Summary of Contents for Jeep 2020 RENEGADE

Page 1 202 0 R EN EGAD E OWN ER’S MA N UA L...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................8 GETTING TO KNOW YOUR VEHICLE ...................11 GETTING TO KNOW YOUR INSTRUMENT PANEL ............78 SAFETY ............................99 STARTING AND OPERATING ....................156 IN CASE OF EMERGENCY ....................238 SERVICING AND MAINTENANCE ..................279 TECHNICAL SPECIFICATIONS ....................324 MULTIMEDIA ..........................
Page 4 INTRODUCTION UCONNECT VOICE RECOGNITION QUICK SENTRY KEY............19 Key Programming ........19 TIPS ...............36 HOW TO USE THIS MANUAL ......... 9 Replacement Keys........19 Introducing Voice Recognition....36 Essential Information ........9 General Information ........19 Get Started........... 36 Symbols ............9 VEHICLE SECURITY ALARM —...
Page 5 HOOD ..............66 WIPERS AND WASHERS ........45 WARNING/INDICATOR LIGHTS AND Front Wiper Operation ......... 45 To Open The Hood ........66 MESSAGES ............86 Rain Sensing Wipers — If Equipped ... 46 To Close The Hood........66 Red Warning Lights ........87 Rear Wiper Operation ........
Page 6 Resume Speed .......... 178 Supplemental Restraint Systems (SRS)...130 NINE-SPEED AUTOMATIC TRANSMISSION — IF Child Restraints .........141 Deactivation..........178 EQUIPPED ............165 Transporting Pets........153 ADAPTIVE CRUISE CONTROL (ACC) — Gear Selector ..........166 SAFETY TIPS ............153 IF EQUIPPED............178 Gear Ranges ..........167 Transporting Passengers ......153 Adaptive Cruise Control (ACC) Transmission Limp Home Mode....170 Exhaust Gas ..........153...
Page 7 FRONT AND REAR PARKSENSE — TRAILER TOWING..........226 Body Computer Fuse Center.....259 Rear Cargo Fuse/Relay Distribution IF EQUIPPED ............194 Common Towing Definitions .....227 Unit ............. 261 Trailer Hitch Classification ......228 ParkSense Sensors ........195 JACKING AND TIRE CHANGING ....... 262 Trailer Towing Weights (Maximum Trailer ParkSense Warning Display ......195 Weight Ratings)..........229 Jack Location/Spare Tire Stowage ..
Page 8 SERVICING AND MAINTENANCE Tire Chains And Traction Devices ....316 E-85 Usage In Non-Flex Fuel Vehicles..326 Tire Rotation Recommendations .....317 CNG And LP Fuel System Modifications .. 326 SCHEDULED SERVICING ........279 DEPARTMENT OF TRANSPORTATION UNIFORM MMT In Gasoline........327 Maintenance Plan........280 Materials Added To Fuel ......327 TIRE QUALITY GRADES ........318 ENGINE COMPARTMENT ........
Page 9 CUSTOMER ASSISTANCE ANDROID AUTO™ & APPLE CARPLAY® — IF CONNECTED SERVICES FAQs ......458 EQUIPPED ............408 SiriusXM Guardian™ Business Hours: ..458 SUGGESTIONS FOR OBTAINING SERVICE FOR Connected Services SOS FAQs ....458 Android Auto™ ...........408 YOUR VEHICLE ..........466 Connected Services Roadside Assistance Apple CarPlay®...
Page 10: Introduction
For this reason, it reserves the right to make changes to the model described for technical and/or commercial reasons. For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® vehicle best, have factory-trained technicians and genuine MOPAR® parts, and care about your satisfaction.
Page 11: How To Use This Manual
HOW TO USE THIS MANUAL Essential Information Consult the Table of Contents to determine which section contains the information you desire. Since the specification of your vehicle depends on the items of equipment ordered, certain descriptions and illustrations may differ from your vehicle's equipment.
Page 12: Warnings And Cautions
Rollover Warning Label Failure to use the driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the US government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 13: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE KEYS 66 ft (20 m). The key fob does not need to be pointed at the vehicle to activate the system. Your vehicle uses a keyless ignition system. The ignition system consists of a key fob with Remote Keyless Entry (RKE) and a START/STOP push button ignition system.
Page 14 GETTING TO KNOW YOUR VEHICLE To Unlock The Doors And Liftgate 1st Push Of Key Fob Unlock Button Vehicles Equipped With Keyless Enter-N-Go — Passive Entry This feature lets you program the system to Push and release the unlock button on the key unlock either the driver's door or all doors on If one or more doors are open, or the liftgate is fob once to unlock the driver's door or twice...
Page 15 GETTING TO KNOW YOUR VEHICLE 1. Remove the emergency key by sliding the mechanical latch on the back of the key fob sideways with your thumb and pull the emergency key out with your other hand. Emergency Key Removal Key Fob Battery Replacement 3.
Page 16 GETTING TO KNOW YOUR VEHICLE Programming Additional Key Fobs NOTE: Le présent appareil est conforme aux CNR d`Innovation, Science and Economic Programming the key fob may be performed by When having the Sentry Key Immobilizer  Development applicables aux appareils radio an authorized dealer.
Page 17: Ignition Switch
GETTING TO KNOW YOUR VEHICLE IGNITION SWITCH NOTE: The vehicle will not start if the key fob is located Keyless Enter-N-Go — Ignition inside the cargo area and the liftgate is opened. This feature allows the driver to operate the WARNING! ignition switch with the push of a button as long as the key fob is in the passenger compartment.
Page 18: Remote Starting System - If Equipped
GETTING TO KNOW YOUR VEHICLE How To Use Remote Start Brake switch inactive (brake pedal not  CAUTION! pushed) Push Remote Start button on the key fob  An unlocked vehicle is an invitation for twice within five seconds. Pushing the Battery at an acceptable charge level ...
Page 19: Remote Start Cancel Message - If Equipped
GETTING TO KNOW YOUR VEHICLE Remote Start Cancel Message — If Equipped NOTE: To Exit Remote Start Mode And Drive The Vehicle The following messages will display in the If an engine fault is present or fuel level is  instrument cluster if the vehicle fails to remote Before the end of 15 minute cycle, push and low, the vehicle will start and then shut down...
Page 20: Remote Start Comfort Systems - If Equipped
GETTING TO KNOW YOUR VEHICLE Remote Start Comfort Systems — If General Information 1. l'appareil ne doit pas produire de Equipped brouillage, et The following regulatory statement applies to all Radio Frequency (RF) devices equipped in this When Remote Start is activated, the heated 2.
Page 21: Sentry Key
GETTING TO KNOW YOUR VEHICLE SENTRY KEY If the vehicle security light turns on during CAUTION! normal vehicle operation (vehicle running for The Sentry Key Immobilizer system prevents longer than 10 seconds), it indicates that there Always remove the key fobs from the ...
Page 22: Vehicle Security Alarm - If Equipped
GETTING TO KNOW YOUR VEHICLE This device complies with Part 15 of the FCC 1. es posible que este equipo o dispositivo no To Arm The System Rules and with Innovation, Science and cause interferencia perjudicial y Follow these steps to arm the vehicle security Economic Development Canada license-exempt alarm: 2.
Page 23: To Disarm The System
GETTING TO KNOW YOUR VEHICLE DOORS To Disarm The System The vehicle security alarm is designed to protect your vehicle. However, you can create The vehicle security alarm can be disarmed Manual Door Locks conditions where the system will give you a false using any of the following methods: alarm.
Page 24: Power Door Locks
GETTING TO KNOW YOUR VEHICLE Power Door Locks WARNING! (Continued) A power door lock switch is located on each of When leaving the vehicle, always remove  the front door trim panels. Use this switch to the key fob from the vehicle and lock your lock or unlock the doors, liftgate and fuel door.
Page 25: Keyless Enter-N-Go - Passive Entry
GETTING TO KNOW YOUR VEHICLE The doors can also be locked and unlocked with The key fob may not be able to be detected by NOTE:  the Keyless Enter-N-Go — Passive Entry system the vehicle’s Passive Entry system if it is If “Unlock All Doors 1st Press”...
Page 26 GETTING TO KNOW YOUR VEHICLE Do NOT grab the door handle when pushing the NOTE: 2. A lock request is made by the Passive Entry door handle lock button. This could unlock the door handle while a door is open. The Passive Entry system will not operate if ...
Page 27 GETTING TO KNOW YOUR VEHICLE To Unlock/Enter The Liftgate The liftgate Passive Entry unlock feature is built into the electronic liftgate release. With a valid Passive Entry key fob within 5 ft (1.5 m) of the liftgate, push the Electronic Liftgate release to open with one fluid motion.
Page 28: Automatic Unlock On Exit Feature - If
GETTING TO KNOW YOUR VEHICLE This device complies with Part 15 of the FCC 1. es posible que este equipo o dispositivo no WARNING! Rules and with Innovation, Science and cause interferencia perjudicial y Never leave children alone in a vehicle, or Economic Development Canada license-exempt ...
Page 29: Child Locks
GETTING TO KNOW YOUR VEHICLE Arming The Dead Lock Device Child Locks NOTE: The device works on all doors and requires  To provide a safer environment for small When the Child-Protection Door Lock system  two pushes of the lock button on the key fob. children riding in the rear seats, the rear doors is engaged, the door can only be opened by For vehicles equipped with Passive Entry, the...
Page 30: Seats
GETTING TO KNOW YOUR VEHICLE SEATS Manual Front Seats Manual Front Seats Forward/Rearward Adjustment Seats are a part of the Occupant Restraint WARNING! On models equipped with manual seats, the System of the vehicle. adjusting bar is located at the front of the seats, Adjusting a seat while the vehicle is moving ...
Page 31: Manual Rear Seat Adjustment
GETTING TO KNOW YOUR VEHICLE Height Adjustment mid-track position. Be sure that the front seats are fully upright and positioned The driver’s seat height can be raised or forward, this will allow the rear seat to fold lowered by using a lever, located on the down easily.
Page 32 GETTING TO KNOW YOUR VEHICLE Cargo Area Enlargement 3. Move the seat belts to the outboard side of Seatback Repositioning the seat and rest them on the seat belt Folding both sides of the rear seat provides NOTE: guide. additional storage in the rear cargo area. If interference from the cargo area prevents the Proceed as follows: 4.
Page 33: Power Adjustment (Front) - If Equipped
GETTING TO KNOW YOUR VEHICLE Power Adjustment (Front) — If Equipped Adjusting The Seat Forward Or Rearward Reclining The Seatback The seat can be adjusted both forward and The angle of the seatback can be adjusted The power seat controls are located on the rearward.
Page 34: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE Press the heated seat button a second  CAUTION! WARNING! time to turn the LO setting on. Do not place any article under a power seat Persons who are unable to feel pain to the ...
Page 35: Unfolding The Rear Armrest 40/20/40
GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS Unfolding The Rear Armrest 40/20/40 The center part of the rear seat can also be used as a rear armrest with cupholders. Pull the rear armrest tab to release it from the Head restraints are designed to reduce the risk seat and pull forward.
Page 36: Front Head Restraints
GETTING TO KNOW YOUR VEHICLE Front Head Restraints To raise the head restraint, pull upward on the WARNING! head restraint. Your vehicle is equipped with front driver and All occupants, including the driver, should  To lower the head restraint, push the passenger head restraints.
Page 37: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL To lock the steering column in position, pull the Auto Comfort Systems — If Equipped tilt/telescoping lever upward until fully In vehicles equipped with Auto On Comfort, Tilt/Telescoping Steering Column engaged. when turning on the vehicle the heated steering wheel will automatically turn on when This feature allows you to tilt the steering WARNING!
Page 38: Uconnect Voice Recognition Quick Tips
GETTING TO KNOW YOUR VEHICLE UCONNECT VOICE RECOGNITION QUICK TIPS If you see the NAV icon on the bottom bar or in the Apps menu of your 8.4-inch touchscreen, Introducing Voice Recognition you have the Uconnect 4C NAV system. If not, you have a Uconnect 4C with 8.4-inch display Start using Uconnect Voice Recognition with system.
Page 39: Basic Voice Commands
GETTING TO KNOW YOUR VEHICLE Notice the visual cues that inform you of your 1. l'appareil ne doit pas produire de Voice Recognition system’s status. brouillage, et General Information 2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le The following regulatory statement applies to all brouillage est susceptible d'en compro- Radio Frequency (RF) devices equipped in this...
Page 40: Additional Information
GETTING TO KNOW YOUR VEHICLE Additional Information the mirror is set in the day position (toward the dimming feature is activated. The sensor to the windshield). right of the button does not illuminate. © 2019 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC.
Page 41 GETTING TO KNOW YOUR VEHICLE NOTE: Manual Adjustment Mirrors — If Equipped To adjust the exterior mirrors, push the corners To adjust the power mirrors, the ignition must  of the mirrors till desired alignment is obtained. be in the ON/RUN position. The power mirror switches will remain active ...
Page 42: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS Heated Mirrors — If Equipped Daytime Running Lights (DRLs) — If Equipped These mirrors are heated to melt frost Headlights or ice. This feature can be activated The Daytime Running Lights (DRLs), if enabled The headlight switch is located on the left side whenever you turn on the Rear through Uconnect Settings, will turn on when...
Page 43: Flash-To-Pass
GETTING TO KNOW YOUR VEHICLE automatic system off, move the headlight NOTE: switch out of the AUTO position. The multifunction lever must be in the high  NOTE: beam position in order to activate the Auto- matic High Beams. The ignition must be in the ON/RUN position before the headlights will come on in the auto- The Automatic High Beam Headlamp Control ...
Page 44: Headlight Delay
GETTING TO KNOW YOUR VEHICLE Headlight Delay NOTE: Cornering Lights The lights must be turned off within two minutes The cornering lights are a feature to improve This feature provides the safety of headlight of placing the ignition in the STOP/OFF position visibility at night while turning the vehicle.
Page 45: Lane Change Assist
GETTING TO KNOW YOUR VEHICLE Lane Change Assist instrument panel lights, door map pocket lights, Front Lights and cubby bin lights. The courtesy lights are mounted between the Tap the lever up or down once, without moving With the parking lights or headlights on, rotate sun visors above the rear view mirror.
Page 46 GETTING TO KNOW YOUR VEHICLE To operate the courtesy lights, push either the Vehicles With Retractable Roof Timing Entering The Vehicle driver or passenger light switch. The dome lights illuminate in the following ways: For vehicles equipped with a retractable roof, there are two interior lights located above the When the doors are unlocked, the dome light NOTE:...
Page 47: Wipers And Washers
GETTING TO KNOW YOUR VEHICLE Timing Exiting The Vehicle Windshield Washer Operation The dome light will illuminate under the To use the washer, pull the lever toward you and following conditions when the ignition is placed hold while spray is desired. If the lever is pulled to the OFF position and the key is removed: while in the intermittent setting, the wipers will turn on and operate for several wipe cycles after...
Page 48: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE Mist This function can be activated or deactivated by windscreen, blocking the blades in ice/snow the Uconnect Settings through the radio. Refer conditions). The user can activate the Rain Use this feature when weather conditions make to “Uconnect Settings”...
Page 49: Rear Wiper Operation
GETTING TO KNOW YOUR VEHICLE Use of Rain-X or products containing wax or front and rear wipers to sync up. Turning the defroster automatically turns off after  silicone may reduce Rain Sensing perfor- front wipers off will cause the rear wipers to also approximately 20 minutes.
Page 50: Windshield Wiper De-Icer - If Equipped
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS Activation By Remote Start Operation —  CAUTION! (Continued) When Remote Start is active and the outside The Climate Control System allows you to ambient temperature is less than 40°F Do not use scrapers, sharp instruments, or ...
Page 51: Manual Climate Controls Overview
GETTING TO KNOW YOUR VEHICLE Manual Climate Controls Overview Center Air Outlets Right Side Air Outlets 1 — Fixed Air Outlet 1 — Fixed Air Outlet Manual Climate Controls 2 — Air Flow Outlet Adjustment 2 — Adjustable Air Outlet 3 —...
Page 52 GETTING TO KNOW YOUR VEHICLE Icon Description Recirculation Button Push the Recirculation button on the Blower Control knob to change the system between recirculation mode and outside air mode. The Recirculation LED light illuminates when Recirculation mode is on. Recirculation can be used when outside conditions, such as smoke, odors, dust, or humidity are present. Recirculation can be used in all modes except for Defrost.
Page 53: Automatic Climate Control Overview
GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Overview Uconnect 4 with 7-inch Display Automatic Climate Controls...
Page 54 GETTING TO KNOW YOUR VEHICLE Uconnect 4C NAV with 8.4-inch Display Automatic Climate Controls...
Page 55 GETTING TO KNOW YOUR VEHICLE Automatic Climate Control Descriptions Icon Description MAX A/C Button MAX A/C sets the system for maximum cooling performance. Push the button to turn on the MAX A/C setting. In MAX A/C, the blower speed and mode position can be adjusted to desired user settings. NOTE: The MAX A/C button is only on the touchscreen.
Page 56 GETTING TO KNOW YOUR VEHICLE Icon Description Front Defrost Button The Front Defrost button changes the current airflow setting to Defrost mode. The indicator illuminates when this feature is on. Air comes from the windshield and side window demist outlets. When the defrost button is selected, the blower level may increase.
Page 57 GETTING TO KNOW YOUR VEHICLE Icon Description Driver and Passenger Temperature Control Push these buttons to regulate the temperature of the driver and passenger settings independently. Pushing the blue arrow indicates cooler temperatures, while pushing the red button indicates warmer temperatures. SYNC Button Press the SYNC button on the touchscreen to toggle the SYNC feature on/off.
Page 58 GETTING TO KNOW YOUR VEHICLE Icon Description Panel Mode Panel Mode Air comes from the outlets in the instrument panel. Each of these outlets can be individually adjusted to direct the flow of air. The air vanes of the center outlets and outboard outlets can be moved up and down or side to side to regulate airflow direction.
Page 59: Climate Voice Commands
GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) To provide you with maximum comfort in the Operating Tips automatic mode, during cold start-ups, the NOTE: Automatic Operation blower fan will remain on low until the engine Refer to the chart at the end of this section for warms up.
Page 60 GETTING TO KNOW YOUR VEHICLE Vacation/Storage Cabin Air Filter CAUTION! Before you store your vehicle, or keep it out of The climate control system filters out dust and Failure to follow these cautions can cause service (i.e., vacation) for two weeks or more, pollen from the air.
Page 61 GETTING TO KNOW YOUR VEHICLE Air Recirculation System Maintenance CONTROL WEATHER Push and release the Air Recirculation button so In Winter, the Climate Control system must be SETTINGS that the LED is on, to enter recirculation mode. turned on at least once a month for Operate in posi- It is recommended to turn the internal air...
Page 62: Windows
GETTING TO KNOW YOUR VEHICLE WINDOWS NOTE: WARNING! If the Remote Start functionality is active, it is  Power Window Controls Never leave children unattended in a vehicle, not possible to move any windows. and do not let children play with power win- The power window switch is located on the dows.
Page 63: Auto-Up Feature With Auto-Reverse
GETTING TO KNOW YOUR VEHICLE Auto-Up Feature With Auto-Reverse down, or the sunroof (if equipped) in certain WARNING! open or partially open positions. This is a normal Protection — If Equipped There is no auto-reverse protection when the occurrence and can be minimized. If the The driver door power window switch and the window is almost closed.
Page 64 GETTING TO KNOW YOUR VEHICLE Venting The Front Panel Sunroof Reinitialization To vent the front panel push and release the The following procedure must be followed to vent switch. reinitialize the sunroof and calibrate obstacle detection: During the vent operation any push on the open/close switch will stop the closing of the 1.
Page 65: Emergency Open/Close
GETTING TO KNOW YOUR VEHICLE 9. As the front panel close switch is held, the Wind Buffeting sunroof panel will cycle to the fully open Wind buffeting can be described as the position and then back to the fully closed perception of pressure on the ears or a position again.
Page 66: Power Glass Sunroof With Power
GETTING TO KNOW YOUR VEHICLE POWER GLASS SUNROOF WITH POWER Opening WARNING! SHADE — IF EQUIPPED Opening Sunroof Never leave children unattended in a  To retract the sunroof to the open position, push vehicle, or with access to an unlocked The power sunroof switches are located the Open/Close switch and the sunroof will fully vehicle.
Page 67: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE Wind Buffeting Closing Power Shade — Automatic Mode WARNING! Pull the shade switch for about one-half second Wind buffeting can be described as the Do not let children play with the sunroof.  and the shade will automatically close. During perception of pressure on the ears or a Never leave children unattended in a the automatic close operation, any movement...
Page 68: Sunroof Maintenance
GETTING TO KNOW YOUR VEHICLE Sunroof Maintenance Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. HOOD To Open The Hood Two latches must be released to open the hood. 1. Pull the hood release lever located under Safety Latch Support Rod And Seat the driver’s side of the instrument panel.
Page 69: Liftgate
GETTING TO KNOW YOUR VEHICLE WARNING! Be sure the hood is fully latched before driv- ing your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 70: Closing
GETTING TO KNOW YOUR VEHICLE Closing NOTE: 3. Clear the pins placed outside of the shelf, The liftgate unlock feature is built into the elec- and then remove the rear shelf pulling it Grasp the liftgate pull handle and initiate tronic liftgate release.
Page 71 GETTING TO KNOW YOUR VEHICLE Cargo Load Floor The load floor provides securing of any cargo Access To The Loading Floor inside this position, so that the cargo will not The vehicle is equipped with a load floor that To access the double load compartment, slide in the case of sudden braking.
Page 72 GETTING TO KNOW YOUR VEHICLE 3. Reposition the load floor. Access To Tire Service Kit Or Spare Tire To access the Tire Service Kit or spare tire and container carrier, proceed as follows: 1. Grasp the load floor handle and remove the floor.
Page 73: Internal Equipment
GETTING TO KNOW YOUR VEHICLE INTERNAL EQUIPMENT Cargo Box — If Equipped Once the glove compartment is open, a light will turn on to illuminate the compartment. The cargo area contains a preformed cargo box Glove Compartment that can be used for the storage of objects that NOTE: allows you to obtain a uniform level when The glove compartment is located on the...
Page 74: Usb/Media Player Control
GETTING TO KNOW YOUR VEHICLE USB/Media Player Control This feature allows an external device to be plugged into the USB port or AUX Jack. Sun Visor Mirror Sliding Sun Visor 1 — Sun Visor Mirror Cover 3. Slide out the sun visor extender for even more side coverage toward the rear.
Page 75: Power Outlets
GETTING TO KNOW YOUR VEHICLE Rear Center Console USB Port Power Outlets WARNING! Located on the rear of the center console is a The front power outlet is located under the To avoid serious injury or death: second USB port. center stack of the instrument panel.
Page 76: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE consoles will exceed this power limit, as will CAUTION! most power tools. Many accessories that can be plugged in  draw power from the vehicle's battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle's battery will discharge sufficiently to degrade battery life and/or prevent the...
Page 77: Cigar Lighter - If Equipped
GETTING TO KNOW YOUR VEHICLE WARNING! CAUTION! To avoid serious injury or death: Do not connect devices with power higher than 180 Watts (15 Amps) to the socket. Do Do not insert any objects into the recepta-  not damage the socket by using unsuitable cles.
Page 78: Front Armrest
GETTING TO KNOW YOUR VEHICLE Front Armrest Push the storage handle and lift up the armrest to access the storage compartment. The front armrest is located between the front seats. WARNING! The armrest can be adjusted by moving it Do not operate this vehicle with a console forward or rearward.
Page 79: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED WARNING! CAUTION! (Continued) Your vehicle may be equipped with a Roof Cargo must be securely tied down before driv- Travel at reduced speeds and turn corners  Luggage Rack for transporting accessories. ing your vehicle.
Page 80: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Base Instrument Cluster...
Page 81: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL Premium Instrument Cluster Instrument Cluster Descriptions 2. Temperature Gauge The gauge will likely indicate a higher  temperature when driving in hot weather The temperature gauge shows engine  1. Tachometer or up mountain grades. It should not be coolant temperature.
Page 82: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL 4. Fuel Gauge controls allow you to scroll through and enter WARNING! the main menus and submenus. You can The fuel gauge shows the level of fuel in  A hot engine cooling system is dangerous. access the specific information you want and the fuel tank when the ignition is in the You or others could be badly burned by steam...
Page 83: Oil Change Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL The instrument cluster display menu items BACK/LEFT Arrow Button  consist of the following: Push and release the left arrow Speedometer  button to access the information screens or submenu screens of a Vehicle Info ...
Page 84: Instrument Cluster Display Menu Items
GETTING TO KNOW YOUR INSTRUMENT PANEL Unless reset, this message will continue to Instrument Cluster Display Menu Items Coolant Temperature — View the engine  coolant temperature. display each time the ignition is cycled to the ON NOTE: or RUN position. To reset the oil change Trans Temperature —...
Page 85 GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Economy Elapsed Time – Shows the total elapsed time Pushing the left or right arrow button will allow  of travel since Trip A or Trip B has been reset. you to scroll through the stored messages. This menu item allows you to view the fuel economy of the vehicle.
Page 86 GETTING TO KNOW YOUR INSTRUMENT PANEL In The Upper Left/Top Right Distance Traveled A (Trip A) Vehicles Equipped With Multi-functional Display  Reconfigurable: The information relating to the following can be Distance Traveled B (Trip B)  displayed: The following menu/submenu items are Restore Default Settings available in the cluster display.
Page 87 GETTING TO KNOW YOUR INSTRUMENT PANEL “Clock & Date” Driver may also turn the Speed Warning Cornering lights: activate/deactivate the  “OFF” should you choose not to use this cornering lights (If Equipped) By selecting the item, “Clock & Date” you can feature.
Page 88: Trip Computer
GETTING TO KNOW YOUR INSTRUMENT PANEL Remote Door Unlock: allows you to open the “Trip A” and “Trip B” are used to display the New trip  driver door only on the first push of the figures relating to: Starts after reset: UNLOCK button on the key fob Distance Traveled ...
Page 89: Red Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL All active telltales will display first, if applicable. on while driving, have an authorized dealer Brake Warning Light, which will turn on when The system check menu may appear different service the vehicle immediately. the brake fluid level in the master cylinder has based upon equipment options and current dropped below a specified level.
Page 90 GETTING TO KNOW YOUR INSTRUMENT PANEL Operation of the Brake Warning Light can be Door Open Warning Light will either stay on or flash depending on the checked by turning the ignition switch from the nature of the problem. Cycle the ignition when This indicator will illuminate when a OFF position to the ON/RUN position.
Page 91 GETTING TO KNOW YOUR INSTRUMENT PANEL Engine Temperature Warning Light Liftgate Open Warning Light Oil Temperature Warning Light This warning light will illuminate to This indicator will illuminate when the This warning light will illuminate to warn of an overheated engine liftgate is left open and not fully indicate the engine oil temperature is condition.
Page 92: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Transmission Fault Warning Light — If Adaptive Cruise Control (ACC) Fault Warning If the ABS light does not turn on when the Equipped Light — If Equipped ignition is placed in the ON/RUN or ACC/ON/ RUN position, have the brake system inspected This light will illuminate (together with This warning light will illuminate to...
Page 93 GETTING TO KNOW YOUR INSTRUMENT PANEL Icy Road Condition Indicator Light — If Refer to “LaneSense – If Equipped” in When the engine is running, the MIL may flash  “Starting And Operating” for further informa- to alert serious conditions that could lead to Equipped tion.
Page 94 GETTING TO KNOW YOUR INSTRUMENT PANEL Service 4WD Warning Light — If Equipped Tire Pressure Monitoring System (TPMS) Each tire, including the spare (if provided), Warning Light should be checked monthly when cold and This warning light will illuminate to inflated to the inflation pressure recommended signal a fault with the 4WD system.
Page 95 GETTING TO KNOW YOUR INSTRUMENT PANEL Please note that the TPMS is not a substitute for severe usage, such as trailer towing. If this light CAUTION! proper tire maintenance, and it is the driver’s turns on, safely pull over and stop the vehicle. responsibility to maintain correct tire pressure, The TPMS has been optimized for the original Then, shift the transmission into PARK and run...
Page 96: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Yellow Indicator Lights Electronic Stability Control (ESC) Active Electronic Stability Control (ESC) OFF Warning Light — If Equipped Warning Light — If Equipped 4WD Low Indicator Light — If Equipped This warning light will indicate when This warning light indicates the This light alerts the driver that the the Electronic Stability Control system...
Page 97: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Immobilizer Fail / VPS Electrical Alarm White Indicator Lights Speed Warning Indicator Light — If Equipped Indicator Light When Set Speed Warning is turned Hill Descent Control (HDC) Indicator Light — If on, the speed warning telltale will This telltale will illuminate when the Equipped vehicle security alarm system has...
Page 98: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Green Indicator Lights Park / Headlight On Indicator Light Gray Indicator Lights This indicator light will illuminate Automatic High Beam Indicator Light — If Electronic Speed Control Ready/Canceled when the park lights or headlights are Equipped Indicator Light turned on.
Page 99: Onboard Diagnostic System (Obd Ii) Cybersecurity
GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND technician in making repairs. Although your WARNING! vehicle will usually be drivable and not need MAINTENANCE PROGRAMS towing, see an authorized dealer for service as ONLY an authorized service technician  should connect equipment to the OBD II soon as possible.
Page 100 GETTING TO KNOW YOUR INSTRUMENT PANEL Your vehicle has a simple ignition actuated test, The MIL will not flash at all and will  which you can use prior to going to the test remain fully illuminated until you place station.
Page 101: Safety
SAFETY SAFETY FEATURES Brake pedal pulsations  WARNING! (Continued) A slight drop of the brake pedal at the end of  Anti-Lock Brake System (ABS) The ABS cannot prevent the natural laws of  the stop physics from acting on the vehicle, nor can The Anti-Lock Brake System (ABS) provides it increase braking or steering efficiency These are all normal characteristics of ABS.
Page 102: Electronic Brake Control (Ebc) System
SAFETY Anti-Lock Brake Warning Light Stability Control (ESC), and Electronic Roll WARNING! Mitigation (ERM). These systems work together The yellow “Anti-Lock Brake Warning Light” will to enhance both vehicle stability and control in The Brake Assist System (BAS) cannot pre- turn on when the ignition is placed in the ON/ various driving conditions.
Page 103 SAFETY maneuver to the driver. The coordinated action NOTE: be reduced to help the vehicle maintain the of brakes and steering increases the safety and ERM is disabled anytime the ESC is in “Full Off” desired path. car control feeling. mode.
Page 104 SAFETY ESC On – Two Wheel Drive Vehicles And Four WARNING! WARNING! (Continued) Wheel Drive Vehicles In 2WD And 4H Range Electronic Stability Control (ESC) cannot Vehicle modifications, or failure to properly   This is the normal operating mode for ESC when prevent the natural laws of physics from maintain your vehicle, may change the operating a two-wheel drive vehicle.
Page 105 SAFETY In this mode, ESC and TCS are turned off WARNING! (except for the “limited slip” feature described When in “Partial Off” mode, the TCS func- in the TCS section) until the vehicle reaches a  tionality of ESC, (except for the limited slip speed of 40 mph (64 km/h).
Page 106 SAFETY NOTE: NOTE: Light” begins to flash during acceleration, ease In 4L Range, the active safety systems are up on the accelerator and apply as little throttle “Full Off” is the only operating mode for ESC  completely bypassed in order to ensure as possible.
Page 107 SAFETY Hill Descent Control (HDC) — If Equipped Enabling HDC Deactivating HDC HDC is enabled by pushing the HDC switch, but HDC will be deactivated but remain available if the following conditions must also be met to any of the following conditions occur: enable HDC: Driver overrides HDC set speed with throttle ...
Page 108 SAFETY Feedback To The Driver: Hill Start Assist (HSA) WARNING! The instrument cluster has an HDC icon and the The Hill Start Assist (HSA) system is designed to There may be situations where the Hill Start HDC switch has an LED, which offers feedback help the driver accelerate the vehicle from a Assist (HSA) will not activate and slight rolling to the driver about the state HDC is in.
Page 109: Auxiliary Driving Systems
SAFETY AUXILIARY DRIVING SYSTEMS Traction Control System (TCS) appropriate wheel(s) to counteract the sway of the trailer. TSC will become active automatically The Traction Control System (TCS) monitors the Blind Spot Monitoring (BSM) — If Equipped once an excessively swaying trailer is amount of wheel spin of each of the driven recognized.
Page 110 SAFETY The BSM detection zone covers approximately The BSM system monitors the detection zone one lane width on both sides of the vehicle, from three different entry points (side, rear, 10 ft (3 m). The zone length starts at the front) while driving to see if an alert is outside mirror and extends approximately 20 ft necessary.
Page 111 SAFETY Entering From The Rear The BSM system will not alert you of objects that are traveling in the opposite direction of the Vehicles that come up from behind your vehicle vehicle in adjacent lanes. on either side and enter the rear detection zone with a relative speed of less than 31 mph (50 km/h).
Page 112 SAFETY Rear Cross Path (RCP) NOTE: Modes Of Operation In a parking lot situation, oncoming vehicles can The Rear Cross Path (RCP) feature is intended Three selectable modes of operation are be obscured by vehicles parked on either side. to aid the driver when backing out of parking available in the Uconnect System.
Page 113 SAFETY NOTE: Blind Spot Monitoring Fault Warnings NOTE: Whenever an audible alert is requested by the Vehicle must be taken to the nearest authorized Blinded Sensor BSM system, the radio is also muted. dealer for service. In the case of a sensor that is blinded: When the system is in RCP, the system will General Information BSM Mirror Warning Lights are turned on...
Page 114: Forward Collision Warning (Fcw) With Mitigation Operation - If Equipped
SAFETY Le présent appareil est conforme aux CNR Forward Collision Warning (FCW) With determines that the driver intends to avoid the collision by braking but has not applied d`Innovation, Science and Economic Mitigation Operation — If Equipped Development applicables aux appareils radio sufficient brake force, the system will The Forward Collision Warning (FCW) System compensate and provide additional brake...
Page 115 SAFETY The FCW system is intended for on-road use Turning FCW On Or Off  only. If the vehicle is taken off-road, the FCW The Forward Collision menu setting is located in system should be deactivated to prevent the Uconnect settings. unnecessary warnings to the surroundings.
Page 116 SAFETY Changing FCW Sensitivity "Far", in the case of a potential accident, “FCW Front Radar Sensor Temporarily Blocked” providing a more dynamic driving of the vehicle. Warning By changing the settings on the menu of the The setting of the sensitivity of the system is The “FCW Front Radar Sensor Temporarily Uconnect system, you can change the maintained in memory when the engine is...
Page 117 SAFETY NOTE: Lane changing of other vehicles Small Vehicles And/Or Not Aligned To The Lane  The system is not able to detect the presence of Passing of vehicles in an oncoming intersec- If the “FCW Front Radar Sensor Temporarily ...
Page 118 SAFETY Lane Changing Of Other Vehicles 2. This device must accept any interference received, including interference that may Vehicles that suddenly change lane, while cause undesired operation. standing in the traffic lane of their vehicle and inside the field of action of the radar sensor may Le présent appareil est conforme aux CNR cause the intervention of the system.
Page 119: Tire Pressure Monitoring System (Tpms)
SAFETY Tire Pressure Monitoring System (TPMS) The TPMS will warn the driver of a low tire For example, your vehicle may have a pressure if the tire pressure falls below the recommended cold (parked for more than three The Tire Pressure Monitoring System (TPMS) low-pressure warning limit for any reason, hours) placard pressure of 33 psi (227 kPa).
Page 120 SAFETY NOTE: pressure levels. Sensors, mounted to each CAUTION! wheel as part of the valve stem, transmit tire The TPMS is not intended to replace normal  The TPMS has been optimized for the orig- pressure readings to the receiver module. ...
Page 121 SAFETY shown in the "Inflate to XX" message. Once the Installing some form of aftermarket window 3. After driving the vehicle for up to  system receives the updated tire pressures, the tinting that affects radio wave signals. 20 minutes above 15 mph (24 km/h), the system will automatically update and the “Tire “TPMS Light”...
Page 122 SAFETY NOTE: The vehicle may need to be driven for up to It is particularly important for you to check the 20 minutes above 15 mph (24 km/h) in order tire pressure in all of the tires on your vehicle for the TPMS to receive this information.
Page 123 SAFETY Lots of snow or ice around the wheels or 4. The instrument cluster will display a graphic 75 seconds and then remain on solid. In  wheel housings showing the tire pressure value in the same addition, the instrument cluster will display color as the other pressure values in place a “SERVICE TPM SYSTEM”...
Page 124 SAFETY TPMS Deactivation — If Equipped then turn off, and the instrument cluster will Le présent appareil est conforme aux CNR display the “SERVICE TPM SYSTEM” message. d`Innovation, Science and Economic The TPMS can be deactivated if replacing all The instrument cluster will also display pressure Development applicables aux appareils radio four wheel and tire assemblies (road tires) with values in place of the dashes.
Page 125: Occupant Restraint Systems
SAFETY OCCUPANT RESTRAINT SYSTEMS 1. Children 12 years old and under should 7. The driver and front passenger seats should always ride buckled up in the rear seat of a be moved back as far as practical to allow Some of the most important safety features in vehicle with a rear seat.
Page 126: Seat Belt Systems
SAFETY Enhanced Seat Belt Use Reminder System BeltAlert Warning Sequence WARNING! (Continued) (BeltAlert) The BeltAlert warning sequence is activated Never install a rear-facing child restraint in  when the vehicle is moving above a specified Front Seat BeltAlert the front seat of a vehicle. Only use a vehicle speed range and the driver or outboard BeltAlert is a feature intended to remind the rear-facing child restraint in the rear seat.
Page 127 SAFETY when an animal or other items are placed on WARNING! WARNING! (Continued) the outboard front passenger seat or when the seat is folded flat (if equipped). It is Relying on the air bags alone could lead to Be sure everyone in your vehicle is in a seat ...
Page 128 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! WARNING! (Continued) 1. Enter the vehicle and close the door. Sit A lap belt worn too high can increase the A seat belt that is worn under your arm is   back and adjust the seat. risk of injury in a collision.
Page 129 SAFETY 3. When the seat belt is long enough to fit, Lap/Shoulder Belt Untwisting Procedure insert the latch plate into the buckle until Use the following procedure to untwist a twisted you hear a “click.” lap/shoulder belt. 1. Position the latch plate as close as possible to the anchor point.
Page 130 SAFETY Adjustable Upper Shoulder Belt Anchorage NOTE: WARNING! (Continued) The adjustable upper shoulder belt anchorage In the driver and outboard front passenger is equipped with an Easy Up feature. This Always make all seat belt height adjust-  seats, the top of the shoulder belt can be feature allows the shoulder belt anchorage to ments when the vehicle is stationary.
Page 131 SAFETY Seat Belt Pretensioner Switchable Automatic Locking Retractor ALR is activated, you will hear a clicking sound as the seat belt retracts. Allow the webbing to (ALR) The front outboard seat belt system is equipped retract completely in this case and then with pretensioning devices that are designed to The seat belts in the passenger seating carefully pull out only the amount of webbing...
Page 132: Supplemental Restraint Systems (Srs)
SAFETY How To Disengage The Automatic Locking Mode Supplemental Restraint Systems (SRS) WARNING! (Continued) Unbuckle the combination lap/shoulder belt Some of the safety features described in this Never install a rear-facing child restraint in  and allow it to retract completely to disengage section may be standard equipment on some the front seat of a vehicle.
Page 133 SAFETY Supplemental Knee Air Bags any part of the system, it turns on the Air Bag NOTE:  Warning Light, either momentarily or If the speedometer, tachometer, or any engine Front and Side Impact Sensors  continuously. A single chime will sound to alert related gauges are not working, the Occupant you if the light comes on again after initial Restraint Controller (ORC) may also be...
Page 134 SAFETY on until the fault is cleared. In addition, a single compartment. The words “SRS AIRBAG” or WARNING! (Continued) chime will sound to alert you that the “AIRBAG” are embossed on the air bag covers. Redundant Air Bag Warning Light has come on Never place a rear-facing child restraint in ...
Page 135 SAFETY The first stage inflator is triggered immediately On the other hand, depending on the type and WARNING! (Continued) during an impact that requires air bag location of impact, front air bags may deploy in deployment. A low energy output is used in less crashes with little vehicle front-end damage but Do not put anything on or around the air ...
Page 136 SAFETY Knee Impact Bolsters Supplemental Side Air Bags When the SAB deploys, it opens the seam on the outboard side of the seatback’s trim cover. The Knee Impact Bolsters help protect the Supplemental Seat-Mounted Side Air Bags The inflating SAB deploys through the seat knees of the driver and front passenger, and (SABs) seam into the space between the occupant and...
Page 137 SAFETY The SABICs may help reduce the risk of partial severity and type of collision. The side impact or complete ejection of vehicle occupants sensors aid the ORC in determining the through side windows in certain side impact appropriate response to impact events. The events.
Page 138 SAFETY The Side Air Bags and seat belt pretensioners WARNING! WARNING! (Continued) will not deploy in all rollover events. The rollover Occupants, including children, who are up sensing system determines if a rollover event Being too close to the Side Air Bags during ...
Page 139 SAFETY Knee Impact Bolsters If you do have a collision which deploys the air Do not drive your vehicle after the air bags have  bags, any or all of the following may occur: deployed. If you are involved in another Driver and Front Passenger Air Bags ...
Page 140 SAFETY Enhanced Accident Response System Cut off battery power to the: by following the procedure described below. If  you have any doubt, contact an authorized In the event of an impact, if the communication Engine  dealer. network remains intact, and the power remains Electric Motor (if equipped) ...
Page 141 SAFETY Customer Will See Customer Action NOTE: Each step MUST BE held for at least two seconds 1. Turn ignition STOP/OFF/LOCK. (Turn Signal Switch Must be placed in Neutral State). Right turn light BLINKS. 2. Turn ignition MAR/ACC/ON/RUN. Left turn light is OFF. Right turn light is ON SOLID.
Page 142 SAFETY Customer Will See Customer Action NOTE: Each step MUST BE held for at least two seconds 12. Turn ignition MAR/ACC/ON/RUN. (Entire sequence needs to be com- System is now reset and the engine may be started. pleted within one minute or sequence will need to be repeated). Turn hazard flashers OFF (Manually).
Page 143: Child Restraints
SAFETY Event Data Recorder (EDR) NOTE: when properly restrained in the rear seats EDR data are recorded by your vehicle only if a rather than in the front. This vehicle is equipped with an Event Data non-trivial crash situation occurs; no data are Recorder (EDR).
Page 144 SAFETY NOTE: Canadian residents should refer to Transport  Canada’s website for additional information: For additional information, refer to http://  https://www.tc.gc.ca/en/services/road/ www.nhtsa.gov/parents-and-caregivers or child-car-seat-safety.html. call 1-888-327-4236. Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and Either an Infant Carrier or a Convertible Child...
Page 145 SAFETY years old. Children should remain rear-facing Children should remain in a forward-facing child WARNING! (Continued) until they reach the highest weight or height seat with a harness for as long as possible, up allowed by their convertible child seat. to the highest weight or height allowed by the After a child restraint is installed in the ...
Page 146 SAFETY Children Too Large For Booster Seats 3. Does the shoulder belt cross the child’s A child’s squirming or slouching can move the shoulder between the neck and arm? belt out of position. If the shoulder belt contacts Children who are large enough to wear the the face or neck, move the child closer to the shoulder belt comfortably, and whose legs are 4.
Page 147 SAFETY Use Any Attachment Method Shown With An “X” Below Combined Weight of Restraint Type the Child + Child LATCH – Lower Anchors LATCH – Lower Anchors Seat Belt + Top Tether Seat Belt Only Restraint Only + Top Tether Anchor Anchor Forward-Facing Child Up to 65 lbs (29.5 kg)
Page 148 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the com- What is the weight limit (child’s weight + weight bined weight of the child and the child restraint of the child restraint) for using the LATCH 65 lbs (29.5 kg) is 65 lbs (29.5 kg).
Page 149 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH The child seat may touch the back of the front Can the rear-facing child restraint touch the passenger seat if the child restraint manufac- back of the front passenger seat? turer also allows contact.
Page 150 SAFETY LATCH-compatible child restraint systems will Always follow the directions of the child room for the child seat. You may also move be equipped with a rigid bar or a flexible strap restraint manufacturer when installing your the front seat forward to allow more room on each side.
Page 151 SAFETY How To Stow An Unused Switchable-ALR The seat belts in the passenger seating WARNING! (Continued) positions are equipped with a Switchable (ALR) Seat Belt: Automatic Locking Retractor (ALR) that is Child restraint anchorages are designed to  When using the LATCH attaching system to withstand only those loads imposed by designed to keep the lap portion of the seat belt install a child restraint, stow all ALR seat belts...
Page 152 SAFETY Lap/Shoulder Belt Systems For Installing Child Restraints In This Vehicle Automatic Locking Retractor (ALR) Locations ALR — Switchable Automatic Locking Retractor — Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight Always use the tether anchor when using the of the child restraint) for using the Tether Anchor seat belt to install a forward facing child...
Page 153 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts Can the buckle stalk be twisted to tighten the Do not twist the buckle stalk in a seating posi- seat belt against the belt path of the child tion with an ALR retractor. restraint? Installing A Child Restraint With A Switchable rear-most position to make room for the...
Page 154 SAFETY Any seat belt system will loosen with time, so 1. Look behind the seating position where check the belt occasionally, and pull it tight if you plan to install the child restraint to find necessary. the tether anchorage. You may need to move the seat forward to provide better Installing Child Restraints Using The Top access to the tether anchorage.
Page 155: Transporting Pets
SAFETY Transporting Pets WARNING! (Continued) WARNING! (Continued) Air Bags deploying in the front seat could harm Do not allow people to ride in any area of If it is necessary to sit in a parked vehicle   your pet. An unrestrained pet will be thrown your vehicle that is not equipped with seats with the engine running, adjust your about and possibly injured, or injure a...
Page 156: Safety Checks You Should Make Inside The Vehicle
SAFETY Safety Checks You Should Make Inside The driving, have an authorized dealer service the WARNING! Vehicle vehicle immediately. An improperly attached, damaged, folded, or Refer to “Occupant Restraint Systems” in Seat Belts stacked floor mat, or damaged floor mat fas- “Safety”...
Page 157: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY Lights WARNING! (Continued) WARNING! (Continued) Have someone observe the operation of brake ONLY use the driver’s side floor mat on the If the vehicle carpet has been removed and   lights and exterior lights while you work the driver’s side floor area.
Page 158: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE Start the engine with the gear selector in the If Engine Fails To Start NEUTRAL or PARK position. Apply the brake Before starting your vehicle, adjust your seat, WARNING! before shifting to any driving range. adjust the inside and outside mirrors, fasten Proceed as follows: Never pour fuel or other flammable liquid into...
Page 159: Cold Weather Operation
STARTING AND OPERATING Extended Park Starting WARNING! CAUTION! NOTE: Never pour fuel or other flammable liquid To prevent damage to the starter, do not con-  Extended Park condition occurs when the into the throttle body air inlet opening in an tinuously crank the engine for more than vehicle has not been started or driven for at attempt to start the vehicle.
Page 160: After Starting - Warming Up The Engine
STARTING AND OPERATING ENGINE BREAK-IN RECOMMENDATIONS After Starting — Warming Up The Engine Opening the driver side door with the ignition in RUN will sound a short chime that reminds the Proceed as follows: A long break-in period is not required for the driver to place the ignition to OFF.
Page 161: Electric Park Brake (Epb)
STARTING AND OPERATING You can engage the EPB in two ways; small amount of brake pedal movement. The CAUTION! EPB can be applied even when the ignition is in Manually, by applying the park brake switch.  Never use Non-Detergent Oil or Straight Min- the OFF mode however, it can only be released Automatically, by enabling the Auto Park ...
Page 162 STARTING AND OPERATING To release the EPB manually, the ignition must WARNING! WARNING! (Continued) be in the RUN mode. Put your foot on the brake pedal, then push the EPB switch down When exiting the vehicle, always remove Always fully apply the parking brake when ...
Page 163: Auto Park Brake
STARTING AND OPERATING To disengage the EPB while the vehicle is in Auto Park Brake SafeHold motion, release the switch. If the vehicle is The EPB can be programmed to be applied SafeHold is a safety feature of the EPB system brought to a complete stop using the EPB, when automatically whenever the vehicle speed is that will engage the park brake automatically if...
Page 164: Brake Service Mode
STARTING AND OPERATING For manual transmissions, the EPB will When servicing your rear brakes, it may be NOTE: automatically engage if all of the following necessary for you or your technician to push the A dedicated message will appear in the instru- conditions are met: rear piston into the rear caliper bore.
Page 165: Manual Transmission - If Equipped
STARTING AND OPERATING MANUAL TRANSMISSION — IF EQUIPPED NOTE: To engage REVERSE gear from the NEUTRAL During cold weather, you may experience position, lift the REVERSE ring, located below increased effort in shifting until the transmis- the knob and simultaneously move the lever to WARNING! the left and then forward.
Page 166: Downshifting
STARTING AND OPERATING NOTE: WARNING! CAUTION! (Continued) A certain amount of noise from the transmis- sion is normal. This noise can be most notice- Do not downshift for additional engine brak- Failure to follow the maximum recom-  able when the vehicle is idling in NEUTRAL with ing on a slippery surface.
Page 167: Nine-Speed Automatic Transmission - If Equipped
STARTING AND OPERATING Manual Transmission Downshift Speeds in MPH (KM/H) Gear Selection 6 to 5 5 to 4 4 to 3 3 to 2 2 to 1 Maximum Speed 80 (129) 70 (113) 50 (81) 30 (48) 15 (24) transmission out of PARK, or to shift from CAUTION! WARNING! NEUTRAL into DRIVE or REVERSE when the...
Page 168: Gear Selector
STARTING AND OPERATING NOTE: CAUTION! WARNING! (Continued) If the gear selector cannot be moved to the Shift into or out of PARK or REVERSE only PARK, REVERSE, or NEUTRAL position (when When leaving the vehicle, always make   after the vehicle has come to a complete sure the ignition is in the OFF mode, pushed forward) it is probably in the AutoStick remove the key fob from the vehicle, and...
Page 169: Gear Ranges
STARTING AND OPERATING economy. By design, some vehicle and When parking on a level surface, you may shift WARNING! (Continued) drive-line combinations utilize 9th gear only in the transmission into PARK first, and then apply very specific driving situations and conditions. the EPB.
Page 170 STARTING AND OPERATING Look at the transmission gear position  WARNING! (Continued) WARNING! (Continued) display and verify that it indicates the PARK position (P), and is not blinking. Unintended movement of a vehicle could Do not leave the key fob in or near the ...
Page 171 STARTING AND OPERATING performance and extend transmission life by AutoStick CAUTION! reducing excessive shifting and heat buildup. AutoStick is a driver-interactive transmission Towing the vehicle, coasting, or driving for any If the transmission temperature exceeds feature providing manual shift control, giving other reason with the transmission in NEU- normal operating limits, the transmission you more control of the vehicle.
Page 172: Transmission Limp Home Mode
STARTING AND OPERATING NOTE: The system will ignore attempts to upshift at Transmission Limp Home Mode  too low of a vehicle speed. In AutoStick mode, the transmission will only Transmission function is electronically shift up or down when the driver moves the gear monitored for abnormal conditions.
Page 173: Ignition Park Interlock
Even if the transmission can be reset, we The four wheel drive (4WD) is fully automatic in recommend that you visit an authorized dealer Jeep Active Drive (4WD) And Jeep Active Drive normal driving mode. at your earliest possible convenience. An autho-...
Page 174 STARTING AND OPERATING Active Drive Control — If Equipped Active Drive With Low Control — (Trailhawk NOTE: Models Only) Both LOCK and LOW LED lights will blink and  then become active on the Selec-Terrain switch until the shift is complete. The instrument cluster display will illuminate ...
Page 175: Selec-Terrain
STARTING AND OPERATING SELEC-TERRAIN slippage, except for in 4WD LOW (Trailhawk models only). Selec-Terrain combines the capabilities of the SAND: For off-road driving or use on surfaces  vehicle control systems, along with driver input, with poor traction, such as sandy bottoms. to provide the best performance for all terrains.
Page 176: Active Grille Shutters - If Equipped
STARTING AND OPERATING ACTIVE GRILLE SHUTTERS — IF EQUIPPED providing assist, you will still have the ability to If the condition persists, see an authorized  dealer for service. steer the vehicle manually. Your vehicle may be equipped with Active Grille STOP/START SYSTEM WARNING! Shutters, an automatic system with mobile...
Page 177: Possible Reasons The Engine Does Not Autostop
STARTING AND OPERATING The vehicle must be completely stopped. Cabin heating or cooling is in process and an It may be possible for the vehicle to be driven   acceptable cabin temperature has not been several times without the Stop/Start system The gear selector must be in a forward gear ...
Page 178: To Manually Turn Off The Stop/Start System
STARTING AND OPERATING A Stop/Start system error occurs. To Manually Turn Off The Stop/Start System To Manually Turn On The Stop/Start System  Push the Stop/Start OFF switch (located on the 4WD system is put into 4WD LOW mode (if 1.
Page 179: Activation
STARTING AND OPERATING Activation When the vehicle has reached the desired speed, push the SET (+) or SET (-) button and Push the on/off button to activate the Speed release. Release the accelerator and the Control. The Cruise Indicator Light in the vehicle will operate at the selected speed.
Page 180: Accelerating For Passing
STARTING AND OPERATING Metric Speed (km/h) If the button is continually pushed, the set Deactivation  speed will continue to decrease until the Pushing the SET (+) button once will result in  A soft tap on the brake pedal, pushing the CANC button is released, then the new set speed a 1 km/h increase in set speed.
Page 181 STARTING AND OPERATING NOTE: You can change the mode by using the cruise WARNING! (Continued) control buttons. The two control modes function If the sensor does not detect a vehicle ahead  differently. Always confirm which mode is Cannot take street, traffic, and weather ...
Page 182: Adaptive Cruise Control (Acc) Operation
STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation of the Adaptive Cruise Control and Forward Collision Warning System. The Speed Control buttons (located on the right side of the steering wheel) operate the ACC To Activate/Deactivate System. Push and release the Adaptive Cruise Control (ACC) on/off button.
Page 183: To Set A Desired Acc Speed
STARTING AND OPERATING When the system is off, the instrument cluster NOTE: The braking temperature exceeds normal  display will read “Adaptive Cruise Control (ACC) ACC cannot be set if there is a stationary vehicle range (overheated). Off.” in front of your vehicle in close proximity. The Electronic Stability Control/Traction ...
Page 184: To Resume
STARTING AND OPERATING To Resume U.S. Speed (mph) Instrument Panel” for more information. The speed decrement shown is dependent on the Pushing the SET (+) button once will result in  If there is a set speed in the memory, push the chosen speed unit of U.S.
Page 185: Setting The Following Distance In Acc
STARTING AND OPERATING NOTE: set speed. When driving uphill and downhill, the ACC system will cancel if the braking When you override and push the SET (+)  temperature exceeds normal range (over- button or SET (-) button, the new set speed heated).
Page 186: Overtake Aid
STARTING AND OPERATING The vehicle will then maintain the set distance until: The vehicle ahead accelerates to a speed  above the set speed. The vehicle ahead moves out of your lane or  view of the sensor. The distance setting is changed. ...
Page 187: Adaptive Cruise Control (Acc) Menu
STARTING AND OPERATING Adaptive Cruise Control (ACC) Menu The ACC screen may display once again if any cases, the instrument cluster display will read ACC activity occurs, which may include any of “ACC Front Radar Sensor Temporarily Blocked” The instrument cluster display shows the the following: and the system will deactivate.
Page 188 STARTING AND OPERATING To keep the ACC System operating properly, it is When the condition that deactivated the system Functionality Wipe Front Windshield” and the important to note the following maintenance is no longer present, the system will return to system will have degraded performance.
Page 189: Precautions While Driving With Acc
STARTING AND OPERATING Service ACC/FCW Warning not be sufficient distance to the vehicle ahead. The offset vehicle may move in and out of the If the system turns off, and the instrument line of travel, which can cause your vehicle to cluster display reads “ACC/FCW Limited brake or accelerate unexpectedly.
Page 190 STARTING AND OPERATING Lane Changing Narrow Vehicles Stationary Objects And Vehicles ACC may not detect a vehicle until it is Some narrow vehicles traveling near the outer ACC does not react to stationary objects and completely in the lane in which you are edges of the lane or edging into the lane are not stationary vehicles.
Page 191: General Information
STARTING AND OPERATING General Information 2. l'utilisateur de l'appareil doit accepter tout without requiring the driver to operate the brouillage radioélectrique subi, même si le accelerator. Speed Control can only be The following regulatory statement applies to all brouillage est susceptible d'en compro- operated if the vehicle speed is above 20 mph Radio Frequency (RF) devices equipped in this mettre le fonctionnement.
Page 192 STARTING AND OPERATING To Set A Desired Speed quent tap of the button results in an increase information. The speed decrement shown is of 1 mph. dependent on the speed of U.S. (mph) or Metric Turn the Normal (Fixed Speed) Cruise (km/h) units: Control on.
Page 193: Rear Parksense - If Equipped
STARTING AND OPERATING To Cancel To Turn Off Rear ParkSense Sensors The following conditions will cancel the Normal The system will turn off and erase the set speed The four Rear ParkSense sensors, located in (Fixed Speed) Cruise Control without clearing in memory if: the rear fascia/bumper, monitor the area the memory:...
Page 194: Enabling And Disabling Rear Parksense
STARTING AND OPERATING The frequency of the acoustic signal: If an obstacle is detected in the center rear message such as “PARKSENSE DISABLED” for region, the display will show a single solid arc in approximately five seconds. Refer to Increases as the distance between vehicle ...
Page 195: Operation With A Trailer
STARTING AND OPERATING Operation With A Trailer If “PARKSENSE UNAVAILABLE WIPE REAR erly. The Rear ParkSense system might not SENSORS” appears in the instrument cluster detect an obstacle behind the fascia/ The operation of the rear sensors is bumper, or it could provide a false indication display, make sure the outer surface and the automatically deactivated when the trailer’s that an obstacle is behind the fascia/...
Page 196: Front And Rear Parksense - If Equipped
STARTING AND OPERATING ParkSense will retain the last system state WARNING! (Continued) CAUTION! (Continued) (enabled or disabled) from the last ignition cycle when the ignition is changed to the ON/RUN Before using ParkSense, it is strongly The vehicle must be driven slowly when ...
Page 197: Parksense Sensors
STARTING AND OPERATING ParkSense Sensors ParkSense Warning Display If an obstacle is detected in the center rear region, the display will show a single solid arc in The six ParkSense sensors, located in the rear The ParkSense Warning screen will only be the center rear region.
Page 198 STARTING AND OPERATING Slow Tone/Solid Arc Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: Slow Tone/Solid Arc Fast Tone/Flashing Arc...
Page 199 STARTING AND OPERATING WARNING ALERTS Arcs — Center None 6th Solid 5th Solid 4th Solid 3rd Flashing 2nd Flashing 1st Flashing Arcs — Right None None None None None 2nd Flashing 1st Flashing Single, 1/2 sec- Audible Alert None ond, audible Audible chime increases as the object gets closer to the vehicle.
Page 200 STARTING AND OPERATING No Tone/Flashing Arc Fast Tone/Flashing Arc Continuous Tone/Flashing Arc The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Front Distance...
Page 201: Enabling And Disabling Parksense
STARTING AND OPERATING WARNING ALERTS Audible chime increases as the object Audible Alert Chime None None None Continuous gets close to the vehicle. Radio Volume Reduced NOTE: If the Uconnect System is equipped, chime When the ParkSense switch is pushed ParkSense will reduce the volume of the radio, volume settings will not be accessible from the to disable the system, the instrument...
Page 202: Service The Parksense Park Assist System
STARTING AND OPERATING Service The ParkSense Park Assist System Cleaning The ParkSense System Clean the ParkSense sensors regularly,  taking care not to scratch or damage them. When the ParkSense System has detected a Clean the ParkSense sensors with water, car The sensors must not be covered with ice, faulted condition, the instrument cluster display wash soap and a soft cloth.
Page 203: Side Distance Warning (Sdw) System
STARTING AND OPERATING NOTE: WARNING! (Continued) CAUTION! (Continued) If any objects are attached to the bumper within a 6.5 ft (2 m) field of view, they will interfere and Before using ParkSense, it is strongly The vehicle must be driven slowly when ...
Page 204 STARTING AND OPERATING Warning system will automatically be WARNING ALERTS deactivated. Arcs-Right Flashing Flashing Message on the display for Side Distance Audible chime Warning feature: increases as “Wipe Sensors” — This message is displayed in the objects the case of a failure of the Side Distance Audible Alert Continuous within the...
Page 205 STARTING AND OPERATING ParkSense Usage Precautions Clean the ParkSense sensors regularly,  WARNING! taking care not to scratch or damage them. Some conditions may influence the The sensors must not be covered with ice, Drivers must be careful when backing up ...
Page 206: Parksense Active Park Assist System
STARTING AND OPERATING maneuver selection, the ParkSense Active Park Enabling And Disabling The ParkSense CAUTION! Assist system is capable of maneuvering a Active Park Assist System ParkSense is only a parking aid and it is vehicle into a parallel or a perpendicular ...
Page 207: Parallel Parking Space Assistance Operation/Display
STARTING AND OPERATING Touching the steering wheel during active Driver's door is closed. Parallel Parking Space Assistance   steering guidance into the parking space. Operation/Display Rear liftgate is closed.  When the ParkSense Active Park Assist system Pushing the ParkSense Front and Rear Park ...
Page 208 STARTING AND OPERATING The driver is responsible to ensure that the When an available parking space has been  selected parking space is suitable for the found, and the vehicle is not in position, you will maneuver and free/clear of anything that be instructed to move forward to position the may be overhanging or protruding into the vehicle for a parallel parking sequence.
Page 209 STARTING AND OPERATING When the driver places the gear selector into NOTE: If the system is canceled during the  the REVERSE position, the system may instruct maneuver for any reason, the driver must It is the driver's responsibility to use the ...
Page 210 STARTING AND OPERATING Once the vehicle is in a standstill condition, the The system will then instruct the driver to check NOTE: driver will be instructed to place the gear their surroundings and move forward. It is the driver's responsibility to use the brake selector into the DRIVE position.
Page 211: Perpendicular Parking Space Assistance Operation/Display
STARTING AND OPERATING When the driver places the gear selector into Your vehicle is now in the parallel park position. or Parallel Park Exit, if you desire. Refer to the REVERSE position, the system may instruct The "Active ParkSense Complete - Check “Exiting The Parking Space”...
Page 212 STARTING AND OPERATING The driver is responsible to ensure that the will be instructed to place the gear selector into  selected parking space is suitable for the the REVERSE position. maneuver and free/clear of anything that may be overhanging or protruding into the parking space (e.g., ladders, tailgates, etc.
Page 213 STARTING AND OPERATING The system will then instruct the driver to check The Active ParkSense System will allow a  their surroundings and move backward. maximum number of shifts between DRIVE and REVERSE. If the maneuver cannot be completed, the system will cancel and the instrument cluster display will instruct the driver to complete the maneuver manually.
Page 214 STARTING AND OPERATING Once the vehicle is in a standstill condition, the The system will then instruct the driver to check NOTE: driver will be instructed to place the gear their surroundings and move forward. It is the driver's responsibility to use the brake selector into the DRIVE position.
Page 215 STARTING AND OPERATING When the driver places the gear selector into Your vehicle is now in the perpendicular park WARNING! the REVERSE position, the system may instruct position. When the maneuver is complete, the the driver to wait for steering to complete. driver will be instructed to check the vehicle's Drivers must be careful when performing par- parking position.
Page 216: Exiting The Parking Space
STARTING AND OPERATING NOTE: CAUTION! (Continued) The following conditions must be met before the vehicle will exit the parking space: The vehicle must be driven slowly when  using the ParkSense Active Park Assist The system must detect an obstacle within ...
Page 217 STARTING AND OPERATING Check Surroundings — Stop And Remove Hands From Check Surroundings — Move Backward Check Surroundings — Shift To Drive Wheel Check Surroundings — Stop Check Surroundings — Wait For Steering To Complete Check Surroundings — Wait For Steering To Complete...
Page 218 STARTING AND OPERATING Check Surroundings — Move Forward Check Surroundings — Shift To Reverse Check Surroundings — Move Backward End Of Maneuver The semi-automatic maneuver ends when the display shows the message of a completed maneuver. At the end of the maneuver, the system gives back the vehicle control to the driver.
Page 219 STARTING AND OPERATING Important Information The sensors may not detect objects of a In the case of parking maneuvers on roads   particular shape or made from particular on a slope, the performance of the system If the sensors undergo impact which alters ...
Page 220: Lanesense - If Equipped
STARTING AND OPERATING NOTE: of the lane, the LaneSense system provides a Turning LaneSense On Or Off visual warning through the instrument cluster The default status of LaneSense is off. Correct system operation is not guaranteed if  display to prompt the driver to remain within the snow chains or the space-saver wheel are The LaneSense button is located on the center lane boundaries.
Page 221 STARTING AND OPERATING Base Instrument Cluster Display — If Equipped from white to gray, the left thin line remains provide visual warnings in the instrument solid white and the LaneSense telltale cluster display and a torque warning in the When the LaneSense system is on, the lane changes from solid white to flashing yellow.
Page 222 STARTING AND OPERATING Lane Sensed (Solid White Thick Line, Solid White Thin Lane Approached (Flashing White To Gray Thick Line, System On (Gray Lines/White Telltale) Line/Solid Yellow Telltale) Solid White Thin Line/Flashing Yellow Telltale) Left Lane Departure — Only Left Lane Detected When the LaneSense system senses the lane ...
Page 223 STARTING AND OPERATING Lane Approached (Flashing Yellow Thick Line, Solid Lanes Sensed (White Lines/Green Telltale) Lane Sensed (Solid Yellow Thick Line, Solid Yellow Thin Yellow Thin Line/Flashing Yellow Telltale) Line/Solid Yellow Telltale) When the LaneSense system senses a lane  drift situation, the left thick lane line and left When the LaneSense system senses the lane ...
Page 224: Changing Lanesense Status
STARTING AND OPERATING NOTE: When enabled the system operates above  37 mph (60 km/h) and below 112 mph (180 km/h). Use of the turn signal suppresses the warn-  ings. The system will not apply torque to the  steering wheel whenever a safety system Lane Approached (Flashing Yellow Thick Line, Solid Parking Camera...
Page 225: Adding Fuel
STARTING AND OPERATING When enabled, active guidelines are overlaid on WARNING! CAUTION! (Continued) the image to illustrate the width of the vehicle and its projected backup path based on the Drivers must be careful when backing up To avoid vehicle damage, the vehicle must ...
Page 226 STARTING AND OPERATING Opening The Door Emergency Refueling Procedure For filling proceed as follows: If the vehicle is out of fuel proceed as follows: Open the liftgate and remove the emergency  1. Open the door, by pushing and releasing fuel fill funnel located in the cargo area.
Page 227: Vehicle Loading
STARTING AND OPERATING Open the fuel door. included on this label and indicates the Month,  WARNING! (Continued) Day and Hour of manufacture. The bar code Insert the emergency fuel fill funnel in the  that appears on the bottom of the label is your The use of objects/plugs do not comply ...
Page 228: Trailer Towing
STARTING AND OPERATING sometimes specified by purchasers for Loading CAUTION! increased durability does not necessarily The actual total weight and the weight of the increase the vehicle's GVWR. Do not load your vehicle any heavier than the front and rear of your vehicle at the ground can GVWR or the maximum front and rear GAWR.
Page 229: Common Towing Definitions
STARTING AND OPERATING Common Towing Definitions Gross Combination Weight Rating (GCWR) Frontal Area The GCWR is the total allowable weight of your The frontal area is the maximum height The following trailer towing related definitions vehicle and trailer when weighed in multiplied by the maximum width of the front of will assist you in understanding the following combination.
Page 230: Trailer Hitch Classification
STARTING AND OPERATING Weight-Distributing Hitch recommended for heavier Tongue Weights (TW) WARNING! (Continued) and may be required depending on vehicle and A weight-distributing system works by applying trailer configuration/loading to comply with Weight Distributing Systems may not be  leverage through spring (load) bars. They are Gross Axle Weight Rating (GAWR) requirements.
Page 231: Trailer Towing Weights (Maximum Trailer Weight Ratings)
STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine Max. GTW (Gross Trailer Wt.) Max. Tongue Wt. (See Note) 1.3L Turbo 2,000 lbs (906 kg) 200 lbs (90 kg) 2.4L 2,000 lbs (906 kg)
Page 232: Towing Requirements
STARTING AND OPERATING Towing Requirements CAUTION! WARNING! (Continued) To promote proper break-in of your new vehicle Do not tow a trailer at all during the first Safety chains must always be used   drivetrain components, the following guidelines 500 miles (805 km) the new vehicle is between your vehicle and trailer.
Page 233 STARTING AND OPERATING Check for signs of tire wear or visible tire Towing Requirements — Trailer Lights And  WARNING! damage before towing a trailer. Refer to Wiring (If Equipped) “Tires – General Information” in “Serving And Do not connect trailer brakes to your ...
Page 234: Towing Tips
STARTING AND OPERATING frequent shifting does occur while in DRIVE, you can use the AutoStick shift control to manually select a lower gear. NOTE: Using a lower gear while operating the vehicle under heavy loading conditions will improve performance and extend transmission life by reducing excessive shifting and heat build up.
Page 235: Recreational Towing
STARTING AND OPERATING Speed Control — If Equipped Cooling System Highway Driving Reduce speed. Do not use in hilly terrain or with heavy loads. To reduce potential for engine and transmission  overheating, take the following actions: Air Conditioning When using the Speed Control, if you experi- ...
Page 236: Recreational Towing
STARTING AND OPERATING Recreational Towing CAUTION! CAUTION! Models With Front-Wheel Drive (FWD) DO NOT flat tow this vehicle. Damage to the Towing this vehicle with ANY of its wheels on  Recreational towing is allowed ONLY if the front drivetrain will result. If this vehicle requires the ground can cause severe transmission wheels are OFF the ground.
Page 237: Off-Road Driving Tips
STARTING AND OPERATING Off-Road Driving Tips Driving through water more than a few inches/ Maintenance centimeters deep will require extra caution to After driving through deep water, inspect your When To Use 4WD LOW Range ensure safety and prevent damage to your vehicle fluids and lubricants (engine, When off-road driving, shift to 4WD LOW for vehicle.
Page 238 STARTING AND OPERATING Hill Climbing NOTE: After Driving Off-Road Remember, never drive diagonally across a hill Off-road operation puts more stress on your NOTE: - drive straight up or down. vehicle than does most on-road driving. After Before attempting to climb a hill, determine the going off-road, it is always a good idea to check If the wheels start to slip as you approach the conditions at the crest and/or on the other side.
Page 239 STARTING AND OPERATING After extended operation in mud, sand,  water, or similar dirty conditions, have the radiator, fan, brake rotors, wheels, brake linings, and axle yokes inspected and cleaned as soon as possible. WARNING! Abrasive material in any part of the brakes may cause excessive wear or unpredictable braking.
Page 240: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS When you must leave the vehicle to seek WARNING! assistance, the Hazard Warning Flashers will The Hazard Warning Flashers switch is located continue to operate even though the ignition is ALWAYS obey traffic laws and pay attention to on the switch bank below the radio.
Page 241 IN CASE OF EMERGENCY ASSIST Call NOTE: 4. You should be able to speak with the SOS In case the SOS Call button is pushed in error, operator through the vehicle audio system The ASSIST Button is used to automatically there will be a 10 second delay before the SOS to determine if additional help is needed.
Page 242 IN CASE OF EMERGENCY in the vehicle. The vehicle’s SOS Call system SOS Call System Limitations WARNING! (Continued) will attempt to remain connected with the Vehicles sold in Mexico DO NOT have SOS Call SOS operator until the SOS operator termi- The SOS Call system is embedded into the ...
Page 243 IN CASE OF EMERGENCY The vehicle battery loses power or becomes NOTE:  WARNING! disconnected during a vehicle crash. Your vehicle may be transmitting data as  Ignoring the overhead console light could  LTE (voice/data) or 4G (data) network and/or authorized by the subscriber.
Page 244: General Information
IN CASE OF EMERGENCY BULB REPLACEMENT General Information 1. l'appareil ne doit pas produire de brouillage, et The following regulatory statement applies to all General Information Radio Frequency (RF) devices equipped in this 2. l'utilisateur de l'appareil doit accepter tout Before you replace a bulb, check the vehicle: ...
Page 245: Replacement Bulbs
IN CASE OF EMERGENCY Replacement Bulbs Interior Bulbs Lamps Bulb Number Front Courtesy Light Front Courtesy Lights (Sun Visors) Rear Dome Light (Models Without Retractable Roof) Rear Interior Lights (Models With Retractable Roof) Interior Lights Dome Light (Glove Compartment) Exterior Bulbs Lamps Bulb Number Low Beam/High Beam Headlamps (LED Version)
Page 246: Replacing Exterior Bulbs
IN CASE OF EMERGENCY Exterior Bulbs Lamps Bulb Number Center High Mounted Stop Lamp (CHMSL) LED (Serviced at an Authorized Dealer) Reverse W16W License Plate Lamp Replacing Exterior Bulbs Headlamps 2. Rotate the headlamp bulb socket counter- clockwise then pull outwards. Hi/Lo Beam Light Halogen CAUTION! To replace the bulbs proceed as follows:...
Page 247 IN CASE OF EMERGENCY 3. Push on the locking tab on the headlamp 4. Install the new headlamp bulb making sure bulb connector and remove the bulb and it is properly locked. socket. 5. Install the headlamp bulb and socket; turn it clockwise making sure it is properly locked.
Page 248 IN CASE OF EMERGENCY 4. Releasing the two tabs, and remove the Front Fog Lights bulb and bulb socket from the housing. To replace the bulbs proceed as follows: 1. Turn the front wheels completely. 2. Use a suitable tool to remove the access door.
Page 249 IN CASE OF EMERGENCY LED Front Fog Lamps – If Equipped 4. Rotate counterclockwise to release the bulb socket from the lamp assembly, and For replacement see an authorized dealer. remove it. Side Indicators Front Side Indicators To replace the bulb proceed as follows: 1.
Page 250 IN CASE OF EMERGENCY 6. Insert the new bulb in the socket. To replace the bulb proceed as follows: 2. Remove the transparent lens assembly as shown. 7. Reinstall the bulb and socket into the lamp 1. Remove the mirror cap on the outside rear assembly by turning it clockwise, making view mirror.
Page 251 IN CASE OF EMERGENCY 4. Remove the bulb from the bulb socket by Rear Tail Lamps 3. Using a suitable tool remove fastener. pulling the bulb straight out. Contain the following: 4. Disconnect the electrical connector by Position lights  pushing the release.
Page 252 IN CASE OF EMERGENCY 5. Remove the rear tail lamp, sliding it toward 7. Replace the bulb as necessary. 12. Reinstall the door making sure it locked into the outside as shown. place. 13. Finally close the liftgate. LED Rear Tail Lamps – If Equipped For replacement see an authorized dealer.
Page 253 IN CASE OF EMERGENCY 2. By pushing the electrical connector tab Center High Mounted Stop Lamp (CHMSL) remove the electrical connector. The CHMSL is LED. For replacement see an authorized dealer. License Plate Lights To replace the bulbs proceed as follows: 1.
Page 254: Replacing Interior Bulbs
IN CASE OF EMERGENCY Replacing Interior Bulbs 4. Insert the new bulbs, making sure that they are properly locked. Front Courtesy Light 5. Reassemble the bulb housing and courtesy To replace the bulbs proceed as follows: light housing making sure that they are 1.
Page 255 IN CASE OF EMERGENCY Dome Light Vanity Mirror Dome Light Glove Compartment Rear Dome Light — Without Retractable Roof To replace the bulbs proceed as follows: To replace the bulb proceed as follows: To replace the bulbs proceed as follows: 1.
Page 256 IN CASE OF EMERGENCY Dome Light — MY SKY To replace the bulbs proceed as follows: 1. Lower the handle in the direction shown remove the dome light. Bulb Light Cover 3. Insert the new bulb, locking it between the 3.
Page 257: Fuses
IN CASE OF EMERGENCY WARNING! (Continued) WARNING! (Continued) Halogen lamps contain gas under pressure, Before replacing a fuse, make sure that the   in the event of breakage be careful of the ignition is off and that all the other services projection of fragments of glass.
Page 258: Engine Compartment Fuses/Distribution Unit
IN CASE OF EMERGENCY Engine Compartment Fuses/Distribution Mounting Fuse Cover and Locking Screw Unit Proceed as follows: Properly secure the fuse cover to the box, The engine compartment fuse panel is located  slide completely from top to bottom. on the left side of the engine compartment. Fully depress the screw, using the special ...
Page 259 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Micro Fuse Description 70 Amp Tan – – Module Body Computer Module Body Computer, Rear Distribution 70 Amp Tan – – Unit – 20 Amp Blue – Controller Power Supply Body Computer –...
Page 260 IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Micro Fuse Description 30 Amp Green – 1.3L Turbo – – Engine Supply Primary Loads 15 Amp Blue – 2.4L Engine Intelligent Battery Sensor (IBS) 2.4L – If – – 5 Amp Tan Equipped –...
Page 261: Body Computer Fuse Center
IN CASE OF EMERGENCY Cavity Maxi Fuse Cartridge Fuse Micro Fuse Description – – 30 Amp Green Heated Rear Window Intelligent Battery Sensor (IBS) 1.3L – If – – 5 Amp Tan Equipped Body Computer Fuse Center The controller is located at the left side of the steering column at the bottom of the instrument panel.
Page 262 IN CASE OF EMERGENCY Cavity Mini Fuse Description Power Under Lock and Key, Brake Control Electronics Module, Electric 7.5 Amp Brown Power-Assisted Steering 20 Amp Yellow Bi-directional Pump Washer 20 Amp Yellow Power Rear Window (Driver Side) 20 Amp Yellow Power Rear Window (Passenger Side) Supply ParkSense, SGW, Mirror, Heated Front Seats, Stabilizer Battery, ESC Sys- 7.5 Amp Brown...
Page 263: Rear Cargo Fuse/Relay Distribution Unit
IN CASE OF EMERGENCY Rear Cargo Fuse/Relay Distribution Unit The fuses may be contained in two units. fuse holder No. 1 and fuse holder No. 2 (if equipped To access the fuses, remove the access door with trailer towing) are located closest to the from the left rear panel of the rear cargo area.
Page 264: Jacking And Tire Changing
IN CASE OF EMERGENCY Fuse Holder No. 2 Cavity Mini Fuse Description 10 Amp Red Controller Exterior Lighting On Trailer 15 Amp Blue Controller Exterior Lighting Lights (Drivers Side) Controller Exterior Lighting Lights (Passenger 15 Amp Blue Side) JACKING AND TIRE CHANGING Jack Location/Spare Tire Stowage WARNING! (Continued) The jack and tools are located in the rear...
Page 265: Preparations For Jacking
IN CASE OF EMERGENCY Preparations For Jacking 1. Park the vehicle on a firm level surface as far from the edge of the roadway as possible. Avoid icy or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 266: Jacking Instructions
IN CASE OF EMERGENCY 6. Chock both the front and rear of the wheel Jacking Instructions WARNING! (Continued) diagonally opposite of the jacking position. WARNING! For example, if changing the driver’s front Only use the jack in the positions indicated ...
Page 267 IN CASE OF EMERGENCY CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle. 1. Remove the spare tire, jack, and wheel bolt wrench. 2. If equipped with wheels where the center Jacking Locations Front Jacking Location cap covers the wheel bolts, use the wheel...
Page 268 IN CASE OF EMERGENCY 8. Install the wheel bolts with the threaded CAUTION! end of the wheel bolt toward the wheel. Be sure to mount the spare tire with the valve Lightly tighten the wheel bolts. stem facing outward. The vehicle could be WARNING! damaged if the spare tire is mounted incor- rectly.
Page 269: Road Tire Installation
IN CASE OF EMERGENCY 11. Securely stow the jack, tools, chocks, and Road Tire Installation 4. Finish tightening the wheel bolts. Push flat tire. down on the wrench while at the end of the 1. Mount the road tire on the axle. handle for increased leverage.
Page 270: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY TIRE SERVICE KIT — IF EQUIPPED Tire Service Kit Components And Operation 1. Remove the Tire Service Kit from the vehicle, take it out from the bag and place Tire Service Kit Storage it near the punctured tire. Screw the clear flexible filling tube to the tire valve.
Page 271: Tire Service Kit Usage Precautions
IN CASE OF EMERGENCY sure. If the pressure is below 19 psi (1.3 bar), WARNING! WARNING! (Continued) do not drive the vehicle, as the tire is too damaged, and contact the nearest autho- The metal end fitting from Power Plug may get If the wheel has any damage.
Page 272: Replacing The Sealant
IN CASE OF EMERGENCY WARNING! CAUTION! WARNING! (Continued) Store the sealant canister in its special com- Do not use a portable battery booster pack or Tire Service Kit Sealant solution contains  latex. In case of an allergic reaction or rash, partment, away from sources of heat.
Page 273: Jump Starting Procedure
IN CASE OF EMERGENCY NOTE: Proceed as follows: Jump Starting Procedure The positive battery post is covered with a 1. Apply the Electric Park Brake, shift the WARNING! protective cap. Lift up on the cap to gain access automatic transmission into PARK (P) to the positive battery post.
Page 274: Refueling In Emergency - If Equipped
IN CASE OF EMERGENCY 3. Connect the negative (-) end of the jumper Disconnecting The Jumper Cables CAUTION! cable to the negative (-) post of the booster 1. Disconnect the negative (-) end of the battery. Accessories plugged into the vehicle power jumper cable from the engine ground of outlets draw power from the vehicle’s battery, 4.
Page 275: If Your Engine Overheats
IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS NOTE: There are steps that you can take to slow down In any of the following situations, you can an impending overheat condition: reduce the potential for overheating your If your Air Conditioner (A/C) is on, turn it off. engine by taking the appropriate action.
Page 276: Gear Selector Override
IN CASE OF EMERGENCY GEAR SELECTOR OVERRIDE If a malfunction occurs and the gear selector cannot be moved out of the PARK position, you can use the following procedure to temporarily move the gear selector: 1. Turn the engine OFF. 2.
Page 277: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY FREEING A STUCK VEHICLE NOTE: CAUTION! Push the “ESC OFF” switch (if necessary), to If your vehicle becomes stuck in mud, sand or place the Electronic Stability Control (ESC) Racing the engine or spinning the wheels ...
Page 278: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The Ground FWD MODELS FOUR WHEEL DRIVE Flat Tow NONE NOT ALLOWED NOT ALLOWED Rear NOT ALLOWED NOT ALLOWED...
Page 279: Four Wheel Drive (4Wd)
IN CASE OF EMERGENCY NOTE: front of the vehicle. The rear hook will be CAUTION! (Continued) Ensure that the Electric Park Brake is released, located on the driver's side of the vehicle. and remains released, while being towed. Front or rear wheel lifts must not be used (if ...
Page 280: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM EVENT DATA RECORDER (EDR) Place the ignition in the ON/RUN position, without opening the door. During towing (EARS) This vehicle is equipped with an Event Data remember that not having the aid of the power Recorder (EDR).
Page 281: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING NOTE: Once A Month Or Before A Long Trip: Under no circumstances should oil change Check engine oil level.  Your vehicle is equipped with an automatic oil intervals exceed 10,000 miles (16,000 km), 1 change indicator system.
Page 282: Maintenance Plan
SERVICING AND MAINTENANCE Maintenance Plan Required Maintenance Intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter. Inspect battery and clean and tighten terminals as required. Inspect the CV/Universal joints. Inspect brake pads, shoes, rotors, drums, and hoses. Inspect engine cooling system protection and hoses.
Page 283 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace the Uconnect box (telematic box) bat- • • • tery (if equipped). Check tire condition/wear and adjust pressure, if necessary, check Tire Service Kit expiration •...
Page 284 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Check engine control system operation (via diag- • • • • • • • • • • • • • • • nostic tool). Visually inspect condition of: exterior bodywork, underbody protection, pipes and hoses (exhaust •...
Page 285 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Check the front suspension, tie rods, CV joints • • • • • • • • • • • • • • • and replace if necessary. Visually inspect the condition of the accessory •...
Page 286 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: • Replace spark plugs (2.4L Engine) • • • • • • • Replace engine air filter. • • • • • • • Replace brake fluid every two years. Replace cabin filter.
Page 287 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes • • first. 1. The Uconnect box (telematic box) battery replacement has to be done every five years, regardless of mileage. 2.
Page 288 SERVICING AND MAINTENANCE WARNING! You can be badly injured working on or  around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 289: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 1.3L Turbo Engine 1 — Oil Fill Cap/Engine Oil Dipstick 5 — Washer Fluid Reservoir 2 — Brake Fluid Reservoir 6 — Engine Coolant Pressure Cap 3 — Battery 7 — Engine Coolant Reservoir 4 — Power Distribution Center (Fuses)
Page 290: 2.4L Engine
SERVICING AND MAINTENANCE 2.4L Engine 1 — Engine Air Cleaner Filter 6 — Washer Fluid Reservoir Cap 2 — Engine Oil Fill Cap 7 — Coolant Pressure Bottle Cap 3 — Brake Fluid Reservoir Cap 8 — Coolant Pressure Bottle 4 —...
Page 291: Checking Oil Level
SERVICING AND MAINTENANCE Checking Oil Level There are four possible dipstick types: Cooling System Crosshatched zone.  To ensure proper engine lubrication, the engine WARNING! oil must be maintained at the correct level. Crosshatched zone marked SAFE.  Check the oil level at regular intervals, such as You or others can be badly burned by hot ...
Page 292: Adding Washer Fluid
SERVICING AND MAINTENANCE Coolant Checks Maintenance-Free Battery CAUTION! Check engine coolant (antifreeze) protection Your vehicle is equipped with a It is essential when replacing the cables on  every 12 months (before the onset of freezing maintenance-free battery. You will never have the battery that the positive cable is weather, where applicable).
Page 293: Dealer Service
SERVICING AND MAINTENANCE DEALER SERVICE Engine Oil Engine Oil Viscosity (SAE Grade) — 1.3L Turbo Engine Change Engine Oil — Gasoline Engine An authorized dealer has the qualified service Mopar SAE 0W-30 SN PLUS synthetic engine oil personnel, special tools, and equipment to Refer to “Scheduled Servicing”...
Page 294: Engine Oil Filter
SERVICING AND MAINTENANCE The engine oil filler cap also shows the Engine Oil Filter Air Conditioner Maintenance recommended engine oil viscosity for your The engine oil filter should be replaced with a For best possible performance, your air engine. For information on engine oil filler cap new filter at every engine oil change.
Page 295: Body Lubrication
SERVICING AND MAINTENANCE The air conditioning system contains refrig- A/C Air Filter Windshield Wiper Blades  erant under high pressure. To avoid risk of See an authorized dealer for service. Clean the rubber edges of the wiper blades and personal injury or damage to the system, the windshield periodically with a sponge or soft Body Lubrication adding refrigerant or any repair requiring...
Page 296 SERVICING AND MAINTENANCE Service Position Strategy Function Deactivation: The functionality is reset if: The service position allows the wiper blades to be placed in a position that allows the wiper The ignition is turned to the MAR/RUN posi-  blades to be easily changed. tion.
Page 297: Exhaust System
SERVICING AND MAINTENANCE Rear Wiper Blade Removal/Installation connections could permit exhaust fumes to CAUTION! seep into the passenger compartment. In 1. Carefully lift the rear wiper arm upward to addition, have the exhaust system inspected The catalytic converter requires the use of ...
Page 298: Cooling System
SERVICING AND MAINTENANCE NOTE: Cooling System Coolant Checks Intentional tampering with emissions control Check engine coolant (antifreeze) protection WARNING! systems can result in civil penalties being every 12 months (before the onset of freezing assessed against you. weather, where applicable). If the engine You or others can be badly burned by hot ...
Page 299 SERVICING AND MAINTENANCE Selection Of Coolant This vehicle has not been designed for use Please review these recommendations for  with propylene glycol-based engine coolant using Organic Additive Technology (OAT) engine Refer to “Fluids And Lubricants” in “Technical (antifreeze). Use of propylene glycol-based coolant (antifreeze) that meets the Specifications”...
Page 300 SERVICING AND MAINTENANCE NOTE: The cap should be inspected and cleaned if or pet, seek emergency assistance there is any accumulation of foreign material on immediately. Clean up any ground spills It is the owner's responsibility to maintain the  the sealing surfaces.
Page 301: Brake System
SERVICING AND MAINTENANCE the radiator and being vaporized when the ther- Do not change the thermostat for Summer or Brake Master Cylinder  mostat opens, allowing hot engine coolant (anti- Winter operation. If replacement is ever The fluid level in the master cylinder should be necessary, install ONLY the correct type ther- freeze) to enter the radiator.
Page 302: Manual Transmission - If Equipped
SERVICING AND MAINTENANCE problems, it may be a result of a leak in the Manual Transmission — If Equipped WARNING! (Continued) hydraulic clutch release system. See an autho- Lubricant Selection rized dealer for service. To avoid contamination from foreign matter ...
Page 303: Automatic Transmission - If Equipped
SERVICING AND MAINTENANCE Automatic Transmission — If Equipped Special Additives malfunction, visit an authorized dealer immediately to have the transmission fluid level The manufacturer strongly recommends Selection Of Lubricant checked. Operating the vehicle with an against using any special additives in the It is important to use the proper transmission improper fluid level can cause severe transmission.
Page 304: Raising The Vehicle
SERVICING AND MAINTENANCE RAISING THE VEHICLE Tire Markings the size designation. Example: P215/65R15 95H. In the case where it is necessary to raise the European — Metric tire sizing is based on vehicle, go to an authorized dealer or service ...
Page 305 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 306 SERVICING AND MAINTENANCE EXAMPLE: H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions  The maximum speed corresponding to the speed symbol should only be achieved under specified operating conditions (i.e., tire pressure, vehicle ...
Page 307 SERVICING AND MAINTENANCE EXAMPLE: ABCD = Code used by the tire manufacturer (one to four digits) 03 = Number representing the week in which the tire was manufactured (two digits) 03 means the 3rd week  01 = Number representing the year in which the tire was manufactured (two digits) 01 means the year 2001 ...
Page 308 SERVICING AND MAINTENANCE Term Definition Vehicle manufacturer's recommended cold tire inflation pressure as Recommended Cold Tire Inflation Pressure shown on the tire placard. A label permanently attached to the vehicle describing the vehicle’s load- Tire Placard ing capacity, the original equipment tire sizes and the recommended cold tire inflation pressures.
Page 309 SERVICING AND MAINTENANCE Steps For Determining Correct Load exceed the available cargo and luggage Loading Limit— load capacity calculated in Step 4. The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on (1) Locate the statement “The combined (6) If your vehicle will be towing a trailer, your vehicle.
Page 310 SERVICING AND MAINTENANCE be accurate for the seating and load carry capacity of your vehicle. For the following example, the combined  weight of occupants and cargo should never exceed 865 lbs (392 kg).
Page 311: Tires - General Information
SERVICING AND MAINTENANCE Safety Both underinflation and overinflation affect the WARNING! stability of the vehicle and can produce a feeling WARNING! Overloading of your tires is dangerous. Over- of sluggish response or over responsiveness in loading can cause tire failure, affect vehicle the steering.
Page 312 SERVICING AND MAINTENANCE Tire Inflation Pressures maximum inflation pressure molded into the reduced vehicle loading may be required for tire sidewall. high-speed vehicle operation. Refer to an The proper cold tire inflation pressure is listed authorized tire dealer or original equipment Check tire pressures more often if subject to a on the driver's side B-Pillar or rear edge of the vehicle dealer for recommended safe operating...
Page 313 SERVICING AND MAINTENANCE Tire Repair Run Flat Tires — If Equipped Tire Spinning If your tire becomes damaged, it may be Run Flat tires allow you the capability to drive When stuck in mud, sand, snow, or ice repaired if it meets the following criteria: 50 miles (80 km) at 50 mph (80 km/h) after a conditions, do not spin your vehicle's wheels rapid loss of inflation pressure.
Page 314 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire NOTE: Wheel Valve Stem must be replaced as well Tread wear indicators are in the original The service life of a tire is dependent upon when installing new tires due to wear and tear equipment tires to help you in determining varying factors including, but not limited to: in existing tires.
Page 315: Tire Types
SERVICING AND MAINTENANCE See the Tire Sizing Chart example found in the WARNING! CAUTION! “Tire Safety Information” section of this manual for more information relating to the Load Index Do not use a tire, wheel size, load rating, or Replacing original tires with tires of a differ- ...
Page 316: Spare Tires - If Equipped
SERVICING AND MAINTENANCE Summer tires do not contain the all season sustained speeds over 75 mph (120 km/h). For Refer to the “Towing Requirements - Tires” in designation or mountain/snowflake symbol on speeds above 75 mph (120 km/h) refer to “Starting And Operating”...
Page 317: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Since this tire has limited tread life, the original Full Size Spare — If Equipped WARNING! equipment tire should be repaired (or replaced) The full size spare is for temporary emergency and reinstalled on your vehicle at the first Limited use spares are for emergency use use only.
Page 318: Tire Chains And Traction Devices
SERVICING AND MAINTENANCE Your wheels are susceptible to deterioration Chrome Cleaner or their equivalent is Dark Vapor Chrome, Black Satin Chrome, or caused by salt, sodium chloride, magnesium recommended or select a non-abrasive, Low Gloss Clear Coat Wheels chloride, calcium chloride, etc., and other road non-acidic cleaner for aluminum or chrome CAUTION! chemicals used to melt ice or control dust on...
Page 319: Tire Rotation Recommendations
SERVICING AND MAINTENANCE Due to limited clearance, the following trac-  CAUTION! CAUTION! (Continued) tion devices are recommended: To avoid damage to your vehicle or tires, Observe the traction device manufacturer’s  All Models: observe the following precautions: instructions on the method of installation, The use of 7mm tire chains is permitted with ...
Page 320: Department Of Transportation Uniform
SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION The suggested Front Wheel Drive (FWD) rotation method is the “forward cross” shown in the UNIFORM TIRE QUALITY GRADES following diagram. This rotation pattern does not apply to some directional tires that must not The following tire grading categories be reversed.
Page 321: Traction Grades
SERVICING AND MAINTENANCE significantly from the norm due to Temperature Grades WARNING! variations in driving habits, service The Temperature grades are A (the The temperature grade for this tire is estab- practices, and differences in road highest), B, and C, representing the tire's lished for a tire that is properly inflated and characteristics and climate.
Page 322: Bodywork
SERVICING AND MAINTENANCE Clean and protect the painted parts by NOTE: vehicle is operated, extreme hot or cold weather  applying protective waxes. When the vehicle has not been started or driven and other extreme conditions will have an for at least 30 days, an Extended Park Start adverse effect on paint, metal trim, and Clean and protect polished metal parts by ...
Page 323: Body And Underbody Maintenance
SERVICING AND MAINTENANCE Body And Underbody Maintenance Use a high quality cleaner wax, such as If you detect any stone chips or scratches in   Mopar Cleaner Wax to remove road film, the paint, touch them up immediately. The Cleaning Headlights stains and to protect your paint finish.
Page 324: Interiors
SERVICING AND MAINTENANCE INTERIORS Cleaning Plastic Instrument Cluster Lenses WARNING! The lenses in front of the instruments in this Seats And Fabric Parts A frayed or torn belt could rip apart in a colli- vehicle are molded in clear plastic. When sion and leave you with no protection.
Page 325: Glass Surfaces
SERVICING AND MAINTENANCE cleaning fluids, solvents, detergents, or Glass Surfaces ammonia-based cleaners to clean your leather All glass surfaces should be cleaned on a upholstery. Application of a leather conditioner regular basis with Mopar Glass Cleaner, or any is not required to maintain the original commercial household-type glass cleaner.
Page 326: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS Your vehicle is equipped with dual hydraulic Proper lug nut/bolt torque is very important to Vehicle Identification Number brake systems. If either of the two hydraulic ensure that the wheel is properly mounted to The Vehicle Identification Number (VIN) is systems loses normal capability, the remaining the vehicle.
Page 327: Fuel Requirements
TECHNICAL SPECIFICATIONS Inspect the wheel mounting surface prior to After 25 miles (40 km), check the wheel bolt While operating on gasoline with the required mounting the tire and remove any corrosion or torque to be sure that all the lug nuts/bolts are octane number, hearing a light knocking sound loose particles.
Page 328: Reformulated Gasoline
TECHNICAL SPECIFICATIONS However, if the engine is heard making a heavy Gasoline/Oxygenate Blends E-85 Usage In Non-Flex Fuel Vehicles knocking sound, see your dealer immediately. Some fuel suppliers blend unleaded gasoline Non-Flex Fuel Vehicles (FFV) are compatible Use of gasoline with an octane number lower with oxygenates such as ethanol.
Page 329: Mmt In Gasoline
TECHNICAL SPECIFICATIONS MMT In Gasoline reduce emissions, and maintain vehicle CAUTION! (Continued) performance. Methylcyclopentadienyl Manganese Tricarbonyl An out-of-tune engine or certain fuel or igni- Designated TOP TIER Detergent  (MMT) is a manganese-containing metallic tion malfunctions can cause the catalytic Gasoline contains a higher level of additive that is blended into some gasoline to converter to overheat.
Page 330: Carbon Monoxide Warnings
TECHNICAL SPECIFICATIONS Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to pre- vent carbon monoxide poisoning: Do not inhale exhaust gases. They contain  carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
Page 331: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 1.3L Turbo / 2.4L Engine 12.7 Gallons 48 Liters Engine Oil With Filter 1.3L Turbo Engine (SAE 0W-30 SN PLUS Synthetic, API Certified) 4.8 Quarts 4.5 Liters 2.4L Engine (SAE 0W-20, API Certified) 5.5 Quarts 5.2 Liters Cooling System *...
Page 332: Fluids And Lubricants
TECHNICAL SPECIFICATIONS FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Engine Coolant (240,000 km) Formula OAT (Organic Additive Technology) or equivalent meet- ing the requirements of FCA Material Standard MS.90032. We recommend you use SAE 0W-30 SN PLUS API Certified Synthetic Engine Oil, meeting the requirements of FCA Material Standard Engine Oil –...
Page 333: Chassis
TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar C Series Manual & Dual Dry Clutch Trans- Manual Transmission – If Equipped mission Fluid. Use only Mopar ZF 8&9 Speed ATF Automatic Transmission Fluid, or Automatic Transmission –...
Page 334: Multimedia
MULTIMEDIA CYBERSECURITY NOTE: WARNING! FCA US LLC or your dealer may contact you Your vehicle may be a connected vehicle and  It is not possible to know or to predict all of  directly regarding software updates. may be equipped with both wired and wireless the possible outcomes if your vehicle’s networks.
Page 335: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS Customer Programmable Features — NOTE: Only one touchscreen area may be selected at Uconnect 3 Settings The Uconnect system uses a combination of a time. buttons on the touchscreen and buttons on the When making a selection, press the button on faceplate located on the center of the the touchscreen to enter the desired mode.
Page 336 MULTIMEDIA Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto Manual Brightness NOTE: The “Brightness” setting can be adjusted by selecting any point on the scale between the + and - buttons on the touchscreen. Language English Español...
Page 337 MULTIMEDIA Voice After pressing the Voice button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Detailed Show Command List Always With Help Never Clock & Date After pressing the Clock & Date button on the touchscreen, the following settings will be available: Setting Name Selectable Options Set Time and Format...
Page 338 MULTIMEDIA Safety/Assistance After pressing the Safety/Assistance button on the touchscreen, the following settings will be available: Setting Name Selectable Options ParkView Backup Camera Delay NOTE: The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image with dynamic grid lines for up to 10 seconds after the vehicle is shifted out of REVERSE.
Page 339 MULTIMEDIA Setting Name Selectable Options NOTE: The “Forward Collision Warning Plus (FCW+)” setting includes Advanced Brake Assist (ABA). The ABA applies additional brake pressure when the driver requests insufficient brake pressure to avoid a potential frontal collision. When the “Sound Only” option is selected, a chime will sound alerting you of a possible collision with the vehicle in front of you and more brake pressure is needed.
Page 340 MULTIMEDIA Brakes — If Equipped After pressing the Brakes button on the touchscreen, the following setting will be available: Setting Name Selectable Options Auto Park Brake Lights After pressing the Lights button on the touchscreen, the following settings will be available: Setting Name Selectable Options Level 1: minimum...
Page 341 MULTIMEDIA Setting Name Selectable Options Cornering Lights — If Equipped NOTE: When the “Cornering Lights” feature is selected, if the steering wheel rotation angle is large or the turn signal indicators are on, a light (incorporated in the fog light) will illuminate on the relevant side to improve visibility at night. Flash Lights With Lock —...
Page 342 MULTIMEDIA Setting Name Selectable Options NOTE: When “Driver” is programmed, only the driver's door will unlock on the first push of the key fob unlock button; you must push the key fob unlock button twice to unlock the passengers’ doors. When “All” is programmed, all of the doors will unlock on the first press of the key fob unlock button. If “All” is programmed, all doors will unlock no matter which Passive Entry equipped door handle is grasped.
Page 343 MULTIMEDIA Setting Name Selectable Options Radio Off Delay 0 min 20 min NOTE: When this feature is selected, the radio will stay on for a preset time after the ignition key is turned to OFF. Audio After pressing the Audio button on the touchscreen, the following settings will be available: Setting Name Selectable Options Equalizer...
Page 344 MULTIMEDIA Setting Name Selectable Options AUX Volume Offset — If Equipped NOTE: The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through the AUX input. Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following settings will be available: Setting Name Selectable Options Paired Phones...
Page 345 MULTIMEDIA Setting Name Selectable Options NOTE: New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM® Satellite Radio with your radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription Information screen to re-subscribe. 1.
Page 346: Customer Programmable Features - Uconnect 4 Settings
MULTIMEDIA Customer Programmable Features — Push the Settings button on the touchscreen to NOTE: Uconnect 4 Settings display the settings menu screen. In this mode, All settings should be changed with the ignition the Uconnect system allows you to access all of in the ACC position.
Page 347 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Español Français Display After pressing the Display button on the touchscreen, the following settings will be available: Setting Name Selectable Options Display Mode Auto...
Page 348 MULTIMEDIA Units After pressing the Units button on the touchscreen, the following settings will be available: Setting Name Selectable Options Units Metric Custom NOTE: When US is selected, Distance is set on miles, Fuel Consumption is set on MPG (US), Pressure is set on psi, and Temperature is set on °F. When Metric is selected, Distance is set on km, Fuel Consumption is set on L/100 km, Pressure is set on bar, and Temperature is set on °C.
Page 349 MULTIMEDIA Clock & Date After pressing the Clock button on the touchscreen, the following settings will be available: Setting Name Selectable Options 12 hour 24 hour Set Time And Format NOTE: Within the “Set Time and Format” setting, press the corresponding arrow buttons on the touchscreen to adjust to the correct time. Show Time Status Set Date (MM/DD/YY) NOTE:...
Page 350 MULTIMEDIA Setting Name Selectable Options ParkView Backup Camera Active Guide Lines NOTE: The “ParkView Backup Camera Active Guide Lines” setting overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle and its projected backup path, based on the steering wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist with parking or aligning to a hitch/receiver.
Page 351 MULTIMEDIA Setting Name Selectable Options Front ParkSense Volume — If High Equipped Rear ParkSense Volume — If High Equipped LaneSense Warning — If Equipped Early Late NOTE: The “LaneSense Warning” setting determines at what distance the LaneSense system warns you, through steering wheel feedback, of a possible lane departure.
Page 352 MULTIMEDIA Brakes — If Equipped After pressing the Brakes button on the touchscreen, the following setting will be available: Setting Name Selectable Options Brake Service Auto Park Brake Lights After pressing the Lights button on the touchscreen, the following settings will be available: Setting Name Selectable Options Interior Ambient Lighting —...
Page 353 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only available if allowed by law in the country of the vehicle purchase. Cornering Lights —...
Page 354 MULTIMEDIA Setting Name Selectable Options Horn With Lock — If Equipped 1st Press 2nd Press Horn With Remote Start — If Equipped Passive Entry — If Equipped NOTE: This feature allows you to lock and unlock the vehicle’s door(s) without having to push the key fob lock or unlock buttons. Remote Door Unlock —...
Page 355 MULTIMEDIA Engine Off Options After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay — If Equipped – NOTE: When this feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle. Radio Off Delay —...
Page 356 MULTIMEDIA Setting Name Selectable Options AUX Volume Offset AutoPlay — If Equipped NOTE: When activated, the “AutoPlay” setting automatically starts playing music off of a connected device as soon as it is connected. Phone/Bluetooth® After pressing the Phone/Bluetooth® button on the touchscreen, the following settings will be available: Setting Name Selectable Options Paired Phones and Devices...
Page 357 MULTIMEDIA Setting Name Selectable Options Channel Skip Channel Skip NOTE: SiriusXM® can be programmed to designate a group of channels that are the most desirable to listen to or to exclude undesirable channels while scanning. To make your selection, press the Channel Skip button on the touchscreen, select the channels you would like to skip. Subscription Information Subscription Info NOTE:...
Page 358: Customer Programmable Features - Uconnect 4C Nav With 8.4-Inch Display Settings
MULTIMEDIA Clear Personal Data After pressing the Clear Personal Data button on the touchscreen, the following settings will be available: Setting Name Selectable Options Clear Personal Data Cancel NOTE: When the “Clear Personal Data” feature is selected, it will remove all personal data including Bluetooth® devices and presets. Customer Programmable Features —...
Page 359 MULTIMEDIA Language After pressing the Language button on the touchscreen, the following settings will be available: Setting Name Selectable Options Language English Español Français NOTE: When the “Language” feature is selected, you may select one of multiple languages (English / Français / Español) for all display nomenclature, including the trip functions and the navigation system (if equipped).
Page 360 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Set Theme” feature is selected, you may select the theme for the display screen. To make your selection, press the Set Theme button on the touchscreen, then select the desired theme option button until a check mark appears showing that the setting has been selected. Metric Units —...
Page 361 MULTIMEDIA Units After pressing the Units button on the touchscreen, you may select each unit of measurement independently displayed in the instrument cluster display. The following selectable units of measurement are listed below: Setting Name Selectable Options Units Metric Custom NOTE: When US is selected, Distance is set on miles, Fuel Consumption is set on MPG (US), Pressure is set on psi, and Temperature is set on °F.
Page 362 MULTIMEDIA Clock & Date After pressing the Clock & Date button on the touchscreen, the following settings will be available: Setting Name Selectable Options Sync Time With GPS — If Equipped Set Time Hours NOTE: The “Set Time Hours” feature will allow you to adjust the hours. The Sync Time With GPS button on the touchscreen must be unchecked. Set Time Minutes NOTE: The “Set Time Minutes”...
Page 363 MULTIMEDIA Setting Name Selectable Options Active ParkView Backup Camera Guidelines NOTE: The “Active ParkView Backup Camera Guidelines” feature overlays the Rear Backup Camera image with active, or dynamic, grid lines to help illustrate the width of the vehicle, and its projected backup path, based on the steering wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist with parking or aligning to a hitch/receiver.
Page 364 MULTIMEDIA Setting Name Selectable Options Forward Collision Warning Sensitiv- Near ity — If Equipped NOTE: The “Forward Collision Warning Sensitivity” setting determines at what relative distance the vehicle directly in front of you needs to be at before the system warns you of a possible collision based on the option selected. “Far” gives you the most amount of reaction time, whereas “Near” gives you the least amount of reaction time, based on the distance between the two vehicles.
Page 365 MULTIMEDIA Setting Name Selectable Options NOTE: When the “Blind Spot Alert” feature is selected, the Blind Spot Monitoring (BSM) system is activated and will show a visual alert in the outside mirrors, or it will show a visual alert in the outside mirrors as well as play an audible alert when the turn signal is on. When “Off” is selected, the BSM system is deactivated.
Page 366 MULTIMEDIA Setting Name Selectable Options NOTE: Selecting the “Brake Service” feature will display a pop-up asking if you would like to retract the park brakes to allow brake system service. Lights After pressing the Lights button on the touchscreen, the following settings will be available: Setting Name Selectable Options Interior Ambient Lighting —...
Page 367 MULTIMEDIA Doors & Locks After pressing the Doors & Locks button on the touchscreen, the following settings will be available: Setting Name Selectable Options Auto Door Lock NOTE: When this feature is selected, all doors will lock automatically when the vehicle reaches a speed of 15 mph (24 km/h). Auto Unlock On Exit Flash Lights With Lock —...
Page 368 MULTIMEDIA Setting Name Selectable Options NOTE: When this feature is selected, the driver’s heated seat and heated steering wheel will automatically turn on with vehicle start when temperatures are below 40°F (4.4°C). Engine Off Options After pressing the Engine Off Options button on the touchscreen, the following settings will be available: Setting Name Selectable Options Headlight Off Delay —...
Page 369 MULTIMEDIA Setting Name Selectable Options NOTE: When in this display you may adjust the “Bass”, “Mid” and “Treble” settings. Adjust the settings with the + and – setting buttons on the touchscreen or by selecting any point on the scale between the + and – buttons on the touchscreen. Bass/Mid/Treble also allow you to simply slide your finger up or down to change the setting as well as press directly on the desired setting.
Page 370 MULTIMEDIA Setting Name Selectable Options NOTE: The “Do Not Disturb” feature allows the paired phone to send a predetermined Call, Text, or Both, to any incoming call or text before sending it directly to voicemail. It also keeps a counter of all missed calls and texts while on the road. Auto Reply Text Call...
Page 371 MULTIMEDIA SiriusXM® Setup — If Equipped After pressing the SiriusXM® Setup button on the touchscreen, the following settings will be available: Setting Name Selectable Options Tune Start NOTE: The “Tune Start” feature begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song.
Page 372 MULTIMEDIA Reset After pressing the Reset button on the touchscreen, the following settings will be available: Setting Name Selectable Options Reset App Drawer Cancel Restore Settings Cancel NOTE: When the “Restore Settings” feature is selected, it will reset all settings to their default settings. Clear Personal Data Cancel NOTE:...
Page 373: Uconnect Introduction
MULTIMEDIA UCONNECT INTRODUCTION Identifying Your Radio Uconnect 4 With 7-inch Display Uconnect 4C NAV With 8.4-inch Display 1 — Radio Button 1 — Radio/Media Button 2 — Media Button 2 — Climate Button 3 — Climate Button 3 — Apps Button Uconnect 3 With 5-inch Display 4 —...
Page 374 MULTIMEDIA NOTE: Uconnect screen images are for illustration purposes only and may not reflect exact software for your vehicle. Feature Description Press the Radio button or Media button to enter Radio Mode/Media Radio/Media Mode and access the radio functions and external audio sources. Refer to “Uconnect Modes”...
Page 375: Drag & Drop Menu Bar
MULTIMEDIA Feature Description Press the Controls button to access vehicle-specific feature like heated Controls seats and steering wheel. Apps Press the Apps button to access a list of the available Uconnect apps. Press the Climate button to enter Climate Mode and access the climate control functions.
Page 376: Safety And General Information
MULTIMEDIA Safety And General Information Stop use immediately if a problem occurs.  Failure to do so may cause injury or damage Safety Guidelines to the product. Return it to an authorized dealer for repair. WARNING! Ensure the volume level of the system is set ...
Page 377 MULTIMEDIA Care And Maintenance 1. This device may not cause harmful La operación de este equipo está sujeta a las interference, and siguientes dos condiciones: Do not press the touchscreen with any hard  or sharp objects (pen, USB stick, jewelry, 2.
Page 378: Uconnect Modes
MULTIMEDIA UCONNECT MODES Déclaration d’exposition aux radiations left-hand control is different depending on which mode you are in. Cet équipement est conforme aux limites Steering Wheel Audio Controls d’exposition aux rayonnements ISED établies The following describes the left-hand control pour un environnement non contrôlé. Cet operation in each mode.
Page 379: Radio Mode
MULTIMEDIA Radio Mode Radio Controls Uconnect 4 With 7-inch Display 1 — Preset Radio Stations 2 — View Next Preset Radio Stations Uconnect 4C NAV With 8.4-inch Display 3 — Status Bar Uconnect 3 With 5-inch Display 1 — Preset Radio Stations 4 —...
Page 380 MULTIMEDIA The radio is equipped with the following modes: TUNE/SCROLL Control station after passing through the entire band two times, the radio will stop at the station Turn the rotary TUNE/SCROLL control knob  where it began. clockwise to increase or counterclockwise to ...
Page 381 MULTIMEDIA Press the available number button on the Did You Know: At any time, if you are not sure of touchscreen to begin selecting a desired what to say or want to learn a Voice Command, station. Once a number has been entered, any push the VR button on the steering wheel and numbers that are no longer possible (stations say “Help”.
Page 382 MULTIMEDIA For the Uconnect 3 With 5-inch Display: Deleting Presets A set of four presets will appear on the screen. A Preset can be deleted in the Presets Browse Press the All button to view all saved presets. To screen by pressing the Trash Can icon for the remove a saved preset, a new preset must be corresponding Preset.
Page 383 MULTIMEDIA SiriusXM® Satellite Radio uses direct This functionality is only available for radios NOTE: satellite-to-receiver broadcasting technology to equipped with a Satellite receiver. In order to You will need to provide the SiriusXM® ID (RID) provide clear, coast to coast radio content. receive satellite radio, the vehicle needs to be located at the bottom of the Channel 0 screen.
Page 384 MULTIMEDIA Radio 3 — Seek Down Button 1 — Browse 4 — Direct Tune Button 2 — Replay Bands 5 — Seek Up Button 3 — Seek Down Button 6 — Traffic & Weather Button (if equipped) 4 — Direct Tune Button 7 —...
Page 385 MULTIMEDIA Replay The replay function provides a means to store and replay up to 22 minutes of music audio and 48 minutes of talk radio. Once the channel is switched, content in replay memory is lost. Press the Replay button on the touchscreen. The play/pause, rewind/forward and live buttons will display at the top of the screen, along with the replay time.
Page 386 MULTIMEDIA Favorites Traffic & Weather — Available On The 4C NAV (If Equipped) Press the Favorites button on the touchscreen to activate the favorites menu, which will time Press the Traffic & Weather button on the out within 20 seconds in absence of user touchscreen to tune to a SiriusXM®...
Page 387 MULTIMEDIA BROWSE button on the TUNE/SCROLL knob to Alert Settings select the currently highlighted Preset. When Press the All button on the Browse Screen. Press the Alert Settings tab at the top of the selected, the Radio tunes to the station stored When pressing the All button, the following Favorites screen.
Page 388 MULTIMEDIA Remove Selection/Trash Can Icon Audio Settings Press the Remove Selection tab at the top of the Press the Audio button within the settings main screen. Press the Delete All button on the menu to activate the Audio Settings screen. touchscreen to delete all of the selections or The audio settings can also be accessed on the press the Trash Can icon next to the selection to...
Page 389 MULTIMEDIA Uconnect 4C NAV With 8.4-inch Display 1 — Balance/Fade 2 — Equalizer 3 — Speed Adjusted Volume 4 — Surround Sound — If Equipped 5 — Aux Volume Offset 6 — Auto Play 7 — Radio Off With Door...
Page 390 MULTIMEDIA Audio Setting Description Press the Balance/Fade button on the touchscreen to Balance audio between the front speakers or fade the audio between the rear and front Balance/Fade speakers. Pressing the Front, Rear, Left or Right buttons or press and drag the red Speaker icon to adjust the Balance/Fade.
Page 391: Media Mode
MULTIMEDIA Media Mode Uconnect 4 With 7-inch Display Uconnect 4C NAV With 8.4-inch Display Operating Media Mode Uconnect 3 With 5-inch Display Uconnect 4 With 7-inch Display Operating Media Mode 1 — Repeat 2 — Track Time Uconnect 4C NAV With 8.4-inch Display Operating Uconnect 3 With 5-inch Display Operating Media Mode 3 —...
Page 392 MULTIMEDIA Audio Source Selection Types of Media Modes Before proceeding, the Bluetooth® device must be paired to the Uconnect Phone to Once in Media Mode, press the Source or USB Mode communicate with the Uconnect System. Source Select button on the touchscreen and Overview On the Uconnect 3 With 5-inch Display, push the the desired mode button on the touchscreen.
Page 393 MULTIMEDIA the radio on, the unit will switch to AUX mode In Bluetooth® Mode, press and release the and begin to play when you insert the device Seek Up button on the touchscreen for the next cable. selection on the Bluetooth® device. Press and release the Seek Down button on the Controlling The Auxiliary Device touchscreen to return to the beginning of the...
Page 394 MULTIMEDIA On the Uconnect 3 With 5-inch Display, rotate Shuffle In Bluetooth® Mode, if the Bluetooth® device the Browse button on the touchscreen to scroll supports this feature, press the Tracks button In USB Mode, press the Shuffle button on the through and select a desired track on the on the touchscreen to display a pop-up with the touchscreen to play the selections on the USB...
Page 395: Phone Mode
MULTIMEDIA Did You Know: Press the Browse button on the Call logs on screen (“Show Incoming Calls,” NOTE:  touchscreen to see all of the music on your USB “Show Outgoing Calls,” “Show Missed Calls,” Your phone must be capable of SMS messaging “Show Recent Calls”).
Page 396 MULTIMEDIA button you will hear a BEEP. The BEEP is your You will be prompted for a specific command WARNING! signal to give a command. and then guided through the available options. ALWAYS drive safely with your hands on the Voice Command Button Prior to giving a voice command, one must ...
Page 397 MULTIMEDIA Natural Speech Help Command To complete the pairing process, you will need to reference your mobile phone’s manual. Your Uconnect Phone Voice system uses a If you need assistance at any prompt, or if you Please visit UconnectPhone.com for complete want to know your options at any prompt, say Natural Language Voice Recognition (VR) mobile phone compatibility information.
Page 398 MULTIMEDIA NOTE: 5. If “No” is selected, and you still would like to pair a mobile phone, press the Pairing or If there are no phones currently connected  Settings button from the Uconnect Phone with the system, a pop-up will appear asking main screen.
Page 399 MULTIMEDIA 9. When the pairing process has successfully You can also use the following VR command to 3. Press the Bluetooth® button on the completed, the system will prompt you to bring up the Paired Phone screen from any touchscreen to display the Paired Audio choose whether or not this is your favorite screen on the radio: Devices screen.
Page 400 MULTIMEDIA NOTE: 3. Press to select the particular phone or the For devices which are not made a favorite, the particular audio device. A pop-up menu will device priority is determined by the order in appear; press “Connect Phone”. which it was paired. The latest device paired will 4.
Page 401 MULTIMEDIA 3. Press the Settings button located to the Phonebook Download (Automatic Phonebook right of the device name for a different Transfer From Mobile Phone) — If Equipped phone or audio device than the currently If supported by your phone, Uconnect Phone connected device or press the preferred has the ability to download contact names and Connected Phone from the list.
Page 402 MULTIMEDIA Depending on the maximum number of 2. After loading the mobile phonebook, select Phone Call Features  entries downloaded, there may be a short Contacts from the Phone main screen, and The following features can be accessed through delay before the latest downloaded names then select the appropriate number.
Page 403 MULTIMEDIA Call Controls The touchscreen allows you to control the following call features: Uconnect 4 With 7-inch Display 1 — Answer 2 — Mute/Unmute Uconnect 4C NAV With 8.4-inch Display 3 — Transfer Uconnect 3 With 5-inch Display 1 — Answer 4 —...
Page 404 MULTIMEDIA Key Pad Number Entry Answer Or Ignore An Incoming Call — No Call Currently In Progress 1. Press the Phone button. When you receive a call on your mobile phone, 2. Press the Dial/Keypad button on the the Uconnect Phone will interrupt the vehicle touchscreen.
Page 405 MULTIMEDIA NOTE: NOTE: Phones that are compatible with the Uconnect Only the first 25 characters can be seen on the system in the market today do not support touchscreen while typing a custom message. rejecting an incoming call when another call is While in Do Not Disturb, Conference Call can be in progress.
Page 406 MULTIMEDIA Toggling Between Calls Call Termination To end a call in progress, momentarily press the End Call button on the touchscreen or the Phone End button on the steering wheel. Only the active call(s) will be terminated and if there is a call on hold, it will become the new active call.
Page 407 MULTIMEDIA Advanced Phone Connectivity Smooth Road Surface Even though international dialing for most  number combinations is supported, some Fully Closed Windows Transfer Call To And From Mobile Phone  shortcut dialing number combinations may not be supported. The Uconnect Phone allows ongoing calls to be Dry Weather Condition ...
Page 408 MULTIMEDIA Phone Voice Commands Voice Text Reply — If Equipped PRE-DEFINED VOICE TEXT REPLY Making and answering hands-free phone calls Uconnect can announce incoming text RESPONSES is easy with Uconnect. When the Phonebook messages. Push the VR button or Phone I’ll call you I need direc- See you in 5...
Page 409 MULTIMEDIA Did You Know: Voice Text Reply is not Power-Up 1. l'appareil ne doit pas produire de compatible with iPhone®, but if your vehicle is brouillage, et After switching the ignition key from OFF to equipped with Siri® Eyes Free, you can use your either the ON/RUN or ACC position, or after a 2.
Page 410: Android Auto™ & Apple Carplay® - If
MULTIMEDIA ANDROID AUTO™ & APPLE CARPLAY® — IF 1. Download the Android Auto™ app from the Google Play store on your EQUIPPED Android™-powered smartphone. Android Auto™ 2. Connect your Android™-powered smartphone to one of the media USB ports NOTE: in your vehicle. If the Android Auto™ app Feature availability depends on your carrier and was not downloaded, the first time you plug mobile phone manufacturer.
Page 411 MULTIMEDIA Once Android Auto™ is up and running on your NOTE: Uconnect system, the following features can be If the VR button is not held, and is only pushed, utilized using your smartphone’s data plan: the built-in Uconnect Navigation system (if equipped) will launch instead of the Android Google Maps™...
Page 412 MULTIMEDIA NOTE: and you must be signed in to the app through Music apps, playlists, and stations must be set your mobile device for it to work with Android up on your smartphone prior to using Android Auto™. Auto™ for them to work with Android Auto™. Refer to g.co/androidauto to see the latest list of available apps for Android Auto™.
Page 413: Apple Carplay
MULTIMEDIA activate Android’s™ VR, which recognizes display, the vehicle's knobs and controls, and natural voice commands, to use a list of your your voice with Siri to get access to Apple smartphone’s features: Music®, Maps, Messages, and more. Maps To use Apple CarPlay®, make sure you are ...
Page 414 MULTIMEDIA NOTE: NOTE: Maps To use Apple CarPlay®, make sure that cellular Only temporarily pushing the VR button on the Push and hold the VR button until the data is turned on, and that you are in an area steering wheel launches a built-in Uconnect VR beep on the steering wheel or tap the with cellular coverage.
Page 415 MULTIMEDIA Apple CarPlay® Voice Command NOTE: Feature availability depends on your carrier and mobile phone maker. Some Apple CarPlay® features may not be available in every region and/or language. Apple CarPlay® allows you to use your voice to interact with Siri through your vehicle’s voice recognition system, and use your smartphone’s data plan to project your iPhone®...
Page 416: Android Auto™ And Apple Carplay® Tips And Tricks
MULTIMEDIA Messages NOTE: NOTE:  AutoPlay is not supported by Android Auto™. Android Auto™ and Apple CarPlay® features Maps — If Equipped  cannot be used with Bluetooth®. A USB connec- tion is required for its use. Android Auto™ and Additional Apps —...
Page 417: Navigation Mode - If Equipped (Uconnect 4C Nav With 8.4-Inch Display Only)
MULTIMEDIA NAVIGATION MODE — IF EQUIPPED Press Where To? to find or route to a destina- Where To?  tion. (UCONNECT 4C NAV WITH 8.4-INCH Where To? — Main Menu Press View Map to view the map.  DISPLAY ONLY) Press Home to navigate to a preset home ...
Page 418 MULTIMEDIA NOTE: Refer to the individual section of the chosen option for further information. Search All Press this button to search all “Where To?” categories for a location. Press this button to search by a street address or a street name with Address house number.
Page 419 MULTIMEDIA Press this button to select a destination directly from the Map screen. Point on Map By selecting a street segment or icon, you can quickly enter a destina- tion without the need to input the city name or street. Press this button to program or confirm a route to the saved home Home address.
Page 420 MULTIMEDIA Press the Trails button and select the option to start trail recording to track the route you are driving. Select the option to “stop trail record- Trails ing” to end tracking. This gives you a point of reference for a particular route if needed.
Page 421 MULTIMEDIA 3. Select the desired location from the list of Address locations that appears. Once the correct 1. Press the Address button. location has been selected, you will be asked to confirm your route by pressing 2. Press Spell City or Spell Street to begin Route To.
Page 422 MULTIMEDIA Recent Favorite Destinations 1. Press the Recent button. 1. Press the Favorites button. 2. Press the button with the name of the 2. Press the button with the name of the desired destination. desired favorite destination and confirm the route with “Route To.”...
Page 423 MULTIMEDIA The following Options are available for each The Point of Interest database allows you to You can also change your POI search area by favorite destination: select a destination from a list of locations and pressing any of the category buttons and public places, or points of interest.
Page 424 MULTIMEDIA POI — Search By Name Community  Entertainment 1. Press the Search by Name button.  A keyboard will appear on the screen. Type Gas Stations  in the POI that you want to search and press Highway Exit the List button to display available items.
Page 425 MULTIMEDIA POI — Restaurant, Hotel/Motel, Gas Stations, 2. Press the desired POI destination and press d. Choose from the following options to add Rest Area, And ATM/Banking Route To to confirm the route. a destination • Address 1. Press the corresponding button for the POI 3.
Page 426 MULTIMEDIA 5. To display the options for a trip, press the NOTE: Gear icon. If the system automatically recognizes the city, or street, it will populate a list of recognized 6. The following Options are available for each cities, or streets. If not, press the List button to trip: select from the available options.
Page 427 MULTIMEDIA Where To? — Home And Work 3. To delete a saved Home location (or other NOTE: saved locations), so you can save a new Refer to the individual section of the chosen Home Home location, follow these steps: option for further information. 1.
Page 428 MULTIMEDIA Where To? — City Center And Closest Cities Closest Cities GEO-Coordinates 1. Press the Closest Cities button. 1. Press the GEO-Coordinates button. City Center 2. Press the desired city from the list. 2. Enter the Latitude by typing in the numbers. 1.
Page 429 MULTIMEDIA 5. Press OK to confirm the destination. 3. When you want to end the recording of a route, press the Record button, and press 6. Press the Route To button to confirm your Yes to confirm. route, and then press GO! to confirm your The trip you recorded will be added to the destination and begin your route.
Page 430: View Map
MULTIMEDIA NOTE: View Map Since toll roads, tunnels and ferries are built for View Map — Main Menu the purpose of shortening travel distances, Press the View Map button from the Nav Main avoiding these road types may increase Menu to display a map of your current position. distance and travel time.
Page 431 MULTIMEDIA Zoom In +/Zoom Out – Options (only during route guidance) View Map — Settings Press the Zoom In (+) or Zoom Out (–) buttons Press the Options button to display the following With the Map displayed, press the button on the to change the zoom level.
Page 432 MULTIMEDIA The following Map Settings are available: Guidance — Press this button to display items  to customize your route guidance. Refer to “Settings — Guidance” within this section for further information. Traffic — Press this button to set how you ...
Page 433 MULTIMEDIA Settings — Map Setup The following Map Setup options are available: Map Appearance Press this button to select different themes for With the Map displayed, press the button in the your map. bottom right corner of the map that has three horizontal bars on it, then press the Settings Display Current Street button and then the Map Setup button.
Page 434 MULTIMEDIA Auto Zoom Vehicle Icon Press this button to change how the Auto Zoom Press this button to change the Vehicle icon feature adjusts the zoom level during guidance that is displayed while in Map View. Press in Map View. Previous or Next to view the available icons.
Page 435 MULTIMEDIA Press the 3D City Models button within Map Setup screen to display 3D 3D City Models City Models while in Map View. Press and release the button until a check mark appears, showing the setting has been selected. Press the 3D Landmarks within the Map Setup screen to display 3D 3D Landmarks Landmarks while in Map View.
Page 436 MULTIMEDIA Settings — Guidance menu by pressing the Settings button in the The following Guidance options are available: lower right of the Nav Main Menu. With the Map displayed, press the Options button, then press the Settings button and then the Guidance button.
Page 437 MULTIMEDIA Press this button to enable Lane Recommendation during route guid- Lane Recommendation ance. Press and release the button until a check mark appears, showing the setting has been selected. Press this button to enable Junction View during route guidance. Press Junction View and release the button until a check mark appears, showing the setting has been selected.
Page 438 MULTIMEDIA Press this button to determine which road types are OK to travel on while Route Options in route guidance. Press and release the desired selection button until a check mark appears, showing the setting has been selected. Press this button to display Highway Services while in route guidance. Offer Highway Services Press and release the selection button until a check mark appears, show- ing the setting has been selected.
Page 439: Information
MULTIMEDIA Information From the Nav Main Menu, press the Information button and select one of the following options to Information view additional information: Information Button Traffic Traffic displays detailed traffic information, . Weather displays detailed weather information about your current posi- Weather tion.
Page 440 MULTIMEDIA Trip Computer displays the following trip information from your last trip: Travel Direction  Distance to final Destination  Vehicle Speed  Distance Traveled  Overall average speed  Trip Computer Moving average speed  Maximum speed  Total time traveled ...
Page 441: Emergency
MULTIMEDIA Emergency You can search for a Hospital, Police Department, or Fire Department by the Emergency following categories, which are button tabs at From the Nav Main Menu, press the Emergency the top of the screen: button and press one of the following options to Name ...
Page 442: Map Updates
MULTIMEDIA Map Updates 3. Or, if you wish, you can also visit your dealer Fuel Prices — Check local gas and diesel  prices in your area and route to the station of or place a phone call to request your Map The map data available in your vehicle is the Update.
Page 443: Siriusxm® Traffic Plus
MULTIMEDIA CONNECTED SERVICES— IF EQUIPPED SiriusXM® Traffic Plus What Is SiriusXM Guardian™? SiriusXM Guardian™ uses an embedded device “Don't drive through traffic. Drive around it.” Introduction To SiriusXM Guardian™ in the Uconnect system installed in your vehicle, Avoid congestion before you reach it. By which receives GPS signals and communicates One of the many benefits of your vehicle’s enhancing your vehicle's navigation system with...
Page 444: Getting Started With Siriusxm Guardian
MULTIMEDIA trical system or other important parts of your Send & Go capability with the Uconnect App. SiriusXM Guardian™ services from your date of  Use the Uconnect App to easily search, map vehicle, network congestion, civil disturbances, purchase. actions of third parties or the government, and send your locations directly to your Ucon- * Included Trials apply to new vehicles only.
Page 445 MULTIMEDIA 3. Select “Customer Care” to speak with a To use the Uconnect app: Using Your Owner’s Site SiriusXM Guardian™ Customer Care agent Once you have activated your SiriusXM Your Owner’s Site website www.mopar.com/  who will activate services in your vehicle, or Guardian™...
Page 446: Using Siriusxm Guardian
MULTIMEDIA Remote Commands: 4. You can enter one mobile phone and/or SiriusXM Guardian™ In-Vehicle Assistance  E-mail address to notify you, and you can Features For vehicles with an active SiriusXM customize the types of messages. With SiriusXM Guardian™, your vehicle has Guardian™...
Page 447 MULTIMEDIA features of SiriusXM Guardian™ are available 2. Once a connection between the vehicle and If the SOS Call system detects a malfunction, everywhere at all times, particularly in remote or a SiriusXM Guardian™ Customer Care agent any of the following may occur at the time the enclosed areas.
Page 448 MULTIMEDIA The vehicle’s electrical systems are not Vehicle must be properly equipped with the   WARNING! (Continued) intact. SiriusXM Guardian™ System. Vehicle must be registered with SiriusXM Guardian™ and Do not add any aftermarket electrical  The SOS Call system software and/or hard- ...
Page 449 MULTIMEDIA SiriusXM Guardian™ Customer Care —  WARNING! (Continued) WARNING! (Continued) Contact the SiriusXM Guardian™ Customer Care call center to activate your services, The Occupant Restraint Controller (ORC) Failure to perform scheduled maintenance   renew after your trial has expired, and for turns on the Air Bag Warning Light on the and regularly inspect your vehicle may in-vehicle support for your SiriusXM...
Page 450 MULTIMEDIA Requirements information obtained through such recording 2. Select your destination from the list that and monitoring in accordance with regulatory appears. Location information will then be This feature is available only on vehicles sold  requirements. You acknowledge, agree and displayed on the map.
Page 451 MULTIMEDIA Vehicle Finder 3. You can also select the “Person” icon to see Vehicle must have an operable LTE (voice/  your location. data) or 3G or 4G (data) network connection Forget where you parked your car? We'll help compatible with your device. you locate it! Simply use the Uconnect App on 4.
Page 452 MULTIMEDIA data. The trial can be activated any time within WARNING! WARNING! the first year of new vehicle ownership. The driver should NEVER use the Wi-Fi Always drive safely with your hands on the Give it a Try! Hotspot while driving the vehicle. Failure to do steering wheel and obey all applicable laws.
Page 453 MULTIMEDIA and must be registered with SiriusXM 3. SiriusXM Guardian™ Customer Care will NOTE: Guardian™ with an active subscription that authenticate that you are the owner of the Certain SiriusXM Guardian™ services are includes this feature. In addition, the vehicle vehicle and contact the law enforcement dependent on a properly installed and opera- with whom you filed the stolen vehicle...
Page 454 MULTIMEDIA How It Works Your Owner’s Site website: 4. You will then be asked to enter your SiriusXM Guardian™ Security PIN (this is the Uconnect App: 1. Log on to your Owner’s Site using the same four-digit code established when you username and password you used when 1.
Page 455 MULTIMEDIA NOTE: NOTE: entered your vehicle with the key, the engine Anyone with access to your PIN may request The SiriusXM Guardian™ Care agents are will shut off automatically. Remote Door Lock/Unlock. It is your responsi- trained to help you with unlocking of your door This remote function requires your vehicle to be bility to protect your PIN appropriately.
Page 456 MULTIMEDIA 5. It will take a little while for the command to has been remote started press the Cancel send a request to your vehicle in one of two go through to your vehicle. The time it takes button. ways: depends on a number of technical Using the Uconnect App from a compatible ...
Page 457 MULTIMEDIA 5. It will take a little while for the command to NOTE: top of your vehicle’s maintenance needs. This is go through to your vehicle. The time it takes A quicker way to turn off your Remote Horn & provided as a convenience to you and does not depends on a number of technical Lights would be to push the Panic button on...
Page 458 Alexa®: to Amazon Alexa®: as recall notices. When you receive a “Alexa®, ask Jeep Wrangler to lock my car.”  notification through your touchscreen, press OK 1. Download the Amazon Alexa® app on your to dismiss the message, or press Call Care to “Alexa®, ask Dodge Challenger to start my...
Page 459: Manage My Siriusxm Guardian™ Account
MULTIMEDIA 5. Link Uconnect to the Skill by tapping LINK Speed Alert Lock or unlock your vehicle by tapping the   ACCOUNT. remote lock button in the app and entering Receive a notification whenever your car your security pin. 6.
Page 460: Connected Services Faqs
MULTIMEDIA CONNECTED SERVICES FAQS Connected Services SOS FAQs 2. If I am subscribed to SiriusXM Guardian™, does it cover towing or other expenses 1. What happens if I accidentally push the SOS For additional information about SiriusXM incurred by using roadside assistance? No, Call button on the mirror? You have 10 Guardian™...
Page 461: Connected Services Vehicle Finder Faqs
MULTIMEDIA Connected Services Vehicle Finder FAQs Connected Services Stolen Vehicle court order telling SiriusXM Guardian™ to do so. We will also provide the service for Assistance FAQs 1. Can someone else locate my vehicle? Your FCA entities to locate a vehicle that you vehicle may be located by anyone who has 1.
Page 462: Connected Services Remote Door Lock/Unlock Faqs
MULTIMEDIA Connected Services Remote Door Lock/ to remotely command your vehicle. Other vehicle, you can use the key fob to turn off Unlock FAQs operating systems may be supported in the the horn and lights by pressing the red future. Panic button.
Page 463 MULTIMEDIA accept Terms and Conditions. Then, you PIN by selecting Edit Profile on your Owner’s certain Apps and services. For more will be directed to the SiriusXM Guardian™ Site. information, please contact SiriusXM home page to complete your profile and Guardian™: You can also call SiriusXM Guardian™...
Page 464 MULTIMEDIA 10. How do I manage my SiriusXM Guardian™ date. When your subscription is about to ex- 16. What should I do if I want to sell my vehicle? notification preferences? Contact SiriusXM pire, you will receive an email or letter noti- Before your vehicle is sold to a new owner, Guardian™...
Page 465: Connected Services Remote Vehicle Start Faqs
MULTIMEDIA RADIO OPERATION AND MOBILE PHONES or 3G or 4G (data) network. Services that password and SiriusXM Guardian™ Security required your smartphone only direct calls PIN help to ensure that nobody can start Under certain conditions, the mobile phone to Roadside Assistance Call may be your vehicle if they happen to find your being on in your vehicle can cause erratic or device.
Page 466 MULTIMEDIA The radio manufacturer believes the internal Le présent appareil est conforme aux CNR RF Exposure Requirements wireless radio is safe for use by consumers. The d`Innovation, Science and Economic This equipment complies with Canada radiation level of energy emitted is far less than the Development applicables aux appareils radio exposure limits set forth for an uncontrolled electromagnetic energy emitted by wireless...
Page 467 MULTIMEDIA NOTE: If this equipment does cause harmful inter-  ference to radio or television reception, This equipment has been tested and found to  which can be determined by turning the comply with the limits for a Class B digital equipment off and on, the user is encour- device, pursuant to Part 15 of the FCC Rules.
Page 468: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE minimal daily charge. If you need a rental, it is If for some reason you are still not satisfied,  talk to the general manager or owner of the advisable to make these arrangements when FOR YOUR VEHICLE you call for an appointment.
Page 469: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC Customer Center Customer Assistance For The Hearing Or Protection Plan, you will receive Plan Provisions and an Owner Identification Card in the mail Speech Impaired (TDD/TTY) P.O. Box 21–8004 within three weeks of the vehicle delivery date. To assist customers who have hearing Auburn Hills, MI 48321–8004 If you have any questions about the service...
Page 470: Warranty Information
CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS To contact NHTSA, you may call the WARNING! Vehicle Safety Hotline toll free at (888) In The 50 United States And Engine exhaust (internal combustion engines 327-4236 (TTY: 1-800-424-9153); or go Washington, D.C. only), some of its constituents, and certain to http://www.safercar.gov;...
Page 471: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Diagnostic Procedure Manuals Owner's Manuals Diagnostic Procedure Manuals are filled with These Owner's Manuals have been prepared To order the following manuals, you may use diagrams, charts and detailed illustrations. with the assistance of service and engineering either the website or the phone numbers listed These practical manuals make it easy for specialists to acquaint you with specific FCA US...
Page 472: Index
INDEX ..........134 ........408 Side Air Bags Apple CarPlay .........324 ........153 ..........106 About Your Brakes Transporting Pets Assist, Hill Start ........87 ..........386 Adaptive Cruise Control (ACC) (Cruise Air Bag Light Audio Settings ............178 ......60 Control) Air Cleaner, Engine (Engine Air Cleaner Auto Down Power Windows ....297...
Page 473 Belts, Seat .............154 Certification Label ......... 225 Compact Spare Tire ........314 Blind Spot Monitoring ........107 Changing A Flat Tire ......262 Connector Bluetooth Chart, Tire Sizing ........... 303 ...............72 Connecting To A Particular Mobile Phone Check Engine Light (Malfunction Indicator Universal Consumer Interface (UCI) .....72 Or Audio Device After Pairing...
Page 474 ..73 ..........273 Electrical Outlet, Auxiliary (Power Outlet) Overheating ........40 ....101 ............. 156 Daytime Running Lights Electronic Roll Mitigation (ERM) Starting ..........291 ..176 ........291 Dealer Service Electronic Speed Control (Cruise Control) Engine Oil Viscosity ........47 ....
Page 475 Fluid Level Checks Gear Ranges ..........163 Holder, Coin .............76 Engine Oil ..........289 Gear Selector Override ......... 274 Holder, Cup ............76 Fluid, Brake ...........331 General Information ........374 Hood Prop ............66 Fluids And Lubricants ........330 Glass Cleaning ..........323 Hood Release ...........66 Fog Lights ............
Page 476 ........... 312 ..91 Life Of Tires Malfunction Indicator (Check Engine) ............. 67 .............96 Key Fob Liftgate Park ..........20 ............68 ............41 Arm The Alarm Closing Passing ........21 ............67 ........89 Disarm The Alarm Opening Seat Belt Reminder ..........23 .......47 ..........90 Keyless Entry Liftgate Window Wiper/Washer...
Page 477 Manual Transmission ......163 Where To? — City Center ......426 Recommendation ......291 Fluid Level Check ........300 Where To? — Go Home ......425 Viscosity ........... 291 Frequency Of Fluid Change .......300 Where To? — Main Menu ......415 Onboard Diagnostic System ......96 Lubricant Selection...
Page 478 ............64 ............ 293 Sunroof Refrigerant ............60 ..... 442 ............374 Windows Registering SiriusXM Guardian Safety ........41 ......154 Power Seats Reminder, Lights On Safety Checks Inside Vehicle ............31 ........124 ...... 155 Forward Reminder, Seat Belt Safety Checks Outside Vehicle .............
Page 479 Seat Belt Pretensioner ......129 Sirius Satellite Radio ........380 Speed Control Seat Belt Reminder ........124 Favorites ........... 384 Distance Setting (ACC Only) ...... 178 Untwisting Procedure ........127 Replay ............383 Mode Setting (ACC Only) ......178 Seat Belts Maintenance ........322 SiriusXM Traffic ........
Page 480 ............303 Sizes ......35 ..........314 Telescoping Steering Column Snow Tires Uconnect .... 57 ........314 ......... 400 Temperature Control, Automatic (ATC) Spare Tires Phone Call Features ........35 ........... 311 Tilt Steering Column Spinning Things You Should Know About Your ...........
Page 481 Pair (Link) Uconnect Phone To A Mobile Washing Vehicle ..........321 Phone ...........395 Vanity Mirrors ..........40 Wheel And Wheel Tire Care ......315 Pair A Bluetooth Streaming Audio Device ..397 Vehicle Finder ........449 Wheel And Wheel Tire Trim ......315 Phonebook Download .......399 Vehicle Health Alert...
Page 483 Some states or provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a ®...
Page 484 © 2019 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep 2020 RENEGADE Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jeep 2020 RENEGADE

Summary of Contents for Jeep 2020 RENEGADE
