHICLE 7. Once the rear Tonneau Cover bar is ONNEAU OVER EMOVAL positioned over the locking mechanism, To remove the Tonneau Cover, proceed as grasp the back of the Tonneau Cover and follows: push downward on the center to engage the locking mechanisms.
Page 109 GETTING TO KNOW YOUR VEHICLE 3. Pull one of the red release straps to release 5. Using the stowage straps, secure the 6. Using a #T50 Torx head driver, remove the the Tonneau Cover latch. Tonneau Cover in the rolled up position. two fasteners securing the Tonneau Cover to the front of the truck bed.
Page 110: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED WARNING! CAUTION! (Continued) Cargo must be securely tied down before Travel at reduced speeds and turn corners NOTE:  driving your vehicle. Improperly secured loads carefully when carrying large or heavy loads Roof rack applications are for Hard Top models can fly off the vehicle, particularly at high on the roof rack.
Page 111: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 112 GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster...
Page 113: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 3. Instrument Cluster Display NSTRUMENT LUSTER ESCRIPTIONS WARNING! The instrument cluster display features a  1. Tachometer A hot engine cooling system is dangerous. driver interactive display. Refer to “Instru- Indicates the engine speed in revolutions You or others could be badly burned by steam ...
Page 114: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY The system allows the driver to select information by pushing the following buttons Your vehicle may be equipped with an mounted on the steering wheel: instrument cluster display, which offers useful information to the driver.
Page 115: Oil Life Reset - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Up Arrow Button: The Main Menu items consists of the following: which means the engine oil change interval may  fluctuate, dependent upon your personal Speedometer Push and release the up arrow  driving style. button to scroll upward through the Vehicle Info ...
Page 116: Off Road + Display - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Secondary Method For Oil Change Reset 4L: 4WD Low Off Road+ Active  NSTRUMENT LUSTER ISPLAY Procedure ELECTABLE TEMS Adaptive Cruise Control (ACC) and Speed 1. Without pushing the brake pedal, place the Control are not available when using Off Road+. The instrument cluster display can be used to If either option is selected, a dedicated ignition in the ON/RUN position (do not...
Page 117 GETTING TO KNOW YOUR INSTRUMENT PANEL Speedometer Off Road — If Equipped NOTE: When vehicle speed becomes too high to Push and release the up or down arrow button Push and release the up or down arrow button display the pitch and roll, “- -” will display in until the speedometer menu icon is displayed in until the Off Road menu icon is displayed in the place of the numbers, and the graphic will be...
Page 118 GETTING TO KNOW YOUR INSTRUMENT PANEL Adaptive Cruise Control Off For further information, refer to “Adaptive Average – The display shows the average fuel  economy (MPG, L/100km, or km/L) since the Cruise Control (ACC) — If Equipped” in “Starting When ACC is deactivated, the display will read And Operating.”...
Page 119 GETTING TO KNOW YOUR INSTRUMENT PANEL Stop/Start — If Equipped Stored Messages Screen Setup Driver Selectable Items Push and release the up or down arrow button Push and release the up or down arrow button Upper Left until the Stop/Start icon/title is highlighted in until the Messages Menu item is highlighted.
Page 120: Battery Saver On, Battery Saver Mode Message, And Electrical Load Reduction Actions (If Equipped)
GETTING TO KNOW YOUR INSTRUMENT PANEL Trip A Distance Favorite Menus Odometer  Speedometer Show (default) Trip B Distance    Vehicle Info Hide Audio    Off Road — If Equipped (show/hide) Defaults Menu Title (default setting) ...
Page 121 GETTING TO KNOW YOUR INSTRUMENT PANEL Load reduction is only active when the engine is The electrical loads that may be switched off (if Installing options like additional lights,  running. It will display a message if there is a equipped), and vehicle functions which can be upfitter electrical accessories, audio systems, alarms and similar devices.
Page 122: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL What to do when an electrical load reduction The vehicle should have service performed if  ARNING IGHTS the message is still present during consecu- action message is present (“Battery Saver On” Air Bag Warning Light or “Battery Saver Mode”) tive trips and the evaluation of the vehicle and driving pattern did not help to identify the...
Page 123 GETTING TO KNOW YOUR INSTRUMENT PANEL If the light remains on when the parking brake NOTE: Operation of the Brake Warning Light can be has been disengaged, and the fluid level is at The light may flash momentarily during sharp checked by turning the ignition switch from the the full mark on the master cylinder reservoir, it cornering maneuvers, which change fluid level...
Page 124 GETTING TO KNOW YOUR INSTRUMENT PANEL Door Open Warning Light Electronic Throttle Control (ETC) Warning ACC/ON/RUN position and remain on briefly as a bulb check. If the light does not come on Light This indicator will illuminate when a during starting, have the system checked by an door is ajar/open and not fully closed.
Page 125 GETTING TO KNOW YOUR INSTRUMENT PANEL Hood Open Warning Light Oil Temperature Warning Light Rear Seat Belt Reminder Warning Light — If Equipped This indicator will illuminate when the This warning light will illuminate to hood is ajar/open and not fully indicate the engine oil temperature is This light indicates when a rear seat closed.
Page 126: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Transmission Temperature Warning Light Vehicle Security Warning Light — If ELLOW ARNING IGHTS — If Equipped Equipped Anti-Lock Brake System (ABS) Warning This warning light will illuminate to This light will flash at a fast rate for Light warn of a high transmission fluid approximately 15 seconds when the...
Page 127 GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Active The ESC system will make buzzing or clicking Low Fuel Warning Light  sounds when it is active. This is normal; the Warning Light — If Equipped When the fuel level reaches sounds will stop when ESC becomes inactive.
Page 128 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Check/Malfunction Indicator Service 4WD Warning Light — If Equipped WARNING! Warning Light (MIL) This warning light will illuminate to A malfunctioning catalytic converter, as signal a fault with the 4WD system. If The Engine Check/Malfunction referenced above, can reach higher the light stays on or comes on during Indicator Light (MIL) is a part of an...
Page 129 GETTING TO KNOW YOUR INSTRUMENT PANEL Speed Control Fault Warning Light Should one or more tires be in the condition As an added safety feature, your vehicle has mentioned above, the display will show the been equipped with a Tire Pressure Monitoring This warning light will illuminate to indications corresponding to each tire.
Page 130: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a 4WD Low Indicator Light — If Equipped CAUTION! TPMS malfunction indicator to indicate when This light alerts the driver that the the system is not operating properly. The TPMS The TPMS has been optimized for the original vehicle is in the four-wheel drive LOW malfunction indicator is combined with the low...
Page 131: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Forward Collision Warning OFF Indicator Rear Axle Lock Indicator Light — If Off Road+ Indicator Light — If Equipped Light — If Equipped Equipped This indicator light will illuminate when Off Road+ has been activated. This indicator light illuminates to This light indicates when the rear axle indicate that Forward Collision...
Page 132 GETTING TO KNOW YOUR INSTRUMENT PANEL Adaptive Cruise Control (ACC) Set With Front Fog Indicator Light — If Equipped Turn Signal Indicator Lights Target Light — If Equipped This indicator light will illuminate When the left or right turn signal is when the front fog lights are on.
Page 133: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Rear Seat Belt Fastened Indicator Light — Adaptive Cruise Control (ACC) Ready Light Two Wheel Drive High Indicator Light — If If Equipped With A Premium Instrument — If Equipped With a Base Cluster Equipped With a Premium Cluster Cluster This light will turn on when the vehicle...
Page 134: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Rear Seat Belt Reminder Indicator Light — Refer to “Occupant Restraint Systems” in Cruise Control Ready Indicator Light — If “Safety” for further information. If Equipped With A Base Instrument Equipped With Base Instrument Cluster Cluster This light will turn on when the speed Cruise Control Ready Indicator Light...
Page 135: Onboard Diagnostic System - Obd Ii
GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II WARNING! CAUTION! Your vehicle is equipped with a sophisticated ONLY an authorized service technician Prolonged driving with the MIL on could   Onboard Diagnostic system called OBD II. This should connect equipment to the OBD II cause further damage to the emission system monitors the performance of the...
Page 136: Emissions Inspection And Maintenance Programs
GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND 1. Cycle the ignition switch to the ON position, If your OBD II system is not ready, you should but do not crank or start the engine. see an authorized dealer or repair facility. If your MAINTENANCE PROGRAMS vehicle was recently serviced or had a battery NOTE:...
Page 137: Safety
SAFETY SAFETY FEATURES The clicking sound of solenoid valves  WARNING! (Continued) Brake pedal pulsations  (ABS) RAKE YSTEM The ABS cannot prevent the natural laws of  physics from acting on the vehicle, nor can A slight drop of the brake pedal at the end of ...
Page 138: Electronic Brake Control (Ebc) System
SAFETY (EBC) Anti-Lock Brake Warning Light The BAS complements the Anti-Lock Brake LECTRONIC RAKE ONTROL System (ABS) by applying the brakes very The yellow “Anti-Lock Brake Warning Light” will YSTEM quickly, creating the most efficient braking turn on when the ignition is placed in the ON/ Your vehicle is equipped with an advanced assistance possible.
Page 139 SAFETY Brake System Warning Light Electronic Roll Mitigation (ERM) WARNING! The red “Brake System Warning Light” will turn The Electronic Roll Mitigation (ERM) system Many factors, such as vehicle loading, road on when the ignition is placed in the ON/RUN anticipates the potential for wheel lift by conditions and driving conditions, influence mode, and may stay on for as long as four...
Page 140 SAFETY ESC uses sensors in the vehicle to determine WARNING! WARNING! (Continued) the vehicle path intended by the driver and compares it to the actual path of the vehicle. Electronic Stability Control (ESC) cannot Vehicle modifications, or failure to properly ...
Page 141 SAFETY ESC Operating Modes To enter the “Partial Off” mode, momentarily Full Off — If Equipped push the “ESC OFF” switch and the “ESC OFF This mode is intended for off-highway or NOTE: Indicator Light” will illuminate. To turn the ESC off-road use only and should not be used on any Depending upon model and mode of operation, on again, momentarily push the “ESC OFF”...
Page 142 SAFETY If equipped with Off Road+ and if Off Road+ is ESC Activation/Malfunction Indicator Light is active. If the “ESC Activation/Malfunction active when "Full Off" mode is enabled by the Indicator Light” begins to flash during And ESC OFF Indicator Light driver, ESC will not switch to "Partial Off"...
Page 143 SAFETY Hill Start Assist (HSA) The gear selection must match vehicle uphill Disabling And Enabling HSA  direction (i.e., vehicle facing uphill is in The Hill Start Assist (HSA) system is designed to This feature can be turned on or turned off. To forward gear;...
Page 144 SAFETY The Electronic Brake Control System will Enabling SSC WARNING! (Continued) prepare the brake system for a panic stop. SSC is enabled by pushing the SSC switch, but HSA is not a parking brake. Always apply  the following conditions must also be met to Selec-Speed Control (SSC) —...
Page 145 SAFETY The set speed for SSC is selectable by the NOTE: Disabling SSC driver, and can be adjusted by using the gear SSC will deactivate and be disabled if any of the During SSC, the +/- gear selector input is ...
Page 146 SAFETY The cluster icon and switch lamp will flash for Trailer Sway Control (TSC)  WARNING! several seconds then extinguish when the Trailer Sway Control (TSC) uses sensors in the driver pushes the SSC switch but enabled If TSC activates while driving, slow the vehicle vehicle to recognize an excessively swaying conditions are not met.
Page 147: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS The BSM detection zone covers approximately The Blind Spot Monitoring (BSM) system may  one lane width on both sides of the vehicle 12 ft experience drop outs (blinking on and off) of (BSM) — I the side mirror Warning Indicator lamps LIND ONITORING...
Page 148 SAFETY The BSM system notifies the driver of objects in Entering From The Side Entering From The Rear the detection zones by illuminating the BSM Vehicles that move into your adjacent lanes Vehicles that come up from behind your vehicle warning light located in the outside mirrors in from either side of the vehicle.
Page 149 SAFETY Overtaking Traffic If you pass another vehicle slowly with a relative speed less than 15 mph (24 km/h) and the vehicle remains in the blind spot for approximately 1.5 seconds, the warning light will be illuminated. If the difference in speed between the two vehicles is greater than 15 mph (24 km/h), the warning light will not illuminate.
Page 150 SAFETY Rear Cross Path (RCP) NOTE: Modes Of Operation In a parking lot situation, oncoming vehicles can The Rear Cross Path (RCP) feature is intended Three selectable modes of operation are be obscured by vehicles parked on either side. to aid the driver when backing out of parking available in the Uconnect system.
Page 151 SAFETY Blind Spot Alert Lights/Chime NOTE: 1. l'appareil ne doit pas produire de The BSM system will store the current operating brouillage, et When operating in Blind Spot Alert Lights/ mode when the vehicle is shut off. Each time Chime mode, the BSM system will provide a 2.
Page 152: Forward Collision Warning (Fcw) With Mitigation - If Equipped
SAFETY (FCW) the driver intends to avoid the collision by NOTE: ORWARD OLLISION ARNING braking but has not applied sufficient brake — I ITIGATION QUIPPED The minimum speed for FCW activation is  force, the system will compensate and provide 3 mph (5 km/h).
Page 153 SAFETY When the FCW is “off”, this prevents the   WARNING! system from warning the driver of a possible When the sensitivity of FCW is set to the  collision with the vehicle in front. If the FCW Forward Collision Warning (FCW) is not “Far”...
Page 154: Tire Pressure Monitoring System (Tpms)
SAFETY This setting provides less reaction time This indicates there is an internal system fault. 2. l'utilisateur de l'appareil doit accepter tout  than the “Far” and “Medium” settings, Although the vehicle is still drivable under brouillage radioélectrique subi, même si le which allows for a more dynamic driving normal conditions, have the system checked by brouillage est susceptible d'en compro-...
Page 155 SAFETY NOTE: The TPMS will continue to warn the driver of low the TPMS Warning Light will still be on. In this The alert warning on the cluster will stay on until tire pressure as long as the condition exists, situation, the TPMS Warning Light will turn off the tire is inflated to the placard pressure.
Page 156 SAFETY accurate tire pressure gauge, even if underin- NOTE: CAUTION! (Continued) flation has not reached the level to trigger illu- It is particularly important for you to check the mination of the TPMS Warning Light. tire pressure in all of the tires on your vehicle Using aftermarket tire sealants may cause ...
Page 157 SAFETY The vehicle may need to be driven for up to Lots of snow or ice around the wheels or  20 minutes above 15 mph (24 km/h) in order wheel housings. for the TPMS to receive this information. Using tire chains on the vehicle. ...
Page 158 SAFETY Tire Fill Alert The hazard lamps will come on to confirm the Selectable Tire Fill Alert (STFA) — If Equipped vehicle is in Tire Fill Alert mode. If the hazard This feature notifies the user when the placard STFA is an optional feature that is included as lamps do not come on while inflating the tire, tire pressure is attained while inflating or part of the normal Tire Fill Alert system.
Page 159 SAFETY NOTE: Horn chirps will indicate STFA status as tires are flash on and off for 75 seconds and then remain The STFA system will only support inflating or inflated/deflated. The horn will chirp under the on. The instrument cluster will display the deflating one tire at a time.
Page 160: Occupant Restraint Systems
SAFETY General Information La operación de este equipo está sujeta a las Some of the safety features described in this siguientes dos condiciones: section may be standard equipment on some This device complies with Part 15 of the FCC models, or may be optional equipment on Rules and with Innovation, Science and 1.
Page 161: Seat Belt Systems
SAFETY 3. If a child from 2 to 12 years old (not in a 9. If the air bag system in this vehicle needs to Research has shown that seat belts save lives, rear-facing child restraint) must ride in the be modified to accommodate a disabled and they can reduce the seriousness of injuries front passenger seat, move the seat as far...
Page 162 SAFETY remain on until both outboard front seat belts vehicle is traveling, the BeltAlert warning Lap/Shoulder Belts are buckled. The outboard front passenger seat sequence will begin until the seat belts are All seating positions in your vehicle are BeltAlert is not active when an outboard front buckled again.
Page 163 SAFETY WARNING! (Continued) WARNING! (Continued) WARNING! (Continued) It is dangerous to ride in a cargo area, Two people should never be belted into a A seat belt that is buckled into the wrong    inside or outside of a vehicle. In a collision, single seat belt.
Page 164 SAFETY portion, pull up on the shoulder belt. To WARNING! (Continued) loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug A shoulder belt placed behind you will not ...
Page 165 SAFETY Lap/Shoulder Belt Untwisting Procedure verify the shoulder belt anchorage is latched, pull downward on the shoulder belt anchorage Use the following procedure to untwist a twisted until it is locked into position. lap/shoulder belt. 1. Position the latch plate as close as WARNING! possible to the anchor point.
Page 166 SAFETY Seat Belt Extender Position the lap belt snug and low below the WARNING! (Continued) abdomen and across the strong bones of the If a seat belt is not long enough to fit properly, hips. Place the shoulder belt across the chest Using a Seat Belt Extender when not ...
Page 167 SAFETY Energy Management Feature In Automatic Locking Mode, the shoulder belt is automatically pre-locked. The seat belt will still The front outboard seat belt system is equipped retract to remove any slack in the shoulder belt. with an Energy Management feature that may Use the Automatic Locking Mode anytime a help further reduce the risk of injury in the event child restraint is installed in a seating position...
Page 168: Supplemental Restraint Systems (Srs)
SAFETY How To Engage The Automatic Locking Mode WARNING! (Continued) 1. Buckle the combination lap and shoulder Failure to replace the seat belt assembly  belt. could increase the risk of injury in colli- sions. 2. Grasp the shoulder portion and pull downward until the entire seat belt is Do not use the Automatic Locking Mode to ...
Page 169 SAFETY The air bag system must be ready to protect you Air Bag Warning Light The ORC also includes diagnostics that will in a collision. The Occupant Restraint Controller illuminate the instrument panel Air Bag Warning The Occupant Restraint Controller (ORC) monitors the internal circuits and Light if a malfunction is detected that could (ORC) monitors the readiness of the...
Page 170 SAFETY For additional information regarding the WARNING! WARNING! Redundant Air Bag Warning Light refer to Ignoring the Air Bag Warning Light in your “Getting To Know Your Instrument Panel” Being too close to the steering wheel or  instrument panel during front air bag instrument panel could mean you won’t have section of this manual.
Page 171 SAFETY Driver And Passenger Front Air Bag This vehicle has an Occupant Classification WARNING! System (“OCS”) in the front passenger seat. The Features OCS is designed to activate or deactivate the No objects should be placed over or near  The Advanced Front Air Bag system has Passenger Advanced Front Air Bag depending the air bag on the instrument panel or...
Page 172 SAFETY Front Air Bag Operation When the ORC detects a collision requiring the seated weight classifies them in a category front air bags, it signals the inflator units. A large other than a properly seated adult. This could Front Air Bags are designed to provide quantity of non-toxic gas is generated to inflate be a child, teenager, or even an adult.
Page 173 SAFETY Occupant Classification Module (OCM) And Sitting upright. The OCS may deactivate the deployment of the  Sensor Passenger Advanced Front Air Bag if the OCS Facing forward.  estimates that: The Occupant Classification Module (OCM) is Sitting in the center of the seat with their feet ...
Page 174 SAFETY Passenger Air Bag Disable (PAD) System Front Passenger Advanced Air Bag Front Passenger Seat Occupant Status Front Passenger Air Bag Status Disabled Indicator Light (“PAD”) Status Unoccupied seat* Unbuckled NOT ILLUMINATED DEACTIVATED Unoccupied seat*Buckled “PASSENGER AIR BAG OFF” DEACTIVATED Grocery bags, heavy briefcases, and other “PASSENGER AIR BAG OFF”...
Page 175 SAFETY Passenger Advanced Front Air Bag Disabled The PAD Indicator Light should be illuminated If The PAD Indicator Light Is Illuminated For An (PAD) Indicator Light and the Passenger Advanced Front Air Bag Adult Passenger: should be deactivated for most properly seated The Passenger Advanced Front Air Bag Disabled If an adult passenger is seated in the front and restrained children in the passenger seat...
Page 176 SAFETY Lighter Weight Passengers (Including Small Do Not Decrease OR Increase The Front WARNING! Adults) Passenger’s Seated Weight On The Front If the PAD Indicator Light remains illumi- Passenger Seat  When a lighter weight passenger, including a nated for an adult passenger, have an The front passenger’s seated weight must be small adult, occupies the passenger seat, the authorized dealer service the air bag...
Page 177 SAFETY The front passenger’s seatback is not in the The OCS determines the front passenger’s most  full upright position. probable classification. If an occupant in the front passenger seat is seated improperly, the The front passenger carries or holds an object ...
Page 178 SAFETY WARNING! WARNING! (Continued) Ignoring the Air Bag Warning Light in your Do not carry or hold any objects (e.g., back-   instrument panel could mean you won’t have packs, boxes, etc.) while seated in the front passenger seat. Holding an object may the air bags to protect you in a collision.
Page 179 SAFETY The passenger seat assembly contains critical Do not add a secondary seat cover or mat. Knee Impact Bolsters  OCS components that may affect Passenger The Knee Impact Bolsters help protect the At no time should any Supplemental  Advanced Front Air Bag inflation.
Page 180 SAFETY The SABs may help to reduce the risk of The Side Air Bags will not deploy in all side WARNING! occupant injury during certain side impacts, in collisions, including some collisions at certain addition to the injury reduction potential Do not use accessory seat covers or place angles, or some side collisions that do not provided by the seat belts and body structure.
Page 181 SAFETY Knee Impact Bolsters  WARNING! (Continued) WARNING! (Continued) Driver and Front Passenger Air Bags  Seat belts (and child restraints where Relying on the Side Air Bags alone could   appropriate) are necessary for your protec- lead to more severe injuries in a collision. Seat Belt Buckle Switch ...
Page 182 SAFETY gymnasium floor. They are not caused by Flash hazard lights as long as the battery has  WARNING! contact with chemicals. They are not perma- power. nent and normally heal quickly. However, if Deployed air bags and seat belt Turn on the interior lights, which remain on ...
Page 183 SAFETY NOTE: Maintaining Your Air Bag System WARNING! (Continued) After an accident, remember to cycle the igni- WARNING! tion to the STOP (OFF/LOCK) position and Do not attempt to modify any part of your air  remove the key from the ignition switch to avoid bag system.
Page 184: Child Restraints
SAFETY for a short period of time, typically 30 seconds To read data recorded by an EDR, special WARNING! or less. The EDR in this vehicle is designed to equipment is required, and access to the record such data as: vehicle or the EDR is needed.
Page 185 SAFETY Before buying any restraint system, make sure NOTE: Canadian residents should refer to Transport  that it has a label certifying that it meets all Canada’s website for additional information: For additional information, refer to http://  https://www.tc.gc.ca/en/services/road/ applicable Safety Standards. You should also www.nhtsa.gov/parents-and-caregivers or child-car-seat-safety.html make sure that you can install it in the vehicle...
Page 186 SAFETY Infant And Child Restraints Older Children And Child Restraints WARNING! Safety experts recommend that children ride Children who are two years old or who have Never place a rear-facing child restraint in  rear-facing in the vehicle until they are two years outgrown their rear-facing convertible child seat front of an air bag.
Page 187 SAFETY Children Too Large For Booster Seats If the answer to any of these questions was WARNING! “no”, then the child still needs to use a booster Children who are large enough to wear the Improper installation can lead to failure of seat in this vehicle.
Page 188 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of LATCH – Lower Restraint Type the Child + Child LATCH – Lower Seat Belt + Top Seat Belt Only Anchors + Top Tether Restraint Anchors Only Tether Anchor...
Page 189 SAFETY Lower Anchors And Tethers For CHildren Your vehicle is equipped with the child restraint LATCH Positions For Installing Child anchorage system called LATCH, which stands (LATCH) / ISOFIX Restraint System Restraints In This Vehicle for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats.
Page 190 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the combined What is the weight limit (child’s weight + weight of the weight of the child and the child restraint is 65 lbs child restraint) for using the LATCH anchorage system 65 lbs (29.5 kg) (29.5 kg).
Page 191 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Never “share” a LATCH anchorage with two or more child restraints. If the center position does not have Can two child restraints be attached using a common dedicated LATCH lower anchorages, use the seat belt lower LATCH anchorage? to install a child seat in the center position next to a child seat using the LATCH anchorages in an outboard...
Page 192 SAFETY Locating The LATCH Anchorages Locating The Upper Tether Anchorages Center Seat LATCH The lower anchorages are round bars There are tether strap anchorages Do not install child restraints with rigid lower that are found at the rear of the seat located behind each of the rear seats.
Page 193 SAFETY To Install A LATCH-Compatible Child 3. Attach the lower hooks or connectors of the How To Stow An Unused Switchable-ALR child restraint to the lower anchorages in Restraint (ALR) Seat Belt: the selected seating position. If the selected seating position has a When using the LATCH attaching system to Switchable Automatic Locking Retractor (ALR) install a child restraint, stow all ALR seat belts...
Page 194 SAFETY Refer to the “Automatic Locking Mode” WARNING! WARNING! description in “Switchable Automatic Locking Improper installation of a child restraint to Improper installation or failure to properly Retractors (ALR)” under “Occupant Restraint   the LATCH anchorages can lead to failure of secure a child restraint can lead to failure Systems”...
Page 195 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight of the Always use the tether anchor when using the seat belt child restraint) for using the Tether Anchor with the Weight limit of the Child Restraint to install a forward facing child restraint, up to the seat belt to attach a forward facing child restraint?
Page 196 SAFETY Installing A Child Restraint With A child seat. You may also move the front 7. Finally, pull up on any excess webbing to seat forward to allow more room for the tighten the lap portion around the child Switchable Automatic Locking Retractor child seat.
Page 197 SAFETY Installing Child Restraints Using The Top The Top Tether anchorages are located behind 5. Push the seat back rearward until the latch each rear seating position. To attach the tether engages and no red indicator is showing on Tether Anchorage strap of the child restraint: the strap WARNING!
Page 198: Transporting Pets
SAFETY RANSPORTING WARNING! (Continued) WARNING! (Continued) Air Bags deploying in the front seat could harm Do not allow people to ride in any area of If it is necessary to sit in a parked vehicle   your pet. An unrestrained pet will be thrown your vehicle that is not equipped with seats with the engine running, adjust your about and possibly injured, or injure a...
Page 199: Safety Checks You Should Make Inside The Vehicle
SAFETY Light has been detected, it will stay on until the AFETY HECKS HOULD WARNING! fault is removed. If the light comes on NSIDE EHICLE intermittently or remains on while driving, have An improperly attached, damaged, folded, or an authorized dealer service the vehicle Seat Belts stacked floor mat, or damaged floor mat immediately.
Page 200: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Inspect sidewalls for cuts, cracks, and bulges. WARNING! (Continued) WARNING! (Continued) Check the wheel nuts for tightness. Check the tires (including spare) for proper cold inflation ONLY use the driver’s side floor mat on the If the vehicle carpet has been removed and ...
Page 201: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE Four-Wheel Drive Models Only WARNING! (Continued) In 4L mode, if the vehicle is stalled, the engine Before starting your vehicle, adjust your seat, Do not leave the key fob in or near the  will start regardless of whether or not the clutch adjust both inside and outside mirrors, and vehicle, or in a location accessible to chil-...
Page 202: Normal Starting
STARTING AND OPERATING To Turn Off The Engine Using ENGINE START/ NOTE: ORMAL TARTING STOP Button The system will automatically time out and the To Turn On The Engine Using The ENGINE ignition will cycle to the OFF mode after 1.
Page 203 STARTING AND OPERATING AutoPark If the vehicle is not in PARK and the driver turns AutoPark will engage when all of these off the engine, the vehicle may AutoPark. conditions are met: AutoPark is a supplemental feature to assist in placing the vehicle in PARK should the AutoPark will engage when all of these Vehicle is equipped with an 8-speed trans-...
Page 204: Extreme Cold Weather (Below -22°F Or −30°C)
STARTING AND OPERATING If the driver shifts into PARK while moving, the Additional customer warnings will be given NGINE AILS TART vehicle may AutoPark. when both of these conditions are met: If the engine fails to start after you have AutoPark will engage ONLY when vehicle speed Vehicle is not in PARK ...
Page 205: After Starting
STARTING AND OPERATING The engine block heater must be plugged in at The engine oil installed in the engine at the WARNING! (Continued) least one hour to have an adequate warming factory is a high-quality energy conserving type effect on the engine. lubricant.
Page 206 STARTING AND OPERATING The parking brake lever is located in the center This light only shows that the parking brake is  WARNING! (Continued) applied. It does not show the degree of brake console behind the gear selector. To apply the parking brake, pull the lever up as firmly as application.
Page 207: Manual Transmission - If Equipped
STARTING AND OPERATING To shift the gears, fully press the clutch pedal CAUTION! CAUTION! (Continued) and place the gear selector into the desired If the “Brake Warning Light” remains on with gear position (the diagram for the engagement Do not drive with your hand resting on the ...
Page 208: Shifting
STARTING AND OPERATING NOTE: Recommended Vehicle Shift Speeds HIFTING A certain amount of noise from the transmis- To utilize your manual transmission efficiently Fully press the clutch pedal before shifting sion is normal. This noise can be most notice- for both fuel economy and performance, it gears.
Page 209: Downshifting
STARTING AND OPERATING OWNSHIFTING CAUTION! CAUTION! (Continued) Moving from a high gear down to a lower gear is Skipping gears and downshifting into lower Failure to follow the maximum recom-   recommended to preserve brakes when driving gears at higher vehicle speeds can damage mended downshifting speeds may cause down steep hills.
Page 210: Automatic Transmission - If Equipped
STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 Maximum Speed 80 (129) 70 (113) 50 (81) 30 (48) 15 (24) NOTE: NOTE: WARNING! (Continued) Vehicle speeds shown in the chart above are for...
Page 211: Ignition Park Interlock
STARTING AND OPERATING RAKE RANSMISSION HIFT WARNING! (Continued) WARNING! (Continued) NTERLOCK YSTEM Unintended movement of a vehicle could Do not leave the key fob in or near the   This vehicle is equipped with a Brake injure those in or near the vehicle. As with vehicle (or in a location accessible to chil- Transmission Shift Interlock system (BTSI) that all vehicles, you should never exit a vehicle...
Page 212 STARTING AND OPERATING NOTE: while in the MANUAL (AutoStick) position Gear Ranges In the event of a mismatch between the gear (beside the DRIVE position) will manually select Do not depress the accelerator pedal when selector position and the actual transmission the transmission gear, and will display the shifting from PARK or NEUTRAL into another gear (for example, driver selects PARK while...
Page 213 STARTING AND OPERATING When exiting the vehicle, always: WARNING! (Continued) WARNING! (Continued) Apply the parking brake.  The transmission may not engage PARK if Unintended movement of a vehicle could   Shift the transmission into PARK. the vehicle is moving. Always bring the injure those in or near the vehicle.
Page 214 STARTING AND OPERATING Look at the transmission gear position  WARNING! WARNING! (Continued) display and verify that it indicates the PARK position (P), and is not blinking. Do not coast in NEUTRAL and never turn off Do not leave the key fob in or near the ...
Page 215 STARTING AND OPERATING When frequent transmission shifting occurs Transmission Limp Home Mode 1. Stop the vehicle. (such as when operating the vehicle under Transmission function is monitored 2. Shift the transmission into PARK, if heavy loading conditions, in hilly terrain, electronically for abnormal conditions.
Page 216 STARTING AND OPERATING AutoStick In AutoStick mode, the transmission will shift up Holding the gear selector in the (-) position  will downshift the transmission to the lowest or down when (+/-) is manually selected by the AutoStick is a driver-interactive transmission driver, unless an engine lugging or overspeed gear possible at the current speed.
Page 217: Four-Wheel Drive Operation
STARTING AND OPERATING FOUR–WHEEL DRIVE OPERATION The transfer case provides four mode positions: N (Neutral) 2H (Two-Wheel Drive High Range)  WARNING! WARNING! 4H (Four-Wheel Drive High Range)  You or others could be injured or killed if you Failure to engage a transfer case position leave the vehicle unattended with the transfer N (Neutral) ...
Page 218 STARTING AND OPERATING will illuminate when the transfer case is shifted release the accelerator pedal after completing into the 4H position. the shift. Do not accelerate while shifting the Four-Wheel Drive Low Range — This range transfer case. Apply a constant force when provides low speed four-wheel drive.
Page 219: Trac-Lok Rear Axle - If Equipped
STARTING AND OPERATING 4H To 4L Or 4L To 4H RONT WARNING! — I With the vehicle rolling at 2 to 3 mph (3 to QUIPPED Failure to engage a transfer case position 5 km/h), shift an automatic transmission into The AXLE LOCK switch is located on the completely can cause transfer case damage NEUTRAL (N), or press the clutch pedal on a...
Page 220: Axle Lock (Tru-Lok) Rear Only - If Equipped
STARTING AND OPERATING — I To activate the system, push the AXLE LOCK To activate the rear system, push the AXLE switch down to lock the rear axle only (the LOCK switch down to lock the rear axle only (the QUIPPED “REAR ONLY”...
Page 221 STARTING AND OPERATING NOTE: WARNING! The stabilizer/sway bar may be torque locked Ensure the stabilizer/sway bar is reconnected due to left and right suspension height differ- ences. This condition is due to driving surface before driving on hard surfaced roads or at speeds above 18 mph (29 km/h);...
Page 222: Off Road+ - If Equipped
STARTING AND OPERATING + — I The Off Road+ telltale will illuminate in the QUIPPED  Instrument Cluster Display Engine/Transmission Calibration: Improved  sand performance/ wheel slip focus, change A mode specific message will display the  in shift schedule for sport mode, pedal cali- Instrument Cluster Display bration set to aggressive, operates at Off Road pages will launch on the radio...
Page 223: Electro-Hydraulic Power Steering
STARTING AND OPERATING ELECTRO-HYDRAULIC POWER STEERING STOP/START SYSTEM — AUTOMATIC likely the vehicle has lost power steering assistance. Refer to “Instrument Cluster TRANSMISSION (IF EQUIPPED) Your vehicle is equipped with an Display” in “Getting To Know Your Instrument electro-hydraulic power steering system that Panel”...
Page 224: Automatic Mode
STARTING AND OPERATING Secondary Battery To Activate The Autostop Mode, The Following UTOMATIC Must Occur: Your vehicle may be equipped with a secondary WARNING! battery used to power the Stop/Start system The system must be in STOP/START READY  state. A STOP/START READY message will be and the 12 Volt vehicle electrical system.
Page 225: Autostop
STARTING AND OPERATING Engine temperature too high OSSIBLE EASONS NGINE TART NGINE HILE  UTOSTOP UTOSTOP The transmission is not in a forward gear  Prior to engine shut down, the system will check While in a forward gear, the engine will start Hood is open ...
Page 226: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING A Stop/Start system error occurs 2. The “STOP/START OFF” message will If the “SERVICE STOP/START SYSTEM”  appear in instrument cluster display within message appears in the instrument cluster STOP/START AUTO STOP ACTIVE time  the Stop/Start section. Refer to “Instrument display, have the system checked by an exceeds 5 minutes Cluster”...
Page 227: Automatic Mode
STARTING AND OPERATING Secondary Battery To Activate The STOP/START AUTO STOP UTOMATIC ACTIVE Mode, The Following Must Occur: Your vehicle may be equipped with a secondary WARNING! battery used to power the Stop/Start system The system must be in STOP/START READY ...
Page 228: Possible Reasons The Engine Does Not
STARTING AND OPERATING Vehicle is at high altitude Conditions that will cause the engine to start OSSIBLE EASONS NGINE  automatically while in STOP/START AUTO STOP UTOSTOP The vehicle is on a steep grade  ACTIVE mode, the engine will start Prior to engine shut down, the system will check automatically when: Forward Gear is engaged...
Page 229: To Manually Turn Off The Stop/Start
STARTING AND OPERATING SPEED CONTROL — IF EQUIPPED 4. If the Stop/Start system is manually ANUALLY switched off, the engine can only be started TART YSTEM When engaged, the Speed Control takes over and stopped by cycling the ignition switch. accelerator operations at speeds greater than 1.
Page 230: To Activate
STARTING AND OPERATING at the same time. If this occurs, the Speed PEED ETTING WARNING! Control System can be reactivated by pushing To Increase Speed the Speed Control on/off button and resetting Leaving the Speed Control system on when the desired vehicle set speed. not in use is dangerous.
Page 231: To Accelerate For Passing
STARTING AND OPERATING Metric Speed (km/h) If the button is continually pushed, the set NOTE:  speed will continue to decrease until the The Speed Control system maintains speed up Pushing the SET (+) button once will result in  button is released, then the new set speed and down hills.
Page 232: To Deactivate
STARTING AND OPERATING ADAPTIVE CRUISE CONTROL (ACC) — IF ACC will allow you to keep cruise control EACTIVATE engaged in light to moderate traffic conditions EQUIPPED A soft tap on the brake pedal, pushing the CANC without the constant need to reset your cruise (cancel) button, or normal brake pressure while control.
Page 233: Operation
STARTING AND OPERATING NOTE: When the system is turned on and in the ready CTIVATE EACTIVATE Normal (Fixed Speed) Cruise Control will not state, the instrument cluster displays “ACC Push and release the Adaptive Cruise Control react to preceding vehicles. Always be aware of Ready.”...
Page 234: To Set A Desired Acc Speed
STARTING AND OPERATING If the system is set when the vehicle speed is ANCEL below 20 mph (32 km/h), the set speed shall The following conditions cancel the system: be defaulted to 20 mph (32 km/h). If the system is set when the vehicle speed is above The brake pedal is applied ...
Page 235: To Turn Off
STARTING AND OPERATING The clutch is depressed for more than NOTE: The driver's preferred units can be selected  10 seconds (manual transmission only) through the instrument panel settings. Refer to If your vehicle stays at standstill for longer  “Getting To Know Your Instrument Panel”...
Page 236: Setting The Following Distance In Acc
STARTING AND OPERATING To Decrease Speed If the button is continually pushed, the set tain set speed. When driving uphill and down-  speed will continue to decrease in 10 km/h hill, the ACC system will cancel if the braking While ACC is set, the set speed can be decrements until the button is released.
Page 237 STARTING AND OPERATING The vehicle will then maintain the set distance until: The vehicle ahead accelerates to a speed  above the set speed The vehicle ahead moves out of your lane or  view of the sensor The distance setting is changed ...
Page 238: Overtake Aid
STARTING AND OPERATING ACC O PERATION WARNING! UTOMATIC RANSMISSION When the ACC system is resumed, the driver In the event that the ACC system brings your must ensure that there are no pedestrians, vehicle to a standstill while following a target vehicles or objects in the path of the vehicle.
Page 239: Display Warnings And Maintenance
STARTING AND OPERATING Adaptive Cruise Control Ready NOTE: ISPLAY ARNINGS If the “ACC/FCW Unavailable Wipe Front Radar When ACC is activated, but the vehicle speed AINTENANCE Sensor” warning is active Normal (Fixed Speed) setting has not been selected, the display will Cruise Control is still available.
Page 240 STARTING AND OPERATING If the sensor or front end of the vehicle is “Clean Front Windshield” Warning When the condition that created limited  damaged due to a collision, see your autho- functionality is no longer present, the system The “ACC/FCW Limited Functionality Clean rized dealer for service.
Page 241: Precautions While Driving With Acc
STARTING AND OPERATING RECAUTIONS HILE RIVING In certain driving situations, ACC may have detection issues. In these cases, ACC may brake late or unexpectedly. The driver needs to stay alert and may need to intervene. NOTE: Do not put stickers or easy passes over the ...
Page 242: General Information
STARTING AND OPERATING Lane Changing Narrow Vehicles ACC may not detect a vehicle until it is Some narrow vehicles traveling near the outer completely in the lane in which you are edges of the lane or edging into the lane are not traveling.
Page 243: Normal (Fixed Speed) Cruise Control Mode
STARTING AND OPERATING Le présent appareil est conforme aux CNR ORMAL IXED PEED RUISE WARNING! d`Innovation, Science and Economic ONTROL Development applicables aux appareils radio In the Normal (Fixed Speed) Cruise Control In addition to Adaptive Cruise Control mode, a exempts de licence.
Page 244 STARTING AND OPERATING To Vary The Speed Setting Metric Speed (km/h) U.S. Speed (mph) To Increase Speed Pushing the SET (+) button once will result in Pushing the SET (-) button once will result in   a 1 km/h increase in set speed. Each subse- a 1 mph decrease in set speed.
Page 245: Parksense Rear Park Assist - If Equipped
STARTING AND OPERATING To Cancel To Resume Speed ParkSense will retain the last system state (enabled or disabled) from the last ignition cycle The following conditions will cancel the Normal To resume a previously set speed, push the RES when the ignition is placed in the ON/RUN (Fixed Speed) Cruise Control without clearing button and release.
Page 246: Parksense Warning Display
STARTING AND OPERATING and will produce a fast sound tone. As the ENSE ARNING ISPLAY vehicle moves closer to the obstacle, the The ParkSense Warning screen is located within display will show the single arc moving closer to the instrument cluster display. It provides visual the vehicle and the tone will change from fast to warnings to indicate the distance between the continuous.
Page 247 STARTING AND OPERATING The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: Fast Tone/Flashing Arc Continuous Tone/Flashing Arc WARNING ALERTS Greater than...
Page 248: Enabling And Disabling Parksense
STARTING AND OPERATING If “PARKSENSE UNAVAILABLE SERVICE NABLING ISABLING ENSE ERVICE ENSE REQUIRED” appears in the instrument cluster SSIST YSTEM ParkSense can be enabled and display, see an authorized dealer. disabled with the ParkSense switch, During vehicle start up, when the ParkSense LEANING ENSE YSTEM...
Page 249: Parksense Front And Rear Park Assist - If Equipped
STARTING AND OPERATING When you turn ParkSense off, the instrument  WARNING! CAUTION! cluster display will read “PARKSENSE OFF.” Furthermore, once you turn ParkSense off, it Drivers must be careful when backing up ParkSense is only a parking aid and it is ...
Page 250: Parksense Sensors
STARTING AND OPERATING ParkSense will retain the last system state The six ParkSense sensors, located in the front ENSE ISPLAY (enabled or disabled) from the last ignition cycle fascia/bumper, monitor the area in front of the The warning display will turn on indicating the when the ignition is placed in the ON/RUN vehicle that is within the sensors/ field of view.
Page 251 STARTING AND OPERATING Single 1/2 Second Tone Slow Tone For Rear Only Fast Tone Slow Tone Fast Tone For Rear Only Continuous Tone...
Page 252 STARTING AND OPERATING The vehicle is close to the obstacle when the display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Less than Rear Distance...
Page 253: Enabling And Disabling Parksense
STARTING AND OPERATING WARNING ALERTS FOR FRONT Front Distance Greater than 47 inches 47-39 inches 39-25 inches 25-12 inches Less than 12 inches (inches / cm) (120 cm) (120-100 cm) (100-65 cm) (65-30 cm) (30 cm) Arcs — Left None None None 2nd Flashing...
Page 254: Service The Parksense Park Assist System
STARTING AND OPERATING ice, mud, dirt or other obstruction and then When you turn the ParkSense system off, the ERVICE ENSE SSIST  instrument cluster display will show a vehicle cycle the ignition. If the message continues to YSTEM appear, see an authorized dealer. graphic of the ParkSense on/off state for two During vehicle start up, when the ParkSense seconds.
Page 255: Parkview Rear Back Up Camera
STARTING AND OPERATING Use the ParkSense switch to turn the Park-  WARNING! (Continued) CAUTION! (Continued) Sense system off if obstacles such as bicycle carriers, trailer hitches, etc. are placed within Before using ParkSense, it is strongly The vehicle must be driven slowly when ...
Page 256 STARTING AND OPERATING NOTE: NOTE: The following table shows the approximate For vehicles equipped with the Uconnect 3 With distances for each zone: If the vehicle speed remains below 8 mph  5-Inch Display, there is only one option for (13 km/h), the Rear View Camera image will Distance To The Rear manual activation of the Rear View Camera.
Page 257: Trailcam System - If Equipped
STARTING AND OPERATING NOTE: NOTE: WARNING! If snow, ice, mud, or any foreign substance The system will stay active while in 4L Drivers must be careful when backing up builds up on the camera lens, clean the lens, (Four-Wheel Drive Low Range). even when using the ParkView Rear Back Up rinse with water, and dry with a soft cloth.
Page 258: Refueling The Vehicle
STARTING AND OPERATING When the vehicle is shifted out of REVERSE The touchscreen button “X” to disable the on the fuel filler door to unlatch it. To close the  display of the camera image is made avail- (with Camera Delay turned off) and TrailCam fuel filler door, push on it a second time.
Page 259: Loose Fuel Filler Cap Message
STARTING AND OPERATING VEHICLE LOADING NOTE: WARNING! When the fuel nozzle “clicks” or shuts off, the  Never have any smoking materials lit in or ERTIFICATION ABEL  fuel tank is full. near the vehicle when the fuel door is open As required by National Highway Traffic Safety or the tank is being filled.
Page 260 STARTING AND OPERATING Payload Rim Size separately to be sure that the load is properly distributed over the front and rear axle. The payload of a vehicle is defined as the This is the rim size that is appropriate for the tire Weighing the vehicle may show that the GAWR allowable load weight a truck can carry, size listed.
Page 261: Trailer Towing
STARTING AND OPERATING TRAILER TOWING Gross Trailer Weight (GTW) WARNING! The GTW is the weight of the trailer plus the In this section you will find safety tips and It is important that you do not exceed the weight of all cargo, consumables and information on limits to the type of towing you maximum front or rear GAWR.
Page 262: Trailer Hitch Classification
STARTING AND OPERATING Weight-Carrying Hitch stability. Trailer sway control and a weight RAILER ITCH LASSIFICATION distributing (load equalizing) hitch are A weight-carrying hitch supports the trailer The following chart provides the industry recommended for heavier Tongue Weights (TW) tongue weight, just as if it were luggage located standard for the maximum trailer weight a given and may be required depending on vehicle and at a hitch ball or some other connecting point of...
Page 263: Trailer Towing Weights
STARTING AND OPERATING Trailer Hitch Classification Definitions Class Max. Trailer Hitch Industry Standards Class I - Light Duty 2,000 lbs (907 kg) Class II - Medium Duty 3,500 lbs (1,587 kg) Class III - Heavy Duty 6,000 lbs (2,722 kg) Class IV - Extra Heavy Duty 10,000 lbs (4,535 kg) Refer to the “Trailer Towing Weights (Maximum Trailer Weight Ratings)”...
Page 264 STARTING AND OPERATING GCWR (Gross Combined Max. GTW (Gross Trailer Max. Trailer Tongue Wt. Model Frontal Area Wt. Rating) Wt.) (See Note) Sport S - Automatic Transmission 11,100 lbs (5,035 kg) 6,000 lbs (2,722 kg) 600 lbs (272 kg) 55 ft (5.11 m (Tow Package) Sport S - Automatic Transmission...
Page 265: Trailer And Tongue Weight
STARTING AND OPERATING part of the total load on your vehicle. Refer to Towing Requirements — Trailer Brakes RAILER ONGUE EIGHT the “Tire And Loading Information” placard for Do not interconnect the hydraulic brake  Never exceed the maximum tongue weight the maximum combined weight of occupants system or vacuum system of your vehicle stamped on your bumper or trailer hitch.
Page 266 STARTING AND OPERATING Towing Requirements — Trailer Lights And WARNING! Wiring Do not connect trailer brakes to your  Whenever you pull a trailer, regardless of the vehicle's hydraulic brake lines. It can over- trailer size, stoplights and turn signals on the load your brake system and cause it to fail.
Page 267: Towing Tips
STARTING AND OPERATING Automatic Transmission — If Equipped Speed Control — If Equipped Select the DRIVE range when towing. The Do not use in hilly terrain or with heavy loads.  transmission controls include a drive strategy to When using the Speed Control, if you experi- ...
Page 268: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) OWING EHICLE EHIND NOTHER EHICLE Towing Condition Wheels OFF the Ground Four-Wheel Drive Models See Instructions Automatic transmission in PARK.  Manual transmission in gear (NOT in NEUTRAL [N]).  Flat Tow NONE Transfer case in (N) Neutral.
Page 269: Recreational Towing - Four-Wheel Drive
STARTING AND OPERATING — Shifting Into (N) Neutral ECREATIONAL OWING CAUTION! (Continued) Use the following procedure to prepare your HEEL RIVE ODELS Before recreational towing, perform the  vehicle for recreational towing. NOTE: procedure outlined under “Shifting Into (N) Neutral” to be certain that the transfer case The transfer case must be shifted into (N) WARNING! is fully in (N) Neutral.
Page 270 STARTING AND OPERATING 1. Bring the vehicle to a complete stop on 12. Shift the transmission into PARK or place 4. Press and hold the brake pedal. level ground. manual transmission in gear (NOT in 5. Shift the transmission into NEUTRAL. NEUTRAL).
Page 271: Driving Tips
STARTING AND OPERATING DRIVING TIPS 2. Remove two nuts and one bolt from the RIVING underside of the vehicle for each of the four Side Step Removal — If Equipped RIVING brackets. Repeat for other side of vehicle. Utility vehicles have higher ground clearance NOTE: Prior to off-road usage, the side steps should be and a narrower track to make them capable of...
Page 272 STARTING AND OPERATING Bumper End Cap Removal — If Equipped good driving posture. Avoid sudden accelerations, turns or braking. In most cases, The end caps on your vehicle’s front bumper there are no road signs, posted speed limits or can be removed by following the steps below: signal lights.
Page 273 STARTING AND OPERATING When To Use 4L Range Driving In Snow, Mud And Sand quarter turn quickly back and forth for additional traction. Mud holes pose an When off-road driving, shift into 4L for Snow increased threat of vehicle damage and getting additional traction and control on slippery or stuck.
Page 274 STARTING AND OPERATING Using A Spotter Crossing A Ravine, Gully, Ditch, Washout Or CAUTION! There are many times where it is hard to see the Reduced tire pressures may cause tire obstacle or determine the correct path. When crossing a ravine, gully, ditch, washout or unseating and total loss of air pressure.
Page 275 STARTING AND OPERATING Crossing Logs Driving Up Hill CAUTION! To cross a log, approach it at a slight angle Once you have determined your ability to Winching or rocking the vehicle off hard objects proceed and have shifted into the appropriate (approximately 10 to 15 degrees).
Page 276 STARTING AND OPERATING Driving Across An Incline WARNING! WARNING! If at all possible, avoid driving across an incline. Never attempt to climb a hill at an angle or If the engine stalls or you lose headway or If it is necessary, know your vehicle's abilities. turn around on a steep grade.
Page 277 STARTING AND OPERATING transmission), or DRIVE (automatic Before You Cross Any Type Of Water determine you can safely cross, then proceed transmission), with the transfer case in the 4L using the low and slow method. As you approach any type of water, you need to (Low) position and proceed very slowly with a determine if you can cross it safely and CAUTION!
Page 278 STARTING AND OPERATING current, the water's depth, approach angle, Inspect the radiator for mud and debris and  WARNING! clean as required. bottom condition and if there are any obstacles. Then cross at an angle heading slightly Abrasive material in any part of the brakes Check threaded fasteners for looseness, ...
Page 279: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS motion. Use it when your vehicle is disabled and If equipped, the overhead console contains an it is creating a safety hazard for other motorists. ASSIST and an SOS button. The Hazard Warning Flashers switch is located When you must leave the vehicle to seek on the instrument panel below the climate WARNING!
Page 280 IN CASE OF EMERGENCY ASSIST Call the cancellation button on the Device Screen. WARNING! Termination of the SOS Call will turn off the The ASSIST Button is used to automatically green LED light on the overhead console. ALWAYS obey traffic laws and pay attention to connect you to any one of the following support the road.
Page 281 IN CASE OF EMERGENCY 5. The SOS operator may attempt to contact SOS Call System Limitations WARNING! (Continued) appropriate emergency responders and Vehicles sold in Mexico DO NOT have SOS Call provide them with important vehicle The SOS Call system is embedded into the ...
Page 282 IN CASE OF EMERGENCY The vehicle battery loses power or becomes NOTE:  WARNING! disconnected during a vehicle crash Your vehicle may be transmitting data as  Ignoring the Rearview Mirror light could  LTE (voice/data) or 4G (data) network and/or authorized by the subscriber.
Page 283: General Information
IN CASE OF EMERGENCY Le présent appareil est conforme aux CNR La operación de este equipo está sujeta a las ENERAL NFORMATION d`Innovation, Science and Economic siguientes dos condiciones: The following regulatory statement applies to all Development applicables aux appareils radio 1.
Page 284: Bulb Replacement
IN CASE OF EMERGENCY BULB REPLACEMENT EPLACEMENT ULBS Interior Bulbs Bulb Name Bulb Number Automatic Transmission Indicator Lamp Heater Control Lamps (2) Rocker Switch Indicator Lamp (Rear Window Defogger Soundbar Dome Lamp ** Bulbs only available from an authorized dealer. Exterior Bulbs Bulb Name Bulb Number...
Page 285: Bulb Replacement
IN CASE OF EMERGENCY Exterior Bulbs Bulb Name Bulb Number Premium Fog Lamps LED – (Serviced at an Authorized Dealer) Rear Premium LED Tail Lamps LED – (Serviced at an Authorized Dealer) Rear Base Tail Lamp Stop/Tail/Turn Bulb 3157 Rear Base Tail Lamp Backup Bulb 7440 Rear Base Tail Lamp Side Marker LED –...
Page 286 IN CASE OF EMERGENCY 10. Remove connector from bulb. Halogen Front Fog Lamp 11. Push connector onto new bulb base, and NOTE: push the connector locking tab to the lock We advise referring to an authorized dealer for position. service. 1.
Page 287: Fuses
IN CASE OF EMERGENCY FUSES LED Front Fog Lamp If your vehicle is equipped with LED fog lamps WARNING! they are replaced as an assembly. When replacing a blown fuse, always use  Rear Tail, Stop, Turn Signal, And Backup an appropriate replacement fuse with the Lamp same amp rating as the original fuse.
Page 288: General Information
IN CASE OF EMERGENCY (PDC) ENERAL NFORMATION OWER ISTRIBUTION ENTER The fuses protect electrical systems against The Power Distribution Center is located in the excessive electrical current. engine compartment near the battery. This center contains cartridge fuses, mini fuses, and When a device does not work, you must check relays.
Page 289 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – 20 Amp Yellow Fuel Pump MTR/FPCM – 5 Amp Tan Security Gateway – – Spare – – Spare – 15 Amp Blue Trans Control Module TCM-8HP CYGNUS – – Spare Key Ignition Node (KIN)/Radio Frequency Hub (RF HUB)/ –...
Page 290 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description Engine Control Module (ECM)/Powertrain Control Module – 10 Amp Red (PCM) Powertrain Control Module (PCM)/Engine Control Module – 10 Amp Red (ECM) – – Spare – 10 Amp Red Module Shift By Wire (MOD_SBW) 40 Amp Green –...
Page 291 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink – TRAILER TOW MOD - If Equipped 30 Amp Pink – TRAILER TOW CONN 7W - If Equipped 20 Amp Blue – Engine Control Module ECM – –...
Page 292 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – – Spare Central Vision Processing Module (CVPM) or Parktronics – 10 Amp Red Module – 10 Amp Red In-Car Temp Sensor/PTC Heater Coil Feed – 20 Amp Yellow Frt Drvr Htd Seat –...
Page 293 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description – – Spare – 10 Amp Red HD ELEC ACC PKG - If Equipped – – Spare – – Spare – – Spare – 20 Amp Yellow ECM (GAS)/PCM (DSL) –...
Page 294 IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description 20 Amp Blue – TRAILER TOW PARK LMP - If Equipped – 20 Amp Yellow Horn 40 Amp Green – HD ACCY #2 - If Equipped 40 Amp Green – HD ACCY #1 - If Equipped –...
Page 295: Jacking And Tire Changing
IN CASE OF EMERGENCY Cavity Cartridge Fuse Micro Fuse Description F110 – – Spare F111 20 Amp Blue – TRAILER TOW BACKUP - If Equipped JACKING AND TIRE CHANGING CAUTION! WARNING! (Continued) When installing the power distribution Never start or run the engine while the ...
Page 296: Jack Location
IN CASE OF EMERGENCY There are two ways to assemble the tools: OCATION The jack and jack tools are stored under the right rear seat. To remove jack and tools proceed as follows: 1. Fold up the right rear seat. 2.
Page 297: Spare Tire Removal
IN CASE OF EMERGENCY NOTE: PARE EMOVAL If the tailgate is lowered, the jack extension with 1. Remove the spare tire before attempting to hook can be added to this assembly to enable jack up the truck. Attach the lug wrench to lowering of the spare tire without having to raise the extension tubes with the curved angle the tailgate.
Page 298 IN CASE OF EMERGENCY 2. Insert the extension tube through the 3. Rotate the lug wrench handle counter- 5. Lift the spare tire with one hand to give clockwise until the spare tire is on the access hole between the lower tailgate and clearance to tilt the retainer at the end of ground with enough cable slack to allow you the top of the bumper and into the winch...
Page 299: Preparations For Jacking
IN CASE OF EMERGENCY REPARATIONS ACKING WARNING! (Continued) 1. Park on a firm, level surface. Avoid ice or Apply the parking brake firmly and shift an  slippery areas. automatic transmission in PARK; a manual transmission to REVERSE. WARNING! Block the wheel diagonally opposite the ...
Page 300 IN CASE OF EMERGENCY Warning Label Assembled Jack And Tools Front Jacking Location 4. Operate the jack from the front or the rear of CAUTION! the vehicle. Place the jack under the axle Do not attempt to raise the vehicle by jacking tube, as shown.
Page 301 IN CASE OF EMERGENCY 10. Finish tightening the lug nuts. Push down on WARNING! the wrench while tightening for increased Raising the vehicle higher than necessary can leverage. Alternate nuts until each nut has been tightened twice. Refer to “Wheel And make the vehicle less stable.
Page 302: To Stow The Flat Or Spare
IN CASE OF EMERGENCY 4. Rotate the lug wrench handle clockwise PARE until the wheel is drawn into place against the underside of the vehicle. Continue to WARNING! rotate until you feel the winch mechanism A loose tire or jack thrown forward in a colli- slip, or click three or four times.
Page 303: Reinstalling The Jack And Tools
IN CASE OF EMERGENCY JUMP STARTING 5. Turn the wing bolt clockwise to secure to the EINSTALLING OOLS floor pan. If your vehicle has a discharged battery, it can 1. Tighten the jack all the way down by be jump started using a set of jumper cables turning the jack turn-screw counter- and a battery in another vehicle, or by using a clockwise until the jack is snug.
Page 304: Preparations For Jump Start
IN CASE OF EMERGENCY NOTE: REPARATIONS TART WARNING! (Continued) The positive battery post is covered with a protective cap. Lift up on the cap to gain access Battery posts, terminals, and related acces-  sories contain lead and lead compounds. to the post.
Page 305: Jump Starting Procedure
IN CASE OF EMERGENCY 1. Connect the positive (+) end of the jumper TARTING ROCEDURE WARNING! (Continued) cable to the remote positive (+) post of the discharged vehicle. Remove any metal jewelry such as rings, WARNING!  watch bands and bracelets that could 2.
Page 306: If Your Engine Overheats
IN CASE OF EMERGENCY 5. Start the engine in the vehicle that has the 5. Reinstall the protective cover over the CAUTION! booster battery, let the engine idle a few remote positive (+) post of the discharged minutes, and then start the engine in the vehicle.
Page 307: Manual Park Release
IN CASE OF EMERGENCY To push or tow the vehicle in cases where the WARNING! transmission will not shift out of PARK (P) (such You or others can be badly burned by hot as a depleted battery), a Manual Park Release engine coolant (antifreeze) or steam from is available.
Page 308: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY FREEING A STUCK VEHICLE Push the "ESC OFF" switch to place the Elec-  CAUTION! tronic Stability Control (ESC) system in "Partial If your vehicle becomes stuck in mud, sand or OFF" mode before rocking the vehicle. Refer to Racing the engine or spinning the wheels ...
Page 309: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described under “Recreational Towing” in the “Starting And Operating” section. Towing Condition Wheels OFF The Ground 4WD MODELS...
Page 310: Four-Wheel Drive Models
IN CASE OF EMERGENCY –W HEEL RIVE ODELS CAUTION! (Continued) The manufacturer recommends towing with all Towing this vehicle in violation of the above  wheels OFF the ground. Acceptable methods requirements can cause severe transmis- are to tow the vehicle on a flatbed or with one sion and/or transfer case damage.
Page 311: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM EVENT DATA RECORDER (EDR) WARNING! (EARS) This vehicle is equipped with an Event Data Do not use a chain for freeing a stuck  Recorder (EDR). The main purpose of an EDR is vehicle.
Page 312: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING On vehicles not equipped with an instrument Severe Duty All Models cluster display, “Change Oil” will flash in the Change Engine Oil at 4,000 miles (6,500 km) or Your vehicle is equipped with an automatic oil instrument cluster odometer and a single chime 350 hours of engine run time if the vehicle is change indicator system.
Page 313: Maintenance Plan
SERVICING AND MAINTENANCE AINTENANCE Required Maintenance Intervals Refer to the maintenance plan on the following pages for the required maintenance intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter  Rotate the tires ...
Page 314 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, rear suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle fluid. Inspect the brake linings, replace as necessary. Adjust parking brake on vehicles equipped with four wheel disc brakes.
Page 315 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Change the manual transmission fluid if using your vehicle for any of the following: trailer towing, snow plowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert operation or more than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C).
Page 316: Heavy Duty Use Of The Vehicle
SERVICING AND MAINTENANCE EAVY EHICLE WARNING! Change engine oil at 4,000 miles (6,500 km) or You can be badly injured working on or  350 hours of engine run time if the vehicle is around a motor vehicle. Do only service operated in a dusty and off-road environment or work for which you have the knowledge and is operated predominately at idle or only very...
Page 317: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L E NGINE 1 — Power Distribution Center (Fuses) 6 — Engine Coolant Pressure Cap 2 — Battery 7 — Brake Fluid Reservoir 3 — Engine Oil Dipstick 8 — Washer Fluid Reservoir Cap 4 — Engine Oil Fill 9 —...
Page 318: Checking Oil Level
SERVICING AND MAINTENANCE antifreeze). When refilling the washer fluid HECKING EVEL WARNING! reservoir, take some washer fluid and apply it to To ensure proper lubrication of your vehicle's a cloth or towel and wipe clean the wiper Battery fluid is a corrosive acid solution and ...
Page 319: Pressure Washing
SERVICING AND MAINTENANCE NOTE: WARNING! (Continued) CAUTION! (Continued) Intentional tampering with emissions control systems may void your warranty and could Serious injury or death could result if you do If the negative battery cables are not   result in civil penalties being assessed against not disconnect both batteries.
Page 320: Engine Oil Filter
SERVICING AND MAINTENANCE Engine Oil Selection 3.6L Engine Shell Helix or equivalent is recommended for all Disposing Of Used Engine Oil And Oil operating temperatures. This engine oil Filters For best performance and maximum protection improves low temperature starting and vehicle under all types of operating conditions, the Care should be taken in disposing of used fuel economy.
Page 321: Engine Air Cleaner Filter
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and NGINE LEANER ILTER Replacement Refer to the “Maintenance Plan” located in Follow the recommended maintenance “Scheduled Servicing” in “Servicing And intervals as shown in the Maintenance Maintenance” for the proper maintenance Schedule in this section.
Page 322: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Installation When inspecting accessory drive belts small Longitudinal belt cracking (cracks between  two ribs) cracks, that run across ribbed surface of belt NOTE: from rib to rib, are considered normal. This is Inspect and clean the housing if dirt or debris is Belt slips ...
Page 323: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling ONDITIONER AINTENANCE CAUTION! R-1234yf — If Equipped For best possible performance, your air Do not use chemical flushes in your air R-1234yf Air Conditioning Refrigerant is a conditioner should be checked and serviced by conditioning system as the chemicals can hydrofluoroolefin (HFO) that is endorsed by the an authorized dealer at the start of each warm...
Page 324 SERVICING AND MAINTENANCE The A/C air filter is located in the fresh air inlet CAUTION! behind the glove compartment. Perform the following procedure to replace the filter: The cabin air filter is identified with an arrow to indicate airflow direction through the filter. 1.
Page 325: Body Lubrication
SERVICING AND MAINTENANCE The wiper blades and wiper arms should be UBRICATION INDSHIELD IPER LADES inspected periodically, not just when wiper Locks and all body pivot points, including such Clean the rubber edges of the wiper blades and performance problems are experienced. This items as seat tracks, door hinge pivot points the windshield periodically with a sponge or soft inspection should include the following points:...
Page 326: Exhaust System
SERVICING AND MAINTENANCE Wiper Blade Removal/Installation 2. To disengage the wiper blade from the wiper Installing The Front Wipers arm, push the release tab on the wiper 1. Lift the wiper arm off of the glass, until the CAUTION! blade, and while holding the wiper arm with wiper arm is in the full up position.
Page 327 SERVICING AND MAINTENANCE seep into the passenger compartment. In NOTE: CAUTION! addition, have the exhaust system inspected Intentional tampering with emissions control each time the vehicle is raised for lubrication or The catalytic converter requires the use of systems can result in civil penalties being ...
Page 328: Cooling System
SERVICING AND MAINTENANCE the system should be drained, flushed, and If the engine coolant (antifreeze) is dirty or OOLING YSTEM refilled with fresh Organic Additive Technology contains visible sediment, have an authorized (OAT) coolant (conforming to MS.90032) by an dealer clean and flush with OAT coolant WARNING! authorized dealer.
Page 329 SERVICING AND MAINTENANCE Do not use water alone or alcohol-based coolant (OAT coolant conforming to MS.90032) NOTE:  engine coolant (antifreeze) products. Do not throughout the life of your vehicle. It is the owner's responsibility to maintain the  use additional rust inhibitors or antirust prod- Please review these recommendations for proper level of protection against freezing ucts, as they may not be compatible with the...
Page 330 SERVICING AND MAINTENANCE The cap should be inspected and cleaned if it to remain in puddles on the ground. If Points To Remember there is any accumulation of foreign material on ingested by a child or pet, seek emergency NOTE: the sealing surfaces.
Page 331: Brake System
SERVICING AND MAINTENANCE If frequent engine coolant (antifreeze) addi- “Maintenance Plan” located in “Scheduled Refer to “Fluids And Lubricants” in “Technical  tions are required, the cooling system should Servicing” in “Servicing And Maintenance” for Specifications” for further information. be pressure tested for leaks. the proper maintenance intervals.
Page 332: Front/Rear Axle Fluid
SERVICING AND MAINTENANCE NOTE: WARNING! (Continued) Make sure that the vehicle is level and supported by the axles. Overfilling the brake fluid reservoir can  result in spilling brake fluid on hot engine Adding Fluid parts, causing the brake fluid to catch fire. Add lubricant only at the fill hole and only to the Brake fluid can also damage painted and level specified above.
Page 333: Automatic Transmission - If Equipped
SERVICING AND MAINTENANCE Fluid Level Check manufacturer's specified transmission fluid. CAUTION! Refer to “Fluids And Lubricants” in “Technical Check the fluid level by removing the fill plug. Specifications” for fluid specifications. It is Do not use chemical flushes in your transmis- The fluid level should be between the bottom of important to maintain the transmission fluid at sion as the chemicals can damage your trans-...
Page 334: Raising The Vehicle
SERVICING AND MAINTENANCE Fluid And Filter Changes Tire Markings NOTE: Under normal operating conditions, the fluid P (Passenger) — Metric tire sizing is based on  installed at the factory will provide satisfactory US design standards. P-Metric tires have the lubrication for the life of the vehicle.
Page 335 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
Page 336 SERVICING AND MAINTENANCE EXAMPLE: H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions  The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle ...
Page 337 SERVICING AND MAINTENANCE EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation This symbol certifies that the tire is in compliance with the US Department of Transportation tire safety standards and is approved for highway use  MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits) 03 = Number representing the week in which the tire was manufactured (two digits)
Page 338 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition The vehicle B-Pillar is the structural member of the body located behind B-Pillar the front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than Cold Tire Inflation Pressure 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 339 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: NOTE: 1. Number of people that can be carried in The proper cold tire inflation pressure is listed the vehicle. on the driver’s side B-Pillar or the rear edge of the driver's side door.
Page 340 SERVICING AND MAINTENANCE NOTE: (3) Subtract the combined weight of the Metric Example For Load Limit Under a maximum loaded vehicle condition, driver and passengers from XXX kg or For example, if “XXX” amount equals 635 kg gross axle weight ratings (GAWRs) for the front XXX lbs.
Page 341: Tires - General Information
SERVICING AND MAINTENANCE — G Fuel Economy IRES ENERAL NFORMATION WARNING! (Continued) Underinflated tires will increase tire rolling Tire Pressure Overinflated or underinflated tires can  resistance resulting in higher fuel consumption. affect vehicle handling and can fail Proper tire inflation pressure is essential to the Tread Wear suddenly, resulting in loss of vehicle safe and satisfactory operation of your vehicle.
Page 342 SERVICING AND MAINTENANCE Example: If garage temperature = 68°F (20°C), CAUTION! WARNING! and the outside temperature = 32°F (0°C), After inspecting or adjusting the tire pressure, then the cold tire inflation pressure should be High speed driving with your vehicle under always reinstall the valve stem cap.
Page 343 SERVICING AND MAINTENANCE Tire Repair These indicators are molded into the bottom of WARNING! the tread grooves. They will appear as bands If your tire becomes damaged, it may be Fast spinning tires can be dangerous. Forces when the tread depth becomes a 1/16 of an repaired if it meets the following criteria: generated by excessive wheel speeds may inch (1.6 mm).
Page 344 SERVICING AND MAINTENANCE Loading Information placard or the Vehicle WARNING! WARNING! Certification Label for the size designation of Tires and the spare tire should be replaced your tire. The Load Index and Speed Symbol for Do not use a tire, wheel size, load rating, or ...
Page 345: Tire Types
SERVICING AND MAINTENANCE Summer Or Three Season Tires — If Snow Tires WARNING! (Continued) Equipped Some areas of the country require the use of Failure to equip your vehicle with tires  snow tires during the Winter. Snow tires can be Summer tires provide traction in both wet and having adequate speed capability can identified by a “mountain/snowflake”...
Page 346: Spare Tire Matching Original Equipped Tire And Wheel
SERVICING AND MAINTENANCE chemicals or a stiff brush. They can damage the PARE ATCHING RIGINAL CAUTION! wheel’s protective coating that helps keep them QUIPPED HEEL from corroding and tarnishing. Do not use scouring pads, steel wool, a bristle Your vehicle is equipped with a spare tire and brush, metal polishes, or oven cleaner.
Page 347: Tire Chains And Traction Devices
SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or WARNING! CAUTION! (Continued) Low Gloss Clear Coat Wheels Using tires of different size and type (M+S, Drive cautiously and avoid severe turns and  CAUTION! Snow) between front and rear axles can large bumps, especially with a loaded cause unpredictable handling.
Page 348: Department Of Transportation Uniform Tire Quality Grades
SERVICING AND MAINTENANCE increase tread life, help to maintain mud, snow, READWEAR CAUTION! and wet traction levels, and contribute to a The Treadwear grade is a comparative smooth, quiet ride. Proper operation of four-wheel drive vehicles rating, based on the wear rate of the tire depends on tires of equal size, type, and Refer to the “Maintenance Plan”...
Page 349: Traction Grades
SERVICING AND MAINTENANCE STORING THE VEHICLE Sustained high temperature can cause RACTION RADES the material of the tire to degenerate The Traction grades, from highest to WARNING! and reduce tire life, and excessive lowest, are AA, A, B, and C. These grades temperature can lead to sudden tire Take care to avoid the radiator cooling fan represent the tire's ability to stop on wet...
Page 350: Bodywork
SERVICING AND MAINTENANCE BODYWORK CAUTION! If the negative battery cables are not isolated ROTECTION TMOSPHERIC properly it can cause a potential power spike GENTS or surge in the system, resulting in damage to Vehicle body care requirements vary according essential electrical components. to geographic locations and usage.
Page 351: Body And Underbody Maintenance
SERVICING AND MAINTENANCE What Causes Corrosion? To minimize the possibility of scratching the CAUTION! lenses and reducing light output, avoid wiping Corrosion is the result of deterioration or with a dry cloth. To remove road dirt, wash with Do not use abrasive or strong cleaning ...
Page 352 SERVICING AND MAINTENANCE If you carry special cargo such as chemicals, After cleaning your vehicle's fabric top,   CAUTION! (Continued) fertilizers, de-icer salt, etc., be sure that such always make sure it is completely dry before materials are well packaged and sealed. lowering.
Page 353: Interiors
Clean them with a mild soap solution and a washed off immediately and thoroughly as and down. Mopar Jeep Soft Glass Window the acid they contain is particularly aggres- small brush. Cleaning products are available Cleaner or equivalent will safely clean all the through an authorized dealer.
Page 354: Carpet Removal
SERVICING AND MAINTENANCE ARPET EMOVAL WARNING! WARNING! (Continued) Front Carpets: If operating the vehicle without carpet in ONLY install carpet designed to fit your   place the floor may become hot, and there vehicle. NEVER install carpet that cannot 1.
Page 355 SERVICING AND MAINTENANCE 3. Remove the grommets under the front seat. Rear Carpet First for the rear carpet and then the front 1. Remove the grommets under the front seat carpet. (one left and one right). Rear Underside Of Front Seat 1 —...
Page 356: Seats And Fabric Parts
SERVICING AND MAINTENANCE 5. Remove the jack and tools by turning the EATS ABRIC ARTS WARNING! wing bolt counterclockwise, remove the Use Mopar Total Clean to clean fabric wing bolt and then lift the assembly out A frayed or torn belt could rip apart in a upholstery and carpeting.
Page 357: Leather Parts
SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster with any liquid. Please do not use polishes, oils, LASS URFACES cleaning fluids, solvents, detergents, or Lenses All glass surfaces should be cleaned on a ammonia-based cleaners to clean your leather The lenses in front of the instruments in this regular basis with Mopar Glass Cleaner, or any upholstery.
Page 358: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS The Vehicle Identification Number (VIN) is found Your vehicle is equipped with dual hydraulic Proper lug nut/bolt torque is very important to on the left front corner of the A pillar, visible brake systems.
Page 359: Fuel Requirements
TECHNICAL SPECIFICATIONS Inspect the wheel mounting surface prior to After 25 miles (40 km), check the lug nut/bolt knocking sound, see an authorized dealer mounting the tire and remove any corrosion or torque to be sure that all the lug nuts/bolts are immediately.
Page 360: Materials Added To Fuel
TECHNICAL SPECIFICATIONS E-85 I ATERIALS DDED ASOLINE XYGENATE LENDS EHICLES Besides using unleaded gasoline with the Some fuel suppliers blend unleaded gasoline proper octane rating, gasolines that contain with oxygenates such as ethanol. Non-Flex Fuel Vehicles (FFV) are compatible detergents, corrosion and stability additives are with gasoline containing up to 15% ethanol CAUTION! recommended.
Page 361: Cng And Lp Fuel System Modifications
TECHNICAL SPECIFICATIONS CNG A LP F NOTE: YSTEM YSTEM AUTIONS Intentional tampering with the emissions ODIFICATIONS control system can result in civil penalties being CAUTION! Modifications that allow the engine to run on assessed against you. Follow these guidelines to maintain your Compressed Natural Gas (CNG) or Liquid vehicle’s performance: ARBON...
Page 362: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 22 Gallons 83 Liters Engine Oil with Filter 3.6L Engine 5 Quarts 4.73 Liters Cooling System * 3.6L Engine (Mopar Antifreeze/Engine Coolant 10 Year/150,000 Mile (240,000 km) Formula or equivalent) 11.2 Quarts 10.6 Liters *Includes coolant recovery bottle filled to MAX level.
Page 363 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other This vehicle has not been designed for use   than specified Organic Additive Technology with propylene glycol-based engine coolant (OAT) engine coolant (antifreeze), may (antifreeze). Use of propylene glycol-based result in engine damage and may decrease engine coolant (antifreeze) is not recom- corrosion protection.
Page 364: Chassis
TECHNICAL SPECIFICATIONS HASSIS Component Fluid, Lubricant, or Genuine Part Use only Mopar ZF 8 & 9 Speed ATF Automatic Transmission Fluid or Automatic Transmission – If Equipped equivalent. Failure to use the correct fluid may affect the function or performance of your transmission. Manual Transmission –...
Page 365: Multimedia
MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain WARNING! security features to reduce the risk of For detailed information about your Uconnect unauthorized and unlawful access to vehicle It is not possible to know or to predict all of ...
Page 366: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS NOTE: USTOMER ROGRAMMABLE EATURES — U CONNECT ETTINGS FCA US LLC or an authorized dealer may The Uconnect system uses a combination of  contact you directly regarding software buttons on the touchscreen and buttons on the updates.
Page 367 MULTIMEDIA When making a selection, press the button on Down Arrow Buttons on the right side of the The following tables list the settings that may be the touchscreen to enter the desired menu. screen will allow you to toggle up or down found within the Uconnect 3 radio, along with Once in the desired menu, press and release through the available settings.
Page 368 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following setting will be available: Setting Name Selectable Options Units Metric Custom NOTE: The “Metric” option changes the Instrument Cluster Display to metric units of measurement.  The “Custom” option allows setting the “Fuel Consumption” (L/100km, or km/L) and “Pressure” (kPa, or bar) units of measurement independently. ...
Page 369 MULTIMEDIA Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE.
Page 370 MULTIMEDIA Setting Name Selectable Options ParkSense — If Equipped Sound Only Sound & Display NOTE: The Rear Park Assist system scans for objects behind the vehicle when the transmission gear selector is in REVERSE and the vehicle speed is less than 7 mph (11 km/h).
Page 371 MULTIMEDIA Setting Name Selectable Options Automatic High Beam Headlamps — If Equipped Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. The feature is only available if allowed by law in the country of the vehicle purchase.
Page 372 MULTIMEDIA Setting Name Selectable Options Remote Door Unlock/Door Lock Driver NOTE: When “Driver” is programmed, only the driver's door will unlock on the first push of the key fob unlock button. You must push the key fob unlock button twice to unlock the passengers’ doors. When “All” is programmed, all of the doors will unlock on the first press of the key fob unlock button. If “All” is programmed, all doors will unlock no matter which Passive Entry equipped door handle is grasped.
Page 373 MULTIMEDIA Engine Off Options After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options 0 sec 30 sec Headlight Off Delay 60 sec 90 sec NOTE: When this feature is selected, it allows the adjustment of the amount of time the headlights remain on after the engine is shut off. Doors On Key Off Power Delay Doors Off Key Off Power Delay AUX Switches...
Page 374 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer Bass Treble NOTE: When in this display, you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the + and – setting buttons on the touchscreen or by selecting any point on the scale between the + and –...
Page 375 MULTIMEDIA Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following setting will be available: Setting Name Selectable Options Paired Phones List of Paired Phones NOTE: This feature shows which phones are paired to the Phone/Bluetooth® system. For further information, refer to “Phone Operation” in “Uconnect 3 with 5-inch display”...
Page 376 MULTIMEDIA Restore Settings To Default After pressing the Restore Settings To Default button on the touchscreen, the following setting will be available: Setting Name Selectable Options Restore Settings To Default Cancel NOTE: When the “Restore Settings” feature is selected, it will reset all settings to their default settings. Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following setting will be available: Setting Name...
Page 377: Customer Programmable Features
MULTIMEDIA Press the Settings button on the bottom bar, or the preferred setting “option” until a check USTOMER ROGRAMMABLE EATURES press the Apps button, then press the mark appears next to the setting, showing that — U CONNECT ETTINGS Settings button on the touchscreen to display setting has been selected.
Page 378 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Display Brightness Headlights On Display Brightness Headlights Off Touchscreen Beep Auto-Show Smartphone Display Upon Connection Control Screen Timeout - If Equipped Phone Pop-ups Displayed in Cluster Units After pressing the Units button on the touchscreen, the following setting will be available:...
Page 379 MULTIMEDIA Voice After pressing the Voice button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List Always With Help Never Clock After pressing the Clock button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS —...
Page 380 MULTIMEDIA Camera — If Equipped After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE.
Page 381 MULTIMEDIA Safety/Driving Assistance — If Equipped After pressing the Safety/Driving Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Forward Collision Warning — If Equipped Warning Only Warning & Braking Forward Collision Warning Sensitivity — If Equipped Near NOTE: Sets the distance in which a Forward Collision Warning occurs.
Page 382 MULTIMEDIA Setting Name Selectable Options Active ParkView Backup Camera NOTE: The “Active ParkView Backup Camera” feature overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle and its projected backup path, based on the steering wheel position, when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist with parking or aligning to a hitch/receiver.
Page 383 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. The feature is only available if allowed by law in the country of the vehicle purchase. Auto Dim High Beams —...
Page 384 MULTIMEDIA Setting Name Selectable Options Remote Door Unlock/Door Lock Driver NOTE: When “Driver” is programmed, only the driver's door will unlock on the first push of the key fob unlock button. You must push the key fob unlock button twice to unlock the passengers’ doors. When “All” is programmed, all of the doors will unlock on the first press of the key fob unlock button. If “All” is programmed, all doors will unlock no matter which Passive Entry equipped door handle is grasped.
Page 385 MULTIMEDIA Engine Off Options — If Equipped After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Doors On Engine Off Power Delay Headlight Off Delay NOTE: When this feature is selected, it allows the adjustment of the amount of time the headlights remain on after the engine is shut off. Doors Off Engine Off Power Delay AUX Switches —...
Page 386 MULTIMEDIA Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Balance & Fade Speaker Icon NOTE: When in this display, you may adjust the Balance & Fade of the audio by pressing and dragging the Speaker Icon toward any location in the box. Equalizer Bass Treble...
Page 387 MULTIMEDIA Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following settings will be available: Setting Name Selectable Options Do Not Disturb Do Not Disturb Options Paired Phones And Audio Devices List Of Paired Phones And Audio Devices NOTE: This feature shows which phones and audio devices are paired to the Phone/Bluetooth®...
Page 388 MULTIMEDIA Setting Name Selectable Options Subscription Info Sirius ID NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM® Satellite Radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe. 1.
Page 389: Customer Programmable Features - Uconnect 4/4C/4C Nav Settings
MULTIMEDIA Press the Apps button, then press the or press the X button on the touchscreen to USTOMER ROGRAMMABLE EATURES Settings button on the touchscreen to close out of the settings screen. Pressing the Up — U 4/4C/4C NAV S CONNECT ETTINGS display the menu setting screen.
Page 390 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following setting will be available: Setting Name Selectable Options Language English Français Español NOTE: When the “Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 391 MULTIMEDIA Setting Name Selectable Options Set Theme Set Theme NOTE: When in this display, you may select the theme for the display screen. To make your selection, press the Set Theme button on the touchscreen, then select the desired theme option button until a check mark appears showing that the setting has been selected. Touchscreen Beep Control Screen Timeout NOTE:...
Page 392 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following setting will be available: Setting Name Selectable Options Units Metric Custom NOTE: The “Metric” option changes the instrument cluster display to metric units of measurement.  The “Custom” option allows setting the “Speed” (MPH or km/h), “Distance” (mi or km) “Fuel Consumption” [MPG (US), MPG (UK), L/100km, or ...
Page 393 MULTIMEDIA Setting Name Selectable Options Set Time Minutes NOTE: The “Set Time Minutes” feature will allow you to adjust the minutes. The Sync Time With GPS button on the touchscreen must be unchecked. Time Format 12 hrs 24 hrs Show Time in Status Bar — If Equipped Camera After pressing the Camera button on the touchscreen, the following settings will be available: Setting Name...
Page 394 MULTIMEDIA Setting Name Selectable Options Fixed ParkView Backup Camera Guidelines Forward Facing Camera Guidelines Forward Facing Auto Launch Off Road+ — If Equipped Off Road Pages Camera Safety & Driving Assistance After pressing the Safety & Driving Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options Automatic Emergency Braking —...
Page 395 MULTIMEDIA Setting Name Selectable Options Blind Spot Alert — If Equipped Lights Lights & Chime NOTE: If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged, the sensor may have become misaligned.
Page 396 MULTIMEDIA Setting Name Selectable Options Headlights with Wipers — If Equipped Daytime Running Lights NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. The feature is only available if allowed by law in the country of the vehicle purchase.
Page 397 MULTIMEDIA Setting Name Selectable Options Sound Horn With Remote Start — If Equipped 1st Press Of Key Fob Unlocks Driver Door All Doors NOTE: When "Driver Door" is programmed with 1st Press Of Key Fob Unlocks, only the driver's door will unlock with the first press of the key fob unlock button.
Page 398 MULTIMEDIA Seats & Comfort — If Equipped After pressing the Seats & Comfort button on the touchscreen, the following setting will be available: Setting Name Selectable Options Auto-On Driver Heated Seat & Steering Wheel With Vehicle Start — If Remote Start All Starts Equipped NOTE:...
Page 399 MULTIMEDIA Key Off Options After pressing the Key Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Key Off Power Delay Doors Off Key Off Power Delay 0 sec 30 sec Headlight Off Delay 60 sec 90 sec NOTE:...
Page 400 MULTIMEDIA Setting Name Selectable Options Speed Adjusted Volume AUX Volume Offset — If Equipped NOTE: This feature provides the ability to tune the audio level for portable devices connected through the AUX input. Auto Play Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following settings will be available: Setting Name Selectable Options Phone Pop-ups Displayed In Cluster...
Page 401 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start Channel Skip List Of Channels NOTE: SiriusXM® can be programmed to include desired channels and exclude undesired channels. This feature allows you to select the channels you would like to skip.
Page 402 MULTIMEDIA Reset After pressing the Reset button on the touchscreen, the following settings will be available: Setting Name Selectable Options Reset App Drawer to Default Order Cancel Restore Apps — If Equipped Back Next NOTE: Restoring Apps will delete all installed apps. This feature is used if there is an issue using or installing apps. To restore apps, press the Next button in the pop-up screen, and then press “Yes”...
Page 403: Safety And General Information
MULTIMEDIA System Information — If Equipped After pressing the System Information button on the touchscreen, the following settings will be available: Setting Name Selectable Options Software Licenses Software Information Screen NOTE: When this feature is selected, a “Licensing Information” screen will appear, displaying a licensing information website for the radio. Download System Information To Map Update —...
Page 404: Uconnect 3 With 5-Inch Display
MULTIMEDIA UCONNECT 3 WITH 5-INCH DISPLAY Safe Usage Of The Uconnect System radio manufacturer believes the internal wireless radio is safe for use by consumers. The Read all instructions in this manual carefully  level of energy emitted is far less than the NTRODUCTION before using your system to ensure proper electromagnetic energy emitted by wireless...
Page 405: Radio Mode
MULTIMEDIA 4 — MORE 10 — MEDIA The radio is equipped with the following modes: Push the MORE button on the faceplate to Pushing the MEDIA button on the faceplate will  access additional options. allow you to switch to Media mode: CD (if ...
Page 406 MULTIMEDIA TUNE/SCROLL Control During a Seek Down function, if the radio commercial-free music, sports, news, talk, and reaches the starting station after passing entertainment. Get all the premium Turn the rotary TUNE/SCROLL control knob through the entire band two times, the radio will programming, including Howard Stern, every clockwise to increase or counterclockwise to stop at the station where it began.
Page 407 MULTIMEDIA and in Alaska and Hawaii. © 2020 SiriusXM® Audio Settings Balance/Fade — Press the Balance/Fade  Radio Inc. SiriusXM® and all related marks and button on the touchscreen to adjust the 1. Push the SETTINGS button on the right side logos are trademarks of SiriusXM®...
Page 408: Media Mode
MULTIMEDIA Clock Settings Audio Source Selection EDIA Once in Media Mode, press the Source button 1. Push the SETTINGS button on the Operating Media Mode on the touchscreen and the desired mode faceplate, or push the MORE button on the button on the touchscreen.
Page 409 MULTIMEDIA Seek Up/Seek Down Functions Repeat the faceplate. Once in Media Mode, press the Source button on the touchscreen, and select Seek Up /Seek Down Press the Repeat button on the touchscreen to the USB/iPod® button. repeat the song selection. To cancel Repeat, Press and release the Seek Up button on the press the Repeat button on the touchscreen a Inserting USB/iPod®...
Page 410: Phone Mode
MULTIMEDIA Before proceeding, the Bluetooth® device must Inserting Auxiliary Device HONE be paired with the Uconnect Phone to Gently insert the Auxiliary device cable into the Operating Phone Mode communicate with the Uconnect system. AUX Port. If you insert an Auxiliary device with the ignition on, the unit will switch to AUX mode Refer to Phone Mode section for pairing and begin to play when you insert the device...
Page 411 MULTIMEDIA The Uconnect Phone is a voice-activated, Main Functions Connecting/Disconnecting A Mobile hands-free, in-vehicle communications system Phone Or Bluetooth® Device The buttons on the display can be used to: with voice command capability. Refer to Voice Compose phone numbers using the graphic ...
Page 412 MULTIMEDIA 1. Place the ignition in the ACC or ON/RUN 7. When prompted on the mobile phone, position. accept the connection request from Uconnect Phone. 2. Push the PHONE button on the faceplate. Some mobile phones will require you to ...
Page 413 MULTIMEDIA delete the device from the list of phones on your 1. Access the Settings menu. 4. Select the specific device (mobile phone or Uconnect system. Next, be sure to remove Bluetooth® device). 2. Select the Phone/Bluetooth® button. Uconnect from the list of devices in your 5.
Page 414 MULTIMEDIA Setting A Mobile Phone Or A Bluetooth® If equipped and specifically supported by your Only the mobile phone’s phonebook is down-  phone, Uconnect Phone asks you if you want to loaded. SIM card phonebook is not part of Audio Device As A Favorite download names (text names) and number the mobile phonebook.
Page 415 MULTIMEDIA Call By Saying A Phonebook Name Or Phone Press the Hold button and dial the number on the touchscreen, or push the PHONE button  Number using the graphic keyboard of the display. on the steering wheel. Answering Or Ignoring An Incoming Call With A 1.
Page 416 MULTIMEDIA Transferring/Call Continuation Uconnect Phone Features Browsing SMS Transferring Using the steering wheel commands, you can Mute/Unmute view and manage the last 10 SMS messages The ongoing calls can be transferred from the received on the instrument panel. To use this 1.
Page 417: Uconnect 4 With 7-Inch Display
MULTIMEDIA UCONNECT 4 WITH 7-INCH DISPLAY 2. Media 7. Settings Press the Media button on the touchscreen Press the Settings button on the touch- NTRODUCTION to access media sources such as USB De- screen to access the Uconnect Settings vice, AUX, and Bluetooth® as long as the re- menu.
Page 418: Radio Mode
MULTIMEDIA The new app shortcut, that was dragged down The electronic volume control turns Seek Up onto the main menu bar, will now be an active continuously (360 degrees) in either direction, Press and release the Seek Up button on the App/shortcut.
Page 419 MULTIMEDIA Fast Seek Down Browse In AM/FM Press and hold the Seek Down button on the Once the last digit of a station has been When in either AM or FM, the Browse Screen touchscreen to advance the radio through the entered, press the OK button, and the Direct provides a means to edit the Presets List and is available stations or channel at a faster rate.
Page 420 MULTIMEDIA Return To Main Radio Screen A huge On Demand catalog Radio Inc. Service available in Canada; see  www.siriusxm.ca. You can return to the Main Radio Screen, by Xtra Channels featuring SiriusXM®  pressing the X button on the touchscreen when This functionality is only available for radios Latino –...
Page 421 MULTIMEDIA NOTE: In addition to the tuning Operation functions Rewind You will need to provide the SiriusXM® ID (RID) common to all Radio modes, the replay, Traffic/ Press the RW button on the touchscreen to located at the bottom of the Channel 0 screen. Weather Jump, and fav button functions are rewind the content in steps of five seconds.
Page 422 MULTIMEDIA Favorites Browse In SXM Presets Press the Fav button on the touchscreen to Press the Browse button on the touchscreen to Press the Presets button located at the left of activate the favorites menu, which will time out edit Presets, Favorites, Game Zone, and Jump the Browse screen.
Page 423 MULTIMEDIA Favorites Game Zone Alert Settings Press the Favorites button located at the left of Press the Game Zone button, located at the left Press the Alert Setting tab at the top of the the Browse screen. of the Browse screen. This feature provides you screen.
Page 424 MULTIMEDIA Balance & Fade Equalizer Speed Adjusted Volume Balance & Fade Equalizer Speed Adjusted Volume Press the Balance & Fade button on the Press the Equalizer button on the touchscreen Press the Speed Adjusted Volume button on the touchscreen to balance audio between the front to activate the Equalizer screen.
Page 425 MULTIMEDIA Surround Sound — If Equipped Loudness AUX Volume Offset Press the On button on the touchscreen to activate Surround Sound. Press Off to deactivate this feature. When Surround Sound is On, you can hear audio coming from every direction as in a movie theatre or home theatre system.
Page 426: Media Mode
MULTIMEDIA Auto Play Radio Off With Door EDIA USB/iPod® Mode Overview USB/iPod® Mode is entered by either inserting a USB device or iPod® and cable into the USB Port or by pressing the Select Source button on the left side of the display, and then selecting USB 1, or USB 2 (if equipped).
Page 427 MULTIMEDIA side of the screen. The center of the browse Info AUX Mode window shows items and its sub-functions, Overview Press the Info button on the touchscreen to which can be scrolled by pressing the Up and display the current track information. Press the AUX (Auxiliary Mode) is entered by inserting an Down buttons to the right.
Page 428 MULTIMEDIA Media Mode display a pop-up with the Song List. The currently playing song is indicated by a red Press the Media button on the touchscreen to arrow and lines above and below the song title. select the desired audio source: AUX. Pressing the Tracks button on the touchscreen Audio while the pop-up is displayed will close the...
Page 429 MULTIMEDIA display. Android Auto™ automatically brings you NOTE: Once Android Auto™ is up and running on your useful information, and organizes it into simple Be sure to use the factory-provided USB cable Uconnect system, the following features can be cards that appear just when they are needed. that came with your phone, as aftermarket utilized using your smartphone’s data plan: cables may not work.
Page 430 MULTIMEDIA Android Auto™ Maps For further information, refer to Android Auto™ Communication www.android.com/auto/ (US Residents) https:/ Push and hold the VR button on the steering With Android Auto™ connected, press and hold /www.android.com/intl/en_ca/auto (Canadian wheel or tap the microphone icon to ask Google the VR button on the steering wheel to activate Residents).
Page 431 MULTIMEDIA Apple CarPlay® Integration 1. Connect your iPhone® to one of the media Once Apple CarPlay® is up and running on your USB ports in your vehicle. Uconnect system, the following features can be Scan this QR code for your digital utilized using your iPhone’s®...
Page 432 MULTIMEDIA Apple CarPlay® Phone Apple CarPlay® Maps Apple CarPlay® Apps With Apple CarPlay®, press and hold the VR To use your Apple Maps® for navigation on your To use a compatible app with Apple CarPlay®, button on the steering wheel to activate a Siri Uconnect system, launch Apple CarPlay®, and you must have the compatible app downloaded, voice recognition session.
Page 433: Phone Mode
MULTIMEDIA Uconnect system via Bluetooth® without any NOTE: 3 — Currently Paired Mobile Phone setup required every time it is within range, if 4 — Siri If using a Samsung device, every time it is  Bluetooth® is turned on. 5 —...
Page 434 MULTIMEDIA Uconnect Phone supports the following Screen Activated Features For Uconnect customer support: features: Dialing via keypad using touchscreen. US residents - visit UconnectPhone.com or   Voice Activated Features call: Viewing and calling contacts from phone-  877-855-8400 Hands-Free dialing via Voice (“Call John ...
Page 435 MULTIMEDIA The Uconnect Phone is driven through your The button on your steering wheel is also used You will be prompted for a specific command Bluetooth® “Hands-Free Profile” mobile phone. to access the Voice Commands for the and then guided through the available options. Uconnect features Bluetooth®...
Page 436 MULTIMEDIA Natural Speech Help Command establishing a wireless connection between a cellular phone and the Uconnect system. Your Uconnect Phone Voice system uses a If you need assistance at any prompt, or if you Natural Language Voice Recognition (VR) want to know your options at any prompt, say To complete the pairing process, you need to engine.
Page 437 MULTIMEDIA 4. Search for available devices on your Search for available devices on your to the Uconnect system at a time. If “No” is  Bluetooth®-enabled mobile phone. Bluetooth®-enabled mobile phone (see selected, simply select “Uconnect” from the below). When prompted on the phone, mobile phone/audio device Bluetooth®...
Page 438 MULTIMEDIA 4. Uconnect Phone will display an in-process 3. Press the Bluetooth® button on the which it was paired. The latest device paired will screen while the system is connecting. touchscreen to display the Paired Audio have the higher priority. Devices screen.
Page 439 MULTIMEDIA Disconnecting A Phone Or Audio Device 4. The options pop-up will be displayed. Phonebook Download (Automatic Phonebook Transfer From Mobile Phone) — If Equipped 5. Press the Delete Device button on the 1. Press the Phone Settings button on the If equipped and specifically supported by your touchscreen.
Page 440 MULTIMEDIA Depending on the maximum number of selected number to display the options Ways To Initiate A Phone Call  entries downloaded, there may be a short pop-up. In the pop-up select Add to Listed below are all the ways you can initiate a delay before the latest downloaded names Favorites.
Page 441 MULTIMEDIA Call By Saying A Phonebook Name Touch-Tone Number Entry These can be accessed by pressing the recent calls button on the Phone main screen. 1. Push the VR button on your steering wheel 1. Press the Phone button on the You can also push the VR button on your to begin.
Page 442 MULTIMEDIA answer button on the touchscreen or caller ID Automatic reply messages can be: Making A Second Call While Current Call Is In box to place the current call on hold and answer Progress “I am driving right now, I will get back to you ...
Page 443 MULTIMEDIA Call Termination Browsing SMS Connect Or Disconnect Link Between The Uconnect Phone And Mobile Phone To end a call in progress, momentarily press the Using the steering wheel commands, you can view and manage the last 10 SMS messages If you would like to connect or disconnect the Phone End button on the touchscreen or the Phone End button on the steering wheel.
Page 444 MULTIMEDIA Performance is maximized under: NOTE: Performance such as audio clarity, echo, and It is recommended that you do not store names loudness to a large degree rely on the phone Low-To-Medium Blower Setting  in your favorites phonebook while the vehicle is and network, and not the Uconnect Phone.
Page 445: Off-Road Pages - If Equipped
MULTIMEDIA OFF-ROAD PAGES — IF EQUIPPED AGES TATUS The Off-Road Pages Status Bar is located along Your vehicle may be equipped with Off-Road the bottom of Off-Road Pages and is present in Pages, which displays vehicle information each of the three selectable page options. It related to the drivetrain, transfer case, and provides information for the following items: coolant/oil gauges.
Page 446: Pitch & Roll
MULTIMEDIA & R ITCH RIVETRAIN The Pitch & Roll page displays the vehicle’s The Drivetrain page displays information current pitch (angle up and down) and roll concerning the vehicle’s drivetrain. (angle side to side) in degrees.The Pitch & Roll The following information is displayed: gauge provide a visualization of the current Steering angle in degrees ...
Page 447: Accessory Gauge
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS left-hand control is different depending on CCESSORY AUGE which mode you are in. The Accessory Gauge page displays the current The remote sound system controls are located The following describes the left-hand control status of the vehicle’s Coolant Temperature, Oil on the rear surface of the steering wheel.
Page 448: Aux/Usb/Mp3 Control
MULTIMEDIA AUX/USB/MP3 CONTROL Both ports share a single data connection. Depending on your vehicle’s specifications, the  The user cannot switch between Type A or USB Port may contain playback capabilities and The Media Hub is located on the instrument Type C.
Page 449: Jeep Wireless Speaker - If Equipped
MULTIMEDIA When a new device or smartphone is plugged Getting To Know Your Speaker into the USB ports, the following message will display depending on the device being utilized: “A new device is now connected. Previous  connection was lost”. “(Phone Name) now connected.
Page 450 5.5mm by 2.5mm. right rear passenger seat. In order to access the charging. Power adapter is not included. Jeep wireless speaker, the seat will need to be Charging The Speaker folded down or tilted forward. Monitoring Battery Level Status LED...
Page 451 NOTE: lithium-ion rechargeable battery. Typical seconds to turn the Jeep wireless speaker If the Jeep wireless speaker is left on with an charging temperatures for these types of inactive Bluetooth® connection for 30 minutes, batteries are from 32 to 113°F (0 to 45°C).
Page 452 To reduce the risk of fire or electric shock, do mode, the volume will not have independent A feature of the Jeep wireless speaker is being not expose the Jeep wireless speaker to rain or speaker control. Pushing the Up or Down able to pair two Jeep wireless speakers together moisture while charging.
Page 453 Jeep follows Safety Instruction for CE- LV. Do not suitable for children under age 3. Do not supply in any way. If either becomes deformed,...
Page 454: Radio Operation And Mobile Phones
AFETY CAUTION! exist. The Commission may adopt implementing NFORMATION If needed, Jeep wireless speaker should be acts specifying how to present that information. USA/CANADA cleaned using a damp cloth and water. Do not Those implementing acts shall be adopted in...
Page 455 MULTIMEDIA The following regulatory statement applies to all 2. l'utilisateur de l'appareil doit accepter tout NOTE: Radio Frequency (RF) devices equipped in this brouillage radioélectrique subi, même si le This equipment has been tested and found to  vehicle: brouillage est susceptible d'en compro- comply with the limits for a Class B digital mettre le fonctionnement.
Page 456: Uconnect Voice Recognition Quick Tips
MULTIMEDIA UCONNECT VOICE RECOGNITION QUICK TIPS If you see the NAV icon on the bottom bar or in the Apps menus of your 8.4-inch touchscreen, you have the Uconnect 4C NAV system. If not, NTRODUCING CONNECT you have a Uconnect 4C with 8.4-inch display Start using Uconnect Voice Recognition (VR) system.
Page 457: Basic Voice Commands
MULTIMEDIA 5. You can interrupt the help message or “Cancel” to stop a current voice session EDIA  system prompts by pushing the VR or Phone “Help” to hear a list of suggested Voice Uconnect offers connections via USB,  button and saying a Voice Command from Commands Bluetooth®...
Page 458: Phone
MULTIMEDIA TIP: HONE PRE-DEFINED VOICE TEXT REPLY When providing a Voice Command, push the VR RESPONSES Making and answering hands-free phone calls button on the steering wheel or Phone button is easy with Uconnect. When the Phonebook Yes. and say “Call”, then pronounce the name Stuck in See you later.
Page 459: Climate - If Equipped
MULTIMEDIA (4C NAV) — I Apple® iPhone® iOS 6 or later supports reading To begin, ensure Siri is enabled on your AVIGATION QUIPPED incoming text messages only. For further iPhone®. Pair your Siri-enabled device to your The Uconnect navigation feature helps you save information on how to enable this feature on Uconnect System.
Page 460: Android Auto™ - If Equipped
MULTIMEDIA ® — I While in Do Not Disturb, Conference Call can be using the factory-provided USB cable, and press PPLE QUIPPED selected so you can still place a second call the new Android Auto™ icon that replaces your NOTE: without being interrupted by incoming calls.
Page 461: General Information
MULTIMEDIA Maps 1. This device may not cause harmful NOTE:  interference, and Changes or modifications not expressly Additional Apps  approved by the party responsible for compli- 2. This device must accept any interference ance could void the user’s authority to operate Refer to "Apple Carplay®"...
Page 462: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE IF YOU NEED ASSISTANCE If an authorized dealer is unable to resolve  the concern, you may contact the manufac- FOR YOUR VEHICLE The manufacturer and its authorized dealers turer's customer center. are vitally interested in your satisfaction. We Any communication to the manufacturer's REPARE PPOINTMENT...
Page 463: Fca Canada Inc. Customer Center
CUSTOMER ASSISTANCE FCA C additional protection beyond your vehicle’s ANADA USTOMER ENTER USTOMER SSISTANCE warranty. If you purchased a Mopar Vehicle (TDD/ EARING PEECH MPAIRED P.O. Box 1621 Protection Plan, you will receive Plan Provisions TTY) and an Owner Identification Card in the mail Windsor, Ontario N9A 4H6 within three weeks of the vehicle delivery date.
Page 464: Warranty Information
CUSTOMER ASSISTANCE designed by the same engineers that created To contact NHTSA, you may call the WARNING! your vehicle, to make it truly yours. From Vehicle Safety Hotline toll free at Engine exhaust (internal combustion engines winches to axles, from suspension to the LED 1-888-327-4236 (TTY: only), some of its constituents, and certain off-road lights, these parts have been crafted to...
Page 465: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals Owner's Manuals Diagnostic Procedure Manuals are filled with These Owner's Manuals have been prepared To order the following manuals, you may use diagrams, charts and detailed illustrations. with the assistance of service and engineering either the website or the phone numbers listed These practical manuals make it easy for specialists to acquaint you with specific FCA US...
Page 466 INDEX ......61 ....59 Air Conditioning Filter Automatic Temperature Control (ATC) .........356 ........59 ........ 209 About Your Brakes Air Conditioning System Automatic Transmission .......60 ..........332 Adaptive Cruise Control (ACC) (Cruise Air Conditioning, Operating Tips Adding Fluid ............230 ............319 ........... 214 Control) Air Filter Autostick...
Page 467 Bluetooth Carpeting ............352 Contract, Service ........... 461 Connect Or Disconnect Link Between the Cellular Phone ..........452 Cooling Pressure Cap (Radiator Cap) .... 327 Uconnect Phone And Mobile Phone ..441 Center High Mounted Stop Light ....285 Cooling System ..........
Page 468 ............440 ............358 Disturb Emergency, In Case Of Ethanol ..........457 ..........293 ........196 Do Not Disturb Jacking Exhaust Gas Caution ............. 82 ........... 301 ........359 Door Frame Jump Starting Exhaust Gas Cautions ..........82 ..........308 ........196 Installation Tow Hooks Exhaust System...
Page 469 Fog Lights ............284 HomeLink (Garage Door Opener) .....91 Fog Lights, Service .........284 Garage Door Opener (HomeLink) ....91 Hood Prop ............88 Fold-Flat Seats ..........33 Gas Cap (Fuel Filler Cap) ..... 256 Hood Release ...........88 Folding Rear Seats .......... 36 Gasoline, (Fuel) ..........
Page 470 ....... 285 ......152 Center Mounted Stop Low Tire Pressure System .........44 .......63 Key Fob Daytime Running Lowering The Soft Top .......... 22 ......45 .......... 323 Arm The System Dimmer Switch, Headlight Lubrication, Body ........22 ..........44 ..........356 Disarm The System Exterior Lug Nuts/Bolts ....
Page 471 Pairing A Phone ..........409 Rear ParkSense System ........ 243 New Vehicle Break-In Period ......203 Parking Brake ..........203 Recreational Towing ........266 ParkSense System, Rear ......243 Shifting Into Transfer Case Neutral (N) ..267 Passive Entry ...........25 Shifting Out Of Transfer Case Occupant Restraints ........158 Pets...
Page 472 ..........182 ........... 164 ........269 Restraints, Child Pretensioners Side Step Removal ..........39 ..........160 .......198 Restraints, Head Rear Seat Signals, Turn ..........9 ..........159 ..............457 Roll Over Warning Reminder Siri ...........108 ........164 ........418 Roof Type Carrier Seat Belt Extender Sirius Satellite Radio ..........345...
Page 473 Starting ..........199 Tread Wear Indicators ......341 Automatic Transmission ......199 Tailgate ............89 Wheel Nut Torque ........356 Button ............15 Telescoping Steering Column ......41 To Open Hood ..........88 Cold Weather ..........202 Temperature Control, Automatic (ATC) .....59 Tongue Weight/Trailer Weight ......
Page 474 ..........330 ....442 ....435 Transfer Case Bluetooth Communication Link Pair Additional Mobile Phones ............362 ... 439 ....... 437 Fluid Call By Saying A Phonebook Name Phonebook Download ......215 ......414 ....440 Four-Wheel-Drive-Operation Call Continuation Place/Retrieve A Call From Hold ..........330 ..........
Page 475 Windshield Vanity Mirrors ..........44 Warnings And Cautions ........10 Folding ............85 Vehicle Identification Number (VIN) ....356 Warnings, Roll Over ........... 9 Windshield Defroster ........197 Vehicle Loading ........257 Warranty Information ........462 Windshield Washers ......48 Vehicle Modifications/Alterations ....10 Washers, Windshield ........
Page 479 Some states or provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a ®...
Page 480 © 2020 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep GLADIATOR 2020 Owner's Manual

Quick Links

Related Manuals for Jeep GLADIATOR 2020

Summary of Contents for Jeep GLADIATOR 2020
